TZ-AVL201 User Guide
V1.0.2
1 Product Overview................................................................................................................. 2
2. For Your Safety.................................................................................................................... 2
3. AVL201 Characteristics....................................................................................................... 2
4. Getting Start............................................................................................................................ 3
4.1 Hardware Features.................................................................................................... 3
4.2 Light and Button Functionality..................................................................................4
4.3First Use.........................................................................................................................6
5. Track by SMS and GPRS........................................................................................................7
5.1 Track by SMS................................................................................................................ 7
5.2 Track by GPRS between Server and Tracker............................................................... 8
6. Main function........................................................................................................................ 10
6.1 Geo-fence alarm.......................................................................................................10
6.2 Other useful function.................................................................................................. 10
7. The format of the GPRS....................................................................................................... 10
8. SMS instruction list...............................................................................................................13
10.Update the firmware of the AVL..........................................................................................17
Update User Guide............................................................................................................17
TZ-AVL201
GPS Tracker
User Guide V1.0.2
Contents
1
2014
May5
Advertisement
Table of Contents
Related Manuals for Tzone TZ-AVL201
Summary of Contents for Tzone TZ-AVL201
-
Page 1: Table Of Contents
TZ-AVL201 User Guide V1.0.2 2014 May5 TZ-AVL201 GPS Tracker User Guide V1.0.2 Contents 1 Product Overview......................... 2 2. For Your Safety........................2 3. AVL201 Characteristics....................... 2 4. Getting Start..........................3 4.1 Hardware Features....................3 4.2 Light and Button Functionality..................4 4.3First Use.........................6 5. -
Page 2: Product Overview
TZ-AVL201 User Guide V1.0.2 2014 May5 1 Product Overview Thank you for purchase our new charming product AVL201.The AVL201 is a GPS/GPRS based personal tracking unit, it provides an easy way to track your targets, for emergency and provide a reliable and accurate location information via SMS or GPRS to send to the cell phone or computer. -
Page 3: Getting Start
TZ-AVL201 User Guide V1.0.2 2014 May5 GPS Sensitivity -162Db GPS Frequency L1, 1575.42 MHz C/A Code 1.023 MHz chip rate Channels 20 channel all-in-view tracking Position Accuracy 10 meters, 2D RMS Velocity Accuracy 0.1 m/s Time Accuracy 1 us synchronized to GPS time... -
Page 4: Light And Button Functionality
TZ-AVL201 User Guide V1.0.2 2014 May5 4.2 Light and Button Functionality AVL201 I/O Port... - Page 5 TZ-AVL201 User Guide V1.0.2 2014 May5 port function I/O 1 I/O 2 I/O 3 I/O 4 Digital Input 3 I/O 5 Digital Output I/O 6 RESERVE I/O7 Digital Input 1 I/O8 Digital Input 2 Notes: The sequence of the 8 sockets in the diagram are for the corresponding sockets in the above picture.
-
Page 6: First Use
TZ-AVL201 User Guide V1.0.2 2014 May5 Green LED - indicating GSM status One call is coming in Flashing (on for 0.1 second and off for 2.9 seconds) AVL201 is connected to the GSM network Flashing (on for 1 second and off for 2 seconds) -
Page 7: Track By Sms And Gprs
TZ-AVL201 User Guide V1.0.2 2014 May5 4.4.1 Ensure that your AVL201 has a working SIM installed. - Check that the SIM has not run out of credit (Test the SIM in a phone to make sure it can send and receive SMS) -
Page 8: Track By Gprs Between Server And Tracker
TZ-AVL201 User Guide V1.0.2 2014 May5 Spd: 000km/h The speed of the tracker, the unit: KM/h Fix: A The tracker received the GPS signal. About Fix: V — have not get the GPS signal. Sat: 04 Received the GPS signal of four satellite HDOP: 01.2... -
Page 9: Set Apn
TZ-AVL201 User Guide V1.0.2 2014 May5 We use the IMEI number of the GSM module as the ID to identify the different devices. 5.2.1 Set APN Command: *$$$$$$,011,APN,Username,Password# Description: Set APN details for the tracker Note: 1. APN username and password are optional. If no APN username and password required, just input APN only. -
Page 10: Main Function
TZ-AVL201 User Guide V1.0.2 2014 May5 6. Main function 6.1 Geo-fence alarm You can set a geo-fence for the device, if the device in or out of the fence, it will send a alarm message. 6.2 Other useful function Get current location: *$$$$$$,000# ... - Page 11 TZ-AVL201 User Guide V1.0.2 2014 May5 $$A7355296038400938|AA$GPRMC,055605.000,A,2232.5946,N,11403.9026,E,0.00,,14071 0,,*18|02.5|02.3|01.0|000000000000|20100714055605|03780000|25337837|0000|0.0000 |0205|D410 Note: All multi-byte data is based on high-byte first, low-byte after for organization in this protocol. Code Explanation 2Bytes, indicates header of command from tracker unit to call centre, in ASCII code (hex is 0x24).
