Thank you for purchasing WESENA’s HTPC Chassis. We recommend that you read this user guide thoroughly before installation. WESENA is the professional global supplier of HTPC cases, we hold the professional product designing, the novel and fashionable outside looking , humanistic inner structure of it ,high-quality QC management and high-quality production team.
Page 3
Index e5 overview-----------------------------------------------------------4 Open the Top panel-------------------------------------------------5 Montherboard installation------------------------------------------5 HDD installation------------------------------------------------------6 ODD installation------------------------------------------------------8 PSU installation -----------------------------------------------------9 PCI or PCIE slot installation--------------------------------------10 Close the Top panel------------------------------------------------10 Open the cardreader door ----------------------------------------10 PCB+cables reference diagram ---------------------------------11...
Page 4
① . Power button ② . Power blue LED ③ . IR Receive window ④ . ODD button ⑤ .USB port ⑥ . Card reader ⑦ . Latch of door ⑧ . Card reader Door ⑨ . Slot of ODD ⑩...
Page 5
Open top plate Rotating top plate , open the handle and the top plate, take out the top plate Shown as photos Motherboard installment Put the I/O baffle plate firstly Put the motherboard secondly, alignment , and lock screws Shown as photos...
Page 6
HDD installment Unload HDD bracket screws, and then take out the HDD bracket Put the HDD with 2.5inch , alignment and lock the screws Put the bracket, which has been put 2.5inch HDD, into the right place of the case. Alignment and lock the screws Shown as photos...
Page 7
Take out the 3.5inch HDD screws, and the anti-vibration pad ,and lock it to the both side of the HDD( pay attention to the install way of anti-vibration pad) After lock the screws in both side of HDD, and then put the HDD into the bracket. Shown as the photos Lock the screws manually Shown as photos...
Page 8
ODD installment Unload screws, take out the ODD bracket Put the ODD on the ODD bracket, and alignment ,lock the screws. Shown as the photos Put the bracket with ODD into the case. Alignment and lock the screws. Shown as photos...
Page 9
DC-DC power installment Twist the DC power plug nut. Alignment it and lock the nut shown as photos Shown as photos Power supply installment Take off the nut , and then take out the power baffle plate. And then put the power into the case.
Page 10
PCI or PCIE expand installment To exit 2 nuts firstly , and then take out the baffle plate Put the PCI or PCIE expand card in. shown as photos.Lock the 2 screws Shown as photos Cover the top plate Check the installation position and connections again after finished the inner installment, cover the plate lastly Shown as photos press top right corner of the card reader door to...
Page 11
Cables connect sketch map GA-H55N-USB3 motherboard For example F-panel ⑧ ⑥ ④ ② F-panel...
Page 12
