Page 2 VEHICLE RECORD SHEET Delivery Date Model Name Tyre Make V.I.N. Tyre Location Batch Code Engine No. Key No. Fr RH Regn. Date Registration No. Fr LH Transmission No. Rr RH Color, Code No. Battery Batchcode/Sl.No. Battery Make Rr LH Owner's Name Spare Address City...
Page 3 Naturally, these Chevrolet retailers knows everything there is to know about your car, and provides you with the best service possible. In fact, every retailer is equipped with the most advanced technology, technicians specially trained by us, and genuine spares. Needless to say, they are also committed to ensure your complete satisfaction.
Page 4 ABBREVIATIONS USED IN THIS MANUAL items covered may not apply to your vehicle. or * .....Variation (optional on some models). Contact your CHEVROLET retailer for information on option and trim availability......For diesel engine models only. Non-GMI Genuine parts and accessories have not ......For turbo charged 4JA1-L engine model.
Page 5: Table Of Contents
SECURING A CHILD RESTRAINT ....... 74 SERVICE AND WARRANTY ........167 Driver's check list (Regular inspection) ......77 24x7 ROADSIDE ASSISTANCE ......... 193 CHEVROLET SALES INDIA DRIVING ............... 88 SALES AND SERVICE NETWORK ......201 Preparation for starting engine ........88...
Page 7: Important Information
The following information is important for the proper care and economical operation of your CHEVROLET vehicle and should be thoroughly understood before placing it into service. It is advisable to write down the chassis and engine number as they are required when contacting your CHEVROLET retailer for repair services.
Page 8: Overloading
Engine number D The engine number is stamped on the left side of the cylinder block. OVERLOADING WARNING Overloading not only shortens the service life of your vehicle, but also creates serious potential safety hazards.
Page 9: Operation Of New Vehicle
OPERATION OF NEW VEHICLE The subsequent performance and the life of your vehicle are directly influenced by the care and treatment that your vehicle receives during the initial break-in period. It is therefore recommended that during the initial 1,000 km. break-in period, the following few simple precautions be carefully observed.
Page 10 Always let the engine idle until it becomes throughly warmed up. Avoid engine racing, abrupt starting and needless hard stops. This will allow your brakes to bed-in properly.
Page 11: Operation And Care Of Vehicle
“CONTROLS AND INSTRUMENTS”, “BEFORE DRIVING YOUR VEHICLE” and “DRIVING” sections. MAINTENANCE In order to maintain safe and dependable vehicle operation, inspection and adjustment should be performed as outlined in “SERVICE AND MAINTENANCE”. Your CHEVROLET retailer is willing to perform regular maintenance operation on your vehicle.
Page 12: Controls And Instruments
QUICK VIEW - CONTROLS AND INSTRUMENTS 1 Side Vent Cigarette Lighter /APO V 15 Brake Pedal 2 Center Vent Ashtray V 16 Accelerator Pedal 17 Hazard Warning Flasher Switch 3 Wiper & Washer Control Lever 10 Audio V 18 Head Lamp Leveling Device 4 Exterior Lights Control Lever 11 Hood Release 19 Rear Deffoger Switch...
Page 13: Steering Column Controls
STEERING COLUMN CONTROLS Steering wheel and horn button The horn button on the steering wheel operates the horn. CAUTION Avoid turning the steering wheel while the vehicle is stationary. NEVER move the vehicle with the steering locked, or damage to the steering assembly will result.
Page 14 “START” : Turning the key to this position will start the engine. The key returns to the “ON” position when released. WARNING NEVER attempt to turn the switch to LOCK while driving. This will cause the steering wheel to lock. If it is difficult to turn the key from LOCK to OFF, turn the steering wheel slightly in either direction while turning the key.
Page 15 Light switch To turn on the clearance lights, tail lights, license plate lights, instrument panel lights, turn the switch knob clockwise. To turn on the headlights and other lights, turn the switch knob clockwise to definite stop. Turn signal switch Move the switch lever in the direction of the turn to be made so that the signal lights operate, causing the turn signal indicator light on the instrument panel to flash.
Page 16 Dimmer switch The headlight beam is alternately switched from high to low or from low to high each time the lever is raised. The headlight high beam indicator on the instrument panel lights up when the headlights are in high beam. CAUTION Always switch the high beam headlamps to low beam when you approach oncoming vehicles or when other vehicles are ahead.
Page 17 Windshield Wipers To operate the windshield wiper, turn the ignition ON and move the windshield wiper / washer lever downward. The windshield wipers operate in the following four position : MIST REAR : System off. Default position. : Intermittent operation. Lever down one level : Continuous wipe, slow speed.
Page 18 Windshield Washer To spray the washer fluid on the windshield. Turn the Ign. switch ON. Ÿ Pull the windshield wiper / washer lever towards you. Ÿ MIST The lever will return automatically to its normal position when released. REAR CAUTION Do not operate the windshield washer continuously for more than 10 seconds, or when the washer fluid tank is empty.
Page 19 Windshield washer tank The tank should be filled only with plain water, GMI genuine washer solution or equivalent. In cold weather, do not fill the windshield washer fluid reservoir more than three quarters full. Washer fluid can freeze and expand in cold temperatures. Filling the reservoir too much does not allow enough expansion room to prevent possible damage to the reservoir.
Page 20: Instrument Panel And Controls
Front fog light switch V Fog lamps provide: • Extra illumination to the sides of the road ahead. • Improved visibility in fog or snow. To turn the fog lamps on: • Make sure that the parking lamp or headlamps are on. •...
Page 21 Rear window defogger switch V With the key turned on, push the rear window defogger switch to use the rear window defroster and defogger. The indicator light will turn on when this switch is in use. Turn off by pushing the switch again when the rear window is clear. NOTE Push to operate...
Page 22 9 seater Seating Position Specification Sr. No. One person in the driver seat The driver, plus one passenger in the front seat farthest from the driver The driver, one passenger in the front seat farthest from the driver, all the seats farthest to the rear occupied All the seats occupied All the seats occupied, plus an evenly distributed load in the luggage boot, in order to obtain the permissible load.
Page 23 METERS AND INDICATOR LIGHTS Temperature gauge Engine tachometer V 14 Water separator indicator light Turn signal indicator lights Oil pressure indicator light 15 Low fuel warning lamp Odometer 10 Generator indicator light Speedometer 11 Brake system indicator light Fuel gauge 12 High beam indicator light Trip counter 13 Engine coolant temperature...
Page 24 Speedometer The speedometer indicates the vehicle speed in kilometers per hour (km/h). Odometer The odometer registers the accumulated distance in kilometers. The figure on the extreme right indicates 1 kilometer.
Page 25 CAUTION If the gauge indicates overheating condition, stop the vehicle and keep the engine idling until coolant temperature lowers to a normal level. Do not drive the vehicle until problem has been solved. Consult your CHEVROLET retailer.
Page 26 Fuel gauge The fuel gauge indicates the level of fuel within the fuel tank when the starter switch is “ON”. The letters “F” and “E” represent “Full” and “Empty” respectively. When the key is turned to the “OFF” position the needle does not return to the (empty) mark but remains to indicate the approximate fuel level.
Page 27 Turn signal indicator lights When the turn signal switch or hazard warning flasher switch is turned on, the turn signal indicator light flashes to indicate operation of the turn signal lights or hazard warning lights. CAUTION These indicators are required for safe driving. Immediately replace any burned out bulbs in your turn signal and hazard warning flasher indicators.
Page 28 Stop the engine immediately and check the level of the oil in the engine crankcase after waiting for few minutes. If the oil level is normal, have the lubricating system checked at your nearest CHEVROLET retailer. Do not run the engine with the light illuminated.
