EmberGlo ES10PB Installation And Service Instructions Manual

Es10 series

Advertisement

Quick Links

Installation and Service Instructions
MADE
in the
USA
Warranty
See the back of this manual for the full warranty.
This warranty does not apply to damages resulting from accident, mis-
use, abuse or alteration.
No equipment may be returned without written authorization from Em-
berGlo, A division of Midco International Inc., or Midco. Returned goods
must be shipped prepaid to the factory.
No equipment may be returned without written authorization from
MIDCO. Warranty card must be fi lled in and returned to EmberGlo (or
Midco) to validate warranty.
CAUTION: This manual contains suffi cient information for
installation of the EmberGlo Steamer in normal locations.
In the United States, installation must conform with local codes.
CODE COMPLIANCE IS THE SOLE RESPONSIBILITY OF
THE INSTALLER.
PURCHASER: Retain these instructions for future use. Post, in a
prominent location near the broiler, instructions for turning off gas valves
in case gas odor is detected and any other instructions as advised by
your local gas supplier.
CAUTION: Cooking equipment should be used in an envi-
ronment protected by an automatic fi re suppression
the National Fire Protection Association NFPA Code 96 or the latest
edition of Standards for Installation of Equipment for Removal of Smoke
and Grease-Laden Vapors From Commercial Cooking Equipment.
AVOID ERROR IN PARTS SELECTION. When ordering use
complete EMBERGLO Part Number and Description. Furnish
Model Number, Bill of Material Number and Serial Number (if
available) from the specifi cation plate found on the product.
IMPORTANT: Availability of parts as well as specifi cations are
subject to change without notice. Please consult factory for
item availability.
EmberGlo
A Div of Midco® International Inc.
4140 West Victoria Street
Chicago, Illinois 60646
toll free 866.705.0515
tel
773.604.8700
fax
866.580.8700
web
www.emberglo.com
e-mail sales@emberglo.com
system. Consult
SAFETY INFORMATION TERMS: The following terms are used to identify hazards, safety precaution of
special notations and have standard meanings throughout this manual. They are printed in all capital letters
using a bold type face as shown below, and preceded by the exclamation mark symbol. When you see the
safety alert symbol and one of the safety information terms as shown below, be aware of the hazard potential.
DANGER:
Identifi es the most serious hazards which will result in severe personal injury or
death.
WARNING:
Signifi es a hazard that could result in personal injury or death.
CAUTION:
Identifi es unsafe practices which would result in minor personal injury or product and
property damage.
Quality Designed for Proven Performance
ES10 Series
Full Pan Size Food Steamers Automatic,
Program able Timer Operation Designed to
Operate with Tap Water - Direct Hookup
ES10PB: Manual Push Button
ES10T: Automatic, Programmable Timer Operation,
External Cycle Timer
WARNING: Additions, changes, conversions and
service must be performed by an authorized EmberGlo representative
or service agency. Use only EmberGlo specifi ed and approved parts.
WARNING: Improper installation, adjustment, alteration,
service or maintenance can cause property damage, injury or
death. Read the installation, operating and maintenance instruc-
tions thoroughly before installing or servicing this equipment.
FOR YOUR SAFETY
Do not store or use gasoline or other fl ammable liquids and
vapors in the vicinity of this or any other appliance.
No Hood Installation Required: According to the Uniform
Mechanical Codes per the International Conference of Building
Offi cials Code EmberGlo Steamers do not require a separate
hood for vapor produced during operation of an EmberGlo
Steamer.
NOTE: EmberGlo ES10 Series Steamers use a cast aluminum
steam generator with two cast in electric heating elements.
For best steaming, the generator casting should contain some
mineral deposits. During fi nal inspection each generator casting
is pre-seasoned with a solution of baking soda and water. The
water marks and mineral deposits seen on a new generator
casting when the perforated food pan is removed is your
assurance that the unit has passed fi nal inspection test and will
readily produce steam.
Specifi cations:
- 240 volts 60HZ AC 3200 watts 13.3 amp
or 208V 60HZ AC 2400 watts 11.6 amps
- Automatic timer operation (timer models only)
- Single shot operation
- End of cycle buzzer (10 seconds)
416
8470 77
Printed in USA
