INSTRUCTION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Citizen C710

Summary of Contents for Citizen C710

  • Page 1 INSTRUCTION MANUAL...
  • Page 2 Ⓜ Ⓑ Ⓐ...
  • Page 3 This watch is a combination quartz watch with calendar and various functions such as alarm, chronograph and timer. It also has a thermometer function and an EL (electroluminescence) light function.

  • Page 4: Table Of Contents

    Contents Name of parts …………………………………………………… 4 Setting the hands ……………………………………………… 7 Changing digital functions (modes) …………………………… 8 Using each function (mode) …………………………………… 9 A. Time mode <TME> ………………………………………… 9 B. Calendar mode <CAL> ………………………………… 12 C. Alarm mode <ALM> …………………………………… 14 D.
  • Page 5 Contents Low battery indicator ………………………………………… 26 All reset ………………………………………………………… 27 Using the bezel ………………………………………………… 28 Water resistance ……………………………………………… 33 Precautionary items and usage limitations ……………… 36 Specifications ………………………………………………… 42...

  • Page 6: Name Of Parts

    Name of parts Mode Time Calendar Name Press once Button Ⓐ EL light ON Press for more than 2 seconds Press once Thermometry Thermometry Button Ⓑ Press for more To calendar To time adjustment mode than 2 seconds adjustment mode Button Ⓜ...
  • Page 7 Name of parts Alarm Chronograph Timer Switching ON/OFF Start/Stop Start/Stop − − − − − − − − Alarm monitor − − − − Split/Reset Set time adjustment To alarm Quick set time − − − − adjustment mode adjustment To <CHR>...
  • Page 8 Name of parts 4: Graphic display Always indicates graphic, syncronized with digital display 1 5: Crown Used for setting analog 6: Hour hand Always indicates time (hours) 7: Minute hand Always indicates time (minutes) 8: Second hand Always indicates time (seconds) Senses current temperature, 9: Thermosenso shown by digital display 2...

  • Page 9: Setting The Hands

    Setting the hands Second hand (1) Pull the crown out to stop the second hand. (2) Turn the crown to set the correct time. (3) Press the crown back in to restart. Setting position Analog and digital time can be set individually as a dual-time watch.

  • Page 10: Changing Digital Functions (Modes)

    Changing digital functions (modes) Besides the time function, this watch has four other functions. Calendar, alarm, chronograph and timer. The current mode can be checked by the mode mark. Each time button Ⓜ is pressed, the watch mode changes in the following sequence. Mode mark Mode (function) Ⓜ...

  • Page 11: Using Each Function (Mode)

    Using each function (mode) A. Time mode <TME> When button Ⓐ is pressed or being pressed in time mode, the EL light is turned on. When button Ⓑ is pressed, the current temperature is recalculated. < Switching to summer time (daylight [Normal time display] saving time)>...

  • Page 12: Setting Digital Time

    Using each function (mode) * When watch is set to the summer time (ON). The “SUM. ” appears and the watch indicates time that is one hour ahead of standard time. <Setting digital time> (1) Press button Ⓑ in normal time mode for more than 2 seconds. The “SUM. ” and “ON/OF”...
  • Page 13 Using each function (mode) • When setting time in 12-hour indication system, make sure it is correctly set for the morning (AM) or the afternoon (PM). • If the watch is left in time setting mode (figures blinking) for more than 2 minutes, it returns to normal time display automatically.

  • Page 14: Calendar Mode

    Using each function (mode) B. Calendar mode <CAL> When button Ⓐ is pressed or being pressed in calendar mode, the EL light is turned on. When button Ⓑ is pressed, the current temperature is recalculated. <Setting calendar> [Normal calendar display] (1) Press button Ⓑ...
  • Page 15 Using each function (mode) • The Year (in the Christian era) can be set between 1998 and 2099. (Year display appears in calendar setting mode only.) • If the watch is left in calendar setting mode (figures blinking) for more than 2 minutes, the watch returns to normal calendar display automatically.

