Summary of Contents for Wesena e6V
- Page 1 Operator’s manual...
- Page 2 Thank you for purchasing WESENA’s HTPC Chassis. We recommend that you read this user guide thoroughly before installation. WESENA is the professional global supplier of HTPC cases, we hold the professional product designing, the novel and fashionable outside looking , humanistic inner structure of it ,high-quality QC management and high-quality production team.
-
Page 3: Table Of Contents
Index e6v overview----------------------------------------------------------4 Open the Top panel-------------------------------------------------5 Montherboard installation------------------------------------------5 HDD installation------------------------------------------------------6 ODD installation------------------------------------------------------8 PSU installation -----------------------------------------------------9 PCI or PCIE slot installation---------------------------------------9 Close the Top panel------------------------------------------------10 Open the card reader door ----------------------------------------10 PCB+cables reference diagram ---------------------------------11... -
Page 4: E6V Overview
① . Power button ② . Power blue LED ③ . VFD acryl window ④ . TOP panel ⑤ . IR acryl window ⑥ . Card reader Door ⑦ . USB port ⑧ . Card reader ⑨ . ODD button ⑩... -
Page 5: Open The Top Panel
Open the top plate Rotating plate, open handle and open plate , and take out the cover plate. Shown as photos Motherboard installment Take off 6 ODD stents screws, and take out the ODD holder Put I/O baffle plate firstly Put motherboard lock screw secondly Alignment, lock screw holes Shown as photos... -
Page 6: Hdd Installation
HDD installment Unload the HDD holder screws, and take out the HDD holder Put 2.5inch HDD first , and then alignment , lock screws holes To put the holder with 2.5inch HDD into the right place of case, lock screws Shown as photos... - Page 7 Take out the 3.5inch HDD screw and anti- vibration pad, lock it to the both side of the HDD, shown as the photo( pay attention to the install way of anti-vibration pad) After locked the screws in both side of HDD, and then put the HDD into the bracket , shown as the photo lock screw manually Shown as photos...
-
Page 8: Odd Installation
ODD installment Put the ODD into the ODD bracket, alignment holes, and lock screws. Shown as the photo To put the ODD button into the cases To put the holders, which have been put ODD, into the case, alignment holes, and lock the 6 screws Shown as photos... -
Page 9: Psu Installation
Power supply installment To put the POWER supply into the case, alignment the hole , and lock the screws Shown as photos PCI or PCIE expand installment To exit the baffle plate screws first , and then take out the baffle plate Put the PCI or PCIE expand card , lock screws, shown as photo Shown as photos... -
Page 10: Close The Top Panel
Cover the top plate Connect all the electric component according to the electric diagrammatic drawing Check the installation position and connections again after finished the inner installment, cover the plate lastly Shown as the photos Tear down the Rubber sheet of 3M gum on the ODD door, to put the ODD door on the ODD place and Stick on the ODD Shown as photos press top right corner of the card reader door to... -
Page 11: Pcb+Cables Reference Diagram
Cables connect sketch map GA-H55N-USB3 motherboard For example F-panel ⑥ ⑧ ② ④ F-panel... - Page 12 Add: No. 809 8F A Area, Huameiju Business Center, Xinhu Rd, Block 82 Baoan District Shenzhen, China 518102 Tel: +86 755 29193778 400 6088 126 Fax: +86 755 23494915 E- mail: info@wesena.com http://www.wesena.com...
