Page 1 Model RF802EW Wireless Router/Access Point User Guide...
Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.
Page 3: Table Of Contents
Specifications ... 10 Chapter 2 - Hardware Installation Hardware Installation ... 12 Safety ... 12 Unpacking the RF802EW ... 12 Cabling ... 13 Chapter 3 - Software Installation and Configuration Software Installation and Configuration ... 15 Software Installation ... 15 Using RouteFinder Setup Wizard ...
Page 4 RouteFinder Monitor ... 59 Running RouteFinder Monitor ... 59 Refresh Device List ... 59 Test Connection ... 59 Terminate Connection ... 60 Save to File ... 60 Save Now ... 61 Autosave ... 61 IP Address/Name ... 61 Event Messages ... 62 TCP/IP Tab ...
Page 5 Appendix B - Tools for your RF802EW ... 109 RouteFinder Monitor ... 109 PING ... 109 WINIPCFG and IPCONFIG ... 109 TRACERT ... 110 Appendix C - Cabling Diagrams ... 111 Glossary ... 112 Index ... 117...
Page 6: Introduction
Chapter 1 - Introduction...
Page 7 Congratulations on the purchase of the Multi-Tech System’s RouteFinder model RF802EW, one of the finest broadband routers available today. The RouteFinder RF802EW provides wireless users with seamless access to their existing wired LAN, enabling them to share broadband access to the Internet as well as other resources. Using the IEEE 802.11b wireless standard, the RouteFinder provides increased speed--up to 11 Mbps--...
Page 8: Front Panel
Slide the switch to the Uplink position to use the LAN port to expand your network by connecting a network cable to another router, switch, or hub. To connect the port to a LAN client workstation, slide the switch to the Normal position. RF802EW Back Panel Chapter 1 - Introduction...
Page 9: Typical Applications
RF802EW to connect a LAN to the Internet using one shared IP address. Connecting a Remote Site via Cable Modem In the following example the RF802EW is used to connect a LAN to the Internet via DSL or a cable modem. Kernal:...
Page 10: Specifications
Specifications Hardware ARM RISC CPU 32 bit, 40MHZ 4MB DRAM and 512k Flash ROM UART Serial port controller LAN Port Interface: 1 10Base-T/100BaseTX RJ-45 Connection Standard: 802.3 WAN Ports 1 x 10Base-T 1 x RS232 (V.24) DTE Speed: Up to 230K asynchronous Wireless Access Point IEEE 802.11b for wireless LAN...
Page 11: Chapter 2 - Hardware Installation
Chapter 2 - Hardware Installation...
Page 12: Hardware Installation
The RF802EW shipping box contains the following items: • System CD • Tucows CD • Power Supply • The RouteFinder RF802EW • The RF802EW RouteFinder Quick Start Guide If any of the items is missing or damaged, please contact Multi-Tech Systems. Chapter 2 - Hardware Installation...
Page 13: Cabling
DHCP server, after your device is properly cabled, you will need to follow the configuration instructions provided in the Software Installation and Configuration chapter. Cabling the RouteFinder RF802EW 1. Before beginning, turn the power off on all network devices (PCs, Cable, DSL modems, analog modems, ISDN TAs and the router).
Page 14: Chapter 3 - Software Installation And Configuration
Chapter 3 - Software Installation and Configuration...
Page 15: Software Installation And Configuration
RouteFinder Monitor is a multi-purpose utility designed to let you know the status of your RF802EW connection. The monitor offers the ability to point and click on an event to access troubleshooting procedures. Refer to the RouteFinder Monitor chapter in this User Guide for more information.
Page 16: Using Routefinder Setup Wizard
Using RouteFinder Setup Wizard Note: Before beginning this procedure, ensure that your RF802EW is properly connected to the network and that the power is turned on. After installing the software, you may return to the RouteFinder Setup Wizard at any time, by clicking Start | Programs | RouteFinder Manager | RouteFinder Wizard.
Page 17 Record the values presented in the Device Information panel for later reference. Device IP Address ______________________ Device MAC Address ____________________ Device Firmware Version _________________ Click Next. Note: If a message appears indicating the device is not found, or you do not see the device you are attempting to configure listed, click Refresh Device List.
