Part No. Z1-002-902, IA002963
Jan 2007

OPERATION MANUAL

REMOTE CONTROLLER
PCR-LA Series
RC04-PCR-LA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC04-PCR-LA and is the answer not in the manual?

Questions and answers

Related Manuals for Kikusui RC04-PCR-LA

Summary of Contents for Kikusui RC04-PCR-LA

  • Page 1: Operation Manual

    Part No. Z1-002-902, IA002963 Jan 2007 OPERATION MANUAL REMOTE CONTROLLER PCR-LA Series RC04-PCR-LA...
  • Page 2 If the manual it gets lost or soiled, a ne w cop y can be pro vided for a fee. In either case, please contact Kikusui distrib utor/agent, and pro vide the “Kikusui P art No. ” gi v en on co v er .

  • Page 3: Safety Symbols

    Is placed before the sign “DANGER,” “WARNING,” or “CAUTION” to emphasize these. When this symbol is marked on the product, see the relevant sections in this manual. Indicates a protective conductor terminal. Indicates a chassis (frame) terminal. RC04-PCR-LA Safety Symbols I...

  • Page 4: Arrangement Of This Manual

    Arrang ement of this man ual This Operation Manual is made up of the follo wing sections. Chapter 1 General Outlines and describes the features of the RC04-PCR-LA Remote Controller . Chapter 2 Precautions and Preparation f or Use Pro vides the precautions and preparation information that must be understood for use of the Remote Controller .

  • Page 5: Table Of Contents

    Mode- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-10 4.3.4 Peak Holding Current Measurement Mode - - - - - - - - - 4-10 4.3.5 Power Line Abnormality Simulation - - - - - - - - - - - - - 4-13 RC04-PCR-LA Contents III...
  • Page 6 Index - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - I-1 IV Contents RC04-PCR-LA...

  • Page 7: Chapter 1 General

    Outline This device (RC04-PCR-LA) is a remote controller for the PCR-LA Series AC power supplies. Use of the RC04-PCR-LA with a PCR-LA AC power supply signifi- cantly extends the power supply functions. Features Use of the Remote Controller allows the PCR-LA AC power supplies to utilize the following enhanced functions in addition to the power supplies’...
  • Page 8 (memory addresses 1 to 9), and reading the data for output as necessary. Connecting the device to the PCR-LA power supply allows a maxi- mum of 99 sets of voltage and frequency to be stored in the memory. 1-2 General RC04-PCR-LA...

  • Page 9: Applicable Product Version

    This Remote Controller requires the PCR-LA Series AC power sup- plies equipped with ROM of version 3.08 or later. This Operation Manual applies to the RC04-PCR-LA Remote Con- trollers equipped with ROM of version 1.0X. When making an inquiry about the product, please provide us with...
  • Page 10 1-4 General RC04-PCR-LA...

  • Page 11: Chapter 2 Precautions And Preparation For Use

    Provides the precautions and preparation information that must be understood for use of the Remote Controller. Check at Unpacking The RC04-PCR-LA Remote Controller was carefully tested and inspected, both mechanically and electrically, before shipment to ensure its normal operation. Check the Remote Controller upon receipt for damage that might have occurred during transportation.

  • Page 12: Handling Precautions

    Together with the RC04-PCR-LA Option name Model name Remote Controller RC03-PCR-LA Table 2-2 Option That Can be Installed Together with the RC04-PCR-LA, but Cannot be Used Simultaneously Option name Model name GPIB Interface IB03-PCR-LA 2-2 Precautions and Preparation for Use...

  • Page 13: Connecting The Remote Controller Cable

    2. Close the core so that the cable is not caught in it. 3. As shown in Fig. 2-3, tie up the cable with the accompany- ing stopper band. Keep the distance between the plug and the core below 100 mm. RC04-PCR-LA Precautions and Preparation for Use 2-3...

  • Page 14: Installation Of The Connector Cover

    2. Insert the cover till it is locked. Fig.2-4 Connector Cover Installation Removal 1. As shown in Fig. 2-5, unlock the connector cover with twee- zers. 2. Slowly pulled down the connector cover. Fig.2-5 Connector Cover Removal 2-4 Precautions and Preparation for Use RC04-PCR-LA...

  • Page 15: Moving Precautions

    Attaching the Magnet Sheet • When the provided magnet sheet is on the back of CAUTION the remote controller, never place the remote control- ler near magnetic-susceptible items, such as floppy disks and credit cards. RC04-PCR-LA Precautions and Preparation for Use 2-5...

  • Page 16: Quick Reference Card

    The remote controller has a quick reference card that briefly describes keys and simulation waveforms. This card is useful when using the memory, sequence, or special waveform output functions. Fig.2-7 Quick Reference Card 2-6 Precautions and Preparation for Use RC04-PCR-LA...

  • Page 17: Chapter 3 Operation Check

    If the Remote Controller is not in the Initial Setup Status, use the reset function to activate the Initial Setup Status. Reset can be performed either on the PCR-LA AC power supply or via the Remote Controller. To perform a reset on the PCR-LA AC power supply, see instructions RC04-PCR-LA Operation Check 3-1...
  • Page 18 To adjust the contrast of the Remote Controller LCD unit, use a small screwdriver to turn the part shown in the figure. Adjust LCD contrast to match lighting conditions at the operating location to obtain an easy-to-see display. CONTRAST Fig.3-1 Contrast Adjustment 3-2 Operation Check RC04-PCR-LA...

