VIESMANN
Installation and service
instructions
for contractors
Vitocal 222-S
Type AWT-AC 221.A04 to A13
Compact heat pumps, split version for heating and cooling opera-
tion
For applicability, see the last page
VITOCAL 222-S
Please keep safe.
5600 950 GB
10/2011