Page 18 Click Next. 9. The Select Function dialog box displays. Select IP Routing (NAT Disabled) to allow the RF802EW to function as a router between IP segments. This option is ideal for organizations needing to segment workgroups. Chapter 3 - Software Installation and Configuration...
Page 19 Select Enable PPPoE to use the RF802EW with a time-base, rather than fixed-cost DSL modem connection. Enter the User Name and Password provided by your ISP. This option is most often used when connecting via DSL to the Internet. Note: Enable PPPoE is valid only when IP Routing (NAT Enabled) is selected.
Page 20: Remote Access
• Select IP Routing (NAT Enabled) to allow all users in the two IP segments (LAN and WAN Ethernet) to share one IP address to the Internet. You may also select this option to use the serial async port for dial backup in the event the DSL or cable modem becomes unavailable. •...
Page 21 • Variable Callback : Select Variable Callback for remote users that travel or dial-in from various locations and need callback security. This option allows clients to specify the callback telephone number each time they connect to the network. Click Add after entering information for each Local Client. Click Next and continue with Step 10 when all users have been added to the database.
Page 22 IP Routing (NAT Enabled) If you select IP Routing for the asynchronous port, the Setup Wizard: IP Routing dialog box displays. Enter the information required to dial-up and login to your ISP’s remote server: Telephone Number Enter the phone number used to dial your remote server (ISP). Note: If you must dial a number to get an outside line (for example, “9”, or “0”), enter the required number plus a “w”(wait) or a comma in the Telephone box (for example, 9w555-2323 or 9,,5552323).
Page 23 Have Disk... to install your modem. Note: This setting configures the initial string of the asynchronous port on the RF802EW so that it will know how to communicate with your modem. If you are using an analog modem and your modem is not included in the selection list, in most cases, Standard Modem will work.
Page 24: Testing Your Connection
Select Connect Port 2 to test the serial async port. The monitor activity will appear in the display window. Refer to the RouteFinder Monitor chapter in this User Guide for additional information about the monitoring capabilities of the RF802EW. 2. After successfully using the Test Connection option in Run Monitor, refer to the LAN Client Settings chapter of this User Guide to continue with your installation by configuring your LAN workstations.
Page 25: Chapter 4 - Telnet
Chapter 4 - Telnet...
Page 26: Using Telnet To Configure Your Routefinder
Note: To successfully configure your router using Telnet, TCP/IP must be correctly configured on your computer. The router and computer must also be located on the same subnet. 1. Start your telnet session and connect to the RouteFinder RF802EW using the router’s default IP address of 192.168.2.1 and vt100 terminal emulation.
Page 27 Router Subnet Mask Enter the subnet mask for your local network. Router Name Enter a network name for the RF802EW. If your ISP requires your device to have a name, you may use the value entered in this field. Router Password The default is no password.
Page 28 Chapter 4 - Telnet Async Port Settings The async port may be used for IP Routing or Remote access . For more information, see the Async Port section of the RouteFinder Manager chapter. IP Routing If you will use the async port for IP Routing, enter the following information as described: Telephone number Enter the phone number the async device must dial to connect to the remote system.
Page 29 Chapter 4 - Telnet Assign Remote IP Select Enable or Disable. If you select Enable, you will be prompted to enter an address to be assigned to the remote system. Remote Access To configure the async port for Remote Access, enter values for each of the following: Remote Access Port Settings IP Assigned Method Select the method the client will use to have their IP address assigned.
Page 30: Virtual Server
Enter the IP address of your Internet Service Provider’s DNS server. DHCP Server You may select Disable or Enable. If you would like the RF802EW DHCP server function to provide IP information to workstations as they connect to the network, select Enable. When you enable DHCP, you will be prompted to provide the beginning and ending IP addresses in the range of addresses administered by your RouteFinder.
Page 31 Chapter 4 - Telnet Diagnostic The Diagnostic option performs basic testing of the RouteFinder, displays information about your firmware and offers options for assigning the LAN and WAN MAC addresses as may be required by your ISP. Type any key to return to the main menu.
