Installation diagram

Assemble membrane :
Install European ceramic faucet :
07
Input water :
To RO system
Deliver valve
To faucet
To water source pipe
S800-Direct Flow Reverse Osmosis Water Systems
1.Remove the membrane housing cap.
2.Replace the membrane.
Install drain saddle :
Drill a 1/4" hole into
the drain pipe.
Mount drain
saddle aligning
holes.

Change filters

1 Unplug electricity.
3 Loose the used pre-filter clockwise
and remove it.
S300RD S300ND S300ST
S300ST
5 Drain out 1 Gallon of water to
purify replacement filters.
S800-Direct Flow Reverse Osmosis Water Systems
2 Turn off water source.
To RO system
4 Screw in and install the new filter
anticlockwise.
S300RD S300ND S300ST
S300ST
08
