Specification - LG LDS5540ST Service Manual

2. SPECIFICATION

ITEM
Rated Voltage / Frequency
Installation
Place Settings
Product Dimension(in)
Product Weight(lbs)
Door Color
Tub Material
Control
Rated Power(Watt)
Heater Power(Watt)
Programs
Upper Rack Position
Lower Rack
Water Consumption(ℓ)
Power Consumption(kWh/year)
Operating Time(min)
Fan Dry System
Delay Start Function
Auto-Off Power Switch
Process Monitor
Wash Level
Racks
Operating Water Pressure(Bar)
SPECIFICATION
AC 120 V / 60 Hz
Built-In
2 3 3 / 4 ̋ x 2 4 5 / 8 ̋ x 3 3 1 / 2 ̋
90.8lbs (for LDS5040, LDS4921 series)
90.8lbs (for LDS5540 series)
97.8lbs (for LDS5560 series)
White, Black, Stainless
Stainless Steel
Electronic
1,300
1,200
5 (for LDS5040, LDS5540, LDS4921 series)
7 (for LDS5560 series)
Adjustable
100% Fold down
8 ~ 27 (Normal)
279 (Normal)
106 ~ 141 (Normal)
Yes
Yes
Yes
Yes
Nylon Coating
0.5-8 (140-830 kPa)
- 5 -
For Authorized Service Technician