Page 32: Chapter 5 - Routefinder Manager
Chapter 5 - RouteFinder Manager...
Page 33: Routefinder Manager
RouteFinder Manager RouteFinder manager is the main program used to configure all the settings of your RF802EW. 1. To run RouteFinder Manager, double-click the RouteFinder Manager icon on your desktop, or click Start | Programs | RouteFinder Manager | RouteFinder Manager.
Page 34: General Settings
After selecting your device from the Available Devices list, click General Settings to view or change all of the major network settings for the RF802EW including LAN and WAN Ethernet segment settings, DNS information, IP Routing, and Remote Access settings. Most of the settings here were entered in Setup Wizard.
Page 35: Wan Ethernet Segment
1. To configure the RF802EW for IP Routing, select IP Routing in the Async Port section of the General Settings dialog box.
Page 36 3. The IP Routing Settings dialog box displays. IP Routing (NAT Enabled) If NAT is enabled, all local users will be firewall protected and will share one IP address through the Async port. Enter values in the fields as described: Tel Number Enter the phone number required to access your ISP.
Page 37 The remote user calls the RF802EW async port to trigger the connection to the ISP server. c. Remote Callback - After dialing, the RF802EW hangs up and waits for the remote site to callback. You must enter the callback telephone number (the telephone number the device should call) in the Tel Number box.
Page 38 When a remote user dials in to the RF802EW, the user’s access profile information (user name, password, callback status, etc.) is validated by checking the user information in this list. The RF802EW can include up to 64 users in the Local Client list. Click Local Client List to add your remote users.
Page 39 Assign a specific IP address for this user Select this option if you would like to have a specific IP address assigned to this user. Enter the IP address. This IP address will be used each time the client logs in and will override the Assign Remote Site an IP Address option as shown in the IP Router Setting dialog box.
Page 40: Remote Access-Remote Access Settings
If you are connecting to a Netware Server, IPX/SPX must be enabled. IPX/SPX Frame Type The RF802EW can automatically detect what kind of IPX/SPX frame type you are using. You may manually select a frame type by using the list box.
Page 41: Enable Ip Mapping - Virtual Server
Enable IP Mapping - Virtual Server IP Mapping is available only when NAT is enabled. If NAT is enabled for a particular port, that port is firewall protected. The Enable IP Mapping function allows you to open a “hole” in your firewall to allow access to your LAN via the Internet.
Page 42: Port Settings
Port Settings The Modem Settings options are used to configure the communication between your modem or ISDN TA and your RouteFinder serial port. You must specify the baudrate, modem and modem string settings for your device. 1. To view or change the port settings, from the main Manager dialog box, click Port Settings. The Port Settings dialog box displays.
Page 43: Edit Login Script For Remote Access
Edit Login Script for Remote Access 1. From the Port Settings, click Edit Login Script. 2. The login Script dialog box displays. A sample remote access login script is shown below. If a remote access client is configured to “bring up a terminal window after dialing”, this remote access login script initiates. For Remote Access, the device will act as the server side...
Page 44 login script. Wait ‘CONNECT’ The Modem will wait for CONNECT to display before moving to the next command. Wait ‘CONNECT 6’ Modem will wait for “CONNECT” to display before moving to the next command. If CONNECT does not display, the modem will go to line 6 of the login script.
Page 45: Modem String Settings
Hangup Send ‘AT S0=1’ Send ‘ATDT 8885678’ Dials phone number 888-5678 (ISP #2) Wait ‘Connect’ 23 Wait ‘username:’ 23 Send ‘Stephen’ Wait ‘password:’ SH ‘5678’ Wait‘====>‘ Send‘1‘ Hangup Jump 2 Modem String Settings The most important modem string is the initialization string because your network device uses it to establish communications with your modem or ISDN TA.
Page 46: Lan Dhcp Server
Individual Port Options Individual Port Options lets you set the idle-timeout function for each serial port of the RouteFinder. You can set the number of minutes you wish to allow a connection to stay idle before disconnection. Note: Default idle timeout for IP Routing is 5 minutes. Default idle timeout for Remote Access is 30 minutes.
