INDUSTRIAL POWER TOOLS
Impact Drill
MODEL EDH720RE2
• Powerful and low noise level motor
• 20mm capacity in concrete
• Easy one touch change-over from rotation to impact
and rotation
• Variable speed
• Forward/reverse action
WARNING: THE SAFETY INFORMATION
GIVEN INSIDE MUST BE READ AND
UNDERSTOOD BY ANY PERSON
USING, INSTALLING, REPAIRING
OR MAINTAINING THESE
TOOLS.
OPERATOR'S MANUAL
Please retain this information for future reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDH720RE2 and is the answer not in the manual?

Questions and answers

Related Manuals for K-EIKO EDH720RE2

Summary of Contents for K-EIKO EDH720RE2

  • Page 1 INDUSTRIAL POWER TOOLS Impact Drill MODEL EDH720RE2 • Powerful and low noise level motor • 20mm capacity in concrete • Easy one touch change-over from rotation to impact and rotation • Variable speed • Forward/reverse action WARNING: THE SAFETY INFORMATION...

  • Page 2: General Safety Rules

    d) Remove any adjusting key or wrench before GENERAL SAFETY RULES turning the power tool on. A wrench or a key left attached to a rotating part WARNING! of the power tool may result in personal injury. Read all instructions e) Do not overreach.

  • Page 3: Specifications

    PRECAUTIONS ON USING IMPACT DRILL 1. Wear ear protectors with impact drills. Exposure to noise can cause hearing loss. 2. Use auxiliary handles supplied with the tool. Loss of control can cause personal injury. 3. Before drilling into walls, ceilings or floors, ensure that there are no concealed power cables inside.
  • Page 4 5. Selecting the appropriate drill bit For keyless chuck (Fig. 3, 4) When boring concrete or stone (1) Mounting the bit Use the drill bits specified in the Optional Turn the lock collar in the direction “AUF . RELEASE” Accessories. and open the chuck.

  • Page 5: Maintenance And Inspection

    CAUTION stopper can be disconnected by pulling the trigger Repair, modification and inspection of K-EIKO Power again. Tools must be carried out by an K-EIKO Authorized CAUTION Service Center. Drill at a maximum rotation speed when drilling This Parts List will be helpful if presented with the wooden materials.
  • Page 6 IMPORTANT Correct connection of the plug The wires of the mains lead are coloured in accordance with the following code: Blue:- Neutral Brown:- Live As the colours of the wires in the mains lead of this tool may not correspond with the coloured markings identifying the terminals in your plug proceed as follows: The wire coloured blue must be connected to the terminal marked with the letter N or coloured black.
  • Page 8 EC DECLARATION OF CONFORMITY We declare under our sole responsibility that this product is in conformity with standards or standardized documents EN60745, EN55014 and EN61000-3 in accordance with Council Directives 73/23/EEC, 89/336/EEC and 98/37/EC. Manufactured for KENNEDY TOOLS Wigston Works, Leicester, England. ISO 9002 REGISTERED COMPANY Signed: Date: 31 January 2007...
