Summary of Contents for THUNDER TIGER Raptor 60
- Page 2 Shaft Drive Tail Rotor The Raptor 60 is designed with a constant drive tail rotor system to permit full tail rotor control during autorotations. Backward autos, pirouette autos and 180 autos are all within your reach now. It has the same aluminum torque tube system as the Thunder Tiger/Taya Imperio helicopter.
- Page 4 Thunder Tiger products are distributed by Ace Hobby Distributors. On the web site www.acehobby.com, there is a list of all the hobby shops in the USA that can special order any Thunder Tiger parts from Ace for you. Technical questions on the Raptor will be answered quickly sending an email to service@acehobby.com or call Technical Support at 949-...
- Page 5 Please monitor the fuel level during flight so you do not run out of fuel during flight. Before each flight, please check that all servos and controls move properly. Do not modify any parts or use other than genuine Thunder Tiger parts. Do not fly in places that are forbidden by law.
- Page 6 MAIN FRAME ASSEMBLY For the kit, parts are bagged according to each major assembly and are labeled "Bag A, Bag B, etc." You will note that the heading for each assembly indicates which bag correlates with each assembly. As a good practice, only open up the bag that you need for the particular assembly.
- Page 7 Upper Frame Assembly BAG A...
