INDUSTRIAL POWER TOOLS
IMPACT DRILL
MODEL EDH550VRE
Wear safety glasses
• Ergonomic design with soft grip handle
• 13mm keyless chuck
• 16mm capacity in concrete
• Lightweight and compact
• Variable speed
• Forward/reverse action
WARNING: THE SAFETY INFORMATION
GIVEN INSIDE MUST BE READ AND
UNDERSTOOD BY ANY PERSON
USING, INSTALLING, REPAIRING
OR MAINTAINING THESE
TOOLS.
OPERATOR'S MANUAL
Please retain this information for future reference
Advertisement
Table of Contents
Related Manuals for K-EIKO EDH550VRE
Summary of Contents for K-EIKO EDH550VRE
- Page 1 INDUSTRIAL POWER TOOLS IMPACT DRILL MODEL EDH550VRE Wear safety glasses • Ergonomic design with soft grip handle • 13mm keyless chuck • 16mm capacity in concrete • Lightweight and compact • Variable speed • Forward/reverse action WARNING: THE SAFETY INFORMATION...
-
Page 2: General Safety Rules
d) Remove any adjusting key or wrench before GENERAL SAFETY RULES turning the power tool on. A wrench or a key left attached to a rotating part WARNING! of the power tool may result in personal injury. Read all instructions e) Do not overreach. -
Page 3: Specifications
Additional rules for impact drills - Wear ear protection Exposure to noise can cause hearing loss. - Use auxiliary handles supplied with the tool. Loss of control can cause personal injury. SPECIFICATIONS Voltage (by areas)* (110V, 230V) Power input 550 W No load speed 0–2900 min Steel... - Page 4 CAUTION CAUTION Do not fix the side handle to the ring of the keyless Do not use the impact drill in the IMPACT mode if the chuck because of a risk that doing so may damage material can be bored by rotation only. Such action the ring.
-
Page 5: Maintenance And Inspection
5. Service parts list CAUTION Repair, modification and inspection of K-EIKO Power Tools must be carried out by a K-EIKO Authorized Service Center. This Parts List will be helpful if presented with the tool to the K-EIKO Authorized Service Center when requesting repair or other maintenance. - Page 8 EC DECLARATION OF CONFORMITY We declare under our sole responsibility that this product is in conformity with standards or standardized documents EN60745, EN55014 and EN61000-3 in accordance with Council Directives 73/23/EEC, 89/336/EEC and 98/37/EC. Manufactured for KENNEDY TOOLS Wigston Works, Leicester, England. ISO 9002 REGISTERED COMPANY Signed: Date: 31 July 2006...