Page 47 Chapter 5 - RouteFinder Manager IP Address Pool The IP Address Pool contains the range of IP addresses that will be automatically assigned to the clients of your network as they connect to the network. Note: By default, the IP address pool range is from 100 to 200. Ranges are listed in the IP Address Pool table.
Page 48: Routing Settings
Routing Settings Routing is the process of moving a packet of data from source to destination. The RF802EW acts as a router to enable messages to pass from one computer to another and eventually reach the target machine. Part of this process involves analyzing a routing table to determine the best path. Use the information below to create a routing table to connect your network to another network, or to connect subnets within your network.
Page 49: Routing Table
Routing Table The routing table stores the routing information so that the RF802EW knows how to route the IP packets to the proper network. What is the purpose of the routing table? In the diagram above, the RF802EW-1 has the routing information to route between 192.168.3.x and 192.168.5.x.
Page 50: Filter Settings
Filter Settings can be used to filter network services such as Mail, WWW, FTP, Telnet and News. 1. From the main Manager dialog box, select your RF802EW, then Filter Settings. 2. The Filter Settings dialog box displays.
Page 51 To remove a defined packet, select the packet you’d like to delete from the table and click Delete. Packets defined by User If you choose to define by User, you must define the byte pattern of the packets. The RF802EW uses the defined byte patterns to block or pass packets from the WAN or from the LAN.
Page 52 The filter works by filtering TCP/IP port numbers. The 5 most commonly used port numbers are listed for you. They include the port numbers for Mail, WWW, FTP, Telnet and News. If you would like to filter other services, you must know the port number for the service. 4.
Page 53: Wireless Settings
Chapter 5 - RouteFinder Manager Wireless Settings Click Wireless Settings in the RouteFinder Manager menu to open the Wireless Settings dialog box. You can enter the ESSID and Channel number for your wireless router. All wireless workstations must use the same ESSID. You may need to try different channels to avoid interference.
Page 54: Refresh Device List
If the device still does not appear, ensure that all cables are correctly connected and that the power to the RF802EW is turned on. If the device still does not appear in the list, refer to the Troubleshooing chapter of this User Guide.
Page 55: Save Settings To File
Note: Entering a password is strongly recommended to protect your RouteFinder from unauthorized reconfiguration. If you enter a password, ensure you have selected something that will be easy to remember or write it down and store it in a safe location. If you have completely forgotten your password, contact Multi-Tech Technical Support for assistance.
Page 56: Upgrade Firmware
6. Click OK to load and apply the settings to the RouteFinder. Upgrade Firmware Warning: Upgrade the firmware of your RouteFinder RF802EW only under the advice and direction of the Multi-Tech Technical Support Group. Improperly upgrading the RF802EW may disable the device! The Upgrade Firmware options allow you to upgrade your RF802EW firmware.
Page 57: General Diagnostic
The General Diagnostic option displays network device information and allows you to determine if the RF802EW is functioning properly. 1. From the main Manager dialog box, click General Diagnostic. 2. The General Diagnostic dialog box displays information about the RF802EW. 3. Record the information if necessary and click OK to exit.
Page 58: Routefinder Monitor
Chapter 6 - RouteFinder Monitor...
Page 59: Running Routefinder Monitor
RouteFinder Monitor RouteFinder Monitor is a utility that provides both monitoring and troubleshooting functions. Running RouteFinder Monitor 1. Click on the RouteFinder Monitor icon, or select Start | Programs | RouteFinder Manager | RouteFinder Monitor. 2. The RouteFinder Monitor dialog box displays. Note: If you receive a message stating “Device is not found”, refer to the Troubleshooting chapter in this User Guide.
Page 60: Terminate Connection
6. Click Exit to close the Test Connection dialog box. Terminate Connection The Terminate Connection option is designed to allow the Network Administrator to terminate an RF802EW connection instantly. 1. From the main RouteFinder Monitor dialog box, select Terminate Connection. 2. The Terminate Connection dialog box displays.
