Installation and Operating Manual
See IMPORTANT OWNER INFORMATION section for details.
Do not operate this equipment unless you have
read and understood the contents of this manual!
Failure to follow the instructions contained in this
manual may result in serious injury or death. This
manual contains important safety information
concerning the maintenance, use, and operation
of this product. If you're unable to understand the
contents of this manual, please bring it to the
attention of your supervisor. Keep this manual in
a safe location for future reference.
Induction Ranges
IRBR2-6200
For
Models
I&W #07.05.260.00
Register your unit online!
No opere este equipo al menos que haya leído y
comprendido el contenido de este manual!
Cualquier falla en el seguimiento de las
instrucciones contenidas en este manual puede
resultar en un serio lesión o muerte. Este manual
contiene importante información sobre seguridad
concerniente al mantenimiento, uso y operación
de este producto. Si usted no puede entender el
contenido de este manual por favor pregunte a su
supervisor. Almacenar este manual en una
localización segura para la referencia futura.
© 2010 Hatco Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IRBR2-6200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hatco IRBR2-6200

Summary of Contents for Hatco IRBR2-6200

  • Page 1 Si usted no puede entender el attention of your supervisor. Keep this manual in contenido de este manual por favor pregunte a su a safe location for future reference. supervisor. Almacenar este manual en una localización segura para la referencia futura. © 2010 Hatco Corporation...

  • Page 2: Table Of Contents

    Parts & Service pull-down menu, and click on “Warranty Registration”. INTRODUCTION Hatco Induction Ranges offer a safe, quick, efficient, and attractive way to prepare foods in commercial kitchens as well as display cooking locations (omelet bars, buffets, etc...). The...

  • Page 3: Important Safety Information

    This unit has no “user-serviceable” parts. If service is maintenance or cleaning. required on this unit, contact an Authorized hatco Service Agent or contact the hatco Service Department at • DO NOT submerge or saturate with water. Unit is not 414-671-6350;...

  • Page 4: Model Description

    MODEL DESCRIPTION The Hatco Model IRBR2-6200 Induction Range is a built-in hob equipped with two induction coils underneath a ceramic glass surface. Dual coils enable the use of two pans on a single hob. The induction coils adapt to the induction-ready pan size to Induction ensure even heat distribution for even cooking.

  • Page 5: Dimensions - Induction Range

    Dimensions — Induction Range Width Depth height Built-In Built-In Front Coil Rear Coil Model Width (D) Depth (E) Diameter (F) Diameter (G) IRBR2-6200 440 mm 580 mm 105 mm 369 mm 500 mm 232 mm 232 mm (17-3/8″) (22-7/8″) (4-3/16") (14-9/16") (19-3/4") (9-1/4")

  • Page 6: Installation

    Control panel faceplate outline. (3/8″) (3-1/2″) combustible materials. Installing Built-In Models 185 mm 185 mm IRBR2-6200 models are built-in hobs that require installation (7-1/4″) (7-1/4″) into a countertop before operation. 15 mm NOTE: Make sure that the installation location allows access to (9/16″) the underside of the unit for maintenance and cleaning Figure 7.

  • Page 7: Operation

    • Proper size (measurements given are the manufacturer’s pan size, not the pan bottom diameter) IRBR2-6200 Induction Ranges are dual-coil hobs. The front coil and rear coil on the hobs are capable of operating - Front Coil = Min. 152 mm (6″) to Max. 254 mm (10″) independently as well as together.

  • Page 8: Startup

    NOTE: The setting of the Coil Heat Controls can be changed at any time during operation. Front Coil Rear Coil Heat Control Heat Control ("off" position) Front Coil Rear Coil Indicator Light Indicator Light Figure 10. IRBR2-6200 Control Panel Form No. IRBRCEM-0910...

  • Page 9: Maintenance

    This unit has no “user-serviceable” parts. If service is bottom of the unit. required on this unit, contact an Authorized hatco Service Agent or contact the hatco Service Department at f. Insert the frame screw and tighten securely.

  • Page 10: Troubleshooting Guide

    Check for damage to power cord. Check electrical supply. Controls defective. Contact Authorized Service Agent or Hatco for assistance. A coil indicator light is flashing Pan being used is not induction- Use an induction-ready pan (see “Pan Specifications” in and the unit will not heat.

  • Page 11: Limited Warranty

    Hatco’s written instructions or Without limiting the generality of the foregoing, SUCH 18 months from the date of shipment from Hatco. Buyer must WARRANTIES DO NOT COVER: Coated incandescent light establish the Product’s purchase date by returning Hatco’s...

  • Page 12: Form No. Irbrcem

    AUThORIzED PARTS DISTRIBUTORS United Kingdom Marren Group Northants +44(0)1933 666233 HATCO CORPORATION P.O. Box 340500 Register your unit online! Milwaukee, WI 53234-0500 U.S.A. Telephone (414) 671-6350 See IMPORTANT OWNER INFORMATION International Fax (414) 671-3976 section for details. partsandservice@hatcocorp.com www.hatcocorp.com P/N 07.04.553.00 Form No.
