Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, put them away in a safe place for future reference.
Page 3
The lightning flash with arrowhead, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. READ INSTRUCTIONS —...
Contents 01 Before you start Checking what’s in the box ...6 Installing the receiver ... 6 Loading the batteries ...6 Making cable connections ...6 Operating range of remote control unit ... 6 02 5 minute guide Introduction to home theater ...7 Listening to surround sound ...
Page 5
08 Making recordings Making an audio or a video recording ... 41 09 Additional information Troubleshooting ... 42 Resetting the main unit ... 44 Cleaning the unit ...44 Specifications (VSX-D414) ... 44 Specifications (VSX-D514) ... 46...
Before you start Checking what’s in the box Please check that you've received the following supplied accessories: • AM loop antenna • FM wire antenna • Dry cell batteries (AA size IEC R6) x 2 • Remote control • These operating instructions •...
5 minute guide Introduction to home theater You are probably used to using stereo equipment to listen to music, but may not be used to home theater systems that give you many more options (such as surround sound) when listening to soundtracks.
/ LD FRONT Video cord CD-R / TAPE / MD VIDEO IN This receiver* VIDEO MONITOR WOOFER PREOUT *The illustration shows the VSX-D514, but DVD connections for the D V D VSX-D414 will be the 5.1CH INPUT same. Video cord...
Page 9
5 minute guide Connect your speakers. A complete setup of six speakers (including the subwoofer) is shown here, but everyone’s home setup will vary. Simply connect the speakers you have in the manner shown below. The receiver will work with just two stereo speakers (the front speakers in the diagram) but using at least three speakers is recommended, and all six is best.
Press QUICK SETUP. The display prompts you to select your speaker setup. Use the MULTI JOG dial to choose your speaker setup. Cycle between the following choices: 5.1ch 5.0ch 4.1ch 2.0ch 2.1ch 3.0ch 3.1ch VSX-D514 MULTI JOG 4.0ch...
Page 11
5 minute guide Check the table below to find the speaker setup that corresponds with your system. Front Center Surround Speakers Speaker Speakers √ 2.0 ch √ 2.1 ch √ √ 3.0 ch √ √ 3.1 ch √ √ 4.0 ch √...
(left), and the yellow plugs to VIDEO. Be sure to insert completely. S-video cables (VSX-D514 only) Use S-video cables (not supplied) to get clearer picture reproduction than regular video cords. Connect from an S-video jack on the rear of the receiver to an S-video jack on the video component you are hooking up.
Connecting up Connecting digital components For proper decoding of Dolby Digital/DTS soundtracks, you need to make digital audio connections. You can do this by either coaxial or optical connections (you don’t need to do both). The quality of these two types of connections is the same, but since some digital components only have one type of digital terminal, it is a matter of matching like with like (for example, the coaxial output from the component to the coaxial input on the receiver).
VSX-D514 only – For better quality video, you can hook up using the component video jacks or the S- video jacks on the rear of the receiver instead of the regular video jacks. Make sure you connect to your TV in the same way that you’ve connected to your other video components.
Page 15
Connecting up AUDIO OUTPUT VIDEO OUTPUT COMPONENT VIDEO OUTPUT TV tuner (or Satellite tuner) S-VIDEO OUTPUT The arrows indicate the direction of the signal. COMPONENT VIDEO OUTPUT S-VIDEO OUTPUT VIDEO OUTPUT DVD player (or LD player) AUDIO OUTPUT The arrows indicate the direction of the signal.
Connecting up Connecting antennas Connect the AM loop antenna and the FM wire antenna as shown below. To improve reception and sound quality, connect external antennas (see Using external antennas below). Always make sure that the receiver is switched off and unplugged from the wall outlet before making or changing any connections.
Connecting up Connecting the speakers A complete setup of six speakers (including the subwoofer) is shown here, but everyone’s home setup will vary. Simply connect the speakers you have in the manner shown below. The receiver will work with just two stereo speakers (the front speakers in the diagram) but using at least three speakers is recommended, and a complete setup is best for surround sound.