Page 61: Save Now
Each computer listed must have a fixed IP address for your network. You may configure a fixed IP address on the individual computer or use the RF802EW’s DHCP server IP reservation system. Refer to the LAN DHCP section of RouteFinder Manager chapter of this User Guide.
Page 62: Event Messages
3. Enter each computer’s IP Address and associated User Name in the provided fields. 4. Click Add after each IP address and name have been added to the list. 5. When all addresses have been added, click OK. Event Messages Event Messages are displayed in the lower half of the RouteFinder Monitor display.
Page 63: Time Tab
1. From the main RouteFinder Monitor dialog box, click the Time tab. 2. The Time tab displays information for each port. Device Power Turned On Displays the time and date that your RF802EW was powered on. Power-On-Time Displays the total time that has elapsed since your RouteFinder was started.
Page 64: Status Tab
Status Tab The Status tab provides information about the status of the WAN Ethernet and Async ports. 1. From the RouteFinder Monitor dialog box, click the Status tab. 2. The Status tab information displays: WAN Ethernet This indicator light shows that either the IP Routing or the Remote Access function is in use. Async Port Modem Power The indicator light is lit when the modem power is turned on.
Page 65: Statistics Tab
Statistics Tab The Statistics tab indicates, by port, how many bytes of data have come in and out through the RouteFinder.. 1. From the RouteFinder Monitor dialog box, click the Statistics tab. 2. The Statistics tab dialog box displays. 3. You may view the following information: IP Address The IP address of the network device.
Page 66: Chapter 7 - Lan Client Settings
Chapter 7 - LAN Client Settings...
Page 67: Lan Client Settings
Computers on your local LAN as well as computers dialing in to your network may use dynamic or static IP addresses. Dynamic IP addresses may be automatically assigned by the DHCP function of the RF802EW or another DHCP server. Static IP addresses can either be reserved from the DHCP server or manually configured on the individual workstation.
Page 68 Chapter 7 - LAN Client Settings Adding the dial-up adapter (NT Server Connection): Windows 95/98: 1. Click Start | Settings | Control Panel. 2. Double-click the Network icon to open the Network dialog box. Win95 Win98 3. Click Add. The Select Network Component Type dialog box opens. 4.
Page 69 5. In the Manufacturers list, select Microsoft. In the Network Adapter s list select Dial-up adapter. 6. Click OK (twice) to return to, and then close, the Network dialog box. Windows NT: Dial-up Networking adds PPP and SLIP protocol support, enabling your workstation to gain access to a remote computer or network, even if your computer is not on a network.
Page 70 Adding Client for Microsoft Networks (NT Server Connection): Windows 95/98: 1. In the Network dialog box, Configuration tab, click Add. 2. Select Network Client and click Add. 3. The Select Network Client dialog box displays. In the Manufacturer’s list, select Microsoft. In the Network Clients list, select Client for Microsoft Networks.
Page 71 Set Your Primary Network Logon (NT Server Connection): Windows 95/98: In the Primary Network Logon list on the Configuration tab of the Network dialog box, select (the previously installed) Client for Microsoft Networks. Click OK to close the Network dialog box. Set up Properties of Components (NT Server Connection): Dial-up Adapter Windows 95/98:...
Page 72 Network Client Windows 95/98: In the Network dialog box, Configuration tab, select Client for Microsoft Networks. Click Properties. The Client for Microsoft Networks Properties dialog box opens. On the General tab, select the Log on to Windows NT domain check box . 4.
Page 73 Access Windows 95/98: 1. In the Network dialog box, click the Access Control tab. 2. Select Share-Level access control. Click OK twice to return to, and then close, the Network dialog box. Note: You must restart your system for the new settings to take effect. Once your machine has restarted, you may continue the configuration process.
Page 74: Accessing A Novell Server
Note: If your particular situation permits, select the Save password check box. 4. Click Connect. 5. After connecting to the RF802EW, you can access the same services and resources as if you were connected to the network locally. Accessing a Novell Server Novell NetWare products are used on up to 70 percent of PC-based local area networks (LANs).
