AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-D607S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
VSX-D607S
KUXJI
KCXJI
SDXJI
CONTENTS
1. SAFETY INFORMATION ...................................... 2
3. SCHEMATIC DIAGRAM ....................................... 8
4. PCB CONNECTION DIAGRAM .......................... 32
5. PCB PARTS LIST ............................................... 44
6. ADJUSTMENT .................................................... 51
PIONEER ELECTRONIC CORPORATION
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Lane Crawford Place, Singapore 0923
c
PIONEER ELECTRONIC CORPORATION 1998
Power Requirement
AC120V
AC120V
AC110V/120-127V/220V/240V
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
RECEIVER POWER TV POWER
POWER
FQ
ENTER
–
FQ
VOL
VOL
CHANNEL
MULTI CONTROL
DVD
LD/SAT
CD
VCR
TV CONTROL
TUNER
PERSONAL
SURROUND
DSP MODE
ATT
TEST TONE
CENTER
REAR
SUBWOOFER
EFFECT
DISC
CLASS
TV/VCR
FUNCTION
MODE CHECK
MULTI
COMMANDER
OPERATION
SYSTEM OFF
SET UP
MULTI CONTROL COMMANDER
PRE-PROGRAMMED AND LEARNING
The voltage can be converted by the
following method.
With the voltage selector
7. GENERAL INFORMATION ................................ 53
7.1 DISPLAY ....................................................... 53
7.2 PCB LOCATION ........................................... 55
7.3 BLOCK DIAGRAM ........................................ 56
7.4 REMOTE CONTROL UNIT .......................... 58
[CU-VSX128 (AXD7153)]
T - IZK JAN. 1998 Printed in Japan
ORDER NO.
RRV1897

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSX-D607S and is the answer not in the manual?

Questions and answers

Related Manuals for Pioneer VSX-D607S

Summary of Contents for Pioneer VSX-D607S

  • Page 1 PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Lane Crawford Place, Singapore 0923 PIONEER ELECTRONIC CORPORATION 1998...

  • Page 2: Safety Information

    The use of a substitute replacement component which does Leakage 0.5mA current Device not have the same safety characteristics as the PIONEER tester under recommended replacement one, shown in the parts list in test this Service Manual, may create shock, fire, or other hazards.

  • Page 3: Exploded Views And Parts List

    See Contrast table (2) Packing Sheet AHG7010 Sub Pad B AHB7027 Caution 220V Label See Contrast table (2) (2) CONTRAST TABLE VSX-D607S/KUXJI, KCXJI and SDXJI are constructed the same except for the following : s i l s i l...
  • Page 4 VSX-D607S 2.2 EXTERIOR SDXJI Type Only Refer to "2.3 FRONT PANEL SECTION".
  • Page 5 VSX-D607S SDXJI Type Only...
  • Page 6 See Contrast table (2) PCB Support AEC7006 PCB Support AEC7056 Sheet AEE1028 Sheet AEE7010 PCB Mold AMR2533 Cord Stopper See Contrast table (2) (2) CONTRAST TABLE VSX-D607S/KUXJI, KCXJI and SDXJI are constructed the same except for the following : i r r...
  • Page 7 VSX-D607S 2.3 FRONT PANEL SECTION • FRONT PANEL SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. POWER SWITCH Assy AWZ8501 FL Filter AAK7294 FRONT INPUT Assy AWZ8502 Sub Panel AAP7042 FL/U-COM Assy AWZ8043 Front Panel...

