U.S. Security Solutions RVH9000Z User Manual

High definition hybrid h.264
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
v1.0
l
RVH9000Z/9000ZD
US916Z/US916ZD
High Definition Hybrid H.264
DVR
This document contains preliminary information and subject to change without notice.
2010.12.29 User Manual v1.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RVH9000Z and is the answer not in the manual?

Questions and answers

Related Manuals for U.S. Security Solutions RVH9000Z

Summary of Contents for U.S. Security Solutions RVH9000Z

  • Page 1 User Manual v1.0 RVH9000Z/9000ZD US916Z/US916ZD High Definition Hybrid H.264 This document contains preliminary information and subject to change without notice. 2010.12.29 User Manual v1.0...
  • Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. NOTE: This equipment has been tested and found to comply with the limits for a class digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS CHAPTER 1 LIVE, PLAYBACK AND PTZ OPERATIONS ________________________________________ 4 1-1 LIVE M ______________________________________________________________________ 4 1-2 PLAYBACK M _________________________________________________________________ 6 1-3 PTZ M ______________________________________________________________________ 8 CHAPTER 2 MAIN MENU SETUP ______________________________________________________ 10 2-1 RECORD SETUP _________________________________________________________________ 11 2-1.1 Quality & Frame Rate Setup ___________________________________________________ 12 2-2 EVENT SETUP __________________________________________________________________ 13 2-2.1 MOTION SETUP _____________________________________________________________ 14 2-2.2 SENSOR SETUP _____________________________________________________________ 16...

  • Page 4: Chapter 1 Live, Playback And Ptz Operations

    CHAPTER 1 LIVE, PLAYBACK AND PTZ OPERATIONS 1-1 LIVE Mode You can monitor all the channels, listen to audio signal and have some related operations under LIVE mode. This paragraph describes the IR remote control, mouse operation and on screen graphical icons under LIVE mode.
  • Page 5 Search menu. Backup menu. PTZ mode. Turn on/off recording. Playback. Resting the cursor on this icon will bring up the following five display icons. FREEZE. PIP，picture in picture display. ZOOM, double the screen size AUTO-sequence LOCK, activate the key lock. Full screen display.

  • Page 6: Playback Mode

    The channel sensor alarm has been triggered (depends on model). Video loss detected on the channel USB device is detected Burner is detected. Connected to the LAN cable. AUTO-seq is on Freeze is on, screen is frozen LOCK is on PTZ control is on Shows the current hard disk space has been used (99% mean used 99%, remain 1%)
  • Page 7 Table 1-2.1 Remote control functions under the PLAYBACK mode Button Description ENTER / MODE Switch to full screen or multi split display. MENU / Turn on/off PAUSE. PLAY Play back at normal speed. / SLOW Play back at slower speed. The speed will be slowed to 1/2, 1/4, 1/8, by each pressing of the button till the slowest limitation of the normal speed.

  • Page 8: Ptz Mode

    「 」 Fast rewind 「 」Fast forward Play/pause ／ 「▲ ▲ ▲ ▲ / SLOW」 ，slow playback 「▼ ▼ ▼ ▼ / ■」stop playback Playback channel by channel with snap shot display Full screen display Quad display 9 screen display 9 screen display 9 screen display 5 channel display...
  • Page 9 Table 1-3.2 Mouse operation under the PTZ mode Icon Description Leave PTZ Mode，back to the LIVE mode Pre-set number N. (0~255) Go to pre-set number N. Set current PTZ location at pre-set number N. 「TOUR」 ，press to activate pre-set tour＊ 「PIP」...

  • Page 10: Chapter 2 Main Menu Setup

    CHAPTER 2 MAIN MENU SETUP To enter the main menu and set up DVR, log-in account and user password are required. The default password of the administrator is “123456”. Please check the “Account Setup” for related setup of other log-in users. Table 4-0.1 Some definition of virtual keyboard.

  • Page 11: Record Setup

    Table 2-0.2 The operation of remote control under the setting menu Item Description Switch to different options under one item Switch to different items MENU Save setup and back to LIVE mode Back to Upper level of menu without saving ENTER Enter the menu, or display virtual keyboard PS.

  • Page 12: 2-1.1 Quality & Frame Rate Setup

    OSD position setup Set up OSD axis Setup the video preservation period. Recorded video will be Video Preservation deleted automatically after expiry of preservation period. Quality & Frame Rate Setup the quality and frame rate for each channel under normal Setup recording and event recording type.

  • Page 13: Event Setup

    2-2 EVENT SETUP Item Description Motion Setup Enter to set up motion detection Motion Setup Enter to set up sensor detection 2010.12.29 User Manual v1.0...