  • Page 16: Alarm Mode

    Using each function (mode) C. Alarm mode <ALM> Once this alarm is set (ON) , it sounds for 20 seconds at the same time every day. <Setting alarms> [Normal alarm display (ON)] (1) Press button Ⓑ in alarm mode for more than Alarm time 2 seconds.
  • Page 17 Using each function (mode) <Switching alarm ON/OFF> Each time button Ⓐ is pressed while in normal alarm display, the alarm is switched ON/OF(off) alternately. When the alarm is ON, the “ ON mark” turns on. Alarm ON mark Ⓐ <Alarm sound duration, Stopping alarm> The Alarm sound duration is 20 seconds.
  • Page 18 Using each function (mode) • When time mode is in 12-hour system, the alarm mode is in the same system. Be aware of A/P indication whether it is set for morning (AM) or afternoon (PM). • If time mode is set for summer time, it does not affect the alarm mode. •...

  • Page 19: Chronograph Mode

    Using each function (mode) D. Chronograph mode <CHR> The chronograph is capable of measuring and indicating a maximum of 23 hours, 59 minutes, 59 seconds and 999 milliseconds in increments of 1/1000 second. After 24 hours, it stops with a reset display of “00°00'00"000”. The chronograph can also measure split time (elapsed time).
  • Page 20 Using each function (mode) <Total elapsed time measurment> (1) The chronograph starts or stops each time button Ⓐ is pressed. (2) To reset the chronograph, press button Ⓑ after it is stopped. <Split time measurment> (1) The chronograph starts or stops each time button Ⓐ is pressed. (2) Press button Ⓑ...
  • Page 21 Using each function (mode) <Changing the mode during time measurement in chronograph mode> Even if button Ⓜ is pressed during a time measurement in chronograph mode and mode is changed, time measurement is continued internally. The measured time is shown when the mode is returned to chronograph again.

  • Page 22: Timer Mode

    Using each function (mode) E. Timer mode <TMR> The timer can be set for 1 minute to 60 minutes in increments of 1 minute. When the set time is up, a time-up warning sound is heard for about 5 seconds. After that, the timer returns to set time and stops.
  • Page 23 Using each function (mode) <Timer countdown> (1) Press button Ⓐ to start the timer at the set time. (2) If button Ⓐ is pressed during timer countdown, the timer stops. If button Ⓐ is pressed again, the timer restarts. (3) If button Ⓑ is pressed when the timer stops, the display returns to the timer set time.
  • Page 24 Using each function (mode) • Confirmation sound At the time of start, stop, reset or timer restart operation in timer mode, a confirmation sound is heard. <Changing modes during timer countdown> If button Ⓜ is pressed in timer mode to change the mode, the time countdown is continued internally.

  • Page 25: Using The Thermometer

    Using the thermometer The thermometer indicates the current or last measured temperature in all modes except the chronograph mode. Temperature is measured in two ways: 1. By button operation at any time 2. Automatically measured every hour, on the hour Temperature can be indicated either in centigrade (°C) or on Fahrenheit (°F).
  • Page 26 Using the thermometer <Temperature measurement range and accuracy> In Centigrade (°C) On Fahrenheit scale (°F) –9.9°C 〜 +59.9°C 14°F 〜 139°F Temperature display range Measurement unit 0.1°C 1°F 20°C 〜 30°C: ±1°C 68°F 〜 86°F: ±2°F Measurement accuracy –5°C 〜 +40°C: ±2°C 23°F 〜...
  • Page 27 Using the thermometer • Do not use the thermometer out of the display range. Extremely hot or cold temperature may cause breakdown of the watch. <Switching temperature display between centigrade and Fahrenheit> Press button Ⓐ in time or calendar mode for more than 3 seconds while pressing button Ⓜ...

  • Page 28: Low Battery Indicator

    Low battery indicator When the battery gets weak, the low battery indicator function appears in digital display 2 as shown below. • The second hand moves at 2-second intervals (moves by 2 increments every 2 seconds). • In time or calendar mode, the temperature display starts to blinking “- - -”. Even when the watch falls into such condition, it still displays the time but the EL light, thermometer and alarm will not function.

  • Page 29: All Reset

    All reset After replacement of the battery, be sure to perform the all reset operation as shown below. If the watch malfunctions or shows an abnormal display as a result of an excessive shock or static electricity (for example, the watch indicates nothing, continuously sounds alarm, etc.).