  • Page 8: Schematic Diagram

    VSX-D607S 3. SCHEMATIC DIAGRAM 3.1 OVERALL CONNECTION DIAGRAM Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST". 2/3, 1/3, DOLBY DIGITAL ASSY (AWX7042) FM/AM TUNER MODULE (AXQ7219:KUXJI,KCXJI) (AXQ3112:SDXJI) R/C AMP ASSY...
  • Page 9 VSX-D607S POWER SWITCH ASSY (AWZ8501) FL/U-COM ASSY SDXJI ONLY (AWZ8043) VOLTAGE SELECTOR 240V 120– 127V 110V TRANS 220V ASSY (AWZ8496) 2/3, 1/3, INPUT ASSY INPUT ASSY REK1077 1.6A 125V (AWX7148:KUXJI,KCXJI) (AWX7149:SDXJI) REK1077 1.6A 125V REK1077 1.6A 125V POWER TRANSFORMER ATS7161 (KUXJI,KCXJI) ATS7163 (SDXJI) REG.1...
  • Page 10 VSX-D607S 3.2 FL/U-COM AND POWER SWITCH ASSEMBLIES CN409 CN206 POWER SWITCH ASSY (AWZ8501) POWER SWITCH ASSY S981 : DSP MODE S982 : POWER S983 : DOLBY PRO LOGIC S984 : LOUDNESS S985 : VIDEO S986 : INPUT MODE...
  • Page 11 VSX-D607S : AUDIO SIGNAL ROUTE FL/U-COM ASSY (AWZ8043) BASS TREBLE BALANCE FL/U-COM ASSY S914 : FM/AM S901 : RESET S915 : MEMORY S903 : SELECT S904 : ENTER S916 : MPX S905 : TAPE2 S918 : DIRECT S906 : CD...
  • Page 12 VSX-D607S 3.3 INPUT ASSY (1/3) CN804 CN1993 CN6201 ADG [J19 (CN207) 5 pin] (REC) VCR OUT FUNCTION SW INPUT ASSY (AWX7148:KUXJI,KCXJI) (AWX7149:SDXJI)
  • Page 13 VSX-D607S : AUDIO SIGNAL ROUTE : AUDIO SIGNAL ROUTE (REAR) (SL) : AUDIO SIGNAL ROUTE (CENTER) : AUDIO SIGNAL ROUTE (TUNER) : AUDIO SIGNAL ROUTE (PHONO) : AUDIO SIGNAL ROUTE (REC) (REC) : AUDIO SIGNAL ROUTE (F.IN) (F-IN) (SL) (SL)

