COEF MP250 FRESNEL Operating Instructions Manual
Hide thumbs
Also See for MP250 FRESNEL:
- Operating instructions manual (39 pages) ,
- Operating instructions manual (20 pages)
Related Manuals for COEF MP250 FRESNEL
Summary of Contents for COEF MP250 FRESNEL
- Page 1 COEF srl. Via Albinatico, 80-82 51019 Ponte Buggianese (PT) ITALY • MANUALE ISTRUZIONI • OPERATING INSTRUCTION Printed in January 1999...
- Page 2 ® COEF srl. tel. (+39) 0572-636536 r.a. Fax (+39) 0572 - 636535 www.coef.it e-mail: info@coef.it Pag. 2 COEF srl. Ponte Buggianese (Pistoia) ITALY...
-
Page 3: How To Use The Manual
OPERATORI ELETTRICI SPECIALIZZATI SPECIALIZED ELECTRIC OPERATORS Qualified staff employed in extraordinary authorized installations and repairs. SEGNALE DI PERICOLO DANGER SIGNAL Generic danger signal. SEGNALE DI PERICOLO DANGER SIGNAL Electric shock danger signal. COEF srl. Ponte Buggianese (Pistoia) ITALY Pag. 3... -
Page 4: Installazione
Leggere attentamente le istruzioni d’uso fornite dal costruttore della lampada. The lamp must be changed if damaged or deformed by heat. WARNING: switch off the projector before operating. Read carefully the lamp builder’s instructions. Pag. 4 COEF srl. Ponte Buggianese (Pistoia) ITALY... -
Page 5: Lamp Adjustment
Adjust the three screws (part. A) until you reach the ideal condition between power and homogeneity. WARNING! The lamp is pre-regulated by the factory. Only fine-adjustment is required. Don’t move the screws A up to upper or lower extremities. COEF srl. Ponte Buggianese (Pistoia) ITALY Pag. 5... -
Page 6: Machine Installation
ATTENTION: COEF is not responsible for installations not correctly made or made without respecting the abo- ve indications: those installations are considered dangerous.. -
Page 7: Advices For A Correct Installation
The projector must be positioned in such a way that objects struck by the light beam are located at least 1,5 metres from the projector objective. 1,5 mt. Minimum distance from inflammable materials: 0.1 meters MAX ambient temperature: 40° C. COEF srl. Ponte Buggianese (Pistoia) ITALY Pag. 7... -
Page 8: Power Supply Connections
Connect the projector to the control unit by means of a RG58 or RG59 coaxial cable supplied with 3 Pin XRL Cannon plugs and connectors. Respect, according to the indications on the panel, the input and the output of the DMX 512 signal. Pag. 8 COEF srl. Ponte Buggianese (Pistoia) ITALY... - Page 9 SEARCH FUNZIONE 1 RESET MACCHINA FUNZIONE 2 FUNZIONE 3 FUNZIONE 4 FUNZIONE 5 FUNZIONE 6 FUNZIONE 7 FUNZIONE 8 FUNZIONE 9 FUNZIONE t FUNZIONE d C, D o E FUNZIONE h FUNZIONE COEF srl. Ponte Buggianese (Pistoia) ITALY Pag. 9...
-
Page 10: Special Functions And Projector Assignment
(9= 16 bit movement resolution + dedicated DIMMER channel. FUNZION If the projector is fixed to the ceiling, this function allows the rotation of the display on 180°. Display will show when “Standard” or when “Opposite”. Pag. 10 COEF srl. Ponte Buggianese (Pistoia) ITALY... -
Page 11: Channels And Digital Values
TILT MOVEMENT TILT MOVEMENT TILT MOVEMENT FINE ADJUSTMENT TILT MOVEMENT FINE ADJUSTMENT DIMMER 0 - 10 DIMMER chiuso / closed 11 - 250 Reg. DIMMER 251 - 255 DIMMER aperto / open COEF srl. Ponte Buggianese (Pistoia) ITALY Pag. 11... -
Page 12: Manutenzione Ordinaria
To let you operate more easily, we advice you to remove the two top covers of MP250 and the two basis covers. In order to put again the cover to its place, operate as shown below: Positionate the top cover on the MP250 FRESNEL projector. Screw down the frontal screws (objective); not yet those on the back (lamp). - Page 13 The same situation will occur in the case of the gobos wheel . The section shutter/strobo doesn’t use sensors during the reset positioning but it’s conditioned by a mechanical beat of the shutter shovels. COEF srl. Ponte Buggianese (Pistoia) ITALY Pag. 13...
-
Page 14: Electronic Maintenance
( color, gobos, shutter etc.). ATTENTION! An improper use of this documentation made by not specifically qualified staff can damage irremediably the electronic and/or mechanical components of the projector. Pag. 14 COEF srl. Ponte Buggianese (Pistoia) ITALY... -
Page 15: Troubleshooting
Position sensor with dust or grease The PAN movement doesn’t co- incide to the selected value Carefully clean the optical group lenses and the projector components (see “Main- tenance” chapter) Technical aid is required. COEF srl. Ponte Buggianese (Pistoia) ITALY Pag. 15... -
Page 16: Dichiarazione Di Conformita
Light fixtures. General instructions and EN 60598-2-17 Safety of household and similar electrical tests. Equipment fixtures for stages, TV EN 60335 appliances and cinema studios Pag. 16 COEF srl. Ponte Buggianese (Pistoia) ITALY... -
Page 17: Schema Elettrico
11.0 SCHEMA ELETTRICO ELECTRIC DIAGRAM COEF srl. Ponte Buggianese (Pistoia) ITALY Pag. 17... - Page 18 12.0 DIMENSIONI DIMENSIONS 350.00 450.00 Pag. 18 COEF srl. Ponte Buggianese (Pistoia) ITALY...
- Page 19 13.0 NOTE NOTES COEF srl. Ponte Buggianese (Pistoia) ITALY Pag. 19...
- Page 20 COEF sr. Ponte Buggianese (Pistoia) ITALY ® COEF srl. ITALY Realized by PC CAD & VIDEO Printed in December 1998...
