  • Page 1 Renault MEGANE Driver’s handbook...
  • Page 2 Renault cars. Lasting protection and optimum performance for your engine – guaranteed. Whether changing the oil or simply topping up, to find the approved ELF lubricant best suited to your vehicle, ask your Renault dealer for a recommendation or consult your vehi- cle maintenance handbook.

  • Page 3: Driving

    This handbook may also contain information about items of equipment to be introduced later in the model year. Throughout the manual, the “approved Dealer” is your RENAULT Dealer. Enjoy driving your new vehicle.

  • Page 5: Table Of Contents

    Sections Getting to know your vehicle ....... Driving ..............Your comfort ............Maintenance ............Practical advice ............ Technical specifications ........Alphabetical index ..........
  • Page 7 The RENAULT card: general information and use ........
  • Page 8 KEY, RADIO FREQUENCY REMOTE CONTROL: general information (1/2) 1 Locks all the opening elements. 2 Unlocks all the opening elements. 3 Ignition and front door key. 5 Locking/unlocking of the boot only. Remote control with switchblade key: Driver’s responsibility 4 Locking/unlocking using the switch- when parking or stopping blade key.
  • Page 9 KEY, RADIO FREQUENCY REMOTE CONTROL: general information (2/2) Radio frequency remote control operating range This varies according to the surround- ings: take care not to lock or unlock the doors by inadvertently pressing the but- tons on the remote control. Replacement and additional keys or remote controls.

  • Page 10: Locking The Doors

    RADIO FREQUENCY REMOTE CONTROL UNIT: use Note: The remote control A can be used to lock or unlock the doors and boot. With the engine running, the ignition It is powered by a battery which must switched on and in accessories position be replaced (refer to the information on (refer to “Ignition switch: vehicles with a “Radio frequency remote control: bat-...
  • Page 11 RADIO FREQUENCY REMOTE CONTROL UNIT: deadlocking If the vehicle is equipped with a dead- locking function, this allows you to lock the opening elements and to prevent the doors from being unlocked using the interior handles (for example, by breaking the window and then trying to open the door from the inside).

  • Page 12: Battery Life

    “Keycard battery low” appears on the instrument panel (refer to the informa- tion on the “RENAULT card: battery” in section 5). When the battery is flat, you can still lock/unlock and start your vehi- cle.
  • Page 13 RENAULT CARD: general information (2/2) Advice Avoid leaving the card in hot, cold or humid areas. Do not keep the RENAULT card in Driver’s responsibility a place where it could be bent or when parking or stopping damaged accidentally, such as in a the vehicle back pocket of a garment.
  • Page 14 There are two ways to unlock/lock the vehicle: – the RENAULT card in “Hands-free” mode; – the RENAULT card in remote con- trol mode. Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone on your vehicle, even for a short time.
  • Page 15 Remote “Hands-free” locking the sensor 3, there is a delay of approx- imately 3 seconds before it can be un- With the RENAULT card in zone 1, With the RENAULT card on you, and locked again. During these 3 seconds,...
  • Page 16 Note: The maximum distance at which system (continued) the vehicle locks depends on the sur- control roundings. If the RENAULT card has been within Unlocking with the card RENAULT range for approximately 15 minutes, Special features Press the button 5.
  • Page 17 RENAULT “HANDS-FREE” CARD: usage (4/4) Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone in your vehicle, even for a short time. They may pose a risk to themselves...
  • Page 18 RENAULT CARD: deadlocking If the vehicle is equipped with a dead- locking function, this allows you to lock the opening elements and to prevent the doors from being unlocked using the interior handles (for example, by breaking the window and then trying to open the door from the inside).

  • Page 19: Locking/Unlocking The Doors

    If the remote control or, depending on the vehicle, the RENAULT card does not work In some cases, the radio frequency remote control or the RENAULT card may not work: – RENAULT card/radio frequency remote control battery worn or run flat, vehicle battery flat, etc.
  • Page 20 – Insert the key 2 into the lock and lock from the inside or by using the key in or unlock the front left-hand door. the front left-hand door. Once you are inside the vehicle, put the key back in its casing in the RENAULT card. 1.14...
  • Page 21 Unlocking the vehicle from the outside is only possible with the RENAULT card in the vehicle’s access zone or using Interior locking/unlocking the key.

  • Page 22: Opening And Closing The Doors

    Opening the doors from the Opening from the inside outside Pull on the handle 2. With the doors unlocked or RENAULT card on you, hold handle 1 and pull it towards you. As a safety precaution, the doors should only be opened or closed when the vehicle is stationary.
  • Page 23 OPENING AND CLOSING THE DOORS (2/3) Once the vehicle reaches a speed of approximately 12 mph (20 km/h), a warning light indicates if the door(s) or luggage compartment are open or im- properly closed, along with the mes- sage “Boot open” or “Door open” and a beep will sound for around 40 seconds or until the door/luggage compartment is closed.

  • Page 24: Child Safety

    OPENING AND CLOSING THE DOORS (3/3) Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone on your vehicle, even for a short time. They may pose a risk to themselves or to others by starting the engine, Child safety activating equipment such as the...

  • Page 25: Automatic Locking When Driving

    AUTOMATIC LOCKING WHEN DRIVING Activating/deactivating the Operating faults function If you experience an operating fault (no automatic locking, the indicator light in- To switch it on: with the vehicle at a corporated in switch 2 does not light up standstill and the engine running, press when trying to lock the doors and boot, switch 2 until a beep sounds.

  • Page 26: Front Headrests

    FRONT HEADRESTS To adjust the angle of the headrest Depending on the vehicle, tilt section A towards or away from you to the re- quired position To remove the headrest Raise the headrest to its highest po- sition (tilt the seatback backwards if necessary).
  • Page 27 FRONT SEATS (1/2) Settings To tilt the seatback Lift handle 3 and tilt the seatback to the To move the seat forwards or back desired position. Release the handle at For safety reasons, make Lift handle 1 to release. Release the the desired position and make sure that these adjustments only handle at the desired position and...
  • Page 28 FRONT SEATS (2/2) Massage Driver Massage Tonic Relaxing Lumbar Intensity Speed Functions – adjust the intensity (+ or -); Heated seats – adjust the speed (+ or -); With the ignition on: Massage – reset the selected settings. Press 7 –...

  • Page 29: Seat Belts

    SEAT BELTS (1/4) Always wear your seat belt when trav- Before starting, first adjust your driv- elling in your vehicle. You must also ing position, then ask all occupants comply with the legislation of the par- to adjust their seat belts to ensure ticular country you are in.
  • Page 30 SEAT BELTS (2/4) Driver’s seat belt reminder ß and, depending on the vehi- cle, front passenger seat belt re- minder This lights up on the central display when starting the engine then, if the driver’s or front passenger’s seat belt (if this seat is occupied) is not fastened and the vehicle has reached approxi- mately 12 mph (20 km/h), it flashes and...
  • Page 31 SEAT BELTS (3/4) Adjusting the height of the Rear seat belts 8 front seat belts The belts are locked, unlocked and adjusted in the same way as the front Use button 7 to adjust the seat belt belts. height so that the shoulder strap is worn as shown previously.
  • Page 32 SEAT BELTS (4/4) The following information applies to the vehicle’s front and rear seat belts. – No modification may be made to the component parts of the originally fitted restraint system: seat belts, seats and their mountings. For special operations (e.g. fitting child seats), contact an authorised dealer. –...
  • Page 33 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (1/4) Depending on the vehicle, they are – Have the entire restraint composed of: system checked following – seat belt inertia reel pretension- an accident. ers; – No operation whatso- –...

  • Page 34: Methods Of Restraint In Addition To The Front Seat Belts

    METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (2/4) Load limiter airbags for driver and passenger Above a certain severity of impact, this mechanism is used to limit the force of Fitted to the driver and passenger side. the belt against the body so that it is at The presence of this equipment is in- an acceptable level.
  • Page 35 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (3/4) Operating faults å This warning light comes on when the engine is started and then goes out after approximately three sec- onds. If it does not come on when the ignition is switched on or if it stays on, there is a fault in the system.
  • Page 36 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (4/4) All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when the air bag inflates. Warnings concerning the driver’s air bag –...
  • Page 37 METHODS OF RESTRAINT IN ADDITION TO THE REAR SEAT BELTS Force limiter Above a certain severity of impact, this mechanism is used to limit the force of the belt against the body so that it is at an acceptable level. –...
  • Page 38 SIDE PROTECTION DEVICES Side air bags These air bags are fitted to the front seats and are activated at the sides of the seats (door side) to protect the oc- cupants in the event of a severe side impact. Curtain air bags These are airbags fitted along the sides of the vehicle in the ceiling which trigger along the front and rear door side win-...

  • Page 39: Additional Methods Of Restraint

    ADDITIONAL METHODS OF RESTRAINT All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when the air bag inflates. The air bag is designed to complement the action of the seat belt.

  • Page 40: Child Safety: General Information

    CHILD SAFETY: General information (1/2) Carrying children Children, and adults, must be correctly seated and strapped in for all journeys. The children being carried in your vehi- cle are your responsibility. A child is not a miniature adult. Children are at risk of specific injuries as their muscles and bones have not yet fin- Driver’s responsibility ished growing.
  • Page 41 CHILD SAFETY: General information (2/2) Using a child seat Set a good example by always fas- The level of protection offered by the tening your seat belt and teaching child seat depends on its ability to re- your child: strain your child and on its installation. –...
  • Page 42 CHILD SAFETY: choosing a child seat Rear-facing child seats Forward-facing child seats Booster cushions A baby’s head is, proportionally, heavier The child’s head and abdomen need to From 15 kg or 4 years, the child can than that of an adult and its neck is very be protected as a priority.

  • Page 43: Choosing A Child Seat Mounting

    CHILD SAFETY: choosing a child seat mounting (1/3) There are two ways of attaching child Attachment via the seat belt seats: via the seat belt or using the The seat belt must be adjusted to ISOFIX system. ensure that it is effective in the event of harsh braking or an impact.
  • Page 44 CHILD SAFETY: choosing a child seat mounting (2/3) Attachment using the ISOFIX Attach the child seat with the ISOFIX system locks, if these are provided. The ISOFIX system allows quick, easy, safe fitting. Approved child seats ISOFIX are stand- ardised in accordance with current reg- The ISOFIX system consists of 2 rings ulations if any of the four cases below and, in some cases, a third ring.
  • Page 45 CHILD SAFETY: choosing a child seat mounting (3/3) The rings are located on the rear seat- backs and indicated by the symbol In all cases, attach the strap hook to the corresponding ring 3 or 4 and place the seat in the desired position. Pull the belt so that the back of the child seat comes into contact with the back of the vehicle seat.

