- Page 1 LCD HD Television " With integrated digital tuner Model Number ALCD3270 instruction manual TEL: 1300 366 144 WEB: warrantyhelp@awa.com.au After Sales Support...
- Page 2 This page has been left blank intentionally.
-
Page 3: Table Of Contents
WELCOME TO THE WORLD OF DIGITAL LCD COLOUR TV Dear customer, Thank you for choosing this digital LCD colour TV. We expect our product and service will deliver many years of visual enjoyment. This manual is to guide you to set up and operate your TV as quickly as possible. -
Page 4: Important Safeguard
IMPORTANT SAFEGUARD FIRE AND SHOCK PRECAUTIONS Adequate ventilation must be provided to prevent heat build up inside the unit. Keep the inside of Ÿ the unit free from foreign objects, such as hairpins, nails, paper, etc. Do not put the set into a bookcase or other enclosures in which it would be poorly ventilated. -
Page 5: Preparation For Using Your New Tv
Preparation for using your new TV Selecting a location for the TV 1. Place the TV on a sturdy platform (away from direct sunlight for optimal viewing). 2. Place the TV far enough from the walls to allow proper ventilation. Inadequate ventilation may cause overheating which may damage the TV.(150mm minimum recommended distance around a covered enclosure) Note: Please contact the retail dealer for wall mounting. - Page 6 Preparation for using your new TV Back Connections AV IN Commponent IN Connector Description AC INPUT Connect the power cord to this connector. RS-232 For service purposes ONLY (will not support consumer products) Plug headphone into this jack. When headphones are plugged in, no sound Headphone jack comes from the headphones.
-
Page 7: Connecting Your Tv
Preparation for using your new TV Connecting your TV Part: 1 Part: 2 HDMI PC/DVI AUDIO IN AV IN Commponent IN Whenever you connect an audio system to your set ensure that all elements are switched off When connecting an external device, match the color of the connection terminal to the cable. NOTE: colors for inputs and cables must correspond on both devices. - Page 8 Preparation for using your new TV Connecting an Aerial To view television channels correctly, a signal must be received by the set from the following source: -An outdoor VHF/UHF antenna -After connecting the antenna, power and all sources required below, switch the LCD on then follow the on screen menu to start automatic tuning.
- Page 9 Preparation for using your new TV Connecting Computer -Connect the D- Sub cable to “PC/VGA (PC IN)” on the rear of your set and the other end to the Video Card of your computer. -Connect the stereo audio cable to “AUDIO (PC IN)” on the rear of your set and the other end to “Audio Out”...
-
Page 10: Using The Remote Control
Using the remote control Preparing the remote control for use Installing the remote control 1. Open the battery cover on the back of the remote control. 2. Install two AAA size(1.5V) batteries. Match the “+” and “-” signs on the batteries to the signs on the battery compartment. 3. -
Page 11: Learning About The Remote Control
Using the remote control Learning about the remote control Remote sensing Window Power Indicator Available source selection On/Off(Standby) Source Zoom image button Sound mode Digital/Analog TV Switch Picture mode Picture Zoom Sound Numeric numbers Display the current channel information Inform Recall To return to the last viewed program Next channel/up button... -
Page 12: Using The Tv
Using the TV Basic operations Power ON/OFF Turning on: Connect the TV to an AC power outlet and turn on the power switch located below the front right Ø hand side of unit. The power indicator will initial be red and then will change to blue. A few seconds later an image will appear on the screen. -
Page 13: Display Channel Information
Using the TV Display channel information Press the [INFO] button to view current channel information in TV source. Press the [EPG] button to view channel information in digital signal source. Selecting picture modes Press the [PICTURE] button to select between 4 different pre-adjusted picture modes: Vivid, Standard, Movie and User (configurable mode). -
Page 14: Menu System
Using the TV Menu System You can conveniently control all functions of your television using an advanced menu system which is visible on the screen via the On Screen Display (OSD) . Press the [ Menu] button to access the menu system. Six submenus will be immediately available: Picture, Audio, Screen, Channel, Lock Settings, System. -
Page 15: Installing In Television Channels
Using the TV Installing/Tuning in television channels Your television has been pre-adjusted to receive the five major TV networks available(only available in analogue TV mode) in capital cities of Australia; however you can add or delete channels at any time using the functions under the Channel submenu. -
Page 16: Picture
Using the TV Fine tuning [Menu, Channel , Fine Tune] Under poor reception conditions, or when receiving analogue signals from distant Fine Tune Channel Frequency: 503.236MHz TV stations, the picture quality might be improved by using the Fine Tune option in -1.5MHz +1.5MHz the Channel submenu. -
Page 17: Adjusting The Picture
Using the TV Adjusting the Picture [Menu, Picture, ...] Picture A wide variety of adjustments and optional advanced picture enhancement features are available in the Picture submenu. Their purpose is described Brightness Contrast below. Saturation Sharpness Color Temp. Cold Enhanced Settings : Move : Change EXIT/MENU: Exit... -
Page 18: Controlling The System Settings
Using the TV Controlling the System The System [Menu, System,...] submenu contains: Bluescreen, SetupWizard, [Fig. 1] OSD Settings, Time and Factory reset. You can adjust them to your liking. System Bluescreen SetupWizard Bluescreen setting [Menu, System, Bluescreen] OSD Settings Time Factory Reset If you prefer a Bluescreen, please set the Bluescreen option to 'On' in the :Move... -
Page 19: Lock Settings
Using the TV Lock Settings The Lock Settings [Menu, Lock Settings,...] submenu contains Parental Guidance, Factory Reset Lock, Child Lock, Change Password, y ou can adjust them for your LockSettings requirements. Parental Guidance Block None Change Password [Menu, System, Change Password] Child Lock -Set and change your password to protect your TV settings. -
Page 20: Screen Settings
Using the TV Lock Settings Child Lock [Menu, Lock Settings, Child Lock] If Child Lock is set to “on” , most of the remote and the panel buttons are invalid except [POWER],[VOL ] , [VOL ] , and the [MENU] buttons on the front side panel and [POWER],[VOL , [VOL ] , [OK] , [MENU] and [NUMBER] buttons on the remote control. -
Page 21: Appendix
Appendix Cleaning and care WARNING: Do not try to remove the cabinet back. Refer servicing to qualified service technicians. To clean the TV screen: 1. Unplug the TV to avoid possible shock hazard. 2. Use a clean cellulose sponge or chamois cloth dampened with a solution of mild detergent and warm water to clean the TV screen and trim. -
Page 22: Specifications
Appendix Innovation is life Specifications Model ALCD3270 LCD panel 32.0 inches TFT LCD Native Screen 1366X768 Pixels Resolution Television system PAL B/G DVB-T PAL/NTSC color system VHF-L: 48.25 to 168.25MHz Channel coverage VHF-H: 175 .25 to 463.25MHz UHF: 471.25 to 863.25MHz...
