    technical data Indoor Units FCQ-C8VEB...
  • Page 2 technical data Indoor Units FCQ-C8VEB...

  • Page 3: Table Of Contents

    • Indoor Units • R-410A • FCQ-C8VEB TABLE OF CONTENTS FCQ-C8VEB Features ............. 2 Specifications .

  • Page 4: Features

    For auto cleaning panel: • 23 different air flow patterns possible - Daikin introduces first auto cleaning cassette to European market • Drain-up pump with 850 mm lift fitted as standard - Higher efficiency and comfort from daily auto cleaning of the filter...

  • Page 5: Specifications

    • Indoor Units • R-410A • FCQ-C8VEB Specifications 2-1 Technical Specifications FCQ35C8VEB FCQ50C8VEB FCQ60C8VEB FCQ71C8VEB FCQ100C8VEB FCQ125C8VEB FCQ140C8VEB Power input 50Hz Cooling Nom. 0.056 0.120 Heating Nom. 0.056 0.120 Casing Material Galvanised steel plate Dimensions Unit Height Width Depth Packed unit...

  • Page 6: Electrical Specifications (50Hz)

    • Indoor Units • R-410A • FCQ-C8VEB Specifications 2-1 Technical Specifications FCQ35C8VEB FCQ50C8VEB FCQ60C8VEB FCQ71C8VEB FCQ100C8VEB FCQ125C8VEB FCQ140C8VEB Decoration Panel Model BYCQ140CW1 Colour Pure White (RAL 9010) Dimensions Weight Model BYCQ140CW1W Colour Pure White (RAL 9010) Dimensions Weight Model BYCQ140CGW1...

  • Page 7: Safety Device Settings

    • Indoor Units • R-410A • FCQ-C8VEB Safety device settings FCQ35-140C8 Safety devices PC board fuse 250V 5A 250V 5A 250V 5A 250V 5A 250V 5A 250V 5A 250V 5A Fan motor thermal fuse °C ± 5 ± 5 ± 5 ±...

  • Page 8: Options

    • Indoor Units • R-410A • FCQ-C8VEB Options FCQ35-140C8VEB OPTIONS Item Model FCQ35 FCQ50 FCQ60 FCQ71 FCQ100 FCQ125 FCQ140 FCQH71 FCQH100 FCQH125 FCQH140 Decoration panel BYCQ140CW1 / BYCQ140CW1W *3 / BYCQ140CGW1 *5,*6 Long life replacement fi lter Non-woven type KAFP551K160 Fresh air intake kit (20% fresh air) Chamber type KDDQ55C140...

  • Page 9: Dimensional Drawing & Centre Of Gravity

    • Indoor Units • R-410A • FCQ-C8VEB Dimensional drawing & centre of gravity 5 - 1 Dimensional drawing for standard panel FCQ35-71C8 860-910 (Ceiling opening) Name Description SEE NOTE Liquid pipe connection ø A flare connection 300 or less 710 (Suspension position Gas pipe connection ø...

  • Page 10: Dimensional Drawing For Auto Cleaning Panel

    • Indoor Units • R-410A • FCQ-C8VEB Dimensional drawing & centre of gravity 5 - 2 Dimensional drawing for auto cleaning panel FCQ100-140C8VEB 860~910 (Ceiling opening) Name Description See note 3 Liquid pipe connection Ø9.52 fl are connection 710 (Suspension position) 300 or less Gas pipe connection Ø15.90 fl...

  • Page 11: Dimensional Drawing With Accessories

    • Indoor Units • R-410A • FCQ-C8VEB Dimensional drawing & centre of gravity 5 - 3 Dimensional drawing with accessories FCQ35,50,60,71C8 Service acces panel: Ventilation resistance in chamber (note 6) 450 x 450 mm or more (Refer to note 1) Name Description Indoor unit...

  • Page 12: Centre Of Gravity

    • Indoor Units • R-410A • FCQ-C8VEB Dimensional drawing & centre of gravity 5 - 4 Centre of gravity FCQ35-140C8 Remote control dimensions Receiver installation procedure Transmitting part Receiver Pipe connection side Drain connection side Decoration panel Remote controller holder installation procedure (installation to wall surface) Receiver detail Liquid crystal...
  • Page 13 • Indoor Units • R-410A • FCQ-C8VEB Dimensional drawing & centre of gravity 5 - 4 Centre of gravity FCQ35-140C8 Models FCQ35~71 FCQ100~140 4TW28839-2 • Split Sky Air • Indoor Units...

  • Page 14: Piping Diagram

    • Indoor Units • R-410A • FCQ-C8VEB Piping diagram FCQ35-140C8 Heat exchanger Refrigerant flow Liquid pipe connection port Cooling Heating Gas pipe connection port Refrigerant pipe connection port diameters Model Liquid FCQ35C8 9.52 6.35 Ø Ø FCQ50C8 12.70 6.35 Ø Ø...

  • Page 15: Wiring Diagram

    • Indoor Units • R-410A • FCQ-C8VEB Wiring diagram 7 - 1 Wiring diagram FCQ35-140C8VEB In case of simultaneous operation system 35~60 CLASS 35~140-Class 35~60 CLASS Indoor unit Indoor unit Indoor unit (master) (slave) (slave) To outdoor unit Norm. emg. Receiver display unit Central remote control (note1)

  • Page 16: Sound Data

    • Indoor Units • R-410A • FCQ-C8VEB Sound data 8 - 1 Sound pressure spectrum FCQ35C8 FCQ50C8 Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz) 4D056856 4D056857 NOTES NOTES...
  • Page 17 • Indoor Units • R-410A • FCQ-C8VEB Sound data 8 - 1 Sound pressure spectrum FCQ100C8 FCQ125C8 (Cooling) Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz) 4D056860 4D056861 NOTES...