  • Page 46: Fitting A Child Seat, General Information

    CHILD SAFETY: fitting a child seat, general information (1/2) Some seats are not suitable for fitting The types of child seat indicated may After installing the child seat, if neces- child seats. The diagram on the follow- not be available. Before using a differ- sary, the seat may be advanced (so as ing page shows you how to attach a ent child seat, check with the manufac-...
  • Page 47 CHILD SAFETY: fitting a child seat, general information (2/2) In the rear seat A carrycot can be installed across the vehicle and will take up at least two seats. Position the child with his or her A child seat with support feet nearest the door.
  • Page 48 CHILD SEATS: attachment by seat belt (1/3) The table below summarises the information already shown in the diagram on the following pages, to ensure the appli- cable regulations are respected. Front passenger Type of child seat Weight of the child Rear side seats Rear centre seat seat (1)
  • Page 49 CHILD SEATS: attachment by seat belt (2/3) X = Seat not suitable for fitting child seats of this type. U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted. (2) A carrycot can be installed across the vehicle and will take up at least two seats.
  • Page 50 CHILD SEATS: attachment by seat belt (3/3) Fitting diagram ³ Check the status of the airbag before fitting a child seat or allowing a passenger to use the seat. Seat not suitable for fitting ² child seats. Child seat attached using the belt ¬...
  • Page 51 CHILD SEATS: attachment using the isofix system (1/3) Fitting diagram Child seat fitted using the ISOFIX mounting Seat which allows an ISOFIX child seat to be fitted. ± The rear seats are fitted with an anchorage point which allows a forward-facing ISOFIX child seat with universal approval to be attached.
  • Page 52 CHILD SEATS: attachment using the isofix system (2/3) The table below summarises the information already shown on the diagram on the previous pages, to ensure the regula- tions in force are respected. Weight of Front passenger Type of child seat Seat size ISOFIX Rear side seats Rear centre seat...
  • Page 53 CHILD SEATS: attachment using the isofix system (3/3) X = Seat not suitable for fitting child seats ISOFIX. IUF/IL = On equipped vehicles, seat which allows an approved “Universal/semi-universal” or “vehicle specific” child seat to be at- tached using the ISOFIX system; check that it can be fitted. i-U = Suitable for the i-Size restraint devices in the “universal”...

  • Page 54: Deactivating/Activating The Front Passenger Airbag

    CHILD SAFETY: deactivating/activating the front passenger air bag (1/3) The front passenger air bag must only be deactivated or activated when the vehicle is stationary. If it is interfered with when the ve- hicle is being driven, indicator lights å ©...
  • Page 55 CHILD SAFETY: deactivating/activating the front passenger air bag (2/3) The markings on the dashboard and labels A on each side of the passen- ger sun visor 3 (example: label shown above) remind you of these instruc- tions. DANGER Since operation of the front passenger airbag is not compatible with the position of a rear-facing child seat, NEVER...
  • Page 56 CHILD SAFETY: deactivating/activating the front passenger air bag (3/3) Operating faults It is forbidden to fit a rear-facing child seat to the front passenger seat if the airbag activation/deactivation system is faulty. Allowing any other passenger to sit in that seat is not recommended. Contact your approved dealer as soon as possible.

  • Page 57: Audible And Visual Signals

    AUDIBLE AND VISUAL SIGNALS Direction indicators Move stalk 1 parallel to the steering wheel and in the direction you are going to turn it. One-touch mode When driving, it is possible that the steering wheel may not be turned suf- ficiently to return the stalk automatically to its starting position.
  • Page 58 DRIVER’S POSITION, LEFT-HAND DRIVE (1/2) 1.52...

  • Page 59: Instrument Panel

    12 Switches for: – hazard warning lights; 4 Driver Airbag and horn location. – electric door locking. 22 Engine start/stop button (vehicles with RENAULT card) 5 Instrument panel. 13 Passenger Airbag location. 23 Ignition switch (vehicles with key). 6 Head-up display.
  • Page 60 DRIVING POSITION: RIGHT-HAND DRIVE (1/2) 10 11 1.54...
  • Page 61 3 Passenger Airbag location. 9 Cruise control/speed limiter and 17 Engine start/stop button (vehicles 4 Controls for: adaptive cruise control controls. with RENAULT card). – front seat heating; – activation/deactivation, depend- 10 Instrument panel. 18 Switches for: ing on the vehicle, of the ECO or –...
  • Page 62 WARNING LIGHTS (1/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Side light warning light š Main beam headlight tell- á tale Dipped beam headlight tell- tale Rear fog lights tell-tale Automatic main beam head- light indicator light Please refer to the information on “External signals and lights”...
  • Page 63 WARNING LIGHTS (2/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Low fuel level warning light Brake circuit fault warning Oil pressure warning light À It lights up orange when the ig- light It lights up when the ignition or nition or the engine is switched on then, It lights up when the ignition or the the engine is switched on and goes off...
  • Page 64 WARNING LIGHTS (3/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Variable power-assisted Toxic Fume Filter System Anti-lock braking warning Ä steering warning light Warning Light light It lights up when the ignition or the On vehicles which are equipped with it, It lights up when the ignition or the engine is switched on and goes off after...
  • Page 65 WARNING LIGHTS (4/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Preheating warning light Air bag warning light Brake pedal warning light É å Ó (Diesel version) This warning light will be dis- This lights up when the brake played on the instrument panel when This should come on when the igni- pedal should be depressed.
  • Page 66 WARNING LIGHTS (5/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Engine standby warning Tyre pressure monitoring Assisted parking brake fault light system light Please see information in the para- Refer to the information on the “Tyre Please refer to the information on the graph on “Stop and Start Function”...
  • Page 67 WARNING LIGHTS (6/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Driver’s seat belt reminder ß and, depending on the vehi- cle, front passenger seat belt re- minder. This lights up when the ignition is switched on, then, if the driver's or front passenger's (if this seat is occupied) seat belt is not fastened and the vehicle...

  • Page 68: Trip Computer And Warning System

    DISPLAYS AND INDICATORS (1/6) Driving style indicator 3 Please refer to the information on “Eco- driving” in Section 2. Trip computer and warning system Refer to the information on the “Trip computer and warning system” in Section 1. Instrument panel A Rev counter 1 (graduations x 1000) lights up when the driver’s door is...
  • Page 69 DISPLAYS AND INDICATORS (2/6) Coolant temperature indicator 4 Fuel gauge 6 In normal use, indicator 4 should be If the level is at the minimum, warn- before area 5. Under “intensive” oper- ing light integrated in the indica- ating conditions, the needle may ap- tor comes on orange, accompanied by proach this zone.
  • Page 70 DISPLAYS AND INDICATORS (3/6) Instrument panel B Rev counter 7 Driving style indicator 9 (graduations x 1000) Please refer to the information on “Eco- lights up when the driver’s door is driving” in Section 2. opened. In some cases, the appear- Speedometer 8 ance of a warning light is accompanied This is displayed differently according...

  • Page 71: Displays And Indicators

    DISPLAYS AND INDICATORS (4/6) Instrument panel in miles (option to switch to km/h) Vehicles not fitted with a navigation system 13 14 – With the ignition off, press the OK button 13 and the engine start/stop button 15; – using control 14, select “Settings”, “Instrument panel”, then the unit;...
  • Page 72 DISPLAYS AND INDICATORS (5/6) You can adjust certain settings from the multifunction screen: with the engine running, access menu “System”, “Display” then “Head-up display”. Adjusting the display information height Depending on your driving position, you can raise or lower the information on the display.
  • Page 73 DISPLAYS AND INDICATORS (6/6) Operating faults In the event of a malfunction (the dis- play fails to open when the engine is started, or the display retracts, with the engine running, following an object im- pacting the display): – stop and restart the engine; –...
  • Page 74 TRIP COMPUTER: general information (1/2) Display selection keys 2 Scroll through the following information by repeated short presses on button 2 (the display depends on the vehicle equipment and country): a) total mileage and trip mileage re- corder; b) journey parameters: –...
  • Page 75 ON-BOARD COMPUTER: general information (2/2) Interpreting some of the values displayed after resetting The values showing average fuel con- sumption and average speed will become more stable and reliable the further you have travelled since the last time the Reset button was pressed. The average fuel consumption may de- crease when: –...
  • Page 76 ON-BOARD COMPUTER: trip settings (1/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected 101778 km 112.4 km a) Total mileage and trip mileage recorder. Middle b) Journey parameters: Average fuel consumption.
  • Page 77 ON-BOARD COMPUTER: trip settings (2/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected Range b) Journey parameters (continued): Estimated range with remaining fuel. 541 km The value is displayed after driving 400 metres. Distance Distance travelled since last reset.
  • Page 78 ON-BOARD COMPUTER: trip settings (3/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected On-board computer with mileage- before-service message d) Mileage before service or oil change. Mileage before service Service in With the ignition switched on, the engine not running and Service Intervals...
  • Page 79 TRIP COMPUTER: trip settings (4/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected On-board computer with distance before next service message (cntd.) d) Mileage before service or oil change. Mileage before service Oil change in With the ignition on, the engine not running and the display...
  • Page 80 ON-BOARD COMPUTER: trip settings (5/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected e) Reset the tyre pressure. Refer to the information on the “Tyre pressure Tyre pressure monitoring system”...
  • Page 81 TRIP COMPUTER AND WARNING SYSTEM: information messages These can help in the vehicle starting phase, or give information about a selection or a driving status. Examples of information messages are given in the following pages. Examples of messages Interpreting the display selected «...
  • Page 82 TRIP COMPUTER AND WARNING SYSTEM: operating fault messages © These appear with the warning light and mean that you should drive very carefully to an authorised dealer as soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle. They disappear when the display selection key is pressed or after several seconds and are stored in the computer log.
  • Page 83 TRIP COMPUTER AND WARNING SYSTEM: warning message ® These appear with the warning light and require you to stop immediately, for your own safety, as soon as traf- fic conditions allow. Stop your engine and do not restart it. Contact an approved Dealer. Some examples of warning messages are given below.

  • Page 84: Vehicle Settings Customisation Menu

    VEHICLE SETTINGS CUSTOMISATION MENU (1/2) Adjusting the settings Select the function to modify: a) Free wheel in ECO mode; (please refer to the information on “Driving advice, ECO-driving” in Section 2) b) Unlock driver door only c) Auto door lock while driving; d) Use handsfree card: open/close;...

  • Page 85: Navigation System

    VEHICLE SETTINGS CUSTOMISATION MENU (2/2) Adjusting the settings Once a line has been selected, press the switch 3 OK to adjust the function. Browse using the control 4 to select the function to adjust: If you select either “PARKING ASSIST VOLUME”...

  • Page 86: Steering Wheel

    STEERING WHEEL Activating the function With the ignition on, press the switch 2, the warning light integrated in the switch lights up. Deactivating the function - Automatic: The function switches off automatically after the regulation phase of approxi- mately 30 minutes. The warning light integrated in the switch 2 remains on.

  • Page 87: Power-Assisted Steering

    POWER-ASSISTED STEERING Power-assisted steering Variable power-assisted steering The variable power assisted steering system is equipped with an electronic control system which alters the level of assistance to suit the vehicle speed. Steering is made easier during parking manoeuvres (for added comfort) while the force needed to steer increases progressively as the speed rises (for enhanced safety at high speeds).