Connecting up Make sure that all the bare speaker wire is twisted together and inserted fully into the speaker terminal. If any of the bare speaker wire touches the rear panel it may cause the power to cut off as a safety measure.
A damaged power cord can cause a fire or give you an electrical shock. Check the power cord once in a while. When you find it damaged, ask your nearest Pioneer authorized service center or your dealer for a replacement.
Controls and displays Remote Control RECEIVER SLEEP INPUT SELECTOR DVD/LD DVD 5.1CH CD-R/ TAPE/MD ADVANCED STANDARD SURROUND TOP MENU SETUP TUNER EDIT ENTER VOLUME CH SELECT LEVEL TEST TONE TUNER TUNING STATION AUDIO DVD CONTROL SUB TITLE RECEIVER RECEIVER Switches the receiver between on and standby. STANDARD (pages 26, 36) Press for Standard decoding and to switch between the various Pro Logic II options.
Page 21
DISPLAY (page 40) Use to switch the display between the station preset name and the frequency. 13 DVD CONTROL buttons You can use these buttons to control a Pioneer DVD player connected to your system. Button What it does Turns DVD power on/off.
MULTI JOG TUNER EDIT (pages 39–40) Use to mute the sound or restore the sound if it has been muted. STANDARD (pages 26, 36) Press for Standard decoding and to switch between the various Pro Logic II options. VSX-D514 MULTI JOG...
Page 23
Controls and displays ADVANCED SURROUND (pages 27, 36) Use to switch between the various surround modes. STEREO/DIRECT (page 28) Switches direct playback on or off. Direct playback bypasses the tone controls and channel levels for the most accurate reproduction of a source. 16 SIGNAL SELECT (page 29) Use to select between an analog or digital signal.
Controls and displays Display SIGNAL SELECT indicators Lights to indicate the type of input signal assigned for the current component: AUTO : Lights when AUTO signal select is on. DIGITAL : Lights when a digital audio signal is detected. 2 DIGITAL : Lights when a Dolby Digital signal is detected.
Page 25
Controls and displays 11 Character display 12 ADV. SURR. (Advanced Surround) Lights when one of the Advanced Surround listening modes of the receiver is selected. 13 LOUDNESS Lights during Loudness listening. 14 TUNER indicators STEREO : Lights when a stereo FM broadcast is being received in auto stereo mode.
Listening to your system Playing sources RECEIVER SLEEP INPUT SELECTOR DVD/LD DVD 5.1CH CD-R/ TAPE/MD ADVANCED STANDARD SURROUND TOP MENU SETUP TUNER EDIT ENTER Turn on the power of the playback component. Turn on the power of the receiver. Use the INPUT SELECTOR buttons to select the source you want to playback.
You can also use with Dolby Digital sources for a wider stereo field than the Standard modes. • 5-STEREO (VSX-D514)– This can be selected to give multi-channel sound to a stereo source, using all of the speakers in your setup.
(STANDARD or ADVANCED SURROUND should be selected). AUDIO/VIDEO MULTI-CHANNEL RECEIVER ENTER MASTER VOLUME SIGNAL MIDNIGHT/ SPEAKER TONE QUICK SETUP DIRECT SELECT LOUDNESS IMPEDANCE MODE DOWN MULTI JOG Press VSB MODE (front panel) repeat- VSX-D514 MULTI JOG...
The Loudness listening feature can be used to get good bass and treble from music sources at low volume levels. The Midnight listening feature allows you to VSX-D514 hear effective surround sound of movies at low MULTI JOG volume levels. The effect automatically adjusts according to the volume at which you’re...
Listening to your system Use the MULTI JOG dial to change the amount of bass or treble as necessary. Wait about five seconds for your changes to be input automatically. • The tone controls can only be used with the Stereo sound mode.
Refer to the following pages for details on each of the settings. If you are using the Pioneer S-FCRW230/240 speaker system, you’ll have to set the Crossover frequency to 200 Hz. You can leave the Speaker setting and the Subwoofer setting in the default settings.
Setting up the receiver Component video input settings (page 35) VSX-D514 only Specify the components to be assigned to the component video inputs (below). • Component video 1 input setting • Component video 2 input setting Digital input settings (page 35) Specify the components to be assigned to the digital inputs (below).