  • Page 14: 2-2.1 Motion Setup

    2-2.1 MOTION SETUP Item Description Alarm Duration(Seconds) When is motion detect, the number of seconds continuous alarm Check the box to Enable/Disable popup screen function for all Motion Popup channels. When Sensor is detected in LIVE mode, the detected channel image will pop up in full screen display. You can setup independently for each channel.
  • Page 15 Item Description Mask Mouse Selection Switch between “select” and “deselect” for cursor-dragging function All Area Detection Select entire screen as detection area. Mask All Area Deselect entire detection area. Continue Continue setup Exit & Save Save setup and leave Exit & Discard Cancel setup and leave 2010.12.29 User Manual v1.0...

  • Page 16: 2-2.2 Sensor Setup

    2-2.2 SENSOR SETUP Item Description Alarm When motion is detect, the number of seconds continuous alarm Duration(Seconds) Sensor Popup Check the box to Enable/Disable popup screen function for all channels. When Sensor is detected in LIVE mode, the detected channel image will pop up in full screen display. All Off Set all sensor off All Low...

  • Page 17: 2-3.1 Schedule Record Setup

    Except from starting recording manually, you can also setup the recording time by weeks and schedule including normal, motion detect, and recording type. Item Description Page Each page provides 10 schedules for setup. 5 pages in total. Holiday Setup Enter to setup holiday, up to 50 days, other than weekends,. View Event/ Motion/...

  • Page 18: Camera Setup

    2-4 CAMERA SETUP Item Description You can setup independently for each channel. Mask Check the box to Enable/Disable mask function for LIVE mode Drag the bar or press ◀ ▶ to adjust Sharpness of your camera from Sharpness value 0 to 15. Drag the bar or press ◀...
  • Page 19 Drag the bar or press ◀ ▶ to adjust Saturation of your camera from Saturation value 0 to 255. The default value is 128. Drag the bar or press ◀ ▶ to adjust Hue of your camera from value 0 to 255.

  • Page 20: Account Setup

    2-5 ACCOUNT SETUP The Account Setup menu is used to provide role-based permission independently setting for each user (maximum of 4 users) to access DVR over network. The default admin account and password is “admin” and “123456” (The default password remains the same after firmware upgrade) Item Description Check to activate the user’s account.

  • Page 21: 2-5.2 User Picture Setup

    2-5.2 User Picture Setup User can select picture wished to be changed to from hard drive. 2010.12.29 User Manual v1.0...

  • Page 22: Networking Setup

    2-6 NETWORKING SETUP Item Description Connect type Setup mode for network connection: (ADSL、 、 、 、 DHCP、 、 、 、 LAN、 、 、 、 3G). HTTP Setup Enter to set up HTTP DDNS Setup Enter to set up DDNS Mail Setup Enter to set up mail 2-6.1 NETWORKING SETUP There are three ways to connect to the network as followed.
  • Page 23 Password Enter password provided by ISP 2-6.1.2 DHCP When DHCP is selected, IP address will be assigned by DHCP server automatically. 2-6.1.3 LAN Select LAN for network connection, the following information is required. Item Description IP Address Enter IP address provided by ISP Subnet Mask Enter IP address of Subnet Mask provided by ISP Gateway...
  • Page 24 2-6.1.4 3G Select 3G for network connection, the following information is required. Item Description Dial-up Number Dial-up Number，Determined as the ISP Enter SIM card password Enter ”internet” Advance Setting The advanced settings (Taiwan ISP outside) Item Description Enable Enable advance setting User Name Enter ISP username Password...

  • Page 25: 2-6.2 Http Setup

    2-6.2 HTTP Setup Item Description Enable HTTP Check to enable HTTP server. Users can remotely access into the Server DVR over the network if the HTTP function is activated. Port Enter a valid port value from 1 up to 65000. The default value is 80. Auto Assign each channel with its maxima accessible fps Chanel number...

  • Page 26: 2-6.4 Mail Setup

    (Including username + Server) If the user name is h.264 and you choose i-dvr as your server, you should enter: h.264.i-dvr.net User Name Enter user name. Password Enter password. ＊ ＊ ＊ ＊ For more detailed I-DVR.NET operation instruction, please refer to appendixⅠ Ⅰ Ⅰ Ⅰ 、 、 、 、 Ⅱ Ⅱ Ⅱ Ⅱ 2-6.4 Mail Setup When event occurs (VLOSS, MOTION), email will be sent to the receiver account automatically.
  • Page 27 User Name Enter to set up User Name. Password Enter to set up Password. Sender E-mail Enter to set up e-mail address of receivers. Enter to select events to send out E-mail notifications when below Trigger Event circumstances happen: Motion, Sensor and Vloss (Video Loss). Receiver E-mail Enter to set up e-mail addresses for up to 10 receivers individually.