  • Page 88: Clock And Exterior Temperature

    CLOCK AND EXTERIOR TEMPERATURE External temperature indicator Special note: When the exterior temperature is be- tween –3 °C and +3 °C, the characters °C flash and the message “Risk of black ice” is displayed on the instru- ment panel 1. The time and/or external tempera- ture are displayed on the multifunc- tion screen 2...

  • Page 89: Rear View Mirrors

    Automatic mode is then deactivated. To – when the ignition is next switched on reactivate it, position switch 3 to B. (function deactivated); – upon detecting the RENAULT card or upon unlocking the vehicle (func- tion activated). Door mirrors Adjustment...

  • Page 90: Interior Rear View Mirror

    DOOR MIRRORS (2/2) Special feature: Interior rear view mirror When the rear-view mirror has been Rear view mirror with lever 4 manually deployed or folded back, it is possible to reset it to a usage position. When driving at night, to avoid being To do this, position the switch 3 to C.

  • Page 91: Headlight Beam Adjustment

    HEADLIGHT BEAM ADJUSTMENT (1/2) For manual settings Examples of positions for adjusting control A according to the load Driver alone, or with front passenger All seats occupied On vehicles fitted with this function, control A allows you to adjust the height Driver with or without passengers and luggage (or load) of the beams according to the load.
  • Page 92 HEADLIGHT BEAM ADJUSTMENT (2/2) When driving on the left in a left- hand drive vehicle (or vice versa), you must adjust your lights tempo- rarily during your stay. Temporary adjustment for vehicles fitted with halogen headlights Open the bonnet and identify the mark- ing B next to one of the front headlight projectors.

  • Page 93: Exterior Lighting And Signals

    EXTERIOR LIGHTING AND SIGNALS (1/5) Dipped beam headlights Manual operation Turn ring 3 until the symbol is opposite mark 2. This indicator light on the in- strument panel comes on. Automatic operation Turn ring 3 until the AUTO symbol is op- posite mark 2: with the engine running, the dipped beam headlights switch on or off automatically depending on the...
  • Page 94 EXTERIOR LIGHTING AND SIGNALS (2/5) Automatic main beam Activation Turn ring 3 until the AUTO symbol is op- headlights posite mark 2. Depending on the vehicle, this system Push stalk 1 to activate the main beam switches the main beam headlights on headlights.

  • Page 95: Daytime Running Lights

    EXTERIOR LIGHTING AND SIGNALS (3/5) Daytime running lights Switching off the lights function There are two possibilities: – manually, move ring 3 to position 0; The daytime running lights come on – automatically, the lights will go out automatically with no action on stalk 1 when the engine is switched off, the when the engine is started, and they go driver’s door is opened or the vehicle...
  • Page 96 With the engine and lights off and vehicle or when opening a door. ing the RENAULT card or when the ve- ring 3 in position 0 or AUTO, pull hicle is unlocked. They switch off automatically:...

  • Page 97: Rear Fog Lights

    EXTERIOR LIGHTING AND SIGNALS (5/5) Rear fog lights Switching off the lights Turn centre ring 4 on the stalk Turn the ring 4 again until the mark 2 until the symbol faces mark 2, then re- is opposite the symbol for the fog light lease it.

  • Page 98: Windscreen Wipers

    WINDSCREEN WASH/WIPE (1/6) Check the condition of the wiper blades. You are responsible for their service life: – they must remain clean: clean the blades, windscreen and rear screen regularly with soapy Vehicle fitted with intermittent Special note water; When driving the vehicle, the wiping windscreen wipers –...
  • Page 99 WINDSCREEN WASH/WIPE (2/6) When activating automatic wiping or when increasing sensitivity, one sweep of the blades is performed. Note: – the rain sensor is only intended as a driving aid. In the event of reduced visibility, the driver should manually activate the wipers.
  • Page 100 WINDSCREEN WASH/WIPE (3/6) Operating fault Special note In the event of a malfunction of the au- When driving the vehicle, the wiping tomatic wiping, the wiper is set to inter- speed slows down whenever the vehi- mittent wiping. Contact an authorised cle stops.

  • Page 101: Service Position

    WINDSCREEN WASH/WIPE (4/6) Specific front wiper position Note: (service position) After your intervention, to reposition the blades correctly, make sure the blades This position enables the blades to be are resting on the windscreen, switch lifted to remove them from the winds- on the ignition and activate the wiper creen.

  • Page 102: Windscreen Washer

    WINDSCREEN WASH/WIPE (5/6) Note: In temperatures below zero, the washer liquid risks freezing to the windscreen, thereby reducing visibility. Heat the windscreen using the demister control before cleaning. Windscreen washer With the ignition on, pull stalk 1 then release. A brief pull will trigger a single sweep of the wipers, in addition to the wind- screen washer.

  • Page 103: Headlight Washers

    WINDSCREEN WASH/WIPE (6/6) Note: To ensure the headlight washers ope- rate correctly in winter, remove snow from the jet trims and de-ice the jet trims using an aerosol de-icer. You are recommended to regularly remove dirt encrusted on the headlight glass.

  • Page 104: Rear Screen Wiper

    REAR SCREEN WASH/WIPE (1/2) To stop the operation, pivot ring 3 again. Note: When washing using a roller type car wash, return the ring 3 on the stalk 1 to the stop position to deactivate auto- matic wiping. Follow usage recommendations. Check the condition of the wiper blades.
  • Page 105 REAR SCREEN WASH/WIPE (2/2) Activation/deactivation of the rear In the event of obstacles present on the screen wiper rear window (dirt, snow, etc.), the wiper will try to sweep away all the obstacles. Engaging reverse gear triggers inter- If an obstacle prevents the blade from mittent wiping (if the front wipers are in moving, it can be stopped.

  • Page 106: Fuel Tank (Filling With Fuel)

    FUEL TANK (1/3) Diesel versions Only use diesel fuel which complies with the information on the label located inside the cover 1. Petrol versions It is essential to use unleaded petrol. The octane rating (RON) must comply with the information given on the label on the cover 1.
  • Page 107 FUEL TANK (2/3) Filling with fuel With the ignition off, insert the nozzle to open valve 2 and insert it fully before turning it on to fill the fuel tank (risk of splashing). Keep the nozzle in this position through- out the entire filling operation.
  • Page 108 – If the engine does not start after sev- eral attempts, please contact an au- Vehicles with RENAULT card thorised dealer. With the card RENAULT in the pas- Persistent smell of senger compartment, press the start fuel button 3 without pressing any of the pedals.
  • Page 109 Starting - Stopping the engine: vehicle with RENAULT card .......

  • Page 110: Running In

    RUNNING IN Petrol version Diesel version For the first 600 miles (1,000 km), do For the first 1,000 miles (1,500 km), not exceed 78 mph (130 km/h) in the do not exceed 80 mph (130 km/h) in highest gear, or 3,000 to 3,500 rpm. the highest gear, or 2,500 rpm.

  • Page 111: Ignition Switch

    IGNITION SWITCH: vehicle with key Ignition position M. The ignition is switched on: Start position D If the engine fails to start at the first attempt, the key must be turned back before the starter can be activated again. Release the key as soon as the engine starts.

  • Page 112: Starting, Stopping The Engine: Vehicle With Key/Remote Control Unit

    STARTING, STOPPING THE ENGINE: vehicle with key Stopping the engine Diesel versions É With the engine idling, turn the key – Turn the ignition key to the “Ignition back to the “Stop” position St. on” position M, and hold this position until the engine preheating light goes off;...

  • Page 113: Starting - Stopping The Engine: Vehicle With Renault Card

    STARTING, STOPPING THE ENGINE: vehicle with RENAULT card (1/3) “Hands-free” starting with the tailgate open In this case, the RENAULT card should not be located in the boot, to avoid any risk of loss. Driver’s responsibility when parking or stopping...
  • Page 114 STARTING, STOPPING THE ENGINE: vehicle with RENAULT card (2/3) Accessories function Operating faults Press the brake or clutch pedal, then place the RENAULT 3 card (logo side) (switching on the ignition) In certain cases, the RENAULT “hands- for around 2 seconds in contact with.
  • Page 115 STARTING, STOPPING THE ENGINE: vehicle with RENAULT card (3/3) If the RENAULT card is no longer in the When you leave your vehi- passenger compartment when you try cle, especially if you have to switch the engine off, the message your RENAULT card with “No keycard Press and hold”...

  • Page 116: Standing Start Procedure

    STANDING START PROCEDURE (1/2) Activating the system The system is activated by: – with the engine running, and the ve- hicle stationary; – Sport mode activated (please see the “Multi-Sense” section); – depress the brake pedal with the left Heavy use of the system will reduce foot;...
  • Page 117 STANDING START PROCEDURE (2/2) Conditions for non-activation of the system Certain conditions will not enable the system to be activated: – five successive authorised standing start procedures - beyond five proce- dures being performed, the function will be prevented for approximately 10 minutes;...

  • Page 118: Stop And Start Function

    STOP AND START FUNCTION (1/4) This system enables a reduced fuel For manual gearboxes: For all vehicles: consumption and lower greenhouse – the gearbox is in neutral; The warning light on the instru- gas emissions. ment panel is lit when the engine is on –...
  • Page 119 STOP AND START FUNCTION (2/4) Preventing the engine from Conditions for coming out of Special note: depending on the vehi- cle, if you switch off the ignition when standing by engine standby the engine is on standby, the warning In certain situations, such as negotiat- For automatic gearboxes: Ä...
  • Page 120 Special case for vehicles with – for vehicles with automatic gear- boxes, the gradient is steeper than standby of the engine a RENAULT card approximately 12%; Certain conditions prevent the system With the engine on standby (traffic jam, – the “Clear View” function is activated from using the engine standby function, traffic lights, etc.), if the driver unfas-...
  • Page 121 STOP AND START FUNCTION (4/4) Special feature of the automatic The system is automatically reacti- engine re-start vated each time the vehicle is started (see “Starting, stopping the engine” in Under certain conditions, the engine Section 2). can restart on its own in order to guar- antee your safety and comfort.

  • Page 122: Special Features Of Petrol Versions

    SPECIAL FEATURES OF PETROL VERSIONS The following operating conditions: If you notice any of the above operating faults, have the necessary repairs car- – driving for long periods when the low ried out as soon as possible by an ap- fuel level warning light is lit;...

  • Page 123: Special Features Of Diesel Versions

    SPECIAL FEATURES OF DIESEL VERSIONS Diesel engine speed Precautions to be taken in winter Diesel engines are fitted with an injec- tion pump which prevents the engine To avoid any faults in icy weather: speed being exceeded irrespective of – ensure that the battery is always fully the gear selected.