Setting up the receiver • If you chose the small front speaker setting, SW YES is automatically set and locked. • You can only select the PLUS setting if the front speakers are set to L. Crossover frequency setting • Default setting: 100 Hz Crossover frequency is the point where the receiver divides the high and low sounds (the frequencies) between the speakers.
Setting up the receiver When C is selected in the speaker setting, the center distance can’t be set. Surround speaker distance setting • Default setting: 10 ft. Like the center speaker, you should set the distance of the surround speakers accurately to hear sounds coming from both front and surround speakers at the same time.
Setting up the receiver Lch1.Rch2 Component video input settings VSX-D514 only Here you tell the receiver what components you have hooked up to the component video jacks on the back of the receiver. Component video 1: • Default settings: DVD Use ’...
Setting up the receiver Setting the relative volume level of each channel • Default setting: 0 dB For best surround sound playback, you should set the relative channel levels from the main listening position. You can set seperate levels for each surround mode. RECEIVER SLEEP INPUT SELECTOR...
• SP 6 OHM – Use this setting if your speakers are rated at 6Ω. • SP 8 OHM – Use this setting if your speakers are rated at 8Ω or more. TUNING CLASS INPUT ATT FL VSX-D514 MULTI JOG...
Using the tuner Listening to the radio The following steps show you how to tune to FM and AM radio broadcasts using the automatic (search) and manual (step) tuning functions. Once you are tuned to a station you can memorize the frequency for recall later—see Saving station presets on the next page for more on how to do this.
TUNING STANDARD SURROUND DIRE LISTENING MODE INPUT ATT FL DIMMER MUTE VSX-D514 MULTI JOG Tune to a station you want to memo- MASTER VOLUME rize. See Listening to the radio (previous page) for more on this. If you’re using the remote control, press RECEIVER.
Using the tuner Press CLASS to select one of the three classes then press } ] to select the station preset you want. You can also use the the MULTI JOG dial (front panel) to select a station preset. Press ENTER. After pressing ENTER, the preset class and number stop blinking and the receiver stores the station.
Making Recordings Making an audio or a video recording You can make an audio or a video recording from the built-in tuner, or from an audio or video source connected to the receiver (such as a CD player or TV) through the analog jacks. You will need to connect a CD recorder, tape deck, MD, VCR, or DVR deck to the CD-R/TAPE/MD or DVR/VCR outputs on the receiver to do so (see...
Sometimes the trouble may lie in another component. Investigate the other components and electrical appliances being used. If the trouble cannot be rectified even after exercising the checks listed below, ask your nearest Pioneer authorized service center or your dealer to carry out repair work.
Page 43
Additional information Problem No sound from surround or center speakers. Noise during playback of a cassette deck. Sound is produced from other components, but not from LD or DVD player. No sound is output or a noise is output when software with DTS is played back.
Additional information Resetting the main unit Use this procedure to reset all the receiver's settings to the factory default. Use the front panel controls to do this. Switch the receiver on. While holding down the TONE button, press STANDBY/ON button for about and hold the three seconds.
Additional information Video Section Input (Sensitivity/Impedance) DVR/VCR, DVD/LD, TV/SAT ... 1 Vp-p/75 Ω Output (Level/Impedance) DVR/VCR ... 1 Vp-p/75 Ω Frequency Response DVR/VCR, DVD/LD, TV/SAT ] MONITOR ... 5 Hz to 7 MHz dB Signal-to-Noise Ratio ... 55 dB Cross Talk ... 55 dB FM Tuner Section Frequency Range ...
Additional information Specifications (VSX-D514) Amplifier Section Continuous average power output of 100 watts* per channel, min., at 8 ohms, from 20 Hz to 20,000 Hz with no more than 0.2 %** total harmonic distortion (front). Continuous Power Output (Stereo) Front ... 100 W (20–20,000 Hz, THD 0.2 %, 8 Ω)
Page 47
Additional information Miscellaneous Power Requirements ... AC 120 V, 60 Hz Power Consumption ... 260 W In Standby ... 0.5 W AC Outlet ... 100 W MAX. (SWITCHED) Dimensions ... 420 (W) x 158 (H) x 393 (D) mm (16-9/16 (W) x 6-1/4 (H) x 15-1/2 (D) in.) Weight (without package) ...