Page 29 NOTE If the light comes on while driving, have the generator circuit checked at your nearest CHEVROLET retailer. Brake system indicator light The brake system indicator light comes on when the parking brake lever is pulled with the starter switch “ON”, or the brake fluid in the reservoir is lower than the...
Page 30 If you have been operating your vehicle under normal driving conditions, you should pull off the road, stop your vehicle and let the engine idle for a few minutes. If the lamp does not go out, you should switch the engine off and consult your CHEVROLET retailer as soon as possible.
Page 31 Dash panel parking brake V To set the parking brake, pull the handle as far as possible toward you. To release, pull the handle slightly toward you, turn the lever counterclockwise, and then push it all the way forward. CAUTION Never drive with the parking brake set as this may overheat or otherwise damage the parking brake mechanism.
Page 32 If the lighter does not spring back after 18 seconds, it is not operating and must be pulled out to the normal position by hand. Trying to operate a malfunctioning lighter can be dangerous. Consult you CHEVROLET retailer. CAUTION The barrel of an operating cigarette lighter can become very hot. Do not touch the barrel of the cigarette lighter.
Page 33: Floor Controls
APO – Auxiliary Power Output V The APO is installed on the rear side of the center console and on the front center console in selected variants. FLOOR CONTROLS 1 3 5 Transmission gearshift lever MT The transmission gearshift lever controls fully-synchronized transmission. The gearshift pattern is shown on the lever knob.
Page 34 WARNING If the brake pedal can be pressed further than normal, the brakes may be in need of repairs. Consult your CHEVROLET retailer immediately. NOTE Disc brake wear indicators: Front disc brakes have built-in wear indicators which are designed to make a high...
Page 35 where new linings are needed. The sound will come and go, or be heard all the time when the wheels are rolling, but may stop when the brake pedal is pushed down firmly. Extensive damage can result if the linings are not replaced when needed.
Page 36: Others
Clutch pedal The clutch pedal should be fully depressed when disengaging. Not doing so, may result in grating of the gears. NOTE Do not allow your foot to rest on the pedal when not using clutch. OTHERS Ventilators A pair of center air outlets is located in the center part of the instrument panel. The side air outlets are located at each end of the instrument panel.
Page 37 Center vents Two center vents are provided on the instrument panel. The knob at the center part of the grille controls direction of air flow vertically and horizontally. Side vents A side vent is located at each end of the instrument panel. The knob at the center part of the grille controls direction of air flow vertically and horizontally.
Page 38 Dome light V Front and rear side The dome light is operative at any starter switch position. “OFF” : The light stays off regardless of the door position. “ON” : The light will turn on and stay on regardless of the door position. When the dome light switch is at center position, the light will turn on while either* door is opened.
Page 39 RFID tag. In case of any damage or mal- function of RFID tag, or in case of windshield replacement, contact your CHEVROLET retailer or agency authorized by the Regulatory authority for the instal- lation of new RFID tag.
Page 40 HEATER-DEFROSTER AND AIR CONDITIONING 1 Air distribution mode knob 3 Temperature control knob 5 Air source select lever 2 Fan control knob 4 Air conditioning (AC) switch...
Page 41 Air d istribution mode knob The knob regulates air flow from the heater, defroster and air conditioning or ventilating outlets. 1. FACE OUTLET (Air to your face) 2. BI-LEVEL (Air to your face and feet) 3. FOOT OUTLET (Air to your foot) 4.
Page 42 BI-level Air is discharged from the upper air outlets and the floor air outlets. Foot outlet Air is delivered from the foot outlet.
Page 43 Foot outlet and defroster Air is delivered from the foot outlet with a small amount from the defroster outlets and the side window defroster outlets. Defroster Air is delivered from the defroster outlets with a small amount delivered from the side window defroster outlets.
Page 44 To defog glass: • Set air distribution mode knob to DEFROST. If set to FOOT/DEFROST, air will be sent to feet simultaneously with defogging. (Since airflow to glass is decreased, defogging capacity becomes lower than DEFROST). To defog glass more quickly: •...
Page 45 Temperature control knob V The temperature control knob controls the temperature of the air that comes through the air vents. Turn the knob to the blue area to get cool air and to the red area to get warm air. Max.
Page 46 Fan control knob V You may control the rate of airflow coming from the system by turning the fan speed control knob. Turn the knob clockwise to increase the fan speed and counterclockwise to decrease the fan speed. Adjust the fan control knob from step 1 to step 4 as you wish. NOTE Long-time maximum heating may cause fogged glass and poor visibility ahead.
Page 47 Air conditioning (AC) switch V Push this switch to operate the air conditioning system. The light-emitting diode in this switch lights up as the system is operating. To turn off the air conditioning push this switch in again. Air conditioning will not operate without the fan control knob in one of ON position.
Page 48 WHEN REMOVING FROST AND FOG FROM THE FRONT AND SIDE GLASSES Turn the Air distribution mode knob to the "DEFROSTING" position. NOTE When operating the air conditioner with the Air distribution mode knob set to the "DEFROSTING" position, do not set the air conditioner to the "MAXIMUM COOLING"...
Page 49 Rear cooler control lever V By sliding this lever, cool air is delivered from the cooler outlets, when the AC & Blower switch is in ON position. Air flow can be controlled in 3 steps. NOTE The rear cooler operates only when the front cooler is in operation. The switch is located on the center of duct.
Page 50 Sun Visors Your vehicle is equipped with sun visors to protect the driver and passenger* from glare. You can swing the sun visors up and down, and to the side. Vanity Mirror V The vanity mirror has been provided on the back of co-driver sun visor.
Page 51 Power window V Windows on either side of the vehicle can be opened or closed with the switch at the driver’s side. The windows operate only when the starter switch is “ON”. To open any of the passenger’s windows, push down on the switch and hold it down until the window reaches the desired position.
Page 52 WARNING • To assure the safety of children and others, make sure that all passengers have their hands, etc. inside the vehicle before opening and closing the windows. • Remove the key when leaving the vehicle to avoid unintentional window operation by children.
Page 53 Glove compartment The glove compartment is located on the passenger's side end of the instrument panel. To lock : Insert the key and turn it clockwise 90 degrees. To open : Insert the key and turn it counterclockwise 90 degrees. If the glove compartment is not locked (simply closed), it can be opened by pulling the handle.
Page 54 Spare wheel hanger The spare wheel is secured to the rear part of the chassis frame by chain. To lower the spare wheel, open the back door and take out the plug. Then insert the handle into the hole in the rear face of the vehicle to engage the catch and turn the handle counterclockwise.
Page 55 External lights Front side 1 Headlights and clearance lights 2 Front turn signal lights 3 Fog lights V Rear side 1 Turn signal lights 2 Back up lights 3 Tail and stop lights 4 Reflector...
Page 56 Tilt Quarter Window V 1. Pull the handle inward to unlock the window. 2. Push the handle outwards to open the window. 3. To hold the window in the open position, secure the handle in lock position by pushing it in the direction as shown.
Page 57 Engine hood release lever To raise the engine hood, unlock the hood lock by pulling the release lever under the instrument panel on the driver's side and unlock the safety catch under the engine hood. Raise the hood all the way up. To make the hood stay in position, be sure the support rod end engages in the hole in the hood reinforcement.
Page 58 Fuel tank filler cap The vehicle is equipped with a fuel door release mechanism. Pull up on fuel filler door release lever located on the floor, right front side of driver’s seat. Turn the fuel filler cap counter clockwise to open the fuel filler cap. To close the filler cap, turn clockwise until a clicking sound is heard (at least 3 clicks) NOTE...
Page 59: Before Driving Your Vehicle
BEFORE DRIVING YOUR VEHICLE OPERATION OF CONTROLS Two keys are provided with your new CHEVROLET. The key number is stamped on the key number plate. Record the key number and keep it in a safe place such as your wallet.