Page 75 3. Click Add. The Select Network Component Type dialog box opens. 4. Select Adapter, then click Add. The Select Network adapters dialog box opens. 5. In the Manufacturers list, select Microsoft. In the Network Adapters list select Dial-up adapter. 6. Click OK twice to return to, and then close, the Network dialog box. Windows NT: Dial-up Networking adds PPP and SLIP protocol support, enabling your workstation to gain access to a remote computer or network, even if your computer is not on a network.
Page 76 Adding IPX/SPX (Novell Server Connection): Windows 95/98: 1. In the Network dialog box, Configuration tab, click Add. The Select Network Component Type dialog box opens. 2. Select Protocol and click Add. The Select Network Protocol dialog box opens. 3. In the Manufacturers list, select Microsoft. In the Network Protocols list, select IPX/SPX- compatible Protocol.
Page 77 Adding Client for NetWare Networks (Novell Server Connection): Windows 95/98: 1. In the Network dialog box, Configuration tab, click Add. 2. Select Network Client and click Add. 3. The Select Network Client dialog box displays. In the Manufacturer’s list, select Microsoft. In the Network Clients list, select Client for NetWare Networks.
Page 78 7. Click Properties. 8. On the General tab, in the Preferred server box, enter the name of your Novell Server Domain. If necessary, select the First Network Drive, then verify that the Enable logon script processing check box is selected. (It’s the default.) 9.
Page 79 Note: If your particular situation permits, select the Save password check box. 4. Click Connect. 5. After connecting to the RF802EW, you can access the same services and resources as if you were connected to the network locally. Chapter 7 - LAN Client Settings...
Page 80: Accessing A Windows Nt Server And A Novell Netware Server
Chapter 7 - LAN Client Settings Accessing a Windows NT Server and a Novell NetWare Server Note: Before configuring your remote site, ensure TCP/IP has been installed on your NT Server. Perform the following procedures if your PC workstation needs to access both a Windows NT Server and a Novel NetWare Server.
Page 81 4. Select Adapter, then click Add. The Select Network adapters dialog box opens. Win95/98 5. (Win95/98 only) In the Manufacturers list, select Microsoft. In the Network Adapters list select Dial-up adapter. Note: In Windows NT workstation there is no Manufacturers list. 6.
Page 82 Adding Client for Microsoft Networks (Novell/NT Server Connection): Windows 95/98: 1. In the Network dialog box, Configuration tab, click Add. 2. Select Network Client and click Add. 3. The Select Network Client dialog box displays. In the Manufacturer’s list, select Microsoft. In the Network Clients list, select Client for Microsoft Networks.
Page 83 Adding IPX/SPX (Novell/NT Server Connection) Windows 95/98: 1. In the Network dialog box, Configuration tab, click Add. The Select Network Component Type dialog box opens. 2. Select Protocol and click Add. The Select Network Protocol dialog box opens. 3. In the Manufacturers list, select Microsoft. In the Network Protocols list, select IPX/SPX- compatible Protocol.
Page 84 Adding Client for NetWare Networks (Novell/NT Server Connection) Windows 95/98: 1. In the Network dialog box, Configuration tab, click Add. 2. Select Network Client and click Add. 3. The Select Network Client dialog box displays. In the Manufacturer’s list, select Microsoft. In the Network Clients list, select Client for NetWare Networks.
Page 85 Chapter 7 - LAN Client Settings Set Up Properties of Components (Novell/NT Server Connection): Dial-up Adapter Windows 95/98 1. In the Network dialog box, Configuration tab, select the TCP/IP - Dial-up adapter. 2. Click Properties. The TCP/IP Properties dialog box opens with the IP Address tab selected. 3.
Page 86 7. Click Properties. 8. On the General tab, in the Preferred server box, enter the name of your Novell Server Domain. Select the First Network Drive and Enable Logon Script processing. 9. Click OK. Network Protocol Windows 95/98: 1. In the Network dialog box, Configuration tab, select IPX/SPX Compatible Protocol. 2.
