Ardmore
Non Boiler Wood Burning Stove
INSTALLATION AND OPERATING INSTRUCTIONS
This appliance is hot while in operation and retains its heat for a long period of time after use. Children,
aged or infirm persons should be supervised at all times and should not be allowed to touch the hot
working surfaces while in use or until the appliance has thoroughly cooled.
When using the stove in situations where children, aged and/or infirm persons are present a fireguard
must be used to prevent accidental contact with the stove. The fireguard should be
manufactured in accordance with BS 8423:2002.
Advertisement
Table of Contents
Related Manuals for Falcon Ardmore
Summary of Contents for Falcon Ardmore
- Page 1 Ardmore Non Boiler Wood Burning Stove INSTALLATION AND OPERATING INSTRUCTIONS This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE NO. General ............... 2 Handling . -
Page 3: General
THE ARDMORE WOOD BURNER NON BOILER STOVE INSTALLATION INSTRUCTIONS FLUES GENERAL Flues should be vertical wherever possible and When installing and maintaining your Stove respect where a bend is necessary, it should not make an basic standards of fire safety. Read these instruc- angle of more than 45 with the vertical. -
Page 4: Flue Pipes
FLUE PIPES Fig.3 A flue pipe should only be used to connect an appli- ance to a chimney and should not pass through any Flue Liner roof space. Sleeve Flue pipes in cast iron, stainless steel or enamelled Flue Flue Pipe steel are suitable for use on this appliance. -
Page 5: Chimney
Fig.6 Fig.5 Filler Piece Blanking Plate Flue Collar CHIMNEY Do not connect to a chimney serving another appliance. Fig.7 The stove is a radiant room heater and must be con- nected to a chimney of the proper size and type. The chimney must have a diameter of at least 5”... - Page 6 The chimney and connecting flue must have a mini- Combustible material should not be located where mum diameter of 125mm and at no point must the the heat dissipating through the walls of fireplaces or diameter reduce to less than the size of the outlet flues could ignite it.
-
Page 7: Clearances To Combustibles
CLEARANCE TO COMBUSTIBLES ALCOVE INSTALLATION Fig.10 Fig.13 FIREPLACE INSTALLATION FLUE CLEARANCES CORNER INSTALLATION Fig.11 Fig.14 MANTLE CLEARANCE Fig.12 Fig.15 MINIMUM COMBUSTIBLE ALCOVE... -
Page 8: Installation Clearances
If it is found that there is excessive draught in the Air vents in internal walls should not communicate chimney then a draught stabiliser should be fitted. with bedrooms, bedsits, toilets, bathrooms or rooms Fitting of a draught stabiliser will affect the require- containing a shower. -
Page 9: External Ducted Air
EXTERNAL DUCTED AIR The vent pipe should be located to prevent the ingress of moisture and in a location where it will not The primary air supply can be ducted from outside. get blocked with leaves or any other debris. As wind An aluminium flexible duct is available to order for effects can create suction and pressure zones of connection to the stove. -
Page 10: Location
FLUE LOCATIONS LOCATION There are several conditions to be considered in Flue outlet to suit 125mm (5”) internal diameter flue selecting a location for your Ardmore Stove. pipe. Fig.18 a. Position in the area to be heated, central locations are usually best. -
Page 11: Technical Data
TECHNICAL DATA WOOD Nominal Output: (kW) 7.7 kW Typical refuelling intervals to obtain nominal .75 hrs outputs: Flue Gas Mass Flow: 6.5 g/s Flue Gas Temperature at Nominal Output: Gross Weight: 150kgs Flue Outlet: 125mm Flue Draught: 12 Pascals Log Size: 340mm WARNING: DO NOT OBSTRUCT PRIMARY AIR SUPPLY TO THE STOVE... -
Page 12: Installation Check List
INSTALLATION CHECK LIST Tick Flue System 1. Minimum Flue Height of 4.6 metres (15 feet). 2. Appliance should be connected to a minimum of 1.8 metres (6 feet) of 150mm (6”) flue pipe with a horizontal run not exceeding 150mm (6”). 3. -
Page 13: Operating Instructions
THE ARDMORE WOOD BURNER FUEL NON BOILER STOVE OPERATING INSTRUCTIONS When operating and maintaining your Stove respect 7. Keep all combustible materials a safe distance basic standards of fire safety. Read these instruc- away from unit, please see section for clear- tions carefully. -
Page 14: Lighting
LIGHTING Before lighting the stove check with the installer that the installation work and commissioning checks described in the installation instructions have been carried out correctly and that the chimney has been swept clean, is sound and free from any obstructions. -
Page 15: Recommended Fuels
RECOMMENDED FUELS AIR CONTROLS All fuels should be stored under cover and kept This product has two independent air controls for as dry as possible prior to use. primary and secondary. Secondary control is located on the left and the primary on the right. This appliance has been tested using seasoned Raise the lever to increase the air supply and lower wood logs. -
Page 16: Refuelling
REFUELLING the right hand edge drop into the stove, drop the baf- fle into the combustion chamber and remove it To achieve the nominal output the product would through the door opening. need to be refuelled at 45 minute intervals with a fuel load of approximately 1.9kg. -
Page 17: Fire Safety
2. For stubborn deposits a soap impregnated FIRE SAFETY pad can be carefully used on the vitreous enamel. To provide reasonable fire safety, the following should be given serious consideration. 3. Use only products recommended by the 1. Do not over fire the stove. Vitreous Enamel Association, these products 2. -
Page 18: Exploded View
EXPLODED VIEW FLUE BLANKING PLATE 25. SIDE LINER LHS FLUE SPIGOT 26. TOP BAFFLE OPERATING TOOL 27. GLASS BASE 28. DOOR HANDLE STOVE LEG 29. OPERATING HANDLE FRONT 30. SPACER TO DOOR HANDLE LEFT HAND SIDE 31. SPACER RIGHT HAND SIDE 32. - Page 19 Manufactured by Waterford Stanley Ltd., Unit 401-403, IDA Industrial Estate, Cork Road, Waterford, Ireland. Tel: (051) 302300 Fax (051) 302315 N00562AXX Rev 002 DP 140905...