  • Page 124: Gear Lever/Handbrake

    GEAR LEVER/HANDBRAKE Handbrake To apply: Pull lever 3 upwards. Check that the To release: vehicle is immobilised. The warning Pull the lever 3 up slightly, press light on the instrument panel will button 2 and then lower the lever to the come on.

  • Page 125: Electronic Parking Brake

    ELECTRONIC PARKING BRAKE (1/3) Note: To indicate that the electronic parking brake is released, a beep sounds and the message “Apply parking brake” ap- pears on the instrument panel: – with the engine running: when the driver’s door is opened; –...

  • Page 126: Manual Operation

    ELECTRONIC PARKING BRAKE (2/3) Special cases To park on a slope or while towing a trailer, for example, pull switch 2 for a few seconds to gain the maximum braking. To park the vehicle without applying the electronic parking brake (if there is a risk of freezing, for example): –...
  • Page 127 ELECTRONIC PARKING BRAKE (3/3) Versions with an automatic Operating faults gearbox © – If there is a fault, the warning light illuminates on the instrument For safety reasons, automatic release panel accompanied by the “Check is deactivated when the driver’s door parking brake”...

  • Page 128: Driving Advice, Eco-Driving

    DRIVING ADVICE, ECO-DRIVING (1/5) Fuel consumption is accredited in ac- cordance with a standard regulatory method. Identical for all manufactur- ers, this enables vehicles to be com- pared with one another. Consumption in real time depends on vehicle usage conditions, the equipment fitted and the user’s driving style.
  • Page 129 DRIVING ADVICE, ECO-DRIVING (2/5) This indicates: – average fuel consumption; – number of miles/kilometres travelled; – number of miles/kilometres saved. This corresponds to driving without fuel consumption (deceleration and/ or foot off the accelerator pedal). An overall rating from 0 to 100 is dis- played to let you assess your eco driv- ing performance.
  • Page 130 DRIVING ADVICE, ECO-DRIVING ( 3/5) ECO mode Activating the function The function can be activated: ECO mode is a function which opti- mises fuel consumption. This acts on – by pressing switch 6. all power consuming elements (engine – by pressing the switch 7 (please refer power, switching gears for vehicles to the information on “Multi-Sense”...
  • Page 131 DRIVING ADVICE, ECO-DRIVING (4/5) – Do not overrev the engine in the in- – Bad weather, flooded roads: termediate gears. You should always use the highest Do not drive through gear possible. floods if the water is – Avoid sudden acceleration. above the lower edge of –...
  • Page 132 DRIVING ADVICE, ECO-DRIVING (5/5) – In vehicles fitted with air condi- tioning, it is normal to observe an increase in fuel consumption (espe- cially in urban conditions) when it is used. For vehicles fitted with manual air conditioning, switch off the system when it is not required.

  • Page 133: Maintenance And Antipollution Advice

    MAINTENANCE AND ANTIPOLLUTION ADVICE Your vehicle complies with criteria for In addition, replacing engine, fuel – Air filter, fuel filter: a choked ele- recycling and recovering vehicles at the supply system and exhaust compo- ment will reduce efficiency. It must end of their service life which will come nents with parts other than those origi- be replaced.

  • Page 134: Environment

    – In all cases, comply with local legis- while in use, and therefore to consume This commitment is illustrated by the lation. less fuel (e.g. 140 g/km, equivalent to Renault eco² signature. 1494.6 mpg (5.3 l/100 km) for a diesel vehicle). Recycling Manufacture...

  • Page 135: Tyre Pressure Monitoring System

    TYRE PRESSURE MONITORING SYSTEM (1/3) Resetting the standard level Resetting procedure for the tyre pressures With the ignition on: – repeatedly and briefly press con- This should be done: trol 2 to select the tyre pressure dis- – when the standard tyre pressure play and, depending on the vehicle, needs to be changed to adapt to the “Tyre pressure”...
  • Page 136 TYRE PRESSURE MONITORING SYSTEM (2/3) “Puncture” A wheel B is shown, depending on the vehicle, in red or white accompanied by the warning light 4 fixed, the message “Puncture” and a beep. This message appears along with the ® warning light. They indicate that the affected wheel is punctured or se- verely underinflated.
  • Page 137 Because the valves are specially de- or more wheels have been fitted with Please see the information on “Tyres” signed, only use equipment approved sensors not recognised by Renault. in Section 5. by the approved network. Please refer Contact an approved Dealer to fit new to “Tyre inflation kit”...

  • Page 138: Driver Correction Devices/Aids

    DRIVER CORRECTION DEVICES AND AIDS (1/10) ABS (anti-lock braking – ABS (anti-lock braking system); system) – ESC (electronic stability control) Under heavy braking, the ABS prevents with understeer control and trac- the wheels from locking, allowing the tion control; stopping distance to be managed and –...
  • Page 139 DRIVER CORRECTION DEVICES AND AIDS (2/10) Operating faults: © – lit up on the in- strument panel alongside mes- sages “Check ABS”, “Check braking system” and “Check ESC”: indicates the ABS, ESC and emergency brake assist are deactivated. Braking is always enabled;...

  • Page 140: Electronic Stability Control

    DRIVER CORRECTION DEVICES AND AIDS (3/10) Electronic stability control Understeer control Operating faults ESC with understeer control This system optimises the action of the When the system detects an operat- and traction control ESC in the case of pronounced under- ing fault the message “Check ESC”...

  • Page 141: Emergency Brake Assist

    DRIVER CORRECTION DEVICES AND AIDS (4/10) Emergency brake assist Braking anticipation Depending on the vehicle, when you This system supplements the ABS rapidly release the accelerator, the and helps reduce vehicle stopping dis- system anticipates the braking ma- tances. noeuvre in order to reduce stopping Operating principle distances.
  • Page 142 DRIVER CORRECTION DEVICES AND AIDS (5/10) If the driver depresses the brake pedal and the system still detects a risk of col- lision, the brake force is increased. If the driver fails to react following an alert of an imminent collision, the system activates the brakes.
  • Page 143 DRIVER CORRECTION DEVICES AND AIDS (6/10) Press the switch 5 OK again to activate or deactivate the function: function activated < function deactivated The warning light is displayed on the instrument panel when the system is deactivated. This system is reactivated each time the ignition is switched on.
  • Page 144 DRIVER CORRECTION DEVICES AND AIDS (7/10) Operating faults Active emergency braking When the system detects an operating This function is an additional driving aid. However, this function is not fault, the warning light lights up under any circumstances intended to replace the due care and attention on the instrument panel, with the mes- of the driver, who should at all times be in control of the vehicle.
  • Page 145 DRIVER CORRECTION DEVICES AND AIDS (8/10) Active emergency braking Limitation of the system operation – The system will only respond to vehicles which are moving or which have been sensed as moving. – A vehicle travelling in the opposite direction will not trigger any alert or any action on the system operation. –...
  • Page 146 DRIVER CORRECTION DEVICES AND AIDS (9/10) Hill start assistance Depending on the gradient of the in- cline, this system assists the driver when starting on a hill. It prevents the vehicle from rolling backwards by au- tomatically applying the brakes when the driver lifts his/her foot off the brake pedal to depress the accelerator pedal.
  • Page 147 DRIVER CORRECTION DEVICES AND AIDS (10/10) Operating faults © – If the warning light, together with the message “Check power steering”, is displayed on the instru- ment panel: please contact an au- thorised dealer. ® – If the warning light , together with the message “Power steering fault”, is displayed on the instrument...

  • Page 148: Lane Departure Warning

    LANE DEPARTURE WARNING (1/3) This system notifies the driver when they accidentally cross a continuous or broken line. This function uses a camera attached to the windscreen, behind the rear-view mirror. This function is a driving aid in the event of the accidental crossing of a continuous or broken line in the road.
  • Page 149 LANE DEPARTURE WARNING (2/3) Activation/deactivation Vehicles not fitted with a navigation The function is set to notify the system driver if: Vehicles fitted with a navigation – the vehicle speed is greater than ap- Press the switch 3. system proximately 45 mph (70 km/h); From the multifunction screen 1: select Operation –...
  • Page 150 LANE DEPARTURE WARNING (3/3) Adjustment – repeatedly press the control 7 up or down until you reach the Lane de- Vehicles fitted with a navigation parture warning setting menu, then system press the switch 6 OK. – Volume: adjust the alert volume to From the multifunction screen 1, select one of three levels;...

  • Page 151: Blind Spot Warning

    BLIND SPOT WARNING (1/4) This function is an addi- tional aid which indicates other vehicles in the blind spot area. This system alerts the driver to other Special feature It can never in any case be a subs- vehicles in the detection zone A. Make sure that the sensors are not ob- titute for care nor for the driver’s scured (by dirt, mud, snow, etc.).
  • Page 152 BLIND SPOT WARNING (2/4) – repeatedly press the control 5 up or down until you reach the Blind spot alert menu, then press the switch 4 OK . – Press the switch 4 OK again to acti- vate or deactivate the function. Activation/deactivation Vehicles not fitted with a navigation system...
  • Page 153 BLIND SPOT WARNING (3/4) Display B The function is activated and has not detected any vehicles. Display C First warning: the indicator 6 means that a vehicle has been detected in the blind spot. Display D When the direction indicator is acti- vated, the indicator light 6 flashes when a vehicle is detected in the blind spot on the side towards which you are about to...
  • Page 154 BLIND SPOT WARNING (4/4) Operating faults If the system detects a fault, the mes- sage “Check blind spot alert” is dis- played on the instrument panel. Consult an authorised dealer. Note: when the engine is started, the indicator light 6, display B, flashes three times.

  • Page 155: Safe Distance Alert

    SAFE DISTANCE ALERT (1/2) Using the sensor 1, this function noti- Activating/deactivating the fies the driver about the time interval function separating them from the vehicle in From the multifunction screen 2, select front, so they can respect a safe dis- menu “Vehicle”, “Driving assistance”, tance between the two vehicles.
  • Page 156 SAFE DISTANCE ALERT (2/2) – C (orange): the time interval falls between around 1 and 2 seconds (in- sufficient distance between the two This function is essential if adaptive vehicles); cruise control is activated. – D (red): the time interval is less than or equal to around one second (very insufficient distance between the two vehicles).
  • Page 157 CRUISE CONTROL/SPEED LIMITER: speed limiter function (1/3) Switching on Press switch 1 on side . Depending on the vehicle, the warning light is orange and the message “Speed limiter” appears on the instru- ment panel accompanied by dashes to indicate that the speed limiter function is activated and waiting to memorise a limit speed.

