Document Number - AVRPDMAN190701E
RapidDome (24V AC)
Owners Installation Guide
Sales: .................................... 800-467-5875
Applications ......................... 877-653-0302
Technical Support ................ 800-645-7492
Fax........................................ 516-921-4307
Web site................................ www.ademcovideo.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RapidDome and is the answer not in the manual?

Questions and answers

Related Manuals for ADEMCO RapidDome

Summary of Contents for ADEMCO RapidDome

  • Page 1 Document Number - AVRPDMAN190701E RapidDome (24V AC) Owners Installation Guide Sales: ........800-467-5875 Applications ......877-653-0302 Technical Support ....800-645-7492 Fax........516-921-4307 Web site........ www.ademcovideo.com...

  • Page 2: Table Of Contents

    Table of Contents Introduction to the RapidDome 1 Setting up the RapidDome Wiring Details Settings on the RapidDome Top Board (VC445V3) Setting Protocols (Ademco Video & Pelco) Coax Control LED on the RapidDome Bottom Board (VC444/3) Alarm / Relay Connections...

  • Page 3: Safety Instructions

    These products contain static electricity sensitive devices. Please take appropriate precautions when handling. Handle the RapidDome with care, as improper handling may cause ir- reparable damage to the precision or sensitive parts within this unit. Never point the camera directly towards a bright light source (for ex- ample sunlight), or expose the camera to intensive light situations as this may damage the camera pick-up device.

  • Page 4: Introduction To The Rapiddome

    360° continuous pan rotation and manual variable speed control at 0.1-100°/second. Because of its attractive compact design and with its low profile (at only 5"), the RapidDome makes the perfect choice for applications where aesthetics are critical. RapidDome is available in two standard dome assemblies; a false ceiling mount and a plug and play pendant.
  • Page 5 (1.0 lux) makes it ideal for the vast majority of indoor installations. • Continuous auto focus with manual override: No matter what the zoom position, RapidDome’s images remain in sharp focus. When the scene requires extra fine control, RapidDome allows the operator to overrride the auto focus settings. •...
  • Page 6 • Preset positioning, alarm activation, and tour capabilities: Introduction RapidDome presets can easily be set up and recalled by the operator when using ADEMCO Video RapidView systems. Three tours may be programmed. Each of RapidDome’s alarm inputs automatically call a preset when an alarm is activated.

  • Page 7: Setting Up The Rapiddome

    1. Setting up the RapidDome 1.1 Wiring Details 1.1.1 Mounting The RapidDome is designed for speed of installation and set up and so the wall and ceiling mount brackets are supplied pre-wired. Customer Chapter 1 wiring is via an internal terminal block PCB which is located inside the base plastic cover.
  • Page 8 24V AC 1.1.3 False Ceiling Mount From end of cable Solder side view of socket fitted on 3 meter (9.84 feet) cable supplied Figure 2 Wiring Details for the RapidDome (False Ceiling Mount) © Ademco Video 2001 AVRPDMAN190701E Page 5...
  • Page 9 Used) Pin 5 Coax Video Pin 5 Coax Video Shield Ground Shield Ground Pin 6 Coax Video Pin 6 Coax Video Core Signal Core Signal Pin 7 (Not Pin 7 (Not Used) Used) Page 6 © Ademco Video 2001 AVRPDMAN190701E...

  • Page 10: Settings On The Rapiddome Top Board (Vc445V3)

    Installation & Operation Guide RapidDome 1.2 Settings on the RapidDome Top Board (VC445V3) In the following section, please refer to Figure 3 below, for the locations on the board. ' ' Chapter 1 D ILSW 1 - R a pidD o m e ad dre ss settin g D IL S w itc h .

  • Page 11: Setting Protocols (Ademco Video & Pelco)

    Installation & Operation Guide 1.3 Setting Protocols (Ademco Video & Pelco) 1.3.1 Selecting the Control Protocol Using the last 2 poles of DIL Switch 1 on the RapidDome board (see Figure 3) set the switches as shown in the table below Table 3...
  • Page 12 ',/ 6:,7&+ 6(77,1*6 'HQRWHV WKH 'HQRWHV WKH VZLWFK SRVLWLRQ VZLWFK SRVLWLRQ ZKHUH ZKHUH 21 21 Chapter 1                 © Ademco Video 2001 AVRPDMAN190701E Page 9...

  • Page 13: Coax Control

    RapidDome Installation & Operation Guide 1.3.3 Additional Features The following RapidDome functions are implemented for use with the Pelco protocol: • Variable Speed Pan & Tilt. • Zoom / Focus & Iris. Digital Zoom is always enabled, but if controlled using AV protocol...

  • Page 14: Led On The Rapiddome Bottom Board (Vc444/3)

    Installation & Operation Guide RapidDome 1.5 LED on the RapidDome Bottom Board (VC444/3) In the following section, please refer to Figure 4, below, for the locations on the board. Chapter 1 D 19 - D a ta R e ceiv ed L E D...

  • Page 15: Alarm / Relay Connections

    Installation & Operation Guide 1.6 Alarm / Relay Connections The connections to the alarm inputs and relay output are via 2 RJ45 sockets located at the top of the RapidDome, shown in Figure 5, below. Chapter 1 C onnector 3...

  • Page 16: Rj45 Connector

    Note: Relay 2 is controlled by a RapidViews’ ‘0’ ‘AUX’ momentary function and can be used to control auxiliary equipment. Note: The maximum current rating for the 2 relays is 1A @ 24V DC or 0.5A @ 120V AC © Ademco Video 2001 AVRPDMAN190701E Page 13...

