Ⅰ.SAFE DRIVE
Rules for Safe Drive
Check must be conducted,bef ore starting the engine,to prevent mishaps and damage to components.
Only the qualified person who has passed the drive examination with a drive license is permitted to drive the
vehicle but not anybody else without a drive license.
Full preoccupation is required during drive, paying attention to the follow ing points to avoid any possible
hurt to you by other motor ized vehicles:
Do not drive too close to other vehicles;
Never contend for lane.
Strictly observe the local traffic rules.
As driving at overspeed is the cause of many accidents. Do not drive at a speed that the actual situation does
not permit.
Particular care should be exercised at the level crossing of roads, entrance and exit of parking lot or on the
autonobile lane.
During drive, grasp the left handlebar by the left hand and the throttle twist grip by the right hand,with feet
on the footrests.
1
Advertisement
Table of Contents
Related Manuals for Kinroad XT50PY
Summary of Contents for Kinroad XT50PY
-
Page 1: Safe Drive
Ⅰ.SAFE DRIVE Rules for Safe Drive Check must be conducted,bef ore starting the engine,to prevent mishaps and damage to components. Only the qualified person who has passed the drive examination with a drive license is permitted to drive the vehicle but not anybody else without a drive license. Full preoccupation is required during drive, paying attention to the follow ing points to avoid any possible hurt to you by other motor ized vehicles: Do not drive too close to other vehicles;... - Page 2 Protective wear 1.Protective wear such as helmet with protective mask, dustproof glasses and gloves should be worn during drive for the sake of personal safety. 2.Loose clothes are not suitable for motorcycle drive or ride as they may get caught on the operating lever ,kick ,footrest or wheel, resulting in danger.
-
Page 3: Main Data
Ⅱ.MAIN DATA Item 50 type Item 50 type 39×41.4 Overall length 1910mm Cylinder bore x stroke 8.8:1 Overall width 760mm Compression ratio 2.0kw/7000r/min Overall height 1140mm Output,max 2.2N.m/62500r/min Wheelbase 1260 mm Torque,max 1500r/min±100r/min Dead weight 92kg Idling speed 49ml Payload 150kg Displacement of cylinder A7TC... -
Page 4: Parts & Subassemblies
III.PARTS & SUBASSEMBLIES... -
Page 7: Operation
IV.OPERATION only be used when the normal supply is run out,) In this case,refueling should be carried out as soon as possible; for there is only Fuel Cock somel.0L of fuel reserve for use. 1.Fuel filling The capacity of the fuel tank is 4.5L.Leadless gasoline of No.90or above or low-lead gasoline is required for the motorcycle.To fuel the vehicle,support it by the main stand, open the lock cover of the fuel tank and fill fuel through the... -
Page 8: Engine Starting
Engine Starting 5.Turn the carburetor choke bar downward Warning:Never start the engine in a closed to fully open the choke when the engine is place or warehouse or warehouse as the sufficiently warmed up. exhausted gas from the vehicle contains toxic ★Caution: carbon monoxide. - Page 9 Electric start button The electric start button is located below the right handlebar.When the ignition switch is set in “ON” position and the engine is in the neutral position, push the button to start the engine Light switch The front light switch has three positions, And “●”(a white point).
-
Page 10: Switches On Left Handle Bar
Switches on Left Handle bar 1. Headlights dimmer button Positi on,Headligh is in high beam. Positi on, Headligt is in low beam. 2. turning light switch position,Left position,Right 3.Horn button press this button for horn... - Page 11 Gear Shifting A non-cycling mode of gear shifting is employed of this motorcycle ● The throttle must be clossed befor the gear shifting every time, Shifing the gear before closing the condition of backing it for four times. ● The speed shifting pedal must be operated suitably. ●...
