Summary of Contents for AngelTrax CATV2400

  • Page 1 Patent Pending...

  • Page 2: Safety Terms And Symbols

    Safety Terms and Symbols: Warning statements identify conditions WARNING: or practices that could result in injury or loss of life. To reduce the possibility of Electrical Shock, do not remove the cover to any component in this package. There are no user-serviceable parts CAUTION: Caution statements identify conditions inside the components.

  • Page 3: Important Safety Instructions

    Important Safety Instructions: 8. Any mounting of the product should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. 1. All of the safety, set-up and operating instructions should be 9. This product should be operated only from the type of power read before the product is operated.
  • Page 4 13. Do not overload wall outlets with extension cords or integral 15. When replacement parts are required, be sure the service convenience receptacles as this can result in a risk of fire or elec- technician has used replacement parts specified by the manufac- tric shock.

  • Page 5: Specifications

    Specifications: Receiver Transmitter Frequency: 2400MHz~2483MHz Frequency: 2400MHz~2483MHz Sensitivity: -90dBm Sender Power: 10dBm Channels: 4 - 2414,2432,2450,2468MHz Channels: 4 - 2414,2432,2450,2468MHz L.O. Stability: +100KHz Frequency Stability: +100KHz Video Input Level: 1 Vp-p Video Input Level: 1 Vp-p Audio Input Level: 1 Vp-p Audio Input Level: 1 Vp-p Supply Voltage:...
  • Page 6 TV viewing experience. Whether you need a TV in your kitchen, garage, back porch or a room without a cable connection, the AngelTrax wire- less cable TV systems will provide you with years of wireless cable TV enjoyment.

  • Page 7: Start Here

    Start Here Setting up the Transmitter Unpack your equipment and locate your Power Adapters, the Transmitter and your RF cables. Rear view of transmitter Power Adapter Front view of transmitter...
  • Page 8 Place your transmitter to the closest cable drop to the remote TV. (NOTE: If you plan to also connect your Digital Cable Box, you must locate the transmitter close to your Digital Box.) See Page 8 for advanced set-up. 2. Connect the 12V For Digital Box Connection.
  • Page 9 Setting up the Receiver 3. Turn on the Transmitter by pressing Unpack your equipment and locate your the power button at the bottom of the Receiver, Power Adapter and Cables. transmitter. Rear view of Receiver Your Transmitter Front view of Receiver Ready...
  • Page 10 Place your receiver close to the remote TV. We have supplied 2 options for connections to your remote TV; Through the Antenna Connection or through the Composite video Input. Choose one: DO NOT USE BOTH! 1. Connect one of the 2.

  • Page 11: Operation

    Your with your TV. Receiver 2. Install the batteries into the AngelTrax remote control. 3. Point the remote at the Receiver and push the RF button on the remote to allow the Transmitter and Ready Receiver to synchronize.
  • Page 12 4. After pressing the RF button on the remote to select the cleanest channel, press SCAN on the AngelTrax remote. The system will now scan all of the available channels. After scanning is complete, you are ready to watch TV using your AngelTrax wireless cable TV system. CATV2400 Receiver...
  • Page 13 Power (Receiver only) Scan (Scans Available TV Channels) TV/AV (Switch to Digital Box if Connected) Fine Tune (Fine Tune TV Channels) Menu (On Screen Menu) Display (Displays TV Channel and Mode) (Select RF Channel) JUMP (Previous TV Channel) CH UP (TV Channel Up) Vol Down Mute...
  • Page 14 Locate the opposite end of the cable in front of the IR receptor of your digital box. 3. Select the TV/AV button on your AngelTrax remote control. This will switch the coaxial input to the RCA input. You are now seeing the digital channel.
  • Page 15 Advanced Set-Up Illustration Connect IR Remote Extender Cable (CATV2400PLUS Only) Digital Cable TV Box RCA Cable Connection...
  • Page 16 Multiple System Set-Up (Advanced Set-Up) The CATV2400 and CATV2400PLUS Wireless Cable TV Systems are designed to be used in applications where more than one system is needed. There are two different applications and a solution for each. 1. If you have two or more locations where a wireless TV solution is needed and those locations are not used simultaneously, then all you need is one complete system and multiple receivers.
  • Page 17 Turning Synchronization OFF 1. Select MENU on the remote 2. Use the CH Down button to move down to the Synchronization area. 3. Use the small arrow buttons under the Ch Down button to move the selection. 4. When finished, select OK on the remote.
  • Page 18 Transmitter IR remote Extender Connector TV/AV Selector Button TV/AV Indicator Light (When Lit, you are in “TV” mode) Composite Input (Digital Box) RF Channel Indicator Light RF Channel Selector Button Cable Output Cable Input Power Button Power Input...
  • Page 19 Receiver TV/AV Selector Button TV/AV Indicator Light Composite Output to TV RF Channel Indicator Lights IR Remote Sensor RF Channel Selector Button TV Channel Up Cable Out to TV (CH3) TV Channel Down TV Volume Up Power Input TV Volume Down Power Button...
  • Page 20 2. When the product is installed by or purchased from an unauthorized AngelTrax dealer, IVS, Inc. will either repair or replace at no charge to the original purchaser any unit which IVS, Inc.
