4-2 Control Panel (for LDS5540, LDS5560 Series)

CONTROL PANEL

Display varies by model(LDS5540)
Display varies by model(LDS5560)

Cycles

Select your desired cycle.
POWER SCRUB
This cycle is for heavily and hard soiled dishes. Power Scrub
can also help reduce hard water spotting on dishes.
NORMAL
This cycle is for normally soiled, everyday loads.
DELICATE
QUICK(LDS5540), Quick&Dry(LDS5560
This is a shortened cycle that is intended for washing and dry
ing recently used dishes or lightly soiled loads.
QUICK (LDS5560)
This is a shortened cycle that is intended to wash recently used
or lightly soiled loads, without drying.

RINSE ONLY

This cycle is a quick rinse for dishes that will not be washed
immediately. This cycle will rinse dishes that have excess
soil to soften dried on residue. Rinsing the dishes will help
prevent odors in the dishwasher. No detergent should be
used.

DUAL WASH

intensities. The default setting for this cycle washes the lower
rack with strong spray intensity and the upper rack with soft
spray intensity. This provides optimum cleaning performance
combinations are desired, use the steps listed below to change
the intensities or to use the HALF LOAD feature.
How To Use Dual Wash:
1. Select Dual Wash.
2. Press the Spray button to toggle between Soft, Medium
and Strong for the upper spray arm.
3. After making your selection for the upper spray arm, press
the Half Load button.
4. Press the Spray button to toggle between Soft, Medium
)
and Strong for the lower spray arm.
-
5. Close the door to start the cycle.
UPPER ONLY
This cycle is only for washing items placed on the upper rack
CHIME ON/OFF
Press and hold the two – LDS5540 : Extra Dry and Delay Start,
LDS5560 : Spray and Delay Start - buttons simultaneously
for approximately three seconds.
