Assembly And Use For The Shredding/Slicing And Grating Discs - Ninja BL200 series Owner's Manual

Assembly and Use for the Shredding/Slicing and Grating Discs

Fig. 12
CAUTION: Shredding/Slicing Disc and Grating Disc are sharp! Handle with care. Make sure that the appliance
is unplugged from the power source before inserting or removing the shredding/slicing or grating disc and
before cleaning.
IMPORTANT: Never feed food by hand. Always use the
food pusher to add food through the feeder tube on the
fully assembled unit.
IMPORTANT: Avoid contacting moving parts.
1 Place the motor base on a clean, dry, level surface such
as a counter or table top.
2 Align and lower the bowl onto the motor base. Handle
should be aligned slightly to the left of the "LOCK"
symbol on the motor base.
3
Rotate the container to the left as far as it will go to lock
in place.
4 Insert the spindle into the bowl. (Fig. 12)
5
Hold the disc by the plastic hub and carefully place
the shredding/slicing disc or the grating disc onto the
spindle. (Fig. 13)
Or
Fig. 13
6
7
8
9
10 The spindle, shredding/slicing disc, grating disc, lid and
Fig. 14
Holding the lid by the feeder tube, place it on top of the
bowl aligning the on/off switch with the bowl's handle.
(Fig. 14)
Place food into the feeder tube. Using the food pusher,
add food through the feeder tube. Push the on/off
switch forward to the "On" position. (Fig. 15)
When you have finished slicing, shredding or grating,
release the on/off switch to turn the appliance off. Wait
for the disc to stop turning and then remove the lid.
Hold the disc by the hub to remove and then remove the
spindle. Empty the food from the bowl.
food pusher are all top rack dishwasher safe.
CAUTION: SHREDDING/SLICING DISC AND
GRATING DISC ARE SHARP! HANDLE CAREFULLY
WHEN CLEANING.
www.sharkninjamanuals.com
On/Off
Switch
Fig. 15
10
