SUPPLEMENTAL SERVICE MANUAL
R-390AW
This is a supplemental Service Manual for Models R-390AW and R-390AK. The R-390AW is quite similar to model
R-390AK, with color changing. And also this supplemental service manual contains update information for the R-390AK.
Use this supplemental manual together with the Base Model Service Manual (Refer No. is S5708R390APK/) for
complete operation, service information, etc..
BEFORE SERVICING ......................................................................................................INSIDE FRONT COVER
FOREWORD ..................................................................................................................... INSIDE FRONT COVER
MICROWAVE MEASUREMENT PROCEDURE ................................................................................................... 1
SCHEMATIC DIAGRAM ........................................................................................................................................ 2
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE .................................................................. 3
CPU UNIT CIRCUIT .............................................................................................................................................. 6
PRINTED WIRING BOARD OF DISPLAY UNIT ................................................................................................... 7
PARTS LIST FOR R-390AW ................................................................................................................................. 8
INFORMATION OF PARTS CHANGING FOR R-390AK .................................................................................... 10
SHARP CORPORATION
MODELS
INDEX
START
POPCOR N
MINUTE PLUS
STOP
CLEAR
1
2
3
4
5
6
7
8
9
0
n the interest of user-safety the oven should be restored to its original
I
condition and only parts identical to those specified should be used.

TABLE OF CONTENTS

MICROWAVE OVEN
R-390AW
R-390AK
This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
R-390AW
R-390AK
SX712R390APW/