Page 87 Chapter 7 - LAN Client Settings 3. Enter a name and description for your computer. 4. Click OK. Set Your Access Control: Windows 95/98: 1. In the Network dialog box, select the Access Control tab. 2. Select the Share-Level access control option. 3.
Page 88: Accessing A Unix Server
Note: If your particular situation permits, select the Save password check box. 4. Click Connect. 5. After connecting to the RF802EW, you can access the same services and resources as if you were connected to the network locally. Accessing a Unix Server Perform the following procedures to prepare your PC workstation to access a remote Unix Server.
Page 89 3. Click Add. The Select Network Component Type dialog box opens. 4. Select Adapter, then click Add. The Select Network adapters dialog box opens. 5. In the Manufacturers list, select Microsoft. In the Network Adapters list, select Dial-up adapter. 6. Click OK twice to return to, and then close, the Network dialog box. Windows NT: Dial-up Networking adds PPP and SLIP protocol support, enabling your workstation to gain access to a remote computer or network, even if your computer is not on a network.
Page 90 Adding TCP/IP (Unix Server Connection) Windows 95/98/NT: 1. In the Network dialog box, Configuration tab, click Add. 2. Select Protocol and click Add. 3. The Select Network Protocol dialog box is displayed. In the Manufacturers list [Win95 only], select Microsoft. In the Network Protocols list, select TCP/IP [Win95/98] or TCP/IP Protocol [WinNT only].
Page 91 Note: If your particular situation permits, select the Save password check box. 4. Click Connect. 5. After connecting to the RF802EW, you can access the same services and resources as if you were connected to the network locally. Chapter 7 - LAN Client Settings...
Page 92: Make New Connection (Windows 2000 Only)
Chapter 7 - LAN Client Settings Make New Connection (Windows 2000 only) Perform the following procedures to prepare your Windows 2000 PC workstation to access any of the remote Servers and enable applications such as e-mail, Web browsing, file sharing, and printing. 1.
Page 93: Chapter 8 Lan-To-Lan Settings
Chapter 8 LAN-to-LAN Settings...
Page 94: Lan-To-Lan Settings
LAN-to-LAN Settings Setting up LAN-to-LAN Routing The majority of settings for LAN-to-LAN Routing are set up through RouteFinder Wizard or RouteFinder Manager when IP routing (NAT disabled) is configured. This section provides an overview of LAN -to- LAN Routing and shows you some of the benefits and limitations of LAN-to- LAN Routing.
Page 95: Using Lmhosts
Chapter 7 - LAN Client Settings Note: If the computer you are attempting to access is on a remote LAN, you may need to press Find Now more than once while you wait for your network device to establish a dial-up connection to your remote LAN.
Page 96: Chapter 9 - Troubleshooting
Chapter 9 - Troubleshooting...
Page 97: And Technical Support
ISP. • Remove the TCP/IP dial-up adapter from all computers that will be using your RouteFinder to access the Internet. TCP/IP dial-up adapter is not needed to use the RF802EW to connect to the Internet.
Page 98 The most common reason for this is not due to a problem or error. If you are the first person to make a connection to the Internet through the RF802EW, there will be a delay when the Dial-On- Demand function automatically makes the connection and logs on to your ISP. Subsequent users will be able to use the connection you’ve established without a delay.
Page 99 Internet. • The RF802EW will only dial the connection if there is a request from one of the computers on the LAN for an IP address on the Internet. Keep in mind that certain applications can be configured to request information from the Internet.
Page 100: Chapter 10 - Service, Warranty And Technical Support
Chapter 10 - Service, Warranty and Technical Support...
Page 101: Introduction
RouteFinder. Limited Warranty Multi-Tech Systems, Inc., (hereafter “MTS”) warrants that the RouteFinder will be free from defects in material or workmanship for a period of two years from date of purchase, or if proof of purchase is not provided, two years from date of shipment.
Page 102: Addendum For International Products
Chapter 10 - Service, Warranty and Technical Support abuse, or user-caused damages are billed on a time-plus-materials basis. Addendum for International Products Distributors should contact Amex, Inc., for information about the repairs for your Multi-Tech product. Amex, Inc. 2724 Summer Street NE Minneapolis, MN 55413 U.S.A.