-
Page 12: Checking,Adjustm- Ent And Maintenance
Renewal of Machine Oil V.Checking,Adjustm- Machine oil plays a very important ent and Maintenance role in the normal operation of the engine and for this reason,it is necessary Machine Oil Checking to check the motorcycle for machine oil ★The vehicle should be checked for periodically and renew the oil once machine oil before drive by sup-porting every800-1,000km of driving by the... -
Page 13: Check-Up Of Spark Plug
Cleaning of machine oil Check-up of Spark Plug. tank 1.Drain off all the run –in machine oil from the oil tank. 2.Dismount the related parts. 3.Wash clean all the related parts. 4.Fill in the required oil. ＊ This job should not be done by untrained persons but shall be done at an authorized service center. -
Page 14: Check-Up & Cleaning Of Air Filter
Check-up & Cleaning of Air Filter service life of the engine. Water should be prevented from entering into the filter in washing the vehicle. Take out the air filter and check if it is The filter shall never be cleaned with gasoline or any contaminated. -
Page 15: Adjustment Of Throttle Cable
Adjustment of Throttle Cable by your dealer. Adjust ment of idling speed shall be made only when the cold engine is warmed up or 10 minutes after the Make sure that the adjust ing nut of the throttle motorcycle is stopped from driving. cable and locking nut work normally. -
Page 16: Check-Up & Adjustment Of Air Valve Gap
Check-up & Adjustment of Air Valve Gap Noise will stem from too big gap of the air valve. However if there is too small gap or even no gap at all, closing of the valve will be hindered, which will cause burn of the valve and output drop. Therefore, the air valve gap must be checked periodically. -
Page 17: Adjustment Of Front Brake
Adjustment of Front Brake (1) The front brake has a free operating movement of 10-20mm as shown in the figure on the right side. (2) inspect the reseivoir capacity and refill if necessary in order to maintain proper level in the reservior.This should be the major project of your regular inspection (3) check the front brake lining for its worm... -
Page 18: Adjustment Of Rear Brake
Adjustment of Rear Brake ★The vehicle should be supported by the main stand for check. (1) The rear brake pedal has a free operating movement of 20-30mm as shown in the figure on the right side. (2) To make adjustment, turn the rear brake adjust ing nut clockwise to reduce snd counter clock wise to increase the free operating movement of the brake pedal. -
Page 19: Greasing Procedures To The Driving Chain
[Greasing procedures to the driving chain] 1.Shut off the engine. 2.Add some machine oil or chain grease to the driving chain. Attention: When the rear wheel axil has moved to the back adjust ing limit, if excess loose be cause of wearing to the driving chain, please change with a new one. -
Page 20: Vehicle Washing
Vehicle Washing Cleaning the vehicle reularly can slow down the color fading of its body and make it easier to check if there is any damage and oil leakage with if. Caution: Washing the motorcycle with over-pressurized water may cause damage to some of its components. Therefore, do not jet over-pressurized water directly on to the follow ing parts: ——Wheel hub ——... -
Page 21: Instructions For Storage
Instructions for Storage draining off fuel. For the motorcycle not to be used for a long period 3.Take out the spark plug, pour about 15-20ml of of time, for example,in wintertime,some steps should clean engine oil into the cylinder, step down the kick be taken to pervent malfunction of and damage to its lever repectitively for several, step down the kick lever components which might be caused by long storage,... -
Page 22: Resumption Of Service
1.Remoe the covering and clean the vehicle. Change the lubricating oil if the vehicle has been off service for over 4 months. 2.Drain off the remaining atomized antirust oil from the fuel tank, followed by filling it with fresh gasoline therein. - Page 23 1.Remove the covering and clean the vehicle. Change the lubricating oil if the vehicle has been off service for over 4 months. 2.Charge the battery and remount it. 3.Drain off the antirust solution from the fuel tank, followed by filling fuel therein to the required level. 4.Prior to driving, test the vehicle at low speed in a safe place.
- Page 24 Frequency Odometer km (Note2) Item /frequency Items of Maintenance 1000km 4000km 8000km 12000km remak ＊ Circurt of fuel system ＊ Fuel filter ＊ Throttle operating system ＊ Choke of car buretor Air filter element NoteI Soark olug ＊ Airvalve gap Airvalve gap Engine lubricating oil R -yearly...
-
Page 25: Electrical Diagram
V.ELECTRICAL DIAGRAM...