  • Page 30: Using The Bezel

    Using the bezel Some watches do not have the following bezel functions because of differences in type or design. 1. Compass function 2. Yachting function 1. Compass function (in the northern hemisphere) Compass direction can be approximated by this function, based on the direction of the sun.
  • Page 31 Using the bezel 2. Yachting function <Background knowledge> Wind Windward mark In general yacht racing, such markings as shown in the figure are set in the course. Yachtsmen compete in how fast they can sail the course in the specified order. Sailing directions are specified by angles such as north Side mark = 0°, east = 90°, south = 180°, west = 270°.
  • Page 32 Using the bezel (2) The course toward the side mark from the windward mark (starboard reach) is in the direction of the green “ ▲ ” mark located in the lower left side. Therefore, sail in this direction so that the yacht reaches the side mark even when the mark is hard to find because of bad weather.
  • Page 33 Using the bezel <Using bezel-2> The yacht can sail in the windward direction Wind at an angle of 45° (high performance yacht can sail 40°). If the yacht is sailed in the windward direction before race and the obtained angle at the red or green mark (upper right or upper left) is set, the wind shift can be read during the race.
  • Page 34 Using the bezel <Using bezel-3> The bezel can be used to find the angle of the start Direction of wind line to the wind direction. The start line is generally set to the wind at an angle of 90°. However, it seldom is the real right angle because the wind direction changes frequently.

  • Page 35: Water Resistance

    Water resistance WARNING Water Resistance • Non-water resistant models are not designed to come into contact with any moisture. Take care not to expose a watch with this rating to any type of moisture. • Water resistance for daily use (to 3 atmospheres) means the watch is water resistant for occasional accidental splashing.
  • Page 36 Water resistance • Refer to the watch dial and the case back for the indication of the water resistance of your watch. The following chart provides examples of use for reference to ensure that your watch is used properly. (The unit “1bar” is roughly equal to 1 atmosphere.) •...
  • Page 37 Water resistance Water-related use Minor exposure Swimming and Operate the crown to water (washing general washing Skin diving, Scuba diving or button when face, rain, etc.) work marine sports using an air tank the watch is wet...

  • Page 38: Precautionary Items And Usage Limitations

    Precautionary items and usage limitations CAUTION To Avoid Injury • Be particularly careful when wearing your watch while holding a small child, to avoid injury. • Be particularly careful when engaged in strenuous exercise or work, to avoid injury to yourself and others.
  • Page 39 Precautionary items and usage limitations • Even if your watch has a high level of water resistance, please be careful of the following. • If your watch is immersed in sea water, rinse thoroughly with fresh water and wipe with a dry cloth.
  • Page 40 For band adjustment, we recommend you consult the retailer from where the watch was purchased or your nearest Authorized Citizen Service Center. Some repair shops may charge a nominal fee for adjustment if the watch was not purchased directly from them.

  • Page 41: Static Electricity

    Precautionary items and usage limitations <Magnetism> • Analog quartz watches are powered by a step motor that uses a magnet. Subjecting the watch to strong magnetism from the outside can cause the motor to operate improperly and prevent the watch from keeping time accurately.
  • Page 42 Precautionary items and usage limitations <Protective Stickers> • Be sure to remove any protective stickers that may be on your watch (case back, band, clasp, etc.). Otherwise, perspiration or moisture may enter the gaps between the protective stickers and the parts, which may result in a skin rash and/or corrosion of the metal parts.

  • Page 43: Caring For Your Watch

    Precautionary items and usage limitations Caring for Your Watch • Wipe any dirt or moisture such as perspiration from the case and crystal with a soft cloth. • For a metallic, plastic or rubber (urethane) watchband, wash any dirt off with water. Remove the small amounts of dirt trapped between the crevices of the metallic band with a soft brush.

  • Page 44: Specifications

    Specifications 1. Caliber No.: C71* 2. Type: Combination (analog and digital) quartz watch 3. Watch accuracy: ±20 seconds per month (average) [Worn at room temperature: +5°C to +35°C (41°F to 95°F)] 4. Operating temperature range: 0°C to +55°C (32°F to 131°F) 5.
  • Page 45 Specifications 8. Battery life: 2 years approx. (operating conditions; alarm sound: 20 seconds/ day, time-up sound in the timer mode: 5 seconds/day, EL light: 3 seconds/day) * The specified battery assures the accuracy for 2 years when the watch is used in the standard operating condition as mentioned above. However, the service life of the battery differs greatly depending on the frequency of use of the alarm, chronograph, EL light, etc.
  • Page 48 Model No.JS1 ＊ Cal.C710 CTZ-B8010 ⑥...