  • Page 14: Table Of Contents

    VSX-D607S 3.4 INPUT (2/3), TRANS AND MOS FET ASSEMBLIES CN9801 C216,C217 KUXJI,KCXJI: ACH7018(8200/71) SDXJI: ACH7019(8200/80) (H.P) (H.P) CN502 CN155...
  • Page 15 VSX-D607S : AUDIO SIGNAL ROUTE (H.P) : AUDIO SIGNAL ROUTE (HEADPHONE) INPUT ASSY (AWX7148: KUXJI,KCXJI) (AWX7149: SDXJI) TRANS ASSY (AWZ8496) FET DRIVER MOS FET ASSY (AWZ8497) OUTPUT PEAK DETECTOR...
  • Page 16 VSX-D607S 3.5 INPUT (3/3), FRONT INPUT AND REG.1 ASSEMBLIES INPUT ASSY (AWX7148:KUXJI,KCXJI) (AWX7149:SDXJI) REG.1 ASSY (AWZ8507)
  • Page 17 VSX-D607S : AUDIO SIGNAL ROUTE (H.P) : AUDIO SIGNAL ROUTE (HEADPHONE) (F-IN) : AUDIO SIGNAL ROUTE (F.IN) 2SC5242 2SA1962 2SA1962 2SC5242 FRONT INPUT ASSY (AWZ8502) (F-IN) (H.P) (H.P)
  • Page 18 VSX-D607S 3.6 DOLBY DIGITAL ASSY (1/3) DOLBY DIGITAL ASSY (AWX7042) TORX176 VTL1019 JA9104 L9108 R9111 C9110 C9111 47/6.3 6.2k JA9000 6.2k (2/2) AKB7095 JA9000 (1/2) AKB7095 R9039 R9038...
  • Page 19 VSX-D607S CN212...
  • Page 20 VSX-D607S 3.7 DOLBY DIGITAL ASSY (2/3) DOLBY DIGITAL ASSY (AWX7042)
  • Page 21 VSX-D607S R9702...
  • Page 22 VSX-D607S 3.8 DOLBY DIGITAL ASSY (3/3) DOLBY DIGITAL ASSY (AWX7042)
  • Page 23 VSX-D607S R9604 6.8k R9614 6.8k (SL) (SL) R9624 (SL) R9634 (SL) (SW) (SW) (SW) CN408 : AUDIO SIGNAL ROUTE (SL) : AUDIO SIGNAL ROUTE (REAR) : AUDIO SIGNAL ROUTE (CENTER) (SW) : AUDIO SIGNAL ROUTE (SW)
  • Page 24 VSX-D607S 3.9 VOLUME ASSY VOLUME ASSY (AWZ8047) (SW) (SL) Q710 DTA143ES Q709 DTA143ES CN301 : AUDIO SIGNAL ROUTE : AUDIO SIGNAL ROUTE (CENTER) (SL) (SW) : AUDIO SIGNAL ROUTE (REAR) : AUDIO SIGNAL ROUTE (SW)
  • Page 25 VSX-D607S 3.10 R/C SPEAKER ASSY R/C SPEAKER ASSY (AWZ8505:KUXJI,KCXJI) (AWZ8613:SDXJI) (SL) (SL) (SL) (SW) 9k/10k SDXJI ONLY AM/FM CHANNEL STEP (SW) (SW) (SW) (SL) : AUDIO SIGNAL ROUTE (REAR) : AUDIO SIGNAL ROUTE (CENTER) (SW) : AUDIO SIGNAL ROUTE (SW)
  • Page 26 VSX-D607S 3.11 R/C AMP ASSY R/C AMP ASSY (AWZ8504) (SL) (SL) (SL) (SL) (SW) (SW) (SW) (SW)
  • Page 27 VSX-D607S (SL) : AUDIO SIGNAL ROUTE (REAR) : AUDIO SIGNAL ROUTE (CENTER) (SW) : AUDIO SIGNAL ROUTE (SW) 2SC5242 OUTPUT DETECTOR (SL) (SL) (SL) 2SA1962 2SA1962 (SL) DC DETECTOR (SL) 2SC5242 (SW) (SW) 2SC5242 2SA1962 (SW) (SW)
  • Page 28 VSX-D607S 3.12 VIDEO/SR ASSY : VIDEO SIGNAL ROUTE (V.REC) : VIDEO REC SIGNAL ROUTE VIDEO/SR ASSY (AWZ8509) (V.REC) MUTE...
  • Page 29 VSX-D607S 3.13 PRIMARY AND REG.2 ASSEMBLIES REG.2 ASSY (AWZ8498) POWER TRANSFORMER ATS7161 (KUXJI,KCXJI) ATS7163 (SDXJI) SDXJI ONLY S1 : AKX-507 VOLTAGE SELECTOR 240V 120– 127V 110V 220V FU1 : REK1085 6.3A 125V (KUXJI,KCXJI) REK1064 3.15A 250V (SDXJI) PRIMARY ASSY (AWZ8865 : KUXJI,KCXJI)
  • Page 30 VSX-D607S 3.14 FM/AM TUNER MODULE FM/AM TUNER MODULE (AXQ7219:KUXJI,KCXJI) (AXQ3112:SDXJI) AM RF TUNING BLOCK AXX1025...
  • Page 31 VSX-D607S C6230,C6232 KUXJI,KCXJI:0.039 SDXJI:0.033 F6202 KUXJI,KCXJI:ATF1156 SDXJI:ATF1155...

