Specifications

*1
Supported media
Supported media formats
Video output
Audio output
Network (wired)
USB host
Interface
Output terminal
Power supply
Power consumption
Operating temperature
range
Operating humidity
range
Storage temperature
range
Storage humidity
range
External dimensions
Weight
*1 Basically the AVeL Link Player can play DVD-ROMs and DVD-Videos created on DVD-R, DVD-RW, DVD+R and DVD+RW media.
Note that some media may not be played properly.
* Only UDF/ISO Bridge and ISO 9660 are supported.
UDF and PacketLight are not supported.
* Even when the overall bit rate of a DivX file is below the maximum bit rate, some portions of the video data may have very high bit rates.
In this case, frames may skip or sound may break in the segments of high bit rates. Playback may even stop if the bit rate remains high
for a long duration.
* Also refer to "Supported Formats" (p.9).
DVD-R/-RW/+R/+RW, CD-R/RW
DVD-VIDEO, CD-ROM, DVD-ROM, CD-DA, VIDEO-CD
Progressive video output (480p, 720p)
Video D/A converter (Max. 148.5 MHz/12 bits)
Dolby Digital (digital audio output), Audio A/D Converter (192 kHz/24 bits)
Conforming standards
Communication speed
Connector
USB specification
Number of connector /
connector shape
USB bus power
Supported devices
Supported file systems
Japanese D4 connector
S-video output
Composite video output
Analog audio output
Optical digital audio output
Coaxial digital audio output
100 to 240 VAC, 50/60 Hz
16 W (normal)
5 to 35 °C
20 to 80% (non-condensing)
-10 to 50 °C
10 to 90% (non-condensing)
430 (W) x 291 (D) x 55 (H) mm
Approx. 3.5 kg (main unit only)
(supported disk size: 8 cm/12 cm)
IEEE802.3, IEEE802.3u (10BASE-T/100BASE-TX)
10 M / 100 Mbps
RJ-45
USB Specification Ver. 2.0 (High Speed, Full Speed)
1 connector, USB A type
Supported (Max. 500 mA)
Mass storage class (USB hard disk, USB memory, USB card reader/writer)
FAT16, FAT32
1 (480i, 480p, 720p, 1080i)
1 (S1, S2)
1
2
1
1
(excluding projections)