  • Page 158: Speed Limiter

    CRUISE CONTROL/SPEED LIMITER: speed limiter function (2/3) Varying the limit speed Exceeding the limit speed The speed limiter can be changed by It is possible to exceed the limit speed repeatedly pressing switch 2 : at any time. To do this: press the accel- erator pedal firmly and fully (beyond –...
  • Page 159 CRUISE CONTROL/SPEED LIMITER: speed limiter function (3/3) Recalling the limit speed If a speed has been stored, it can be re- called by pressing switch 3 (R). Putting the function on Switching off the function standby The speed limiter function is deac- tivated if you press switch 1: in this The speed limiter function is suspended case a speed is no longer stored.
  • Page 160 OVERSPEED ALERT (1/3) Operating principle For vehicles equipped with a navigation system and if the vehicle is travelling in The system detects speed limit signs a country where the speed units differ on the side of the road and displays the from those of the vehicle, the system speed limit.
  • Page 161 OVERSPEED ALERT (2/3) – repeatedly press the control 6 up or down until you reach the Speed alert menu, then press the switch 5 OK. – Press OK to turn the function on or off. Varying the limit speed If the speed limiter notification differs from the detected speed value, press and hold the switch 4: –...
  • Page 162 OVERSPEED ALERT (3/3) Operating fault This function is an additional driving aid. However, this function is not The system cannot detect the speed under any circumstances intended to replace the due care and attention limit if: of the driver, who should at all times be in control of the vehicle. –...
  • Page 163 CRUISE CONTROL/SPEED LIMITER: cruise control function (1/4) 4 This control is only activated for ve- hicles fitted with adaptive cruise control (refer to the information on “adaptive cruise control” in sec- tion 2). This function is an addi- tional driving aid. However, the function does not take the place of the driver.
  • Page 164 CRUISE CONTROL/SPEED LIMITER: cruise control function (2/4) Activating cruise control At a steady speed (above approx. 20 mph or 30 km/h), press switch 2 side a (+): the function is activated and the current speed is saved. The cruising speed replaces the dashes and cruise control is confirmed by dis- playing of the cruising speed, the mes- sage “Cruise control”...
  • Page 165 CRUISE CONTROL/SPEED LIMITER: cruise control function (3/4) Exceeding the cruising speed The cruising speed may be exceeded at any time by depressing the accelera- tor pedal. While it is being exceeded, the cruising speed flashes on the in- strument panel. Then, release the accelerator: after a few seconds, the vehicle will automati- cally return to its set cruising speed.
  • Page 166 CRUISE CONTROL/SPEED LIMITER: cruise control function (4/4) Returning to the cruising speed If a speed is stored, it can be recalled, once you are sure that the road con- ditions are suitable (traffic, road sur- face, weather conditions, etc.). Press switch 3 (R) if the vehicle speed is above 20 mph (30 km/h).

  • Page 167: Adaptive Cruise Control

    ADAPTIVE CRUISE CONTROL (1/7) When traffic conditions permit (large free-flowing road or motorway), the adaptive cruise control gives you the option of maintaining a chosen speed, known as cruise control, adjusta- ble from 30 mph to 85 mph (50 and 140 km/h), while keeping a following distance from the vehicle in front in the same lane.
  • Page 168 ADAPTIVE CRUISE CONTROL (2/7) Controls Switching on The cruising speed replaces the dashes and cruise control is confirmed by the Press switch 5. Indicator light 5 Main “On/Off” switch. appearance of the message “Adaptive comes on, lit green, and the message 2 Controls for: cruise ctrl”...
  • Page 169 ADAPTIVE CRUISE CONTROL (3/7) Driving Varying the following distance Once a cruising speed is memorised and the cruise control function is active, You can vary the following distance you may lift your foot off the accelera- from the vehicle in front at any time by tor pedal.
  • Page 170 ADAPTIVE CRUISE CONTROL (4/7) Putting the function on Returning to the cruising speed standby If a speed is stored, it can be recalled, once you are sure that the road con- The function is set to standby if: ditions are suitable (traffic, road sur- –...
  • Page 171 ADAPTIVE CRUISE CONTROL (5/7) Note: if the speed previously stored is much higher than the current speed, the vehicle will accelerate to reach this threshold. Under certain conditions (coming up behind a vehicle moving more slowly, rapid change of lane of vehicles in front, etc.), the system may not have time to respond and may emit a beep alongside the alert D when the situation...
  • Page 172 ADAPTIVE CRUISE CONTROL (6/7) This function is an additional driving aid. However, this function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. The driver should always adapt their speed to the traffic conditions, regardless of the system indications.
  • Page 173 ADAPTIVE CRUISE CONTROL (7/7) Limitation of the system operation – A vehicle travelling in the opposite direction will not trigger any alert or any action on the system operation. – The sensor area should be kept clean and free of any modifications in order to ensure the proper operation of the system.

  • Page 174: Parking Distance Control

    PARKING DISTANCE CONTROL (1/5) Operating principle Ultrasonic sensors in the rear bumper measure the distance between the ve- hicle and an obstacle. This measurement is indicated by beeps which become more frequent the closer you come to the obstacle, until they become a continuous beep when the vehicle is approximately 20 to This function is an addi-...
  • Page 175 PARKING DISTANCE CONTROL (2/5) Note: the display 2 shows the vehicle Operation surroundings and emits beeps. Most objects located less near the It is necessary to travel a few metres front, rear and sides of the vehicle are before the side detection is activated. detected.
  • Page 176 PARKING DISTANCE CONTROL (3/5) If a side obstacle is detected: – the beeps become faster and then sound continuously as the obstacle gets nearer. Green, orange and red zones will be displayed on the dis- play D; – if there is no risk of collision, no beep will sound when approaching the ob- stacle.
  • Page 177 PARKING DISTANCE CONTROL (4/5) System sound Enables the system sound to be chosen. Deactivating the system sound Activate or deactivate the parking dis- tance control sound. Note: If you deactivate the sound, you will no longer be notified with beeps when approaching an obstacle.
  • Page 178 PARKING DISTANCE CONTROL (5/5) Automatic deactivation of the Operating faults parking distance control When the system detects an operating fault, a beep sounds for approximately The system deactivates: 3 seconds each time reverse gear is se- – when the vehicle speed is above ap- lected and is accompanied by the mes- proximately 6 mph (10 km/h);...

  • Page 179: Reversing Camera

    REVERSING CAMERA (1/2) Operation 3 moving guide line: This gauge remains fixed and indicates the vehicle trajectory if the wheels are This is shown in blue on the multifunc- Moving into reverse gear, the camera 1 in line with the vehicle. tion screen 2.
  • Page 180 REVERSING CAMERA (2/2) You can also adjust the camera image settings (brightness, contrast, etc.) The screen shows a reverse mirror Activating, deactivating the image. This function is an additional reversing camera The frames are a representation aid. It cannot, therefore, projected onto flat ground;...

  • Page 181: Assisted Parking

    ASSISTED PARKING (1/4) This function assists with parking ma- Switching on Special features noeuvres. With the vehicle at a standstill or driving Ensure that the ultrasonic sensors indi- Take your hands off the steering wheel. at less than approximately 18.6 mph cated by arrows 3 are not obscured (by You only control the pedals and the (30 km/h), press switch 1.
  • Page 182 ASSISTED PARKING (2/4) Choice of manoeuvre Operation Your speed should not exceed around 4 mph (7 km/h). The system can perform four types of Parking manoeuvres: Once the warning light on the As long as the vehicle speed is less –...
  • Page 183 ASSISTED PARKING (3/4) Your speed should not exceed around In this case, the reason for suspending 4 mph (7 km/h). the manoeuvre will be displayed on the Once in position to exit the space, the multifunction screen. system will notify you of the end of the Make sure: manoeuvre.
  • Page 184 ASSISTED PARKING (4/4) This function is an additional driving aid. However, this function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. Make sure that the manoeuvre complies with the applicable traffic regulations at your location.

  • Page 185: Selector Lever

    AUTOMATIC TRANSMISSION (1/3) Selector lever 1 Operation Gear shift paddles 3 (depending on the vehicle) P: park With the selection lever 1 in position P, switch on the ignition. The paddles 3 enable you to change R: reverse gear while the gear lever is in “manual To move out of position P, you must de- N: Neutral mode”...

  • Page 186: Automatic Gearbox

    AUTOMATIC TRANSMISSION (2/3) Driving in automatic mode Driving in manual mode Special circumstances With the selector lever in position D, Put lever 1 into position D. – If the bends and road surface do move the lever to the left into the M po- not allow you to stay in automatic In most road conditions you will en- sition.

  • Page 187: Automatic Transmission

    AUTOMATIC TRANSMISSION (3/3) Parking the vehicle Operating faults When the vehicle is stopped, move the – when driving, if the “CHECK AUTO lever to position P while keeping your GEARBOX ” message appears on foot on the brake pedal: the gearbox is the instrument panel, it indicates a in neutral and the drive wheels are me- fault.
  • Page 188 2.80...

  • Page 189: Your Comfort

    Section 3: Your comfort multi-Sense ..............Air Vents .

  • Page 190: Multi-Sense

    MULTI-SENSE (1/2) Mode Eco The Multi-Sense system acts, depend- Multi-Sense ing on the mode selected and depend- Mode Eco is geared towards saving ing on the vehicle, on the drive, the Sport energy and the environment. The light environment, the comfort and the Neutral Comfort Perso...

  • Page 191: Sport Mode

    MULTI-SENSE (2/2) Sport mode This mode permits an increased re- sponsiveness from the engine and the gearbox. The steering is firmer. Note: depending on the vehicle, this mode may inhibit the Stop And Start mode (refer to the information on the “Stop and Start Function”...
  • Page 192 AIR VENTS: air outlets (1/2) 1 side window demister outlets 2 side air vents 3 windscreen demister outlet 4 centre air vents 5 footwell heater outlets for front pas- 7 footwell heater outlets for rear pas- sengers sengers 6 multifunction screen 8 centre console air vents...
  • Page 193 AIR VENTS: air outlets (2/2) Front seats Air flow Rear seats Turn control knob 9: Direction Right/left direction : maximum air flow; Move cursor 11. Right/left direction : closed. Move cursor 8. Up/down direction To remove bad odours from your ve- Move cursor 11.
  • Page 194 MANUAL AIR CONDITIONING (1/3) 9 10 11 The controls Indicators Switching air conditioning on or off 1 Adjusting the air temperature. The following indicators are displayed on the multimedia screen A: The air conditioning is switched on (in- 2 De-icing/demisting of the rear screen dicator light on) or off (indicator light off) and, depending on the vehicle, the 8 Air temperature.

  • Page 195: Manual Air Conditioning

    MANUAL AIR CONDITIONING (2/3) Distribution of air in the passenger compartment There are five air distribution options. Turn control 5 to choose the distribution option. The air distribution is displayed on the multimedia screen. The air flow is directed to the õ...
  • Page 196 MANUAL AIR CONDITIONING (3/3) Rear screen de-icing/ demisting With the engine running, press the control 2. The operating tell-tale comes This function permits rapid demisting/ de-icing of the rear screen and de-icing of the door mirrors (on equipped vehi- cles). To exit this function, press the con- trol 2 again.