Page 60 Inside door handle/Door lock (inside) The door can be opened by pulling the inside door lock lever. Lock The door can be locked by pushing in the door lock knob after closing it. NOTE Before driving, be sure that the doors are closed and locked, especially when young children are in the vehicle.
Page 61 Locking and unlocking the power lock doors from the inside Push the driver's side door lock to lock all the vehicle doors and pull to unlock Lock them. Individual door locks can also be locked or unlocked by the passengers' side. Unlock Back door Lift to open...
Page 62 Back door inner handle V The back door can be opened by pulling the back door inner handle. Back door lock (Inside) The back door can be locked by pushing in the door lock knob after closing it. Lock NOTE Before driving, make sure that the door is closed and locked, especially when young children are in the vehicle.
Page 63 Child-proof door locks Rear doors can be locked by closing the door with the child-proof lever pushed towards arrow. Rear doors can not be opened from inside regardless of the position of the lock button. To unlock the child-proof lock, open the door from the outside and slide lever away from the arrow.
Page 64 Captain seat's with arm rest - Front and second row seat's only Seat slide adjustment To move the seat forward or backward : Pull up and hold the lever located under the front lower part of the seat. Slide the seat to the desired position. Release the lever.
Page 65 Seat back Front seat back inclination angle can be adjusted by raising the adjust lever on door side of seat. WARNING • To reduce the risk of injury and to ensure maximum seat belt effectiveness during a collision or a sudden stop, the seat should not be reclined any more than needed for comfort.
Page 66 Head restraint V Height adjustment The head restraints are adjusted for height. You need both hands to adjust the restraint. Press the release button and move the restraint up and down, so that your head is nearly centered on the head restraint. LOCK WARNING •...
Page 67 Folding type second seat V Folding the second seat The second seat can be folded forward to provide additional luggage space. Pull any of the lever upward on the either side of backrest and fold the seat back forward. Lift the entire seat and push it forward.
Page 68 Folding type second seat V Unfolding the second seat 1. Lift the entire seat. Some variants require pulling of lever as illustrated. 2. Raise the seat back. CAUTION Ensure that the latch area is clear of any objects. Center armrest V The center armrest can be pulled out when there are only 1 or 2 second row seat passenger.
Page 69 Folding type jump seat V Folding the jump seat 1. Tilt seat cushion (1) upward. 2. Tilt seat trigger (2) downward. 3. Secure the seat lock strap (3) to the seat back mounted hook. Unfolding the jump seat 1. Raise the seat trigger (2). 2.
Page 70 Folding type third seat Folding the third seat The third seat can be folded forward to provide additional luggage space. 1. Press the head rest sleeve knob to push the head rest down. 2. Pull the Strap (Black colour) down provide on the rear side of the back seat. 3.
Page 71 4. Pull the seat latch lever towards your side to detach the seat latch. 5. Lift the entire seat with rod and push the seat assembly forward. CAUTION Do not use seat latch lever to lift the seat.
Page 72 Attach the band (with hook) provided below the third seat to clasp on to the head rest of the second seat back. Removing the third seat V To remove the seat assembly, rotate the wheel knob in anti clockwise direction and pull the seat out.
Page 73 Folding type third seat Unfolding the third seat 1. Remove the clasping band from the headrest rod of the second seat back. 2. Lower the third seat, then raise the seat back. 3. Drop the seat assembly from height of about 200mm with backrest straight. 4.
Page 74 Front seat and rear seat lap/shoulder belts The front seat is equipped with a 3-point seat belt which features one buckle for the lap and shoulder belt. How to use the belt system properly in your vehicle is as follows: 1.
Page 75 (Continued) Position the lap portion of the belt across the lap by the hips as low as possible. Then adjust to a snug fit by holding the shoulder portion of the front seat belt and pulling it upward through the latch plate, until the lap portion is snug across the lap.
Page 76 (Continued) The shoulder portion of the front seat belt has an “Emergency locking retractor” which is designed to lock during a sudden stop or impact. At other times, it is designed to move freely with the seat occupant. To unfasten the belts, push in the center of the buckle.
Page 77: Child Restraints
Seat belt inspection and care • Periodically inspect belts, buckles, latch plates, retractors, and anchors for damage that could lessen the effectiveness of the restraint system. • Keep sharp edges and damaging objects away from belts. • Replace belts if cut, weakened, frayed, or subjected to collision loads. •...
Page 78 Selecting The Right System Children should travel facing rearwards in the vehicle as long as possible. This makes sure that the child's backbone, which is still very weak, is under less strain in the event of an accident. Children under 12 years or under 150 cm tall should only travel in an appro-priate child safety seat.
Page 79 NOTE Do not stick anything on the child restraint systems and do not cover them with any other materials. A child restraint system which has been subjected to stress in an accident must be replaced. Please ensure that infants and children are seated in the rear seats using child restraints.
Page 80: Securing A Child Restraint
SECURING A CHILD RESTRAINT This vehicle has the safety belt to secure the child restraint in 2nd Row - Outboard Seating Position Only. Be sure to follow the instructions that came with the child restraint. Secure the child in the child restraint when and as the instructions say. General Instructions 1.
Page 81 4. To tighten the belt, push down on the child restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt and feed the shoulder belt back into the retractor. If the child restraint system has a lock-off mechanism, use it to secure the vehicle safety belt.
Page 82 Inside rearview mirror: day and night V To adjust, move the mirror right or left and up or down. Switch the mirror to the night operation position to reduce the glare from following headlights. Outside rearview mirror Adjust the outside rear view mirrors so that you can see the each side of your vehicle in the portion of the mirror closest to your vehicle.
Page 83: Driver's Check List (Regular Inspection)
DRIVER'S CHECK LIST (REGULAR INSPECTION) The following checks should be performed to maintain safe and dependable vehicle operation. If any abnormal condition of the vehicle is found, consult your nearest CHEVROLET retailer. NOTE Refer to “MAINTENANCE GUIDE” for proper check-up procedures.
Page 84 Exterior 1. Check tires for inflation pressure and damage. 2. Check wheel nuts for looseness. Wheel nut torque: 118N·m...
Page 85 3. Check chassis springs for damage. 4. Check operation of lights. 5. Check level of electrolyte in each cell of the battery. Not required in vehicles fitted with maintenance free batteries.
Page 86 Check for any oil, water, fuel and brake fluid leakage. Check the setting angle of the rearview mirrors.
Page 87 Check operation of the door locking mechanism. Lock Unlock 9. Check clutch pedal free play, height and function.
Page 88 Within engine compartment 1. Check engine oil level. 2. Check accessory drive belt / fan belt tension.
Page 89 3. Check that the level of the power steering fluid is within “MAX” and “MIN” level. PS Check the tension of power steering pump drive belt.
Page 90 5. Check that the level of the windshield washer solution in reservoir tank is within “MAX” and “MIN” level. Back door side...
Page 91 6. Check that the level of the engine coolant in reservoir tank is within “MAX” and “MIN” level. WARNING Coolant level check or replenishment should be made at the reservoir tank and the radiator filler cap should not be removed unless necessary. 7.
Page 92 After starting engine With the engine running, check that oil pressure indicator light, generator indicator light and water separator indicator light go off and remain off. 2. Check brake pedal free play, height and function.
Page 93 3. Check for abnormal engine noise and color of exhaust gases.
Page 94: Driving
DRIVING Proper care and operation will not only extend the life of your vehicle but also improve oil and fuel economy PREPARATION FOR STARTING ENGINE Set the parking brake firmly. Place the transmission in neutral. STARTING ENGINE Turn the key to "ON." See if the oil pressure indicator light, generator indicator light, brake system indicator light and water separator indicator light comes on.