  • Page 17: Installing The Rapiddome

    RapidDome Installation & Operation Guide 2. Installing the RapidDome Note: When handling the RapidDome, DO NOT touch the acrylic, or any sensitive or precision parts, as this will cause damage to the unit. 2.1 Installation Process 2.1.1 Ceiling and Wall Mounted Models Figure 7, below, details the ceiling and wall mount brackets, including dimensions.
  • Page 18 Figure 8 Fitting the RapidDome into the bracket Instruction Step 2 Align the lug on the RapidDome with the slot on the bracket. Carefully push the RapidDome into the bracket and twist clockwise. Allow to drop into the retainer. See Figure 8 & Figure 9.
  • Page 19 Figure 10 Fitting the Cable Covers Note: When the RapidDome is to be fitted to a mounting pole, then the hole in the cable cover will need to be aligned with the screw hole in the pole when fitting the M3 CSK safety locking screw as shown in Figure 11.
  • Page 20 1½" NPT female threaded socket to work comfortably on. Make all necessary electrical connections and terminations to the connector, noting the cable, connector and socket orientations. See figure 13. © Ademco Video 2001 AVRPDMAN190701E Page 17...
  • Page 21 By doing so, the center part of the adapter is prevented from rotating and the cable inside is prevented from twisting up while the 1½" NPT thread engages. Page 18 © Ademco Video 2001 AVRPDMAN190701E...
  • Page 22 2.1.6 False Ceiling Model Note: The RapidDome is designed to be mounted in a flat ceiling installation. Mounting the RapidDome in an angled ceiling installation will affect the units center of gravity and, consequently, programmed tours will be affected.
  • Page 23 (Point ‘A’). Step 5 Insert the RapidDome through the ceiling and fit the retaining disk to the back of the RapidDome. (The rear of the the ceiling face). Step 6 Screw down the three M4 Nyloc nuts to lock the RapidDome into place.

  • Page 24: Technical Specifications

    Digital Zoom ........2X Focus & Iris .......... Auto/Manual Override Design........... Aspherical Focal Length......... 5.4-64.8 mm Aperture..........ƒ 1.8 Viewing Angle ........5.4mm 48.8° (H) x 37.6° (V) 64.8mm 4.4° (H) x 3.3° (V) © Ademco Video 2001 AVRPDMAN190701E Page 21...
  • Page 25 Manual Pan Speed ........ 0.1°-100°/second Preset Pan Speed ........300°/second maximum Pan Travel..........360° continuous Manual Tilt Speed ........ 0.1° to 100°/second Preset Tilt Speed........200°/second maximum Tilt Travel..........90° Pan/Tilt Accuracy......... 0.25º Page 22 © Ademco Video 2001 AVRPDMAN190701E...
  • Page 26 Alarm Outputs........2 relay outputs (Form-C) 1A@24VDC or 0.5A@120VAC Electrical Voltage ..........24VAC, Class 2 LPS, 60 Hz Power............ 40 Watts Power On-Rush Current ....... 2.1 AMPS Surge Protection RS485 ........... Transorbs Alarm Inputs......... Filtered for transients © Ademco Video 2001 AVRPDMAN190701E Page 23...
  • Page 27 RS232 control code Code Distribution Unit ADCD8TP ..........8 independent RS485 TP code outputs TP= Twisted Pair, UTC= Up-the-Coax AD5RCFC12.........RapidDome False Ceiling Version, NTSC AD5RCFC12X........RapidDome False Ceiling Version, AD5RC12..........RapidDome Plug & Play Pendant, NTSC Page 24 © Ademco Video 2001 AVRPDMAN190701E...
  • Page 28 Installation & Operation Guide RapidDome AD5RC12X...........RapidDome Plug & Play Pendant, AD5PB80 ..........Plug & Play Extension, 80mm (3”) AD5PB300 ........... Plug & Play Extension, 300mm (12”) AD5PB600 ........... Plug & Play Extension, 600mm (24”) AD5PBNPT.......... Plug & Play 1-1/2 inch NPT Adapter AD5WBW ..........

  • Page 29: Appendix A. Typical System Diagrams

    3 (termination off), for all RapidDomes in the chain except the final one. The double link must be fitted across pins 1 and 2 of the last RapidDome. (Termination on). Figure 17 on page 28 shows a system using two RapidDomes in this way.

  • Page 30: Star Connections

    Connection to one twisted pair output using long cables - use the ‘daisy chain’ method detailed above instead. If separate cables are brought back from the RapidDome to the transmitter then the code distributor (ADCD8TP) must be used to provide individual RS485 output to the cameras.
  • Page 31 IMPORTANT: The above rules concerning the use of RS485 must be adhered to so that the control data is not corrupted. Failure to adhere to these rules will seriously reduce the performance of the RapidDome. _______________________________________________________ Page 28 © Ademco Video 2001 AVRPDMAN190701E...
  • Page 32 388 Castle Peak Road Madrid Tsuen Wan, N.T Spain Hong Kong 34-91-533-4706 852-2405-2323 Security House LATIN AMERICA Amperestraat 41 ADEMCO International (Latin America) 1446 TR Purmerend 1769 NW 79 Ave. Netherlands Miami, FL 33126 31-299-419-000 1-305-477-5204 Video Controls Ltd. Aston Fields Rd.
  • Page 33 Ademco Video 175 Eileen Way Syosset NY 11791 All documentation subject to change without notice.
