- Page 1 Recycle all your Green Waste CHIPPER SHREDDER 650 Operation and Maintenance Manual...
-
Page 2: Table Of Contents
INDEX General Description Initial Assembly Safety Procedures Decals Storage & Transporting Pre-Start Checks and Starting Chipping Shredding Maintenance Spare Parts and Warranty... -
Page 3: General Description
Lower grate pin The Deutscher Chipper Shredder is designed to chip branches up to 65mm diameter and shred a range of garden waste including branches up to 12mm diameter. A Swedish Viking steel chipper blade attached to a rotating disc behind the chipper tube does the chipping, and 9 hardened steel flails inside the shredding chamber rotate at high... -
Page 4: Initial Assembly
INITIAL ASSEMBLY THE FOLLOWING INSTRUCTIONS APPLY WHEN THE UNIT HAS NOT BEEN ASSEMBLED. 1. Do not put oil into the engine until the unit is assembled. 2. Remove the discharge deflector, then lower the shredding chamber onto its front as shown below. -
Page 5: Safety Procedures
SAFETY PROCEDURES Preparation 1. Do not allow children to operate this equipment. 2. Do not operate this equipment in the vicinity of bystanders. 3. Do not run the unit in an enclosed area since the exhaust from the engine contains some carbon monoxide, which is a colourless, odourless, tasteless and poisonous gas. - Page 6 SAFETY PROCEDURES Operation: 1. Before starting the machine, look into both the chipper tube and the hopper to ensure they are empty. 2. Keep tour face and body away from the feed intake opening. 3. Do not allow hands or any other part of the body or clothing inside the hopper, chipper tube, discharge area, or near any moving part.
-
Page 7: Decals
The decals shown below are attached to each new machine. It is the operators responsibility to ensure these decals are in place and legible. They can be purchased from Deutscher Mowers Pty Ltd as a set. See “Spare Parts”, in this manual. -
Page 8: Storage & Transporting
STORAGE & TRANSPORTING Always allow the machine to cool before storing. Store the machine in a dry area away from children and where petrol vapours cannot be ignited by a spark, such as a welder, or a flame from say the pilot light in a gas appliance. When storing the unit for longer than three months, it is a wise practice to run the fuel tank dry beforehand. -
Page 9: Pre-Start Checks And Starting
PRE-START CHECKS & STARTING • Ensure you are wearing safety glasses and hearing protection. • Avoid wearing loose fitting clothing. • Place the machine on a level “dirt or grass” surface. • Check that all fasteners on the machine are secure and all guards are in place. •... -
Page 10: Chipping
Never leave the engine running and unattended. 1. The Deutscher chipper shredder can chip branches up to 65mm diameter. Should a branch contain sharp bends, the bends can be cut 2/3 through with a bow saw. Then the branch can be forced straight and will easily feed into the tube. -
Page 11: Shredding
SHREDDING Warning! In general, materials will “self fed” into the hopper. Do not push material into the hopper with your hands. Use a light green branch (no larger than 20mm diameter) or a piece of softwood. If materials are jammed, a safer practice is to turn off the machine, remove the offending material, restart and feed it in again. -
Page 12: Maintenance
MAINTENANCE BASIC MAINTENANCE Tools required : 5mm Allen Key (chipper blade replacement) 13mm ring / open ended spanner. 17mm ring / open ended spanner General When the machine is stopped for servicing, inspection, or to change an accessory, shut off the engine, disconnect the spark plug wire from the spark plug and make sure that all moving parts have come to a complete stop. - Page 13 MAINTENANCE 12mm deflection Drive belt Chipper blade replacement/ sharpening The chipper blade will become blunt with extended use, particularly if you are chipping dry hardwood. You can feel when the blade is blunt, as the processing time is longer and the engine is more likely to slow down under heavy loading.
- Page 14 MAINTENANCE DETAILED MAINTENANCE Tools Required: 1/8” Allen Key 8mm ring spanner and small socket spanner. 18mm open ended spanners. Double ended bearing puller may also be needed. Shifting spanner, 200mm approx. Philips screwdriver with a shaft at least 210mm long, or a _” pin at least 250mm long. General The rotor assembly should be inspected after every 20 hours of use or after a solid impact, by removing the hopper.
- Page 15 MAINTENANCE ROTOR SPACERS Spacer No. Part Number Length mms. Quantity 3180 3179 3181 51 (with hole) 3182 51 (no hole) • Engine Replacement • Switch off the engine and remove the spark plug lead from the spark plug. • Remove the hopper. •...
- Page 16 • The engine on this unit is covered by the engine manufactures warranty supplied with the unit. For your nearest engine dealer, Phone: Briggs & Stratton: 1800 650 042 or Honda M.P.E.: 1800 809 327...