Page 95 2. Crank up the engine by turning the starter switch key fully clockwise. Release the key as soon as the engine starts. The key will return automatically to "ON." CAUTION Do not keep the starter engaged for more than 30 seconds at a time. If the starter is operated repeatedly, but the engine does not start, check the fuel system and electrical system.
Page 96: Before Driving Off
BEFORE DRIVING OFF Lock the doors. Lock 2. Adjust the seat position.
Page 97 3. Adjust the inside and outside mirrors. Fasten the seat belt.
Page 98: Stopping Engine
STOPPING ENGINE Turn the starter switch to the “ACC” or “OFF” position. Your vehicle is powered by a turbo diesel engine. Before turning the engine OFF, allow the engine to run for about 1 to 2 minutes at idle speed. PARKING When leaving your vehicle unattended: Set the parking brake.
Page 99: Driving Precautions
WARNING Do not park your vehicle over combustible materials, such as dry grass or leaves. They could touch the hot exhaust system and ignite. CAUTION Do not leave your vehicle unattended with the engine running. If the engine might overheat, you would not be there to react to the temperature warning light or gauge. This could result in costly damage to your vehicle and its contents.
Page 100 2. If abnormal noise or smell becomes noticeable while driving, stop the engine and check to locate the cause of trouble. 3. If the indicator lights or instruments give an indication of abnormal condition while driving, stop the engine and check to locate the cause of trouble.
Page 101 4. Avoid needless hard acceleration and hard stops. 5. Do not drive with your foot resting on the clutch pedal as it produces a partly disengaged condition, causing premature wear of clutch facing.
Page 102 6. Allow the vehicle to stop completely before shifting to reverse or to first gear after reversing. When starting the vehicle from rest, it is always advisable to use 1st gear not only on slopes but also paved roads. 7. When climbing a slope, shift to a lower gear to relieve the engine from overload before engine begins to strain.
Page 103 8. When descending a slope, shift to a lower gear to gain retardation effect of the engine. 9. Repeated use of the foot brake on a long downgrade will cause the brakes to lose their effectiveness.
Page 104 10. When driving across a shallow river or patch of water, extreme care must be exercised or water may enter the air duct causing serious engine damage. After driving across water, check gear oil in rear axle, and transmission case for presence of water.
Page 105: Driving For Economy Mt
If such a sound is produced, have the brake pads or linings replaced at your CHEVROLET retailer. DRIVING FOR ECONOMY MT 1. Needless high-speed driving and slow driving in high gears will result in...
Page 106 2. After accelerating, shift to a higher gear and engage the clutch smoothly. 3. After shifting to top or overdrive, maintain your speed constant as possible.
Page 107 4. Always drive with the coolant temperature within the normal range. 5. Under-inflated tires cause deterioration in fuel economy.
Page 108: In Case Of Emergency
IN CASE OF EMERGENCY Emergency stop 1. If you must stop your vehicle on the road for some reason, pull your vehicle over to the left side of the road as far as possible and try not to park in a driving lane.
Page 109 Emergency starting WARNING Never tow the vehicle to start the engine because when the engine starts it could cause a collision with the towing vehicle. WARNING Exercise extreme care when handling the battery to avoid serious personal injury and damage to your vehicle which might result from battery explosion, acid burns, electrical burns, or damaged electric components.
Page 110 4. Increase the idling speed of the engine on the other vehicle a little and start the engine on the damaged vehicle. 5. If the engine starts, disconnect the cable following the above procedure in reverse. CAUTION Never connect the cable between the positive and negative terminals. Do not remove the battery cables from the terminals while the engine is running.
Page 111 WARNING Do not pump the brakes when the power assist has been lost, except when necessary to maintain steering control on slippery surfaces. Without the power assist, the vehicle can still be stopped by pushing harder on the brake pedal. However, the stopping distance may be longer, even though the brakes themselves remain fully operational.
Page 112 Front wheels off the ground 1. Transmission in Neutral. 2. Maximum speed: 60km/h. 3. Maximum distance: 80km. NOTE For distances over 80km disconnect the rear propeller shaft at rear axle carrier and secure it in a safe position. Rear wheels off the ground 1.
Page 113 Bleeding of fuel system If the fuel tank is emptied, air might be allowed to go into the fuel system. With air in the fuel system, smooth flow of fuel into the engine is interrupted. To prevent this, bleed the fuel system. 1.
Page 114 4. After starting the engine, check that there is no fuel leakage from the drain plug. Also check that the water separator indicator has turned off. CAUTION If water separator requires frequent draining, have the fuel tank drained at your CHEVROLET retailer.
Page 115 Jacking instructions and changing a flat tire Vehicle front side The common tool and jack (1) are stored under the front passenger seat. The jack bar(2) is stored under the 2nd row seat assembly on selected variants. Jack Bar storage ( on selected variants) Insert the Jack Bar in velcro pocket given on left side of cushion of 3rd row front facing seat.
Page 116 SCISSOR TYPE JACK ASSEMBLY Jack Store the jack and common tool in toolkit bag and securely strap them under the front passenger seat. CAUTION Do not store jack, spare tyre or other equipment other than specified location. In sudden stop or collision, loose equipment can be thrown around inside your vehicle and cause personal injuries.
Page 117 7. Place the jack at correct jacking point. Front : Concave position on bottom surface of attachment bracket under the side frame. Rear: Under the Rear Axle Tube.
Page 118 WARNING Do not jack up the vehicle on a slope or a soft ground. It is very dangerous. Do not jack up on any points other than specified jack points. l Never use a jack designed for another vehicle to lift your vehicle, or use your jack to lift another vehicle.
Page 119 2. Install and semi-tighten the wheel nuts and lower the wheel to the ground. 3. With the wheel wrench, tighten the wheel nuts in sequence as shown in the figure. Wheel nut torque: 118N·m (12 kgf-m/87 ib-ft) WARNING Make sure to use proper nuts or bolts tightened to the proper torque. Using incorrect parts or improperly tightened wheel nuts or bolts can cause wheel to come off the vehicle.
Page 120: Service And Maintenance
To ensure driving safety and maximum economical operation, periodic inspection and maintenance should be performed at your CHEVROLET retailer according to the maintenance schedule. For service operations which call for disassembly or specialized instruments, contact your CHEVROLET retailer. Maintenance operations...
Page 121: Maintenance Schedule
Maintenance schedule I: Inspect and correct or replace as necessary A: Adjust R: Replace or change T: Tighten to specified torque L: Lubricate x 1,000 km SERVICE INTERVAL: (Use odometer reading or months, whichever comes first) 102108 114 120 * Under severe conditions, additional maintenance is required. Refer to "Maintenance schedule under severe conditions"...
Page 122 Maintenance schedule I: Inspect and correct or replace as necessary A: Adjust R: Replace or change T: Tighten to specified torque L: Lubricate x 1,000 km (Use odometer reading or months, whichever comes first) 102108 114 120 * Under severe conditions, additional maintenance is required Refer to "Maintenance schedule under severe conditions"...
Page 123 102108 114 120...
Page 124 Maintenance schedule I: Inspect and correct or replace as necessary A: Adjust R: Replace or change T: Tighten to specified torque L: Lubricate x 1,000 km SERVICE INTERVAL: (Use odometer reading or months, whichever comes first) 102108 114 120 * Under severe conditions, additional maintenance is required Refer to "Maintenance schedule under severe conditions"...
Page 125 (Use odometer reading or months, whichever comes first) 102108 114 120 Wheel Alignment and Wheel Balancing As and when required or as suggested by CHEVROLET retailer * Under severe conditions, additional maintenance is required Refer to "Maintenance schedule under severe conditions"...
Page 126 Maintenance schedule under severe driving conditions Severe driving conditions Repeated short trips Driving on rough roads Driving on dusty roads Driving in extremely cold weather and/or on salted roads Condition Item Interval Engine oil Change every 5,000 km Engine oil filter Replace every 5,000 km Exhaust pipes and mounting Inspect every 5,000 km...