Page 50
être posés de façon à ne pas être écrasés. Un câble abîmé peut provoquer un risque d’incendie ou un choc électrique. Vérifier le câble d’alimentation de temps en temps. Contacter le service après-vente PIONEER le plus proche ou le revendeur pour un remplacement. D3-4-2-1-3_Fr CAUTION ATTENTION –...
Page 51
Table des matières 01 Préparatifs Vérification du contenu de la boîte ... 5 Installation du récepteur ...5 Pour charger les piles ...5 Pour faire des raccordements de câbles ...5 Portée de fonctionnement de la télécommande ...5 02 Guide en 5 minutes Présentation du cinéma à...
Page 52
08 Pour faire des enregistrements Pour faire un enregistrement audio ou un enregistrement vidéo ... 40 09 Information complémentaire Guide de dépannage ... 41 Réinitialisation de l'unité principale ... 43 Nettoyage de l'appareil ...43 Spécifications (VSX-D414) ... 43 Spécifications (VSX-D514) ... 45...
Préparatifs Vérification du contenu de la boîte Veuillez vérifier que vous avez reçu les accessoires fournis suivants: • Antenne cadre AM • Antenne filaire FM • Piles sèches (taille AA IEC R6) x 2 • Télécommande • Ce mode d’emploi •...
Guide en 5 minutes Présentation du cinéma à domicile Vous avez probablement l’habitude d’utiliser un appareil stéréo pour écouter de la musique mais peut-être que vous n’avez pas l’habitude des systèmes cinéma à domicile qui offrent pourtant beaucoup plus d’options au moment d’écouter des bandes-sonores. Le cinéma à...
/ LD FRONT Cordon vidéo D V D 5.1CH INPUT CD-R / TAPE / MD VIDEO IN Cordon vidéo Ce récepteur* VIDEO MONITOR WOOFER PREOUT *L'illustration montre le modèle VSX-D514, mais les connexions DVD sont identiques pour le modèle VSX-D414.
Page 56
Guide en 5 minutes Raccordez vos enceintes. Une configuration complète de six enceintes (y compris un subwoofer) est montrée ici, mais la configuration à domicile de chacun est différente. Raccordez simplement les enceintes de la manière indiquée ci-dessous. Le récepteur fonctionnera avec seulement deux enceintes stéréo (les enceintes avant dans le diagramme) mais il est recommandé...
Appuyez sur QUICK SETUP. L’afficheur vous invite à sélectionner votre configuration d’enceinte. Utilisez le cadran MULTI JOG pour choisir votre configuration d’enceinte. Passez cycliquement parmi les choix suivants: 5.1ch 5.0ch 4.1ch 2.0ch 2.1ch 3.0ch 3.1ch VSX-D514 MULTI JOG 4.0ch...
Page 58
Guide en 5 minutes Consultez le tableau ci-dessous pour trouver la configuration d’enceinte qui correspond à votre système. Appuyez sur ENTER. L’afficheur vous invite à sélectionner votre configuration d’enceinte. Utilisez le cadran MULTI JOG pour choisir la taille de votre pièce. Selon la distance entre les enceintes et la position d'écoute, choisissez petite, moyenne ou grande (S, M ou L), M correspondant à...
(droite), les fiches blanches à la borne L (gauche) et les fiches jaunes à VIDEO. Vérifiez de les insérer complètement. Câbles S-vidéo (VSX-D514 uniquement) Utilisez des câbles S-vidéo (non fournis) pour obtenir une reproduction de l’image plus nette qu’avec des cordons vidéo ordinaires.
Raccordement Raccordement de composants numériques Pour un décodage approprié de bandes sonores Dolby Digital/DTS, vous avez besoin de faire des connexions audio numériques. Vous pouvez le faire soit avec une connexion coaxiale ou optique (vous n’avez pas besoin de faire les deux). La qualité de ces deux types de connexions est la même mais puisque certains composants numériques n’ont qu’un type de borne numérique, c’est un problème de correspondance (par exemple, la sortie coaxiale du composant avec l’entrée coaxiale du récepteur).