- Page 12 TZ-AVL201 User Guide V1.0.2 2014 May5 |+ LACCI(8 Bytes) + | + Temperature(4 Bytes) | +Mile-meter+| +Serial(4 Bytes) + | + Checksum (4 Byte) + \r\n(2 Bytes) Alarm type 0x01 IO-3 Open 0x42 Out Geo-fence Alarm 0x43 Into Geo-fence Alarm...
-
Page 13: Sms Instruction List
TZ-AVL201 User Guide V1.0.2 2014 May5 Eg：0345 mean +34.5℃，1234 mean +123.4℃，-123 means -12.3℃ Mile-meter(14 Bytes) —— Location information elements： Format is AAAA.BBBBKm. Four bytes after the radix point. Serial(4 Bytes) —— Serial number： Format：SSSS Every time reboot the device or reset,the serial number will initialize to 0001. - Page 14 TZ-AVL201 User Guide V1.0.2 2014 May5 alarm message. Y=0, Disable GEO-fence alarm. Y=1, Into GEO-fence alarm. Y=2, Out of GEO-fence alarm. Turns on Geo-fencing alarm. When the tracker moves in/out the preset scope,it will send an GPRS alarm to the server.
- Page 15 TZ-AVL201 User Guide V1.0.2 2014 May5 version. Initialization Tracker *$$$$$$,990,099# It will set all parameter to factory default value (Excluding the Password). Reboot by SMS command *$$$$$$,991# It will reboot the AVL201 by this SMS command. Clear data flash *$$$$$$,500#...
-
Page 16: Q&A
TZ-AVL201 User Guide V1.0.2 2014 May5 9. Q&A 1. Question: Unit will not turn on Answer: 1) Battery needs to charge. Resolution: 1) Recharge the unit for 2 hours. 2. Question: Turn on the unit, and come into sleep mode. -
Page 17: Update The Firmware Of The Avl
TZ-AVL201 User Guide V1.0.2 2014 May5 6. Question: Can`t connect the server via the GPRS. Answer: 1) SIM card in AVL201 doesn`t support GPRS function. 2) The APN is not correct. 3) Incorrect IP and Port 4) GSM signal is weak. - Page 18 TZ-AVL201 User Guide V1.0.2 2014 May5 2) Run FLY260 Floader_R2_9_6007.exe program, the interface is as follow, click the button in the red pane.
- Page 19 TZ-AVL201 User Guide V1.0.2 2014 May5 3) You will see the following interface, select the program file (XXXXX.pac) that need to be updated. 4) Click the button in the red pane.
- Page 20 TZ-AVL201 User Guide V1.0.2 2014 May5 5) Choose the Com Port that the RS232 Cable used...
- Page 21 TZ-AVL201 User Guide V1.0.2 2014 May5 6) Click the button in the red pane. 7) You will see the following interface .
- Page 22 TZ-AVL201 User Guide V1.0.2 2014 May5 8) Restart the module, update begins, the interface is as follow. 9) Update complete, the interface is as follow:...
- Page 23 TZ-AVL201 User Guide V1.0.2 2014 May5 10) Then click the stop button in the red pane of the following picture, Update complete. 11) Restart the module.
