- Page 1 DLB100 Item ref: 154.291UK User Manual DMX LED Light Bar...
- Page 2 The DLB100 is supplied with mounting feet which allow the bar to tilt on its axis The mounting feet can be used to fix the DLB100 to a wall or ceiling if required If mounted at height, attach a drop cable for safety ...
- Page 3 Press to decrease value Setting up Connect the IEC inlet (1) of the DLB100 to mains power using the IEC mains lead provided. Power for additional DLB100 bars can be daisy-chained via IEC outlets (5) for up to 30 units.
- Page 4 Menu flow chart DMX Mode 1 DMX Mode 2 DMX Mode 3 154.291UK User Manual...
- Page 5 DMX Mode 4 DMX Mode 5 DMX Mode 6 154.291UK User Manual...
- Page 6 DMX Mode 7 154.291UK User Manual...
-
Page 7: Specifications
Specifications Power supply 90-270Vac, 50/60Hz (IEC) Fuse F1AL Power consumption Housing material Aluminium Housing colour Black Beam angle 40° LED type 10mmØ high output LED power 75mW LED lifespan 50,000 hours Total luminous flux 1910lm LED quantity 320 (128 red, 96 green, 96 blue) DMX channels 2, 3, 4, 8, 14, 24 or 48 Projection distance... - Page 8 154.291UK User Manual...