Au raccordement de votre équipement, vérifiez toujours que l’alimentation est coupée et que le cordon d’alimentation est débranché de la prise de courant murale. VSX-D514 uniquement – Pour obtenir une qualité vidéo optimale, vous pouvez effectuer le branchement en utilisant les prises vidéo en composantes ou S-vidéo situées à l'arrière du récepteur plutôt que les prises vidéo classiques.
Page 62
Raccordement AUDIO OUTPUT VIDEO OUTPUT COMPONENT VIDEO OUTPUT Tuner du téléviseur (ou tuner satellite) S-VIDEO OUTPUT Les flèches indiquent la direction du signal. COMPONENT VIDEO OUTPUT S-VIDEO OUTPUT VIDEO OUTPUT Lecteur DVD AUDIO (ou lecteur LD) OUTPUT Les flèches indiquent la direction du signal.
Raccordement Raccordement d’antennes Raccordez l'antenne cadre AM et l'antenne filaire FM comme indiqué ci-dessous. Pour améliorer la réception et la qualité du son, utilisez des antennes externes (voir la section Utilisation d'antenne externes, ci-dessous). Vérifiez toujours que le récepteur est éteint et débranché...
Raccordement Raccordement des enceintes Une configuration complète de six enceintes (y compris un subwoofer) est montrée ici, mais la configuration à domicile de chacun est différente. Raccordez simplement les enceintes de la manière indiquée ci-dessous. Le récepteur fonctionnera avec seulement deux enceintes stéréo (les enceintes avant dans le diagramme) mais il est recommandé...
Raccordement Vérifiez que tout le fil d’enceinte dénudé est torsadé et insérez-le complètement dans la borne d’enceinte. Si le fil touche le panneau arrière cela peut provoquer une coupure de courant comme mesure de sécurité. Utilisez du fil d’enceinte de bonne qualité pour raccorder les enceintes au récepteur. Conseils pour l’emplacement des enceintes Les enceintes sont habituellement conçues dans l’idée d’un emplacement précis.
Un cordon d’alimentation endommagé peut provoquer un incendie ou une décharge électrique. Vérifiez le cordon d’alimentation de temps en temps. Si vous remarquez qu’il est endommagé, adressez-vous au service après- vente Pioneer le plus proche ou au revendeur pour le remplacer.
Commandes et affichages Télécommande RECEIVER SLEEP FL DIMMER INPUT ATT INPUT SELECTOR DVD/LD DVD 5.1CH TV/SAT DVR/VCR CD-R/ TAPE/MD ADVANCED MIDNIGHT/ STANDARD SURROUND STEREO LOUDNESS TOP MENU SETUP MENU TUNER EDIT ENTER RECEIVER VOLUME MUTE CH SELECT LEVEL EFFECT TEST TONE CLASS TUNER TUNING STATION...
Page 68
DISPLAY (page 39) Sert à commuter l’affichage entre le nom d’une station préréglée et la fréquence. 13 Touches DVD CONTROL Vous pouvez utiliser ces touches pour commander un lecteur DVD Pioneer raccordé à votre système. Touche Fonction Allume/éteint le DVD.
Utilisez cette touche pour rendre l’afficheur fluorescent (FL) plus sombre ou plus lumineux. 14 MUTE Utilisez cette touche pour mettre le son en sourdine et pour le restituer s’il avait été coupé. VSX-D514 AUDIO/VIDEO MULTI-CHANNEL RECEIVER MULTI JOG ENTER MASTER VOLUME...
Page 70
Commandes et affichages 15 Touches LISTENING MODE STANDARD (pages 25, 35) Appuyez pour un décodage standard et pour commuter entre les différentes options Pro Logic II. ADVANCED SURROUND (pages 26, 35) Sert à commuter entre les différents modes surround. STEREO/DIRECT (page 27) Active ou désactive la lecture directe.