  • Page 32: Pcb Connection Diagram

    VSX-D607S 4. PCB CONNECTION DIAGRAM 4.1 FL/U-COM AND POWER SWITCH ASSEMBLIES FL/U-COM ASSY CN802 CN206 CN9301 CN411 VR1901 VR1902 VR1903 Q901 Q906 IC1901 Q903 IC901 Q907 Q902 Q905 IC1902 IC902 POWER SWITCH ASSY...
  • Page 33 VSX-D607S CN409 SIDE A (ANP7175-B) Q907 Q904 Q952 Q951 IC902 IC951 Q953 NOTE FOR PCB DIAGRAMS : 1. Part numbers in PCB diagrams match those in the schematic 3. The parts mounted on this PCB include all necessary parts for diagrams.
  • Page 34 VSX-D607S 4.2 INPUT ASSY INPUT ASSY CN702 CN6201 CN1993...
  • Page 35 VSX-D607S (ANP7173-C) Q308 Q315 Q316 Q310 Q309 Q322 Q313 Q306 Q311 Q312 Q307 Q314 Q398 Q304 Q397 Q302 Q321 IC204 Q206 Q205 Q301 Q305 IC201 Q303 IC409 CN51 Q407 Q405 CN9801 IC407 IC408 IC404 Q408 Q406 IC405 IC406 Q411 Q410...
  • Page 36 VSX-D607S 4.3 TRANS, MOS FET, FRONT INPUT AND REG.1 ASSEMBLIES TRANS ASSY REG.1 ASSY (ANP7175-B) CN207 CN210 (ANP7173-C) MOS FET ASSY FRONT INPUT ASSY CN413 (ANP7173-C) (ANP7175-B) SIDE A D E F G...
  • Page 37 VSX-D607S 4.4 VOLUME AND R/C SPEAKER ASSEMBLIES VOLUME ASSY CN410 IC702 Q701 Q702 IC703 Q703 Q704 Q705 VR701 Q709 IC701 Q710 Q706 Q707 Q708 (ANP7174-D) CN301 R/C SPEAKER ASSY CN220 (ANP7175-B) SIDE A...
  • Page 38 VSX-D607S 4.5 DOLBY DIGITAL ASSY • This diagram has four layers. In the two middle layers, mainly Vcc and GND are connected. DOLBY DIGITAL ASSY CN212 CN408 (ANP7183-D) Q9462 Q9431 IC9371 IC9361 Q9401 IC9461 Q9461 Q9402 IC9121 IC9301 IC9251 IC9431...
  • Page 39 VSX-D607S • This diagram has four layers. In the two middle layers, mainly Vcc and GND are connected. DOLBY DIGITAL ASSY (ANP7183-D) Q9302 Q9304 IC9471 IC9441 IC9501 IC9621 IC9641 Q9303 Q9002 IC9041 IC9411 IC9601 Q9621 Q9651 Q9032 Q9006 Q9251 Q9601...
  • Page 40 VSX-D607S 4.6 R/C AMP ASSY R/C AMP ASSY Q603 Q605 Q619 Q607 Q609 Q611 Q615 Q601 Q617 Q602 CN703 Q613 Q620 Q612 Q614 Q604 Q618 Q606 Q608 Q610 Q616 Q501 CN153 Q505 Q513 Q503 Q507 Q509 Q515 Q511 Q517 Q519...
  • Page 41 VSX-D607S 4.7 VIDEO/SR, PRIMARY AND REG.2 ASSEMBLIES VIDEO/SR ASSY (ANP7174-D) Q1851 Q853 Q852 Q1898 IC851 Q851 Q802 Q801 Q1852 Q854 Q1853 IC1851 Q1801 Q1899 IC1853 Q855 AC POWER CORD PRIMARY ASSY LIVE NEUTRAL POWER TRANSFORMER VOLTAGE SELECTOR REG.2 ASSY VOLTAGE...
  • Page 42 VSX-D607S 4.8 FM/AM TUNER MODULE FM/AM TUNER MODULE (ANP1729-B) SIDE A...
  • Page 43 VSX-D607S FM/AM TUNER MODULE (ANP1729-B) SIDE B...