Page 127 Maintenance schedule under severe driving conditions Severe driving conditions Repeated short trips Driving on rough roads Driving on dusty roads Driving in extremely cold weather and/or on salted roads Condition Item Interval Change every 20, 000 km Differential oil after changing at initial 10,000 km Front brake pads and discs Inspect every 5,000 km Rear brake lining and drum...
Page 128: Maintenance Guide
MAINTENANCE GUIDE REGULAR INSPECTION Engine oil level Pull out the level gauge rod (oil dipstick). Wipe clean it and reinsert. Again pull it out and check that oil level is within high and low level marks. Also check the oil on the gauge rod for contamination. NOTE Engine oil level should be checked with the vehicle parked on level ground (before the operation of engine).
Page 129 Accessory drive belt/Fan belt Check that the accessory drive belt/fan belt gives specified deflection when the middle part of the belt is depressed with a force of 10 kg. Also check the belt for cracks and damage. CAUTION Do not leave the key in the ignition while checking the drive belts. Moving parts of an operating engine can cause serious injuries.
Page 130 Coolant level WARNING When the coolant is heated to a high temperature, be sure not to loosen or remove the radiator cap. Otherwise you might get scalded by hot vapor or boiling water. To open the radiator cap, put a piece of thick cloth on the cap and loosen the cap slowly to reduce the pressure or when the coolant has become cooler.
Page 131 NOTE If the steering parts have excess play or looseness or if any abnormal condition is noted, have your CHEVROLET retailer check the steering system immediately. Parking brake lever travel Dash panel parking brake lever travel must be 8 to 12 notches (When pulled with a force of 30 kg.)
Page 132 Brake and clutch (MT) fluid level Check that the brake and clutch fluid reservoir is filled up to the level mark. If the level is too low, replenish with the recommended hydraulic brake fluid. WARNING If the brake indicator light comes on while driving, the fluid reservoir should be filled to the level mark with the recommended hydraulic brake fluid.
Page 133 Windshield washer solution level Check that the washer tank is filled sufficiently with solution. Also check the operating condition of the windshield washer. CAUTION Insert the lever portion of the cover first while re-fitting to prevent any damage to the same.
Page 134 Clutch pedal free play and height Standard value : mm (1) Free play : 5-15 (2) Height : 168-178 Brake pedal free play, height and allowance Standard value : mm (1) Free play : 6-10 (2) Height : 164-174 (3) Allowance : More than 55 (When depressed with a force of the 50 kg)
Page 135 PERIODIC MAINTENANCE Air cleaner Use of fouled air cleaner element not only cause a deterioration in the engine output but also give a raise in fuel consumption and dark exhaust smoke. The air cleaner element should be serviced in the following manner: CAUTION The cover should be reinstalled after aligning the setting marks to prevent dust from entering.
Page 136 Dry paper element cleaning To clean the element, apply the following method. When the element is fouled with dust but dry: Apply compressed air to the element from inside while turning the element by hand. Pressure of compressed air should not exceed 490 KPa (5 kg/cm / 71 psi) CAUTION It is strongly advisable to use the GMI genuine air cleaner element at the time of replacement.
Page 137 Oil filter 1. Loosen the oil filter by turning it counterclockwise with a filter wrench. 2. With a rag, wipe the fitting face of the oil cooler clean so that the new oil filter can be seated properly. 3. Lightly oil the O-ring and turn the oil filter until the sealing face is fitted against the O-ring.
Page 138 Fuel filter with water separator 1. Loosen the fuel filter turning it counterclockwise with a filter wrench and remove it. 2. Then loosen the level sensor by turning it counterclockwise with a wrench and remove it from the fuel filter. 3.
Page 139 4. Wipe the fitting face of the filter cover clean with a rag, so that the new fuel filter can be seated property. 5. Lightly oil the O-ring and turn in the fuel filter until the sealing face is fitted against the O-ring. Further turn 2/3 turns with the filter wrench.
Page 140 Valve clearance adjustment D 1. Bring the piston in the No. 1 cylinder to the top dead center (T.D.C.) on compression stroke by turning the crankshaft until T.D.C. line on damper pulley is aligned with the timing pointer. CAUTION Check the rocker arm shaft bracket nuts for looseness and retighten as necessary before adjusting the valve clearances.
Page 141 3. Adjust the clearance of the valves indicated by arrows. 4. Turn the crankshaft one full turn (360 degrees) and adjust the clearances of the valves indicated by arrows.
Page 142 Clutch pedal adjustment 1. Adjust the pedal height by loosening lock nut (2) and turn push rod (1). 2. After adjustment, tighten lock nut (2). 3. Drive in (3) so that (L) becomes 0.5 to 1.5 mm (0.02 - 0.05 in) then lock (4) to adjust free play.
Page 143 Brake pedal adjustment The push-rod serves as the brake pedal stopper when the pedal is fully released. Brake pedal height adjustment should be performed as follows. Measure the brake pedal height after making sure the pedal is fully returned by the pedal return spring. If the measured value deviates from the specified pedal height, adjust the brake pedal as follows.
Page 144 Parking and service brake All brakes are self-adjusting. Brakes are adjusted by repeated stepping on the brake pedal. The dash panel parking brake adjustment should be performed as follows: (1) Release the parking brake lever fully. (2) Loosen the lock nut (A). (3) Repeat stepping the brake pedal firmly, and releasing it until the rear brake auto-adjuster completes the function.
Page 145 To check the floor mounted parking brake stroke, do the following: 1. Turn engine off. 2. Apply parking brake, counting notch clicks you hear. If the number of clicks differs from the specification (7 ~ 10 notches), have your CHEVROLET retailer adjust the parking brake. Tire rotation When the front and rear tires are the same size, rotate the wheels as shown in the figure.
Page 146 Tire inflation pressure Standard inflation pressure for tires are listed below. NOTE Check tire pressure when the tires are cold (after the vehicle has been inoperative for more than 3 hours or driven less than 1.6 km. Tire pressure-kg/cm (PSI) Tire Size Front Rear...
Page 147 Tire pressure label The tire pressure label is located on the frame of driver's side. Specific gravity of battery electrolyte If your new vehicle has a maintenance-free battery, you will never have to add water, instead install a new battery. Do not try to jumpstart the vehicle or charge it or test the battery if the fluid level is below the lower level line on side of the battery.
Page 148 Cleaning of battery If the external part of the battery is fouled, clean with tepid water. Apply a thin coat of vaseline or grease onto the battery terminals to prevent corrosion. WARNING When reconnecting the cable to the battery be careful to ensure the clamps are fully seated, then tighten the retaining bolts so that clamps will not vibrate loose.
Page 149 Headlights Proper aiming of the headlights is most important in ensuring sufficient illumination on the highway without blinding other motorists. When light aiming is necessary it is advisable to contact an authorized retailer who has special equipment for this purpose. NOTE When replacing a bulb, make sure the light switch is “OFF”.
Page 150 Rear combination light Unscrew each of the two screws securing the lens License plate light Unscrew the two screws securing the lens.
Page 151 Dome light The lens can be removed easily by hand then remove the bulb from the socket by pulling it. Replacing light bulbs When replacing a bulb, make sure the light switch is “OFF”. Use only bulbs with the same wattage rating. The standard bulb wattage ratings are given below.
Page 152: Bulb Specification
BULB SPECIFICATION Bulb Wattage x Quantity Remark Headlamp (High/Low) 60/55W x 2 Halogen Parking Lamp 5W x 2 Turn Signal Lamp 21W x 2 Front Turn Signal Lamp (LT) 21W x 2 Amber Fog Lamp (LT) 27W x 2 Halogen Side Turn Signal Lamp 5W x 2 Amber...