  • Page 28: Ptz & Rs485 Setup

    2-7 PTZ & RS485 SETUP The DVR allows users to control PTZ functions of your camera. To enable PTZ function, the 485 cable should be connected to the RS-485 port of DVR. Item Description Enable PTZ Click the box to Enable/Disable PTZ function for each channel. Protocol Set up the protocol of PTZ cam.

  • Page 29: System Setup

    2-8 SYSTEM SETUP Item Description DVR Name The name of DVR will be shown when users login from remote access. Click or press ▼ to select OSD language. Language Remote ID Default ID is 0. DVR is controlled by standard remote control, After one minute without any action, the DVR will switch to LIVE mode automatically.

  • Page 30: 2-8.1 Display Setup

    「○」: the function, 「×」: Enable Disable the function Note 1: When logged out automatically, you will have to operate in limited authority such as operations like: Freeze the screen, Picture in picture, Zoom in/ out, switch between channels…etc. If you need to enter the Setup menu, Search menu, backup menu, Record…etc, user’s account and password are required.

  • Page 31: 2-8.2 Date/Time Setup

    2-8.2 DATE/TIME SETUP Item Description Hour Format 12HOURS/ 24HOURS Date Format MM-DD-YY/DD-MM-YY/YY-MM-DD Date/Time Position Choose the position of Time and Date display Change Date & Time Setup time and date of DVR Time Zone Setup Set up GMT and Daylight Saving Time. Internet Time Setup Setup automatic synchronization with internet server 2010.12.29 User Manual v1.0...
  • Page 32 2-8.2.1 CHANGE DATE & TIME Setup date and time of DVR manually according to user’s local time. 2-8.2.2 TIME ZONE AND DAYLIGHT SAVING TIME SETUP Set up time zone and activate Daylight Saving Time function according to user’s DVR location. Item Description Select Time Zone...

  • Page 33: 2-8.3 Buzzer & Relay Setup

    2-8.2.3 INTERNET TIME SETUP Synchronize your DVR time with internet time server. Item Description Check to enable DVR automatic synchronization function. Automatic Effective by this option selected, DVR will automatically Synchronization synchronize the time upon rebooting or by every 24 hours after booting.

  • Page 34: 2-8.4 Spot Setup

    Item Description Key Tone Enable/Disable keystrokes. Enable/Disable buzzer operation when the alarm is triggered for Buzzer sensor, motion and vloss (Video Loss). Enable/Disable the signal to be sent to the RELAY OUT blocks Relay when the alarm is triggered for sensor, motion and vloss. 2-8.4 SPOT SETUP DVR's Main Monitor output signal, do the main screen output or switch SPOT mode output...

  • Page 35: Utility Setup

    Item Description Channels display in spot for two different modes: SPOT MODE Disable:The screen is same the main screen with VGA output, Enable: Spot Mode The duration time in seconds for the interval between channels under Interval (Seconds) SPOT mode. Skip Video Loss Whether to skip channels without video signal.

  • Page 36: Diagnostic

    completed. Notice! DO NOT TURN OFF POWER OR UNPLUG USB DEVICE DURING THE UPGRADE as it may cause incomplete firmware upgrade and damage to the DVR. 4-10 DIAGNOSTIC Item Description Version The current firmware version of DVR The connected IP address of DVR. If disconnected from network, the screen will display”...

  • Page 37: Chapter 3 Backup & Search

    CHAPTER 3 BACKUP & SEARCH 3-1 BACKUP SETUP User can backup any segment of recorded data in a specified time frame. To do so, either a CD R/W or storage device, like USB, must be connected to the DVR. The format of backup file is IRF file that can be played by both “Ifileplay”...
  • Page 38 iFileplay Use Method Step 1: install 「iFileplay」 software to your PC. You can get 「 iFileplay」 file from the CD with DVR Packing. PS: When you using USB to backup file, iFileplay.exe will copy to USB with the backup file automatically. Step 2：Setup「ifileplaypack.exe」...
  • Page 39 Step 4：Ifileplay software will play the backup file automatically. Step 5：If there is no display on the screen, The backup file is not our DVR recording format. Please check it. 2010.12.29 User Manual v1.0...