  • Page 197: Automatic Climate Control

    AUTOMATIC CLIMATE CONTROL: Controls A (1/5) Automatic mode Climate The automatic climate control system guarantees comfort in the passen- ger compartment and good visibility (except in the event of extreme condi- tions), while optimising consumption. The system controls the ventilation speed, air distribution, air recirculation, and starting and stopping the air condi- tioning and air temperature.
  • Page 198 AUTOMATIC CLIMATE CONTROL: Controls A (2/5) Note: The air conditioning configura- Climate tion depends on the mode selected in the “Multi-Sense” menu (please refer to the information on “Multi-Sense” in sec- tion 3). The displayed temperature values Varying the ventilation speed Temperature adjustment show a comfort level.
  • Page 199 AUTOMATIC CLIMATE CONTROL: Controls A (3/5) To exit this function, press either: Climate – button 4; – again button 6; – on button 8, 9 or 10. Clear View function Press button 6 – the integrated indica- tor light comes on. This function quickly demists and de- Press button 3 to stop the heated rear ices the windscreen, the rear screen,...
  • Page 200 AUTOMATIC CLIMATE CONTROL: Controls A (4/5) Rear screen de-icing/ Climate demisting Press button 3 – the integrated indica- tor light comes on. This function en- ables rapid demisting or de-icing of the rear screen and de-icing of the door mirrors (on equipped vehicles). To exit this function, press button 3 again.
  • Page 201 AUTOMATIC CLIMATE CONTROL: Controls A (5/5) Automatic usage Climate Press button 16 (a warning light comes on in zone 14). Manual use Press button 5 to force air recirculation. Prolonged use of this position may lead to odours, caused by non-renewal of air, and the formation of condensation on the windows.
  • Page 202 AUTOMATIC CLIMATE CONTROL: Controls B and C (1/5) Automatic mode The automatic climate control system guarantees comfort in the passen- ger compartment and good visibility (except in the event of extreme condi- tions), while optimising consumption. The system controls the ventilation speed, air distribution, air recirculation, 18 5 and starting and stopping the air condi-...
  • Page 203 AUTOMATIC CLIMATE CONTROL: Controls B and C (2/5) Note: The air conditioning configura- tion depends on the mode selected in the “Multi-Sense” menu (please refer to the information on “Multi-Sense” in sec- tion 3). 18 5 18 5 The displayed temperature values Varying the ventilation speed Temperature adjustment show a comfort level.
  • Page 204 AUTOMATIC CLIMATE CONTROL: Controls B and C (3/5) To exit this function, press either: – again button 10; – one of the buttons 14, 15 or 16. 14 15 14 15 Clear View function Press button 10 – the integrated indica- tor light comes on.
  • Page 205 AUTOMATIC CLIMATE CONTROL: Controls B and C (4/5) Rear screen de-icing/ demisting Press button 6 – the integrated indica- tor light comes on. This function en- ables rapid demisting or de-icing of the rear screen and de-icing of the door mirrors (on equipped vehicles).
  • Page 206 AUTOMATIC CLIMATE CONTROL: Controls B and C (5/5) Automatic usage Press button 8 (a warning light comes on in zone 1). Manual use Press button 9 to force air recirculation. Prolonged use of this position may lead to odours, caused by non-renewal of air, and the formation of condensation on the windows.

  • Page 207: Air Conditioning: Information And Advice On Use

    AIR CONDITIONING: information and advice on use Advice on use Fuel consumption Operating faults In some situations, (air conditioning You will normally notice an increase in As a general rule, contact your ap- off, air recirculation activated, ventila- fuel consumption (especially in town) proved dealer in the event of an oper- tion speed at zero or low, etc.) you may when the air conditioning is operating.

  • Page 208: Outside Air Quality And Deodorisation Functions

    OUTSIDE AIR QUALITY AND DEODORISATION FUNCTION Deodorisation function This reduces unpleasant odours in the passenger compartment. Deodorization cycle – ON: helps to reduce the unpleasant odour more quickly in the passenger compartment, – OFF: stop the function. Note: The function is on a timer. It stops auto- matically after a few minutes.

  • Page 209: Electric Windows

    Driver’s responsibility Never leave your vehicle with the RENAULT card or key inside, and never leave a child, adult who is not self-sufficient or a pet, even for a short while. They may pose a risk to themselves or to others by starting the engine or activating equip- ment (such as the gear lever or electric windows).
  • Page 210 ELECTRIC WINDOWS (2/2) Operating faults One-touch mode This mode works in addition to the ope- In case of a fault when closing a ration of the electric windows described window, the system reverts to normal previously. mode: pull the switch as many times as Briefly press or pull the window switch necessary until the window closes com- fully: the window is fully lowered or...

  • Page 211: Electric Sunroof

    ELECTRIC SUNROOF (1/3) Driver’s responsibility Never leave your vehicle with the RENAULT card inside, and never leave a child who is not self-sufficient or a To slide the curtain 1 To slide the sunroof pet, even for a short while.

  • Page 212: Remote Control

    Closing the sunroof by remote control If you press the locking button on the card twice in quick succession RENAULT,, the windows and the elec- tric sunroof will close automatically. It is recommended that the user only operates the system when the vehi- cle can be seen clearly and no one is inside.
  • Page 213 Driver’s responsibility should not interfere with the opera- Never leave your vehicle tion of the sunroof. with the RENAULT card Contact an approved dealer for de- inside, and never leave a tails of possible conversions; child who is not self-sufficient or a Operating faults –...

  • Page 214: Interior Lighting

    INTERIOR LIGHTING (1/2) Note: for vehicles fitted with a naviga- tion system, you can use the multifunc- tion screen to deactivate/activate the courtesy lights which come on when the doors or boot are opened. To do this, please refer to “Vehicle settings customisation menu”...
  • Page 215 INTERIOR LIGHTING (2/2) Glove box light 5 Boot lights Light 5 comes on when the cover is Light 6 comes on when the luggage opened. compartment is opened. With the doors properly shut, lock- ing or starting the engine makes the interior lights and the courtesy lights go out.

  • Page 216: Sun Visor/Blinds

    SUN VISOR, BLINDS Front sun visor Ticket holder 4 Lower the sun visor 1 on the wind- Can be used to hold motorway toll tick- screen or unclip it and lower it over the ets, maps, etc. side window. Vanity mirror Lift the cover 3.

  • Page 217: Passenger Compartment Storage/Fittings

    PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (1/4) Door pockets 1 Passenger storage compartment It can hold a bottle. Pull handle 2 to open it. The glove box can hold A4-size docu- ments, a large bottle of water, etc. Ensure that no hard, heavy or pointed objects are Nothing should be placed placed in the “open”...
  • Page 218 PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (2/4) Central storage Cup holders 6 compartment 4 Slide the curtain 5 to open the storage compartment. It may house a sliding cup holder system. Central storage When turning corners, compartment 3 accelerating or braking, Ensure that no hard, heavy ensure that the recepta- or pointed objects are...
  • Page 219 PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (3/4) Central storage Grab handle 9 compartment 8 This offers support and can be held when the vehicle is being driven. With the sliding armrest 7 in its rear- most position, raise it. Do not use it for getting into or out of the vehicle.
  • Page 220 PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (4/4) Rear door storage Front seat storage pockets 12 Rear armrest with cup holder compartment 11 Lower armrest 14. Rear central storage compartment 13 Ensure that no hard, heavy When turning corners, or pointed objects are accelerating or braking, placed in the “open”...

  • Page 221: Accessories Socket

    ASHTRAY/CIGAR LIGHTER/ACCESSORIES SOCKET Cigarette lighter 1 Ashtray 3 Accessories sockets With the ignition on, push in cigar It can be housed in either position 2. You can use the one of sockets 1. lighter 1, it will spring back with a click They are provided for connecting ac- To open, lift the cover.

  • Page 222: Rear Headrests

    REAR HEADRESTS Position for using the central Central headrest B storage To remove a headrest headrest A position Raise the headrest as far as it will go, then press button 1 and remove the Raise the headrest as far as possible to Press the button 1 and lower the head- headrest.

  • Page 223: Rear Bench Seat

    REAR BENCH SEAT When refitting the seat- back, make sure it is cor- rectly locked in place. To manually fold down the To replace the seatback, proceed in If seat covers are fitted, the reverse order to removal. make sure these do not prevent the seatbacks Refit the seatback and click it back into seatback latch from locking in.

  • Page 224: Luggage Compartment

    TAILGATE To open Opening manually from inside the vehicle Press button 1 and lift the tailgate. Special note: To close If it is impossible to unlock the tailgate, Lower the tailgate using the handles 2 it can be done from inside. inside the tailgate to help you.

  • Page 225: Rear Parcel Shelf

    REAR PARCEL SHELF Removal Lift rear parcel shelf 2 slightly and pull it towards you. Unhook the two cords 1 (tailgate side). To refit it, proceed in reverse order to removal. Do not place any objects, especially heavy or hard objects, on the parcel shelf.

  • Page 226: Luggage Compartment Storage

    LUGGAGE COMPARTMENT STORAGE Storage under the carpet Bag hooks 3 Anchorage points To gain access to this, lift the boot Maximum weight per hook: 5 kg. Attachment points 4 carpet 1 using the tab 2. If your vehicle is not equipped with anchorage points, you can get them from an authorised dealer.

  • Page 227: Transporting Objects In The Luggage Compartment

    TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT Always position the objects transported so that the largest surface is against: – The rear bench seatback for normal loads (example A). – The front seatbacks with the rear seatbacks folded down, as is the case for maximum loads (example B).

  • Page 228: Transporting Objects

    TRANSPORTING OBJECTS towbar A: 895 mm. Permissible nose weight, maxi- mum permissible towing weight, braked and unbraked: refer to the information on “Weights” in Section 6. Choice and fitting of towing equipment Maximum weight of towing equip- ment: 36 kg For fitting and conditions of use, If the towbar ball obscures the regis- refer to the equipment’s fitting in-...

  • Page 229: Roof Bars

    ROOF BARS Precautions during use Handling the tailgate Before handling the tailgate, check the objects and/or accessories (bike rack, roof box, etc.) fitted to the roof bars: these must be correctly positioned and secured, so as not to hinder the opera- tion of the tailgate.

  • Page 230: Multimedia Equipment

    MULTIMEDIA EQUIPMENT (1/2) Multimedia systems Hands-free telephone integrated control 1 Multimedia touchscreen display; 2 Steering column controls; For equipped vehicles, use the steering 3 Steering wheel controls; wheel controls 3. 4 Microphone. Using the telephone We remind you of the need to conform to the legislation in force concerning the use Refer to the equipment instructions...
  • Page 231 MULTIMEDIA EQUIPMENT (2/2) The sockets USB can also recharge ac- cessories with a maximum power rating of 12 Watts (voltage: 5V) per socket, which have been approved by our Technical Department. The JACK socket enables the radio to be used with an auxiliary cable. Multimedia sockets 5 You can use the USB ports or, de- pending on the vehicle, the SD card...
  • Page 232 3.44...
  • Page 233 Section 4: Maintenance Bonnet ............... . Engine oil level: general information .