Commandes et affichages Afficheur Indicateurs SIGNAL SELECT S’allume pour indiquer le type de signal de sortie affecté pour le composant actuel: AUTO : S’allume quand le réglage AUTO de SIGNAL SELECT est activé. DIGITAL : S’allume quand un signal audio numérique est détecté.
Page 72
Commandes et affichages S’allume quand INPUT ATT est utilisé pour atténuer (réduire) le niveau du signal d’entrée (peut s’utiliser uniquement avec un signal analogique). 10 Indicateur d’enceinte Indique si le système acoustique est activé ou pas. SP 3A signifie que les enceintes sont activées. SP 3 signifie que les écouteurs sont raccordés.
Configuration de l'écoute Lecture de sources RECEIVER SLEEP FL DIMMER INPUT ATT INPUT SELECTOR DVD/LD DVD 5.1CH TV/SAT DVR/VCR CD-R/ TAPE/MD ADVANCED MIDNIGHT/ STANDARD SURROUND STEREO LOUDNESS TOP MENU SETUP MENU TUNER EDIT ENTER RECEIVER Allumez le composant de lecture. Allumez le récepteur.
Dolby Digital pour un champ stéréo plus large que les modes standard. FL DIMMER INPUT ATT • 5-STEREO (VSX-D514)– Ce mode peut être sélectionné pour offrir un son à canaux TV/SAT DVR/VCR multiples à une source stéréo, en utilisant toutes les enceintes dans votre configuration.
Appuyez plusieurs fois sur VSB MODE (panneau avant) pour activer ou désactiver le canal surround arrière virtuel. Notez que cela est uniquement possible lorsque vous écoutez en mode surround (STANDARD ou ADVANCED SURROUND doivent être sélectionnés). VSX-D514 MULTI JOG MASTER VOLUME...
La caractéristique du mode d’écoute Loudness peut s’utliser pour obtenir de bons sons graves et aigus des sources musicales à des niveaux de volume bas. VSX-D514 AUDIO/VIDEO MULTI-CHANNEL RECEIVER La caractéristique du mode d’écoute Midnight MULTI JOG vous permet d’entendre un son surround ENTER effectif de films à...
Configuration de l'écoute Utilisez le cadran MULTI JOG pour changer la quantité de graves et d’aigus nécessaire. Attendez environ cinq secondes pour que vos changements soient saisis automatiquement. • Les contrôles de tonalité peuvent s’utiliser uniquement avec le mode de son stéréo. •...
Si vous utilisez le système acoustique S- FCRW230/240 de Pioneer vous devrez régler la fréquence de croisement sur 200 Hz. Vous pouvez laisser le réglage des enceintes et le réglage du subwoofer sur les réglages par défaut.
Configuration du récepteur Réglages de l'entrée vidéo en composantes (page 34) VSX-D514 uniquement Spécifiez les composants à affecter aux entrées vidéo en composantes (ci-dessous). • Réglage de l'entrée vidéo en composantes 1 • Réglage de l'entrée vidéo en composantes 2 Réglages de l’entrée numérique (page 34)
Configuration du récepteur PLUS Le canal LFE et les basses fréquences de toutes les enceintes sont envoyés vers le subwoofer (les grandes enceintes "L" émettent aussi les basses). Aucune basse fréquence n'est envoyée vers le subwoofer. • Si vous choisissez le réglage des petites enceintes avant, SW YES est automatiquement réglé...
Configuration du récepteur Réglage de la distance de l’enceinte centrale • Réglage par défaut: 10 pieds Normalement, l’enceinte centrale est placée directement en face de la pièce d’écoute et plus proche de la position d’écoute que les enceintes avant. Cela signifie que le son de l’enceinte centrale sera audible avant les enceintes avant.
DUAL MONO. Lch1.Rch2 Réglages de l'entrée vidéo en composantes VSX-D514 uniquement Vous indiquez ici les composants que vous avez connectés aux prises vidéo en composantes situées à l'arrière du récepteur. Vidéo en composantes 1 : •...
Configuration du récepteur Pour régler le niveau de volume relatif à chaque canal • Réglage par défaut: 0 dB Pour obtenir une lecture de son surround, vous devriez régler les niveaux du canal relatif depuis la principale position d’écoute. Vous pouvez régler des niveaux séparés pour chaque mode surround.