Page 153 When replacing a fuse, it is important to use a spare fuse of the amperage shown on the fuse junction block cover. If the spare fuse also burns out, have the circuit checked at your nearest CHEVROLET retailer. Normal Burned out...
Page 154 Fuse Box: Engine Room 30 A 30 A 30 A REV LP COND (P / W) (ECU) LAMP LAMP LAMP LAMP LAMP LAMP (PW WND) / HORN DIMMER (REV LP) COND RR DEF USE SPECIFIED FUSES ONLY. UNSPECIFIED FUSES CAN CAUSE FIRE AND P.
Page 155 Fuse Box : Instrument Panel D Fuse No. Capacity Indication on label ENGINE FT. WIPER RR. WIPER TURN, BACK AUDIO (ACC), CIGAR...
Page 156: Recommended Lubricants And Diesel Fuels
RECOMMENDED LUBRICANTS AND DIESEL FUELS In order to obtain maximum performance and longest service life from your CHEVROLET vehicle, it is very important to use lubricants and diesel fuels selected and listed in the chart. The lubrication intervals in the maintenance schedule and application of the New Vehicle Warranty are based on the use of recommended lubricants as given in the chart, which will serve as a guide for selecting lubricants of proper grade.
Page 157 DIESEL FUELS APPLICABLE STANDARD RECOMMENDATION JIS (Japanese Industrial Standard) No.2 DIN (Deutsche Industrie Normen) Din 51601 SAE (Society of Automotive Engineers) No. 2-D Based on SAE J-313C BS (British Standard) Class A-1 Based on BS/2869-1970...
Page 158: Lubrication
LUBRICATION Lubricants should be carefully selected according to the lubrication chart. It is also important to select viscosity of lubricants according to the ambient temperature by referring to the following table. OIL VISCOSITY CHART FOR DIESEL ENGINE...
Page 159 OIL VISCOSITY CHART FOR REAR AXLE...
Page 160 OIL VISCOSITY CHART FOR TRANSMISSION CASE...
Page 161: Lubrication Guide
LUBRICATION GUIDE Changing engine oil Drain the engine crankcase completely by removing the drain plug on the lower part of the oil pan while the engine is hot and then install the drain plug. Next fill the engine crankcase from the filler port with new engine oil of the specified grade.
Page 162 Changing transmission oil Drain the transmission case by removing the drain plug (D) on the lower face of the transmission case. Fill the transmission case to the level with the specified oil through the level plug hole (L). CAUTION Make sure the transmission is cool before you attempt this procedure. Do not overfill the manual transmission fluid.
Page 163 Changing power steering fluid PS Draining Jack up the front wheels until they are clear of the ground. Remove the fluid hose between the steering unit and the fluid reservoir. When draining is completed, remove remaining fluid within hydraulic system by turning the steering wheel fully in both directions several times.
Page 164 With the engine stationary, turn the steering wheel fully in both directions several times. NOTE While bleeding check the fluid level and replenish if necessary. With the engine idling turn the steering wheel fully several times in both directions CAUTION Avoid turning steering wheel to lock and holding it there for more than 5 seconds, or the fluid temperature will increase sharply.
Page 165 Check level of fluid in the fluid reservoir, then check joints for leakage. RE-PACKING FRONT HUB BEARING WITH GREASE It is suggested that the vehicle be taken to your CHEVROLET retailer when the above operation becomes necessary as the operation calls for disassembly and...
Page 166: Main Data And Specifications
MAIN DATA AND SPECIFICATIONS DIMENSION Overall length 4435 Overall width 1680 Overall height 1765 Wheel base 2685 Wheel track 1445 Front 1420 Rear Min. ground clearance WEIGHT 2550 Gross vehicle mass (8, 9, 10 Seater) Gross vehicle mass (7 Seater) 2510 Gross vehicle mass (Ambulance) 2185...
Page 167 Exhaust Idle speed 800 ± 25 @ No Load Firing order 1-3-4-2 Fan belt tension mm/10kg 9~13 Compressor / Power steering belt mm/10kg 14 ~17 Service change engine oil capacity (with filter changes) liters 4.3~5.3 (without filter changes) liters 3.5~4.5 Coolant capacity liters Fuel tank capacity...
Page 168 Pedal free play 5-15 TRANSMISSION Model and type MSG5K: 5-speed, fully synchronized manual transmission with a constant mesh type reverse gear Gear ratio (to 1) position Rev. MSG5K 4.12 2.49 1.50 1.00 0.86 3.72 1.55 Lubricant capacity liters...
Page 169 MAIN DATA AND SPECIFICATIONS REAR AXLE Type Spiral bevel & hypoid gear, semi-floating Gear ratio (to 1) D 3.909 Oil capacity liters Filler & drain plug torque kg.m 2.0-3.5 STEERING Type Recirculating ball Steering wheel free play 10-30 Wheel alignment Toe-in 2 ±...
Page 170 PARKING BRAKE Type Mechanical internal-expanding, action on rear wheels. Brake lever travel (notches) IP mounted 8-12 (When pulled with force of 30kg) Floor mounted 7-10 (When pulled with force of 20kg) WHEEL AND TIRE Tire size 205/65R15 99S Wheel dimension 6JJ X 15 2.2/2.4 (Front/Rear) or 1.8/2.4 (Front/Rear) PS Tire pressure...
Page 171 Refrigerant Specified Amount (R134a) SINGLE 725 DUAL...
Page 173: Service And Warranty
SERVICE AND WARRANTY...
Page 175 Service Certificate 1st Owner 3rd Owner Customer name Customer name Registration no. Registration no. 2nd Owner Customer name Registration no.
Page 176: Predelivery Inspection And Vehicle Delivery
Vehicle Delivery Before delivering the vehicle we carried out a thorough predelivery inspection in order to ensure that your CHEVROLET vehicle is in a fault- free condition. Accompanying this appropriately filled out service booklet are the owner's manual, the tool kit and your vehicle documents.
Page 177 Owner’s Statement of Acceptance I hereby certify that the vehicle has been delivered in an orderly and proper operating condition, including keys, owner's manual, service booklet and tool kit. I have read and understood the terms and conditions pertaining to the New Vehicle Warranty and agree to abide by the same.
Page 179 I confirm that the vehicle has been inspected and delivered to my satisfaction. In the unlikely event of an emergency assistance, please call Customer signature your nearest CHEVROLET retailer as mentioned in this booklet or please feel free to call our 24 hr. helpline at 1800 3000 8080.
Page 180 1000 kms Reassurance check-up General Status review Hazard indicator & all other telltale lamp Check closing efforts of doors, key less entry system, sunroof Cigarette lighter/rear defogger & other functions auto cut off Under hood Check lighting system Visually check routing, leaks & Horn/Radio/OutsideMirrors/ damage auto parking mode...
Page 181 CHEVROLET Inspection CHEVROLET Inspection 1st Service Check Six months /5000 kms whichever occurs 2nd Service Check One Year /10000 kms whichever occurs earlier earlier Regn. No: Regn. No: Delivery Date Delivery Date Date : Date : Kms: Kms: I confirm that the job has been attended to my satisfaction.
Page 182 Delivering retailer's stamp & date Delivering retailer's stamp & date I hereby certify that the work has been carried out as per the I hereby certify that the work has been carried out as per the schedule. schedule. Servicing retailer's / ASO stamp &...
Page 183 CHEVROLET Inspection CHEVROLET Inspection 3rd Service Check Eighteen months/15000 kms whichever 4th Service Check Two Years /20000 kms whichever occurs occurs earlier earlier Regn. No: Regn. No: Delivery Date Delivery Date Date : Date : Kms: Kms: I confirm that the job has been attended to my satisfaction.