Page 103: Software User License Agreement
MULTI-TECH SOFTWARE LICENSE AGREEMENT Multi-Tech Systems, Inc. (MTS) agrees to grant and Customer agrees to accept on the following terms and conditions, a non-transferable and non-exclusive license to use the software program(s)
Page 104 Chapter 10 - Service, Warranty and Technical Support...
Page 105: Technical Support
Technical Support Multi-Tech provides free technical support for as long as your product remains in service. Before calling Technical Support, please read through the Troubleshooting chapter of this User Guide. Also, ensure you have completed the Recording RouteFinder Information section below. To contact our Technical Support group, use one of the following contact options, keeping in mind that phone calls are handled with first priority: Contacting Technical Support...
Page 106: About The Internet
About the Internet Multi-Tech System’s is a commercial provider on the Internet. The Multi-Tech web site is located at The Multi-Tech FTP site is located at Ordering Accessories SupplyNet, Inc. can provide you with replacement transformers, cables and connectors for select Multi-Tech products.
Page 107: Appendixes
Appendixes...
Page 108: Appendix A - Regulatory Compliance Information
Appendix A - Regulatory Compliance Information Class B Statement FCC Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 109: Appendix B - Tools For Your Rf802Ew
WINIPCFG (for Windows 95/98) 1. Select Start | Run and type winipcfg. 2. The IP address, default gateway (the RF802EW IP address), and the MAC (adapter address) display. IPCONFIG (for Window NT/2000) 1. From a DOS Prompt, type IPCONFIG and press Enter.
Page 110: Tracert
Appendixes TRACERT TRACERT is an extensive PING utility that allows you to trace the route of an IP address. The utility reports the number of router hops, the time for each hop, and any failed attempts to cross a hop. The information provided by this utility assists you to locate the specific site of a failed PING.
Page 111: Appendix C - Cabling Diagrams
Appendix C - Cabling Diagrams WAN/LAN Cables Serial Cable Circuit Signal Name TD+ Data Transmit Positive TD- Data Transmit Negative RD+ Data Receive Positive RD- Data Receive Negative Appendixes...
Page 112: Glossary
Glossary...
Page 113 Glossary The following is a glossary of terms used in this manual: Baudrate Baudrate refers to the number of bits per second (Bps) that are transmitted between your network device and modem or ISDN TA. DHCP (Dynamic Host Configuration Protocol) A protocol that was made to lessen the administrative burden of having to manually configure TCP/IP Hosts on a network.
Page 114 A static IP address is a permanent IP address that is set up on each individual computer. When your RouteFinder dials-up your ISP, your ISP can give it a fixed or dynamic IP address. Likewise when you power on your computer, the RF802EW can give your computer a dynamic or fixed IP address.
Page 115 Glossary that requested it. If someone on the Internet tries to access your network, the firewall function of the RouteFinder stops the request. The device will not reverse translate network addresses unless you have specifically allowed this feature using the Virtual Server function (IP Mapping). NetworkAddress The network portion of an IP address.
Page 116 Glossary TCP/IP (Transmission Control Protocol/Internet Protocol) A suite of communication protocols used to connect hosts on the Internet. Every computer that wants to communicate with another computer on the Internet must use the TCP/IP protocol to transmit and route data packets. The format of an IP address is a 32-bit numeric address written as four octets separated by periods.
Page 117: Index
Index Adding TCP/IP ... 69, 90 Async Port ... 35 Authentication ... 38 Available Devices ... 33 Back Panel ... 8 Baudrate ... 42 Cabling ... 13 Callback Settings ... 37 Callback Type ... 38 Configuration ... 15 Connection ... 10 Device IP Address ...
Page 118 Index Rx ... 65 Safety ... 12 Save Settings to File ... 55 Save to File ... 60 SMTP ... 41 Software Installation ... 15 Software User License Agreement ... 103 Statistics Tab ... 65 Status Tab ... 64 TCP/IP ... 81 TCP/IP Tab ...