  • Page 44: Pcb Parts List

    VSX-D607S Mark No. Description Part No. Mark No. Description Part No. 5. PCB PARTS LIST • NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. • mark found on some component parts indicates the importance of the safety factor of the part.
  • Page 45 VSX-D607S Mark No. Description Part No. Mark No. Description Part No. C905,C906 CKPUYF473Z16 Q210,Q303-Q306 2SA992 C901,C904,C918,C945,C965 CKPUYY103M16 Q205,Q206,Q397,Q398 2SC1740S C910 CKPYF103Z50 Q401,Q402 2SC1740S Q208 2SC1845 Q315,Q316 2SC2240 RESISTORS R919 RA8T103J Q207,Q301,Q302 2SC2878 VR1903 (500kΩ) ACS1016 Q309,Q310 2SC3334 VR1901,VR1902 (30kΩ) ACS7020...
  • Page 46 VSX-D607S Mark No. Description Part No. Mark No. Description Part No. C427,C428 CQMA242J50 OTHERS C425,C426 CQMA822J50 8P CABLE HOLDER 51052-0800 C221 (4700µF/35V) RCH1107 11P CABLE HOLDER 51052-1100 H291-H296 FUSE CLIP AKR1004 RESISTORS R343,R344 (0.33Ω/5W) ACN7001 R226 (27Ω/5W) ACN7022 R319,R320 RD1/4LMF680J...
  • Page 47 VSX-D607S Mark No. Description Part No. Mark No. Description Part No. C9257 CEAS471M6R3 DOLBY DIGITAL ASSY C9107,C9128,C9201,C9221,C9403 CEV100M16 C9405,C9408,C9433,C9435,C9438 CEV100M16 SEMICONDUCTORS C9463,C9465,C9468,C9502,C9504 CEV100M16 C9602,C9605,C9612,C9615,C9622 CEV100M16 IC9401,IC9431,IC9461 AK4319-VM IC9251 AK5340-VS C9625,C9632,C9635,C9642,C9645 CEV100M16 IC9121 CD0004AF C9652,C9655 CEV100M16 IC9361 KM62V256CLG-7L C9262 CEV101M6R3 IC9301...
  • Page 48 VSX-D607S Mark No. Description Part No. Mark No. Description Part No. CAPACITORS R/C AMP ASSY C720,C721 CCCSL271J50 C703,C704 CCPUSL560J50 SEMICONDUCTORS C719 CEANP100M50 Q509,Q609,Q610 2SA1321 C722 CEAS220M50 Q517,Q617,Q618 2SA1837 C701,C702,C705-C708 CEAS4R7M50 Q503,Q603,Q604 2SA970 Q505,Q507,Q605-Q608 2SA992 C711-C714,C717,C718 CEAS4R7M50 Q513,Q613,Q614 2SC1740S C729,C730 CFTXA473J50...
  • Page 49 VSX-D607S Mark No. Description Part No. Mark No. Description Part No. RESISTORS REG.2 ASSY R860,R861 RD1/4PM331J Other Resistors RD1/4PU SEMICONDUCTORS IC282 NJM78M05FA OTHERS IC281 NJM78M12FA 2P PIN JACK AKB7016 3P PIN JACK AKB7018 CAPACITORS CN804 4P JAMPER CONNECTOR KPE4 C282...
  • Page 50 VSX-D607S Mark No. Description Part No. Mark No. Description Part No. CAPACITORS C6202,C6234,C6236 (1µF/16V) ACG1051 C6229 CCSCH821J50 C6107 CCSCK1R0C50 C6108,C6203,C6268 CCSQCH101J50 C6111,C6116,C6208,C6221,C6222 CCSQCH150J50 C6115 CCSQCH330J50 C6101 CCSQCH5R0C50 C6110 CCSQCK2R0C50 C6114 CCSQRH080D50 C6113 CCSQRH180J50 C6105 CCSQTH150J50 C6224,C6246,C6262 CEAS100M50 C6227 CEAS101M10 C6261...

  • Page 51: Adjustment

    VSX-D607S 6. ADJUSTMENT 6.1 TUNER ADJUSTMENT ADJUSTMENT OF FM TUNER SECTION • Set the FM/AM selector to FM BAND. • Connect the wiring as shown in Fig. 6–1. ± d ( µ ) V − ± v i t y t i i n i ±...
  • Page 52 VSX-D607S 60cm Loop antenna AM antenna terminal AM SG Center Center PRODUCT MPX SG FM SG voltmeter FM75Ω antenna terminal Fig.6-1 AM and FM Adjustment Wiring Diagram FM/AM TUNER MODULE IC6202 L6102 L6101 75Ω antenna T6101 terminal C6238 Pin 28...

  • Page 53: General Information

    VSX-D607S 7. GENERAL INFORMATION 7.1 DISPLAY AAV7034 (FL/U-COM ASSY : V901) • FL TUBE • Pin Assignment • Grid Assignment...
  • Page 54 VSX-D607S • Anode Connection...