  • Page 234: Bonnet

    BONNET (1/2) To open, pull handle 1, located on the Unlocking the bonnet catch left-hand side of the dashboard. To unlock, push tab 3 at the same time When working in the engine as opening the bonnet. compartment, ensure that the windscreen wiper stalk Opening the bonnet is in the park position.

  • Page 235: Closing The Bonnet

    BONNET (2/2) Closing the bonnet Check that nothing has been left in the engine compartment. To close the bonnet again, hold the bonnet in the middle and guide it down, allowing a 30 cm gap before it is closed, then release it. It will latch automatically under its own weight.

  • Page 236: Engine Oil Level: General Information

    ENGINE OIL LEVEL: general information It is normal for an engine to use oil for lubrication and cooling of moving parts and it is normal to top up the level be- tween oil changes. However, contact your approved Dealer if more than 0.5 litres is being In order to prevent splashback, it is consumed every 600 miles (1,000 km) recommended that a funnel be used...

  • Page 237: Engine Oil Level: Topping Up/Filling

    ENGINE OIL LEVEL: topping up, filling (1/3) Topping up/Filling – Unscrew cap 1; – top up the level (as a guide, the ca- The vehicle must be parked on level pacity between the minimum and ground and the engine should be cold maximum reading on the dipstick 2 (for instance, before the engine is is between 1.5 and 2 litres, depend-...
  • Page 238 ENGINE OIL LEVEL: topping up, filling (2/3) Before performing any action in the engine com- partment, the ignition must In order to prevent splashing, it is be switched off (please see Do not exceed the max level and recommended that a funnel be used the information on “Starting, stop- do not forget to refit cap 1 and dip- when topping up/filling the oil.

  • Page 239: Oil Change

    ENGINE OIL LEVEL: topping up, filling OIL CHANGE (3/3)/ Oil change Engine oil grade Service interval: refer Refer to the Maintenance Service Maintenance Service Booklet for your Booklet for your vehicle. vehicle. Oil change capacity Filling: take care when Please refer to the maintenance docu- topping up the oil that ment for your vehicle, or contact an au- no oil drips onto engine...

  • Page 240: Levels

    LEVELS (1/3) Checking intervals Replacement intervals Check the coolant level regularly Refer to the Maintenance Document for (very severe damage is likely to be your vehicle. caused to the engine if it runs out of coolant). If the level needs to be topped up, only use products approved by our Technical Department which ensure: –...

  • Page 241: Brake Fluid Level

    LEVELS (2/3) Level 2 Topping up It is normal for the level to drop as After any operation on the hydraulic cir- the linings become worn, but it should cuit, a specialist must replace the fluid. never drop below the “MINI” warning Only use fluids approved by our line.

  • Page 242: Windscreen Washer Reservoir

    LEVELS /FILTERS (3/3) Filters Liquid Windscreen washer fluid. In winter, use The replacement of filter elements (air anti-freeze product. Use products rec- filter, passenger compartment filter, ommended by an authorised dealer. diesel filter, etc.) is scheduled in the maintenance operations for your vehi- Note: Do not use pure water (risk of cle.

  • Page 243: Battery

    BATTERY (1/2) Depending on the vehicle, a system continuously checks the battery charge status. If this decreases, the message “Battery low start engine” is displayed on the instrument panel. In this case, start the engine. The message will go off. The charge status of your battery can decrease especially if you use your ve- hicle:...
  • Page 244 BATTERY (2/2) Replacing the battery As this operation is complex, we advise you to contact an approved Dealer. Label A Observe the indications on the battery: – 2 Naked flames and smoking are for- bidden; – 3 eye protection required; –...

  • Page 245: Tyre Pressure

    TYRE PRESSURE (1/2) Vehicle fitted with a tyre pressure monitoring system If under-inflated (puncture, low pres- sure, etc.), the warning light lights up on the instrument panel; please refer to “Tyre pressure loss warning” or “Tyre pressure monitoring system” in Section 2. Vehicle used fully laden (Maximum Permissible All-up Weight) and towing a trailer...
  • Page 246 TYRE PRESSURES (2/2) Tyre safety and use of snow chains: Refer to the information on “Tyres” in Section 5 for the servicing conditions and, depending on the version, the use of chains. For your safety, please re- spect the speed limit. When they need to be re- placed, only tyres of the same make, size, type and profile...

  • Page 247: Bodywork Maintenance

    BODYWORK MAINTENANCE (1/2) What you should not do You should A well-maintained vehicle will last longer. It is therefore recommended to Do not degrease or clean mechani- Wash your car frequently, with the maintain the exterior of the vehicle reg- cal components (e.g.
  • Page 248 BODYWORK MAINTENANCE (2/2) Vehicles with a matte paint Using a roller type car wash Respect local regulations about wash- ing vehicles (e.g. do not wash your ve- finish Return the windscreen wiper stalk to hicle on a public highway). the Park position (refer to the informa- This type of paint requires certain pre- Observe the vehicle stopping distances tion on the “Windscreen washer, wiper”...

  • Page 249: Interior Trim Maintenance

    INTERIOR TRIM MAINTENANCE (1/2) Glass instrument panel Textiles (seats, door trim, etc) A well-maintained vehicle will last longer. It is therefore recommended to (e.g.: instrument panel, clock, exterior Vacuum-clean the textiles regularly. maintain the interior of the vehicle regu- temperature display, radio display, mul- larly.
  • Page 250 INTERIOR TRIM MAINTENANCE (2/2) Removal/replacing removable You should not: equipment originally fitted in You are strongly advised not to po- the vehicle sition objects such as deodorants, scents, etc. near air vents, as this could If you need to remove equipment in damage your dashboard trim.

  • Page 251: Practical Advice

    RENAULT card: battery ........

  • Page 252: Puncture/Emergency Spare Wheel

    PUNCTURE/EMERGENCY SPARE WHEEL (1/2) In case of puncture Depending on the vehicle, a tyre infla- tion kit or emergency spare wheel is provided (refer to the following pages). Special note The Tyre Pressure Monitor function does not check the emergency spare wheel (the wheel replaced by the emer- gency spare wheel disappears from the instrument panel display).
  • Page 253 PUNCTURE/EMERGENCY SPARE WHEEL (2/2) Emergency spare wheel 3 To access it: – open the boot; This is located in the luggage compart- ment. – lift up the boot carpet 1 using the tab 2; – unscrew the central fixing located, depending on the vehicle, under the jack 4;...
  • Page 254 TYRE PRESSURE KIT (1/3) Do not attempt to use the The kit is only approved for inflation kit if the tyre has inflating the tyres of the ve- been damaged as a result hicle originally equipped of driving with a puncture. with the kit.
  • Page 255 TYRE PRESSURE KIT (2/3) With the engine running and the – after a maximum of 15 minutes, stop parking brake applied, inflating and read the pressure (on pressure gauge 5). – unroll the hose from the container; Note: while the bottle is emptying –...
  • Page 256 TYRE PRESSURE KIT (3/3) Precautions when using the Once the tyre is correctly inflated, remove the kit: slowly unscrew the in- flation end piece 1 to prevent any prod- The kit should not be operated for more uct spatter and store the container in than 15 consecutive minutes.

  • Page 257: Tools

    TOOLS Hubcap tool 3 This tool is used to remove the wheel trims. Screw guide 4 For tightening/loosening wheel bolts on vehicles fitted with alloy wheels Towing hitch 5 Refer to the information on “Towing” in Section 5. Wheelbrace 6 Tool kit storage Jack 1 Locks or unlocks the wheel bolts and...
  • Page 258 HUBCAP Remove using the hubcap tool 1 (lo- cated in the tool kit) by connecting the hook in the recess provided next to the valve 2 (to attach the metal clip). To refit it, align it with valve 2. Push the retaining hooks in fully, starting with side A near the valve, followed by B and C, finishing at D opposite the valve.

  • Page 259: Wheel Trim

    CHANGING A WHEEL (1/2) Vehicles equipped with a jack Place the jack 3 horizontally; the jack head must be lined up with the sill clos- and wheelbrace est to the wheel concerned, as shown If necessary, remove the wheel trim. by an arrow 1.
  • Page 260 CHANGING A WHEEL (2/2) Undo the bolts and take off the wheel. Fit the emergency spare wheel onto the hub and rotate it until the mounting holes in the wheel coincide with those of the hub. If bolts are supplied with the emergency spare wheel, only use these bolts for the emergency spare wheel.

  • Page 261: Tyres (Tyre And Wheel Safety, Use In Winter)

    TYRES (1/3) The tyres are the only contact between When the tread has worn down to the the vehicle and the road, so it is essen- wear warning strips, these strips will tial to keep them in good condition. become visible 2: it is then necessary to replace your tyres because the tread You must make sure that your tyres rubber is now only 1.6 mm deep at...

  • Page 262: Tyre Pressures

    TYRES (2/3) Tyre pressures The pressures should be checked cold: Vehicle fitted with a tyre pressure ignore higher pressures which may be monitoring system Adhere to the tyre pressures (including reached in hot weather or following a If under-inflated (puncture, low pres- the emergency spare wheel).
  • Page 263 TYRES (3/3) Fitting new tyres Use in winter Studded tyres This type of equipment may only be Chains used for a limited period and as laid For safety reasons, fitting snow down by local legislation. It is neces- chains to the rear axle is strictly for- For safety reasons, this op- sary to observe the speed specified by bidden.

  • Page 264: Headlights (Changing Bulbs)

    FRONT HEADLIGHTS: replacing the bulbs (1/2) LED dipped beam Halogen dipped beam Halogen main beam headlights 1 headlight 1 headlight 2 Please see an authorised dealer. To change the bulb: To change the bulb: – open the bonnet; – open the bonnet; –...
  • Page 265 FRONT HEADLIGHTS: replacing the bulbs (2/2) Front fog lights 7 Cleaning the headlights – Access the bulb holder via the un- Use a soft cloth. If this does not clean derneath of the vehicle; it properly, moisten the cloth with soapy –...

  • Page 266: Brake Lights

    REAR AND SIDE LIGHTS: changing bulbs (1/3) Side light 3 Access to the bulb holders 6 Brake lights 1 et 7 Consult an approved dealer. Turn bulb holder 6 a quarter of a turn and take out the bulb. Open the boot, remove the cover 4 to access the screw 5 and undo it.

  • Page 267: Reversing Lights

    REAR AND SIDE LIGHTS: changing bulbs (2/3) Reversing lights Turn bulb holder 9 a quarter of a turn High level brake light 10 and take out the bulb. From the boot, unclip the cover on the Consult an approved dealer. Bulb type: W16W.
  • Page 268 REAR AND SIDE LIGHTS: changing bulbs (3/3) Number plate lights 12 Side repeaters 13 et welcome lighting 14 – Unclip the light 12 (using a tool such as a flat-blade screwdriver). The wing mirror needs to be removed; consult an authorised dealer. –...

