LifeSource dt-705 Instruction Manual

Fast read flex tip thermometer

Advertisement

Available languages

Available languages

Quick Links

F
R
F
T
AST
EAD
LEX
IP
DISPLAY WINDOW
BATTERY COVER
SENSOR TIP
START BUTTON
Instruction Guide – MODEL DT-705
Congratulations on your purchase of the LifeSource
®
Fast Read Flex Tip
Thermometer. Please read the instructions carefully to ensure accurate temperatures
and safe operation. When used properly, this high quality product will give you
years of accurate, dependable service.
SAFETY INFORMATION
High, prolonged fever requires medical attention (over 100.0°F or 37.8°C) for
young children. In case of high readings, please contact your physician.
Do not allow children to take their temperature unattended.
Read the enclosed instructions carefully to ensure accurate temperature readings.
Temperature readings are affected by many factors including exercise, drinking
hot or cold beverages prior to taking, and technique.
Do not allow children to walk or run during temperature taking. The rigid probe
could present a hazard.
Oral, underarm, and rectal temperatures vary by approximately 1°F (0.5°C).
DT705.indd 1-4

SPECIAL PRODUCT FEATURES

Reads temperature in Fahrenheit or Celsius.
Memory feature: automatic recall of last temperature reading.
Beeps when peak temperature is reached.
Auto-Off in approximately 9 minutes.
Thermometer is water resistant, but not 100% waterproof. Do not submerge unit
in any liquid.
Long-life, replaceable battery (approximately 3,000 temperatures).
Low Battery Indicator "
".
Oral, Rectal or Underarm use.

HOW TO CARE FOR THIS PRODUCT

The thermometer should be cleaned after every use even when probe covers are
used.
Clean the thermometer tip and probe using isopropyl alcohol or soap and water.
Do not boil the thermometer. Do not submerge the thermometer in any liquid.
Store the unit in the protective case while not in use.
Do not store or keep in direct sunlight, or in high temperatures.
Do not open the thermometer except to replace the battery.
Do not drop the thermometer, as this may break the unit.
Do not attempt to disassemble the unit except to replace the battery.
WHAT IS A "NORMAL" TEMPERATURE?
Temperature readings vary among individuals. A normal temperature refers to each
individual' s average temperature while they are well. Normal average temperatures
range from 97°F/36.1°C to 100°F/37.7°C when taken orally. A rectal temperature is
considered your real or "core" body temperature. A rectal temperature is 1°F/0.5°C
higher than an oral reading and an underarm temperature is 1°F/0.5°C lower than
an oral reading.

HOW TO TAKE TEMPERATURE

1.
Select oral, underarm or rectal as your measurement site (see following instuctions)
2.
Ensure that the thermometer has been turned off before taking temperature.
3.
Press the START button. A short beep will be heard. All the symbols will be
turned on for one second to ensure all parts of the LCD are functioning properly,
and then the last measurement taken will be shown on the display for about two
seconds. The flashing °F or °C will appear to indicate that the thermometer is
ready to measure. Begin measurement.
4.
When the probe tip reaches its thermal equilibrium or peak, the °F (or °C) sym-
bol stops flashing and the beeper will sound eight times. The temperature on the
display will appear.
5.
After measuring, turn off the unit by pressing the START button. If the power
is left on, the "automatic shut-off function" will activate in approximately nine
minutes to save power.
NOTE: If the measured temperature is higher than 99.5°F (37.5°C), the fever alarm
will beep quickly for about four seconds.

ORAL USE

Do not drink hot or cold fluids, exercise, smoke or
perform other activities that raise or lower temperature.
The mouth should remain closed up to 5 minutes before
attempting a reading.
Place the probe tip well under the tongue in locations as
indicated by the "✔" (see diagram). Instruct children not
to bite down on the probe.
The approximate measurement time is 15-25 seconds.
Opening the mouth or improper placement of the probe
tip may result in a longer time for a reading.

UNDERARM (AUXILIARY) USE

From a medical point of view, this method will always
give an inaccurate reading and should not be used if a
precise measurement is required.
Wipe underarm with a dry towel.
Place probe tip in armpit and bring arm down against the
body. The measuring sensor should be pointing upward
parallel to the arm.
The approximate measurement time may be 5 minutes or longer depending on
the placement of the probe and closure of the arm against the body.
2/14/06 3:09:47 PM
