Mini 2007 Owner's Manual page 133

LAMPS AND BULBS
Side turn signal indicators
5 watt bulb
1. Slide the lamp toward the rear of the
vehicle and remove
2. Remove and replace the bulb.
Tail lamps
Turn signal lamp 1:
Rear lamp 2: 21/5 watt bulb
Backup lamp 3:
1 Turn signal indicator
2 Rear lamp/Brake lamp
3 Backup lamp
Replacing bulbs
21 watts To access the bulb holder, remove the cover
on the side panel in the luggage compart-
ment for MINI and MINI Convertible.
16 watts
1. Unplug the power supply, arrow 1
2. Squeeze the retaining clips together, see
yellow
arrows 2, and remove the bulb holder
red
3. Apply gentle pressure to the bulb while
white
turning it to the left
4. Remove and replace the bulb
5. Press the bulb holder into position until
you hear it engage
6. Plug in the power supply.
Online Edition for Part no. 01 41 0 012 950 - © 08/06 BMW AG
131