  • Page 269: Interior Lighting: Changing Bulbs

    INTERIOR LIGHTING: changing bulbs (1/2) Ambient lighting Please consult an authorised dealer. Map reading lights 1 Courtesy light 2 Please consult an authorised dealer. Please consult an authorised dealer. 5.19...
  • Page 270 INTERIOR LIGHTING: changing bulbs (2/2) Glove box light 3 Luggage compartment light 4 Unclip light 3 by pressing the tabs on Unclip light 4 by pressing the tabs on each side (using a flat-blade screw- each side (using a flat-blade screw- driver or similar).

  • Page 271: Fuses

    FUSES (1/2) Use the fuse allocation label on the back of flap A to identify the fuses. Certain fuses should only be replaced by a qualified professional. These fuses are not listed on the label. Only change the fuses represented on the label.
  • Page 272 FUSES (2/2) Allocation of fuses (the presence of certain fuses depends on the vehicle equipment level) Symbol Allocation Symbol Allocation Windscreen washer Towbar socket Ý Not used Not used ë Front cigarette lighter, front and rear second row Diagnostic socket, audio alarm Æ...

  • Page 273: Connecting A Battery Charger

    BATTERY: troubleshooting (1/2) To avoid all risk of sparks: Connecting a battery charger – Ensure that any consumers (cour- The battery charger must be com- tesy lights, etc.) are switched off patible with a battery with nominal before disconnecting or reconnect- voltage of 12 volts.
  • Page 274 BATTERY: troubleshooting (2/2) Starting the vehicle using the battery from another vehicle If you have to use the battery from an- other vehicle to start, obtain suitable jump leads (with a large cross section) from an approved dealer or, if you al- ready have jump leads, ensure that they are in perfect condition.

  • Page 275: Battery

    RENAULT lock/unlock the vehicle (please refer to Note: it is not advisable to touch the card: the information on “Locking/unlocking...

  • Page 276: Radio Frequency Remote Control: Batteries

    RADIO FREQUENCY REMOTE CONTROL: batteries Replacing the battery Note: It is not advisable to touch the electronic circuit in the key cover when Open the case at slot 1 using a flat- replacing the battery. blade screwdriver or similar, and re- place the battery 2, observing the po- larity shown on the back of the cover.

  • Page 277: Accessories

    ACCESSORIES Electrical and electronic accessories Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po- sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer. Connect accessories with a maximum power of 120 Watts only.
  • Page 278 WIPER BLADES: REPLACEMENT (1/2) Replacing windscreen wiper – In frosty weather, make blades 1 sure that the wiper blades are not stuck by ice (to With the ignition on and engine avoid the risk of the motor switched off, lower the windscreen overheating).
  • Page 279 WIPER BLADES: REPLACEMENT (2/2) To refit To refit the wiper blade, proceed in re- verse order to removal. Make sure that the blade is correctly locked in position. Rear screen wiper blade 4 Stalk in stop position (deactivated): – Lift wiper arm 6; –...
  • Page 280 Transport the vehicle on a trailer or tow RENAULT card on you, press the it with the front wheels off the ground. engine start button for 2 seconds. Reposition the lever to neutral (posi-...
  • Page 281 TOWING: breakdown recovery (2/2) Use the towing eye 5 only (refer to the information on the “tool kit” in Section 5). – Use a rigid towing bar. If a rope or cable is used (where the law allows this), the vehicle being towed must be able to brake.
  • Page 282 Dealer as soon as possible. Using the RENAULT card POSSIBLE CAUSES WHAT TO DO The RENAULT card does not lock or Card battery is flat. Replace the battery. You can still lock/ unlock the doors. unlock and start your vehicle (refer to the in- formation on “Locking, unlocking the open-...

  • Page 283: Operating Faults

    OPERATING FAULTS (2/7) The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact an approved dealer as soon as possible. Using the remote control POSSIBLE CAUSES ACTION REQUIRED The remote control does not lock or The remote control battery is flat.
  • Page 284 Starting conditions are not Please refer to the information on “Starting, stopping fulfilled. the engine” in Section 2. The RENAULT card does Please refer to the information on “Starting, stopping not work. the engine” in Section 2. The engine cannot be switched off.
  • Page 285 OPERATING FAULTS (4/7) On the road POSSIBLE CAUSES WHAT TO DO Vibrations. Tyres not inflated to correct pres- Check the tyre pressures: if this is not the sures, incorrectly balanced or dam- problem, have them checked by an ap- aged. proved Dealer.
  • Page 286 OPERATING FAULTS (5/7) On the road POSSIBLE CAUSES WHAT TO DO Steering becomes heavy. Assistance overheating. Consult an approved dealer. The engine is overheating. The cool- Engine cooling fan not working. Stop the vehicle, switch off the engine and ant temperature indicator is in the contact an approved dealer.
  • Page 287 OPERATING FAULTS (6/7) Electrical equipment POSSIBLE CAUSES WHAT TO DO The wipers do not work. Wiper blades stuck. Free the blades before using the wipers. Faulty electrical circuit. Consult an approved dealer. Fuse damaged. Replace the fuse, refer to the information on “Fuses”.
  • Page 288 OPERATING FAULTS (7/7) Electrical equipment POSSIBLE CAUSES WHAT TO DO Traces of condensation in the lights. Traces of condensation may be a nat- ural phenomenon caused by varia- tions in temperature. In this case, the traces will disappear slowly once the lights are switched The front seat belt reminder light An object is stuck between the floor Remove all objects from underneath the...

  • Page 289: Technical Specifications

    Section 6: Technical specifications Vehicle identification plates ............Engine identification plates .

  • Page 290: Vehicle Identification Plates

    VEHICLE IDENTIFICATION PLATES The information shown on the ve- 4 MMAC (Maximum permissible hicle identification plate should be all-up weight). quoted on all correspondence or 5 MTR (Gross train weight: vehicle orders. fully loaded, with trailer). 6 MMTA (Maximum Permissible The presence and location of the in- Weight) front axle.

  • Page 291: Engine Identification Plates

    ENGINE IDENTIFICATION PLATES (1/2) Please quote the information on the engine plate or label A in all corre- spondence or orders. (Location varies depending on engine) 1 Engine type. 2 Engine suffix. 3 Engine number.
  • Page 292 ENGINE IDENTIFICATION PLATES (2/2) Please quote the information on the engine plate or label A in all corre- spondence or orders. (Location varies depending on engine) 1 Engine type. 2 Engine suffix. 3 Engine number.

  • Page 293: Dimensions

    DIMENSIONS (in metres) 0,921 2,670 0,768 1,574 to 1,596 4,359 1,446* 1,565 to 1,599 2,058 * Unladen...

  • Page 294: Engine Specifications

    ENGINE SPECIFICATIONS Versions 1.2 TCe 1.6 16V 1.6 TCe 1.5 dCi 1.6 dCi Engine type H5F Turbo M5M Turbo (see engine plate) Cubic capacity (cc) 1197 1598 1618 1 461 1598 Diesel The label located in the fuel filler Type of fuel It is essential that you use unleaded petrol of the octane flap indicates authorised fuels.

  • Page 295: Weights

    WEIGHTS (in kg) The weights indicated are for a basic vehicle without options: they may vary depending on your vehicle’s equipment. Consult an approved Dealer. Maximum Permissible All-Up Weight (MMAC) Weights are indicated on the vehicle identification plate (refer Gross Train Weight (MTR) to the information on “Vehicle identification plates”...

  • Page 296: Replacement Parts And Repairs

    REPLACEMENT PARTS AND REPAIRS Original parts are based on strict specifications and are subject to highly-specialised tests. Therefore, they are of at least the same level of quality as the parts fitted originally. If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out within the manufacturer’s Network using original parts are guaranteed according to the conditions set out on the reverse of the repair order.

  • Page 297: Service Sheets

    SERVICE SHEETS (1/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 298 SERVICE SHEETS (2/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 299 SERVICE SHEETS (3/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 300 SERVICE SHEETS (4/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 301 SERVICE SHEETS (5/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 302 SERVICE SHEETS (6/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...

  • Page 303: Anticorrosion Check

    ANTICORROSION CHECK (1/5) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.15...
  • Page 304 ANTICORROSION CHECK (2/5) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.16...
  • Page 305 ANTICORROSION CHECK (3/5) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.17...
  • Page 306 ANTICORROSION CHECK (4/5) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.18...
  • Page 307 ANTICORROSION CHECK (5/5) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.19...
  • Page 308 6.20...

  • Page 309: Alphabetical Index

    ALPHABETICAL INDEX (1/5) bulbs ABS ...............2.30 → 2.39 changing ..........5.14 → 5.20, 5.20 accessories................ 5.27 accessories socket ........... 3.33, 3.43 catalytic converter........... 2.14 – 2.15 adaptive cruise control...........2.59 → 2.65 central door locking ....1.2 – 1.3, 1.5, 1.12 → 1.15, 1.19 additional methods of restraint .....1.27 →...
  • Page 310 ALPHABETICAL INDEX (2/5) dimensions ................6.5 display ........1.56 → 1.67, 1.64 → 1.67, 3.42 faults doors..............1.16 → 1.19 operating faults ..........5.32 → 5.38 doors/tailgate .............. 1.4, 1.12 filter driver’s position .............1.52 → 1.61 air filter ................. 4.10 driving ..2.2 → 2.7, 2.14 – 2.15, 2.17 → 2.24, 2.27 → 2.39, diesel filter ..............
  • Page 311 ALPHABETICAL INDEX (3/5) hands-free telephone integrated control ....3.42 – 3.43 hazard warning lights signal ..........1.51 lane departure warning ..........2.40 → 2.42 headlight beam adjustment ........1.85 – 1.86 levels: headlight flashers .............. 1.51 brake fluid ..............4.9 headlight washer ...........1.94 → 1.97 coolant ................
  • Page 312 ............... 5.26 multimedia (equipment) .......... 3.42 – 3.43 remote control door locking unit ........1.2 → 1.4 multimedia equipment ..........3.42 – 3.43 RENAULT ANTI-INTRUDER DEVICE (RAID) ....1.19 Multi-Sense..............3.2 – 3.3 RENAULT card battery ................5.25 use ..............1.6 → 1.12 navigation ...............
  • Page 313 ALPHABETICAL INDEX (5/5) steering wheel trims ..................5.8 adjustment ..............1.80 trip computer and warning system... 1.56 → 1.61, 1.68 → 1.77 Stop & Start ............2.10 → 2.13 tyre inflation kit............5.4 → 5.6 Stop & Start function..........2.10 → 2.13 tyre pressure......2.27 → 2.29, 4.13 – 4.14, 5.12 stopping the engine .............
  • Page 316 RENAULT S.A.S. SOCIÉTÉ PAR ACTIONS SIMPLIFIÉE AU CAPITAL DE 533 941 113 € / 13-15, QUAI LE GALLO 92100 BOULOGNE-BILLANCOURT R.C.S. NANTERRE 780 129 987 — SIRET 780 129 987 03591 / TÉL. : 0810 40 50 60 NU 1163-1 – 99 91 052 13R – 09/2015 – Edition anglaise...

Table of Contents