Page 184 Delivering retailer's stamp & date Delivering retailer's stamp & date I hereby certify that the work has been carried out as per the I hereby certify that the work has been carried out as per the schedule. schedule. Servicing retailer's / ASO stamp &...
Page 185: Maintenance Record Sheet
MAINTENANCE RECORD SHEET (Repair category - Free Service/Paid Service/Running Repair/Acc. Repair) Repair Name of Servicing Service Repair Details of Repair Done Retailer Stamp R.O. No. Kms. Adv. Sign. Date Category Retailer...
Page 186 MAINTENANCE RECORD SHEET (Repair category - Free Service/Paid Service/Running Repair/Acc. Repair) Repair Name of Servicing Service Repair Details of Repair Done Retailer Stamp R.O. No. Kms. Adv. Sign. Date Category Retailer...
Page 187 DO NOT USE GREASE. Battery top & vent plugs must always be kept clean & dry . Electrolyte level must always be maintained in line with the CHEVROLET Retailer’s bottom of the vent hole. In case of any drop in electrolyte level, Stamp add pure distilled water.
Page 188 Battery Service Record Retailer stamp & Voltage Specific Gravity Remarks Date signature...
Page 189: Standard Limited Warranty Coverage
Works/Registered office at Chandrapura Industrial Estate, Halol, District Panchmahals, Gujarat 389351 (“General Motors India”) warrants that your new Chevrolet Tavera (“Vehicle”) is free from defect in material or workmanship, subject to your compliance with the following terms and conditions mentioned hereunder and other vehicle maintenance norms as mentioned elsewhere in this service booklet.
Page 190 The obligation under this New Vehicle Warranty is limited to the repair of the new motor vehicle at no charge by the CHEVROLET authorized retailer during the New Vehicle Warranty period. For parts replaced during such repair the same warranty applies until the end of the New Vehicle Warranty period as stipulated herein.
Page 191 Warranty repair not performed by a Chevrolet authorized retailer. chipping, scratches, iron dust or any other extraneous Charges or fees for telephone, tow, transportation charges of the circumstances like external mechanical or chemical influences vehicle to the nearest Chevrolet authorized retailer, rental car, and...
Page 192 Fuses, etc. Spring bushing MAKING THE WARRANTY EFFECTIVE The warranty goes into effect after Chevrolet authorized Retailer fills in the appropriate information about your vehicle and places the No warranty repair shall be made if it is found that the vehicle retailer's official seal and signature in the warranty &...
Page 193 EXPENSES ASSOCIATED WITH WARRANTY WORK The expenses of repair work and parts of your Chevrolet will be covered by Chevrolet standard limited warranty in accordance with the WARRANTY & SERVICE BOOKLET. Other expenses that are not covered by the Chevrolet Standard Limited Warranty must be covered by the owner.
Page 194: Emission Warranty
Sr. No. 3 above with the authorized by the GMI, the vehicle is limit of the product Warranty (Chevrolet instructions in the Owner ‘s Manual (OM). discovered to be failing to meet the emission...
Page 195 In-use emission standards on the vehicle which the failure is discovered, the test 6. A vehicle on which the odometer is not not meeting any such given legal/ having been carried out either for obtaining functioning or the odometer has been regulatory requirement, during inspection a new certificate, or pursuant upon being changed or the reading of which has been...
Page 196 Annexure-I Definitions: 1. Vehicle : The Motor Vehicle approved for sale within India under the provisions of Central Motor Vehicle Rules, 1989 or any subsequent amendment or substitution thereof. 2. Owner Manual (OM) : A document given to the customer at the time of sale of the vehicle giving guidelines on use and maintenance of the vehicle including the terms and conditions of Warranty.
Page 197 Annexure - II List of Components Covered under Emission Warranty S. No. Part name Catalytic Converter*** Exhaust manifold gasket Electronic Control Module Idle Air Control Motor Manifold Absolute Pressure Sensor Throttle Position Sensor Air Temp. Sensor Oxygen sensor Coolant Temperature Sensor Injectors Knock sensor Fuel Injection Pump ‘D”...
Page 199: 24X7 Roadside Assistance
24x7 ROADSIDE ASSISTANCE How to request assistance .... Benefits ........191 Covered area ........ 191 Chevrolet Roadside Assistance at home or on the road ..... 191 Vehicle recovery following mechanical or electrical 24x7x365 Days Access Fuel Assistance Taxi Assistance Tyre Assistance breakdown ........
Page 200: How To Request Assistance
The Chevrolet Roadside Assistance Program is focused to enhance your overall Chevrolet ownership experience by providing 24x7 Roadside Assistance emergency support for a period of three years starting from the date of invoice of the Chevrolet vehicle sold from an authorized CHEVROLET retailer, in the unfortunate event of vehicle breakdown or accident of your Chevrolet vehicle.
Page 201: Benefits
If your Chevrolet vehicle is immobilized whether at home or on the road, Chevrolet Roadside Assistance Program personnel will attend to your Chevrolet vehicle. If the problem is something that can be resolved at the roadside, a mobile technician will be sent to mobilize your vehicle at the roadside.
Page 202: Vehicle Recovery Following An Accident
If your Chevrolet vehicle is recovered to an authorized CHEVROLET retailer by Chevrolet Roadside Assistance Program personnel, the driver and passengers, if any, of the Chevrolet vehicle will be provided with one free taxi ride, up to 50 kms from the breakdown location, in order to continue your journey.
Page 203 5. Boot cannot be opened. 6. The front and/or rear demisters are not functioning. 7. Horn is not functioning. However, if the horn is sounding continuously, the Chevrolet Roadside Assistance Services will be provided. 8. Damaged door mirrors. 9. When the rear view mirror is damaged but it does not obstruct the driver’s vision.
Page 204: Special Exclusions
SPECIAL EXCLUSIONS The following scenarios are special exclusions under the Chevrolet Roadside Assistance Program, and therefore neither CSIPL nor its authorized retailers will be responsible for any assistance/repair costs and are excluded from Chevrolet Roadside Assistance Program: 1. Vehicle is involved in motor racing, rallies, speed or endurance tests, practice runs or operated outside official roads.
Page 205: Force Majeure
RIGHT OF REFUSAL Chevrolet Roadside Assistance Program shall have the right to refuse any or all benefits under the program, if it is found that the information furnished by you at the time of making the request for assistance are false.
Page 206: Disclaimer
DISCLAIMER CSIPL shall be under no liability whatsoever in respect of any loss or damages arising directly or indirectly due to any delay or non-delivery of the services under the CSIPL Roadside Assistance Program. In case the vehicle cannot be mobilized on- site, Customers are advised to use the towing facility as may be arranged by CSIPL Roadside Assistance Program Vendor personnel for taking the vehicle to the nearest authorized...
Page 207: Chevrolet Sales India Sales And Service Network
CHEVROLET SALES INDIA SALES AND SERVICE NETWORK North zone........198 West zone ........204 South zone ........209 East zone ........214 International ......... 217 Indicates Retailer (Sales and Service) m Indicates Chevrolet Authorized Service Center Authorized Service Center (ASC) are authorized to carry out Periodic Maintenance (Free/Paid, Minor Running Repair) Only.
Page 208: North Zone
Showroom : Metro Motors Pvt. Ltd. Ganganagar Automobiles Pvt. Ltd. Ramgarh, Near Central Jail Bridge, Chandigarh Road, Showroom & Workshop : (Aarav Chevrolet) Baldev Nagar, Ambala City - 134 003 Bawa Potteries Industrial Complex, Showroom : Tel. : 0171 - 2543010...
Page 209 Ambala Road, Kaithal, Haryana - 136 027 KANGRA Tel. : 0174 - 6226827 Himachal Autowheels Pvt. Ltd. Showroom 2 : (Platinum Chevrolet) DLF City Court, Sikanderpur, Gurgaon - 122001 KARNAL Showroom & Workshop : Tel. : 9582216504, 9582216510 Aryaman Automobiles N.H 20 Kachhiary, Kangra - 176 001...
