- Page 4 8' 3" Notch at center of screen case. Case dimensions 6" high x 4-3/4" wide. Ceiling mounting bracket. Hardware by others. Wall mounting bracket. Hardware by others. DRAPER SILHOUETTE Isometric Mounting Detail Case Length Viewing surface DRAPER SILHOUETTE/M Dimensions & Data...
- Page 5 Bottom of viewing surface enclosed in dowel; dowel to disappear inside case 72" x 96" 8'3" when retracted. Note: All viewing surfaces will be seamless. 96" x 96" 8'3" Entire unit patented by Draper, Inc. (U.S. Patent No. 6,111,694) Nom. Viewing Case Net Wt. Qty. Diag.