  • Page 18: Sound Power Spectrum

    • Indoor Units • R-410A • FCQ-C8VEB Sound data 8 - 2 Sound power spectrum FCQ35-50C8 FCQ60C8 Octave band center frequency (Hz) Octave band center frequency (Hz) 4TW28927-1 4TW28947-1 NOTES NOTES Data is valid at free field condition. Data is valid at free field condition. Data is valid at nominal operation condition.
  • Page 19 • Indoor Units • R-410A • FCQ-C8VEB Sound data 8 - 2 Sound power spectrum FCQ125C8 FCQ140C8 Octave band center frequency (Hz) Octave band center frequency (Hz) 4TW28977-1 4TW28987-1 NOTES NOTES Data is valid at free field condition. Data is valid at free field condition. Data is valid at nominal operation condition.

  • Page 20: Air Flow Pattern

    • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ35C8 Cooling air velocity distribution All round air discharge, air flow direction: horizontal 2.7m 2.0m/s 1.5m/s 1.0m/s 0.5m/s Cooling air temperature distribution All round air discharge, air flow direction: horizontal 2.7m 20°C 22°C...
  • Page 21 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ50C8 Cooling air velocity distribution All round air discharge, air flow direction: horizontal 2.7m 2.0m/s 1.5m/s 1.0m/s 0.5m/s Cooling air temperature distribution All round air discharge, air flow direction: horizontal 2.7m 20°C 22°C...
  • Page 22 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ60C8 Cooling air velocity distribution All round air discharge, air flow direction: horizontal 2.7m 2.0m/s 1.5m/s 1.0m/s 0.5m/s Cooling air temperature distribution All round air discharge, air flow direction: horizontal 2.7m 20°C 22°C...
  • Page 23 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ71C8 Cooling air velocity distribution All round air discharge, air flow direction: horizontal 2.7m 2.0m/s 1.5m/s 1.0m/s 0.5m/s Cooling air temperature distribution All round air discharge, air flow direction: horizontal 2.7m 20°C 22°C...
  • Page 24 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ100C8 Cooling air velocity distribution All round air discharge, air flow direction: horizontal 3.2m 2.0m/s 1.5m/s 1.0m/s 0.5m/s Cooling air temperature distribution All round air discharge, air flow direction: horizontal 3.2m 20°C 22°C...
  • Page 25 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ125C8 Cooling air velocity distribution All round air discharge, air flow direction: horizontal 3.2m 2.0m/s 1.5m/s 1.0m/s 0.5m/s Cooling air temperature distribution All round air discharge, air flow direction: horizontal 3.2m 20°C 22°C...
  • Page 26 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ140C8 Cooling air velocity distribution All round air discharge, air flow direction: horizontal 3.2m 2.0m/s 1.5m/s 1.0m/s 0.5m/s Cooling air temperature distribution All round air discharge, air flow direction: horizontal 3.2m 20°C 22°C...
  • Page 27 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ35C8 Heating air velocity distribution All round air discharge, air flow direction: horizontal 2.7m 2.0m/s 1.5m/s 1.0m/s 0.5m/s 0.25m/s Heating air temperature distribution All round air discharge, air flow direction: horizontal 2.7m 28°C 27°C...
  • Page 28 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ50C8 Heating air velocity distribution All round air discharge, air flow direction: horizontal 2.7m 2.0m/s 1.5m/s 1.0m/s 0.5m/s 0.25m/s Heating air temperature distribution All round air discharge, air flow direction: horizontal 2.7m 28°C 27°C...
  • Page 29 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ60C8 Heating air velocity distribution All round air discharge, air flow direction: horizontal 2.7m 2.0m/s 1.5m/s 1.0m/s 0.5m/s 0.25m/s Heating air temperature distribution All round air discharge, air flow direction: horizontal 2.7m 28°C 27°C...
  • Page 30 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ71C8 Heating air velocity distribution All round air discharge, air flow direction: horizontal 2.7m 2.0m/s 1.5m/s 1.0m/s 0.5m/s 0.25m/s Heating air temperature distribution All round air discharge, air flow direction: horizontal 2.7m 28°C 27°C...
  • Page 31 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ100C8 Heating air velocity distribution All round air discharge, air flow direction: horizontal 3.2m 2.0m/s 1.5m/s 1.0m/s 0.5m/s 0.25m/s Heating air temperature distribution All round air discharge, air flow direction: horizontal 3.2m 28°C 27°C...
  • Page 32 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ125C8 Heating air velocity distribution All round air discharge, air flow direction: horizontal 3.2m 2.0m/s 1.5m/s 1.0m/s 0.5m/s 0.25m/s Heating air temperature distribution All round air discharge, air flow direction: horizontal 3.2m 28°C 27°C...
  • Page 33 • Indoor Units • R-410A • FCQ-C8VEB Air flow pattern FCQ140C8 Heating air velocity distribution All round air discharge, air flow direction: horizontal 3.2m 2.0m/s 1.5m/s 1.0m/s 0.5m/s 0.25m/s Heating air temperature distribution All round air discharge, air flow direction: horizontal 3.2m 28°C 27°C...
  • Page 34 Specifications are subject to change without environment. This challenge demands the eco design prior notice. Daikin Europe N.V. explicitly rejects any liability for any direct or and development of a wide range of products and an indirect damage, in the broadest sense, arising from or related to the use energy management system, resulting in energy and/or interpretation of this publication.