6 ohm. • SP 8 OHM – Utilisez ce réglage si l'impédance de vos enceintes est de 8 ohm ou supérieure. STATION TUNING TUNER EDIT CLASS INPUT ATT FL MULTI JOG VSX-D514 AUDIO/VIDEO MULTI-CHANNEL RECEIVER MULTI JOG ENTER MASTER VOLUME DOWN...
Utilisation du tuner Pour écouter la radio Les étapes suivantes vous montrent comment régler des émissions de radio FM et AM en utilisant les fonctions de réglage automatique (recherche) et de réglage manuel (pas). Une fois qu’une station est réglée vous pouvez mémoriser la fréquence pour la faire revenir plus tard—voir Pour mémoriser des stations préréglées à...
STANDARD SURROUND DIRE LISTENING MODE TUNER EDIT CLASS INPUT ATT FL DIMMER MUTE MULTI JOG VSX-D514 AUDIO/VIDEO MULTI-CHANNEL RECEIVER mémoriser. Voir Pour écouter la radio (page précédente) pour MULTI JOG en savoir plus à ce sujet. ENTER MASTER VOLUME DOWN appuyez sur RECEIVER.
Utilisation du tuner Appuyez sur CLASS pour sélectionner une des trois classes puis appuyez sur } ] pour sélectionner la station préréglée que vous voulez. Vous pouvez aussi utiliser le cadran MULTI JOG (panneau avant) pour sélectionner une station préréglée. Appuyez sur ENTER.
Pour faire des enregistrements Utilisation du tuner Pour faire un enregistrement audio ou un enregistrement vidéo Vous pouvez faire un enregistrement audio ou vidéo depuis le tuner intégré, ou depuis une source audio ou vidéo raccordée au récepteur (comme un lecteur CD ou un téléviseur) à travers les prises analogiques.
Parfois le problème peut se trouver dans un autre composant. Examinez les autres composants et les appareils électriques en usage. Si le problème ne peut pas se résoudre malgré les indications ci-dessous, consultez votre service après-vente Pioneer le plus proche pour le faire réparer. Problèmes Impossible de mettre sous tensio.
Page 90
Information complémentaire Problèmes Pas de son des enceintes surround ou de l’enceinte centrale. Bruit lors de la lecture d’une platine cassette. Le son est produit par d’autres composants, mais pas par le lecteur DVD ou LD. Pas de son ou du bruit est fourni lors de la lecture d’un logiciel avec DTS.
Information complémentaire Réinitialisation de l'unité principale Utilisez cette procédure pour réinitialiser tous les réglages du récepteur à leur valeur d'usine. Pour cela, utilisez les commandes du panneau avant. Allumez le récepteur. Tout en appuyant sur la touche TONE, appuyez et maintenez enfoncée la touche ON pendant environ trois secondes.
Page 92
Information complémentaire Section Vidéo Entrée (Sensibilité/impédance) DVR/VCR, DVD/LD, TV/SAT ... 1 Vp-p/75 Ω Sortie (Niveau/impédance) DVR/VCR ... 1 Vp-p/75 Ω Réponse en fréquence DVR/VCR, DVD/LD, TV/SAT ] MONITOR ... 5 Hz à 7 MHz dB Rapport signal/bruit ... 55 dB Diaphonie ...
Information complémentaire Spécifications (VSX-D514) Section amplificateur Moyenne de puissance de sortie continue de 100 watts* par canal, à 8 ohms min., de 20 Hz à 20.000 Hz avec moins de 0,2 %** de distorsion harmonique totale (avant). Puissance de sorite continue (Stéréo) Avant ...
Page 94
Information complémentaire Divers Puissance requise ... 120 V secteur, 60 Hz Consommation ... 260 W En mode d’attente ... 0.5 W Prise de courant secteur ... 100 W MAX. Dimensions ... 420 (W) x 158 (H) x 393 (D) mm (16-9/16 (W) x 6-1/4 (H) x 15-1/2 (D) pouces) Poids (sans emballage) ...