  • Page 40: Search Setup

    3-2 SEARCH SETUP Item Description Event Search Event search menu Time Search Enter time search menu 3-2.1 EVENT SEARCH The DVR automatically records events with type, time and channel information included. If there is recording data for an event, a yellow signal will be shown on the left side of time information.
  • Page 41 Item Description Criteria Setup conditions of event search Page Switch between pages of events Date/Time Date/time when event occurred. Event type, defined as following MOTION Motion Detected Video Loss Video Loss Remote Login user log-in over the network Remote Logout user log-out over the network Event Type Power On...

  • Page 42: 3-2.2 Time Search

    3-2.2 TIME SEARCH TIME SEARCH can search for the specific time of recording data to playback. Press “Enter” or left click on the desired date to playback. Note that dates with recording data are marked with a □ □ □ □ red square “...

  • Page 43: Chapter 4 Remote Software Installation And Setup

    CHAPTER 4 Remote Software Installation and Setup 4-1 AP Software Installation and instruction AP software:「DVR Remote Desktop」can allow you to remotely access and control the DVR from PC. p.s. Operation system currently supports Windows XP SP2 and above and Window s Vista, Windows 7 Step One：Enter the IP address of DVR in IE browser Step Two: Windows as below will show up.
  • Page 44 Step Four: Run or Save our AP software. Step Five: If you choose to run the software, Start window will be shown up. Please enter information of login DVR: IP, Port, Username and Password, or choose “Play Recorded File” to open backup files in your PC. Step Six: You’ve logged into the DVR 2010.12.29 User Manual v1.0...

  • Page 45: How To Do Remote Monitoring Through Ie

    4-2 How to do remote monitoring through IE Step One：Enter the IP address of DVR in IE browser. The address appeared in this image is only for demonstration. Actual address is depending on the setup of on-site DVR. Step Two: Windows as below will show up. Please enter the user name and password. Default user name and password is admin/123456.
  • Page 46 Step Three: Click on “Internet Explorer 6, 7, and 8”to start downloading the AP software. ( The first option is for IE view, please refer to next chapter for more information) p.s. There will be IE connection security issue when clicking this link for the first time. Please refer to index II for Remote Monitoring IE ActiveX Control Installation Instruction.

  • Page 47: How To Do Remote Monitoring Through Jpeg Viewer (O Nly Monitor Function )

    4-3 How to do remote monitoring through JPEG VIEWER (Only Monitor Function) Step One：Enter the IP address of DVR in IE browser. The address appeared in this image is only for demonstration. Actual address is depending on the setup of on-site DVR. Step Two: Windows as below will show up.

  • Page 48: Ap Software Operation

    PS : Only for viewer, without any operation function. 4-4 AP Software Operation Open the file “DVRemoteDesktop.exe”; enter the information of DVR “IP address”, “Port” “Username” and “Password” and click “OK”. You should be able to login DVR successfully and start to use the software.

  • Page 49: Chapter 5 Specificaitons

    Or visit: http://en.wikipedia.org/wiki/Intel_GMA CHAPTER 5 SPECIFICAITONS 1. VIDEO Input Level 1.0 Vp-p±10% Composite, 75Ω Balanced NTSC HD 30FPS, D1 240fps Display Speed HD 30FPS, D1 200fps NTSC 1280x720,704(H) X 480(V) Display Resolution 1280x720,704(H) X 576(V) 1VGA(1280x1024)+1BNC(704x480 704x576) Monitor Output Co-monitor 2.
  • Page 50 Ethernet 1 RJ45 connector, 10/100 Mbps 6. ELECTRICAL Power Source DC 12V / 5A (4CH/8CH), DV 12V / 6A (16CH) 7. ENVIRONMENTAL Operation Temperature 5℃ ~ + 40℃ Humidity Less than 90% 8. PHYSICAL Dimension 430(W) x 293(D) x 55(H) mm Weight 1.85kg ( without HDD) 9.

  • Page 51: Chapter 6 Mobile Application Installation And Usage

    CHAPTER 6 MOBILE APPLICATION INSTALLATION AND USAGE You can remotely monitor all channels of DVR through your mobile device. The required mobile application is from DVR manufacturer and it supports mobile OS for 1. Windows mobile 5.0 above. 2. Symbian. 3.

  • Page 52: Chapter 7 Cms Installation And Usage Guide

    CHAPTER 7 CMS INSTALLATION AND USAGE GUIDE 9-1 CMS Installation System Requirement: ＊ Intel Pentium 4 processor or equivalent. ＊ Microsoft Windows Vista、Windows XP、Windows 2003 Server. ＊ Besides OS and other required APs, there will be 512MB remaining memory needed or above. ＊...
