In the interests of user-safety (Required by safety regulations in some countries) the set should be restored
to its original condition and only parts identical to those specified should be used.
•
SERVICING NOTICES ON CHECKING ..............................................................................
•
HOW TO ORDER PARTS ....................................................................................................
•
IMPORTANT .........................................................................................................................
•
HOTEL MODE FUNCTION ..................................................................................................
•
ABOUT LEAD FREE SOLDER (PbF) ..................................................................................
•
PARENTAL CONTROL - RATING LEVEL ...........................................................................
•
GENERAL SPECIFICATIONS ..............................................................................................
•
DISASSEMBLY INSTRUCTIONS ........................................................................................
•
SERVICE MODE LIST ..........................................................................................................
•
WHEN REPLACING EEPROM (MEMORY) IC ....................................................................
•
SERVICING FIXTURES AND TOOLS .................................................................................
•
INSTALL FOR WRITING TOOLS .........................................................................................
•
RE-WRITE FOR DIGITAL SOFT FIRMWARE .....................................................................
•
ELECTRICAL ADJUSTMENTS ............................................................................................
•
TROUBLESHOOTING GUIDE .............................................................................................
•
BLOCK DIAGRAM ................................................................................................................
•
PRINTED CIRCUIT BOARDS ..............................................................................................
•
SCHEMATIC DIAGRAMS ....................................................................................................
•
WAVEFORMS ......................................................................................................................
•
MECHANICAL EXPLODED VIEWS .....................................................................................
•
REPLACEMENT PARTS LIST .............................................................................................

LCD COLOR TELEVISION

LC-32AD5E-BK
MODEL
CONTENTS
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
#########
Page
A1-1
A1-1
A1-1
A1-2
A1-3
A1-3
A2-1~A2-6
B1-1~B2-2
C-1
C-2
C-3
C-3
C-4~C-13
D-1~D-7
E-1~E-7
F-1~F-14
G-1~G-10
H-1~H-40
I-1, H-2
J-1~J-4
K1-1~K2-12