  • Page 55: Pcb Location

    VSX-D607S 7.2 PCB LOCATION VIDEO/SR ASSY R/C SPEAKER ASSY PRIMARY ASSY DOLBY DIGITAL ASSY FM/AM TUNER MODULE Rear POWER TRANSFORMER INPUT ASSY TRANS ASSY REG.1 ASSY FRONT INPUT ASSY REG.2 ASSY VOLUME ASSY MOS FET ASSY POWER SWITCH ASSY FL U-COM ASSY...

  • Page 56: Block Diagram

    VSX-D607S 7.3 BLOCK DIAGRAM AF SECTION...
  • Page 57 VSX-D607S AC-3 DECODE ASSY AND VIDEO COMPOSITE SECTION AC-3 DECODE ASSY 3.3V SRAM KM62V256CLG-7L 384fs PCM/ 3.3V L out DF/DAC DOLBY AK4319-VM BCK(64fs) DATA DIGITAL CD0004AF COAX R out DATA PCM/ AC-3 DOLBY LS out DIGITAL DF/DAC Analogue MB86342A AK4319-VM...

  • Page 58: Remote Control Unit

    VSX-D607S 7.4 REMOTE CONTROL UNIT [CU-VSX128 (AXD7153)] 7.4.1 EXPLODED VIEWS AND PARTS LIST • NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. • mark found on some component parts indicates the importance of the safety factor of the part.
  • Page 59 VSX-D607S 7.4.2 SCHEMATIC DIAGRAM Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST". SWITCHES K01 : 0 K02 : 1 K03 : 2 K04 : 3 K05 : 4...
  • Page 60 VSX-D607S 7.4.3 PCB DIAGRAM...
  • Page 61 VSX-D607S 7.4.4 PCB PARTS LIST • NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. • mark found on some component parts indicates the importance of the safety factor of the part.

  • Page 62: Panel Facilities And Specifications

    VSX-D607S 8. PANEL FACILITIES AND SPECIFICATIONS * The size of characters shown in the figure may differ NAMES OF PARTS from that on the actual product. Front panel DOLBY AUDIO/VIDEO MULTI-CHANNEL RECEIVER D I G I T A L STANDBY...

  • Page 63: Overload Indicator

    VSX-D607S Display 2 3 4 5 2 MONO DIRECT JOG MODE PRO LOGIC CLASS SIGNAL DOLBY TUNED SELECT LOUDNESS DSP MODE TAPE 2 ST FREQ STEREO DIGITAL DELAY DIGITAL MEMORY ANALOG AUTO OVERLOAD 1 SIGNAL SELECT indicators = JOG MODE indicator The input signal format currently selected will light .

  • Page 64: Connecting Devices

    VSX-D607S When connecting or changing equipment, be sure to turn CONNECTING DEVICES OFF the POWER switch, and disconnect the power cord from the wall outlet. 7 When AM broadcast reception is poor 7 For better reception of signals, Connect a 5 to 6 meter (15~18 feet) long vinyl-coated wire to the AM an- use an FM external antenna.

  • Page 65: Front Panel

    * The size of characters and terminal positions in the figures may differ from those on the actual product. AC OUTLET PIONEER projection TV [SWITCHED 100 W (0.8 A) (Center channel) MAX] Speakers system (Rear)

  • Page 66: Power Button

    VSX-D607S 7 SURROUND/PERSONAL button Remote control unit [When setting MULTI operations] Press when setting the personal mode using multi operations. RECEIVER POWER TV POWER [When setting to other than MULTI opera- tions] Press when performing surround operations and POWER setting/changing setting modes.

  • Page 67: Specifications

    VSX-D607S SPECIFICATIONS Amplifier Section FM Tuner Section Continuous average power output of 100 Frequency Range ......... 87.5 MHz to 108 MHz Usable Sensitivity ..... Mono: 11.2 dBf, IHF (1.0 µV/75 Ω) watts* per channel, min., at 8 ohms, from 20 50 dB Quieting Sensitivity ........