Page 210 BATALA ROPAR Workshop : Kashmir Autmobiles Pvt. Ltd. (Platinum Chevrolet) Padam Cars Pvt. Ltd. Khasara No-319 Kankarda Bhunaboy, NH-8, Showroom & Workshop: Showroom & Workshop : Jaipur Road, Ajmer - 305001 Opp. Cambridge International School, Saidmubarak, Chandigarh Road, Nangal Chowk, Ropar - 140 001 Tel.
Page 211 JAIPUR KOTA Workshop : Triumph Motors Triumph Motors Kanodia Mill Compound 1, Luker Ganj, Showroom 1 : Showroom & Workshop : Allahabad - 211 001 Corporate Tower, A-1, Jawahar Lal Marg, E - 137C, Road No. 5, Tel. : 0532 - 2616368 Jaipur - 302 015 Indraprastha Industrial Area, Kota Tel.
Page 212 Tel. : 0135 - 2640877 Near Mariampur Crossing, Kanpur - 208 012 Tel. : 0512 - 3224701 / 3224702 VARANASI Vinayak Automotive Pvt. Ltd. (Vinayak Chevrolet) LUCKNOW Showroom & Workshop : Megha Auto (I) Pvt. Ltd. Adjacent to Essar Petrol Pump, Showroom &...
Page 213 WEST ZONE BHAVNAGAR Workshop : V Raj Motors Jamnagar to Rajkot Highway, 8 - Happa, Showroom & Workshop : Jamnagar - 320 120 STATE - GOA Plot No. 150, Near Press Quarter, Tel. : 0288 - 3921194 - 98 Opp. Maruti Showroom, Bhavnagar-Rajkot Road, VASCO-DA-GAMA Chitra, Bhavnagar - 364 003 MEHSANA...
Page 214 Workshop : Workshop : STATE - MADHYA PRADESH Next To Sameeti School, Patel Nagar Circle, Plot No.- 11/11,11/12, Survey No.- 26, Gram Palada, Udhna Gam, Surat - 394 210 Khandwa Road, Indore - 452011 Tel.: 0261 - 3091001 BHOPAL Tel : 0731 - 6656000 Super Cars Ltd.
Page 215 Tel. : 022 - 434594444, 24221711-12 AURANGABAD Tel. : 0231 - 2535315, 2535425 Fax : 022 - 24222713 Mishrikotkar Motors LLP (Arihant Chevrolet) Showroom : Fax : 0231 - 2535615 Sector P, Town Centre, Jalna Road, CIDCO, Workshop 2 :...
Page 216 Tel. : 02525 - 655454 / 655353 Showroom : PUNE 442-3, Kulkarni Complex, 100 feet road, Nikhil Automobiles Pvt. Ltd. Platinum Chevrolet South Sivaji Nagar, Sangli - 416 416 Showroom & Workshop : Showroom & Workshop 1 : Tel. : 0233 - 2326544 Survey No.
Page 217 Showroom 2 : Ashoka Millenium, Ring Road, Raipur - 492 011 Tel. : 7714030104, 7712410008...
Page 218: South Zone
SOUTH ZONE Workshop : Workshop : Plot No. 95 & 96, Wood Complex, Opposite to Fusion Towers, 36-12-2, Near Ayyappa Temple, Nellore - 524 004 Near Siddartha Public School, Moghul Rajapuram, STATE - ANDAMAN & NICOBAR Tel. : 9247000022 Vijayawada - 520 010 Tel.
Page 219 K.H.T. Chevrolet (A Division Of Morzaria Real MANGALORE COCHIN Tech Private Limited) Vibrant Motors Geeyem Motors Pvt. Ltd. Showroom : Showroom: Showroom & Workshop : No: 725, West of Cord Road, Rajajinagar, Mont Tiera Apartments, Vivekanand Road, 11/336, NH-47 Bye Pass, Nettor P.O.,...
Page 220 Workshop : PATHANAMTHITTA STATE - PONDICHERRY Cantonment, North Nagar, Pullikada, Kollam - 691001 Deedi Motors Pvt. Ltd. Tel. : 0474 - 2750010 / 11 Showroom & Workshop : PONDICHERRY Kumbazhethu Buildings, Churulicode P.O., Aakash Auto Pvt. Ltd. KOTTAKKAL Kozhencherry Road, Pathanamthitta - 689 645 Showroom : German Motors Tel.
Page 221 CUDDALORE KARUR PERAMBALUR Aakash Auto Pvt. Ltd. Pressana Automobile Jayaraj Karz Showroom & Workshop: Showroom & Workshop : Showroom & Workshop : RS No.155/11, Vadalur Main Road, Periamedu, No.3, Salem Byepass Road, Kulathupalayam, No. 36, Trichy to Chennai Highway, Eraiyur, Karaikadu Village, Cuddalore Taluk, Karur - 635 006 Veppanthattai, Perambalur, Tamilnadu - 621 133...
Page 222 Showroom & Workshop 3 : STATE - TELANGANA A2, Balanagar Techno Craft Industrial Estate, Balanagar, Hyderabad - 500 037 HYDERABAD Tel. : 040 - 23721111 Kun Automobiles (P) Ltd. Fax : 040 - 23729999 Showroom & Workshop 1 : Plot No. 74, Snehapuri Colony, Near Andhra Bank, KARIMNAGAR Nagole Main Road, Nagole, Hyderabad - 500 035 Kun Automobiles (P) Ltd.
Page 223: East Zone
EAST ZONE Workshop 2 : PATNA Nova Furniture Factory Compound, Pandey Motors Pvt. Ltd. Milan Nagar, Jorhat - 785001 Showroom : STATE - ARUNACHHAL PRADESH Tel. : 0376 - 2309263 Pandey Plaza, Exhibition Road, Patna - 800 001 Tel. : 0612 - 2205195, 3955491 ITANAGAR SHIBSAGAR Fax : 0612 - 2205196...
Page 224 HAZARIBAGH Super Sales Automobiles Pvt. Ltd. Workshop 2 : Laxmi Auto Showroom & Workshop : 108 F, Nilgunge Road, Agarpara, Kolkata - 700 058 Showroom & Workshop : Plot No. 644/2148, NH-5, Pahal, Tel. : 033 - 25552509 Zulu Park Road, Near SBI Main Branch, Bhubneswar, Dist - khurda - 752 101 Hazaribagh - 825 301 Tel.
Page 225 STATE - NAGALAND DIMAPUR Urban Station Showroom & Workshop : NSC Petrol Pump, NH-39, 6th Mile, Kohima Road, Dimapur, Nagaland - 797 112 Tel. : 03862 - 240994, 240992 STATE - TRIPURA AGARTALA Sri Krishna Automobiles Showroom & Workshop : Plot No.
Page 226 INTERNATIONAL SRI LANKA Mag City Motor Company Pvt. Ltd. Showroom & Workshop : No. 320A, Darley Road, Colombo - 10, Sri Lanka Tel. : 0094777410407 BHUTAN Global Trade Showroom : Lkahilham, Changgankha, Thimphu, Bhutan Workshop : Post Box No. 1037, Olarongcchu, Thimphu, Bhutann NEPAL SPG Automobiles Pvt.
Page 228 General Motors India Pvt. Ltd. All information, illustrations and specifications contained in this Owner's Manual are based on the latest production information available at the time of publication. The right is reserved to make changes at any time without notice. Regd.

Chevrolet Tavera BS3 Owner's Manual

Table of Contents

24X7 Roadside Assistance

Quick Links

Chapters

Related Manuals for Chevrolet Tavera BS3

Summary of Contents for Chevrolet Tavera BS3

Table of Contents