  • Page 19: Operation Check

    3. Turn JOG or SHUTTLE to check that the voltage changes on the display. This completes the operation check. This operation check does not check all functions. However, if the operation check has been complete, the main functions operate cor- rectly. RC04-PCR-LA Operation Check 3-3...
  • Page 20 Setup Status. In this condition, the PCR-LA AC power supply back-up data has been lost for some reasons. Re-check the steps described in sections 2.4 and 2.5. If this still does not remedy the condition, notify Kikusui distributor/agent. P A N E L B A C K...

  • Page 21: Chapter 4 Operation Method

    F R Q V r m s In the figure below (next page example, sequence setting display), the F1 to F5 keys correspond to the five items displayed at the lower part of the display respectively. RC04-PCR-LA Operation Method 4-1...

  • Page 22: Functions In Common With The Pcr-La Ac Power Supply

    OUTPUT ON/OFF OUTPUT key Self-test function SELF TEST (SHIFT, 3) Key-lock function KEYLOCK (SHIFT, 4) Sensing function SENSING (SHIFT, 5) Reset function RESET (SHIFT, 6) Output voltage range change RANGE (SHIFT, 7) Synchronization function SYNC (SHIFT, 9) 4-2 Operation Method RC04-PCR-LA...

  • Page 23: Functions Whose Key Operation Differs From That Of The Pcr-La Ac Power Supply

    Supply Operation Manual. Voltage setting function To enter the voltage setting mode on the Remote Controller, press the F5 (Vrms/Vpk/Vset/Vave) key in the Home Position. (On the PCR- LA AC power supply, press the V key.) RC04-PCR-LA Operation Method 4-3...

  • Page 24: Functions Extended By Using The Remote Controller

    AC, AC-S and DC. Use of the Remote Controller allows an additional output voltage mode, AC + DC mode. The AC + DC mode is a func- tion that superimposes DC voltage on AC voltage or vice versa. 4-4 Operation Method RC04-PCR-LA...
  • Page 25 DC voltage setting mode, “DC” blinks in the MODE display area. Use the numeric keys or JOG/SHUTTLE to set the AC or DC output voltage. For setting using the numeric keys, press the ENTER key to confirm the value. RC04-PCR-LA Operation Method 4-5...

  • Page 26: Memory Function

    3. Using the F1, F3, and F5 function keys and the MENU key, select the desired item. Selectable items are shown in Table 4-3. To select an item, follow steps 4 onward. The Setting display consists of two displays that can be switched using the MENU key. 4-6 Operation Method RC04-PCR-LA...
  • Page 27 For the waveform banks, see “4.3.8 Special Waveform Output”. W 0 0 + 0 . 0 V A D R S WA V E V d c 6. Press the ESC key to quit the memory edit mode. RC04-PCR-LA Operation Method 4-7...
  • Page 28 Changes in the Output Voltage in Reading Data from Memory In the actual case, the duration of 30 μs shown in the above figure is very short in comparison with each ADRS time. Out- put voltage changes like pulse. 4-8 Operation Method RC04-PCR-LA...
  • Page 29 ESC key. Pressing the ESC key allows you to exit the memory content-indi- cating display. Press the ENTER key to confirm the set values, then press the ESC key to end the memory read operation. RC04-PCR-LA Operation Method 4-9...

  • Page 30: Power, Power Factor, And Apparent Power Measurement

    Therefore, peak cur- rent display shows an absolute value (no positive or negative symbol). A peak value can be measured in the AC, DC, or AC + DC mode. 4-10 Operation Method RC04-PCR-LA...
  • Page 31 AC mode. Irms WATT In the DC or AC + DC mode, the indication changes as follows: Irms WATT Iave Where “Ip” is peak current value display and “Iph” is peak holding current value display. RC04-PCR-LA Operation Method 4-11...
  • Page 32 Upper rear part of PCR-LA Internal circuit of PCR-LA AC Power Supply PEAK INIT IN terminal SLOT 4 SLOT 3 SLOT 2 (GPIB) SLOT 1 Fig.4-3 PEAK INIT IN Terminal and Its Circuit 4-12 Operation Method RC04-PCR-LA...
  • Page 33 F1 to F5 keys, and a value is set using the numeric keys or JOG/SHUTTLE. (For setting using the numeric keys, press the ENTER key to confirm the value.) Fig.4-5 Simulated Waveforms and Parameters RC04-PCR-LA Operation Method 4-13...
  • Page 34 The final voltage value increased (pop) or decreased (dip). This value is specified at the interval of T3. Third Repetition count display The number of repetitions from T1 to T5 (N). • For items T5 or N, specify one 4-14 Operation Method RC04-PCR-LA...
  • Page 35 • When T5 is set to other than integral multiple of 1 cycle, the real restoration duration gets longer than the set T5 time because the voltage change is started after the waveform crossed the zero level. RC04-PCR-LA Operation Method 4-15...
  • Page 36 Table 4-6 Magnifications and Keys for Switching Item Magnification Key operation x1 ms/x1 deg T1 (SHIFT, F1) x1/x10 T2 (SHIFT, F3) x1/x10 T3 (SHIFT, F5) x1/x10 T4 (SHIFT, F1) x1/x10 T5 (SHIFT, F3) x1/x10/x100 T5 (SHIFT, F3) 4-16 Operation Method RC04-PCR-LA...
  • Page 37 12.Press the F1 (RUN) key. This starts the simulation of power line abnormality. During power line abnormality simulation, the “RUN” indication on the Remote Controller lights up and “1” in the S-MODE area on the PCR-LA power supply control panel lights up. RC04-PCR-LA Operation Method 4-17...
  • Page 38 This function changes phase by 180 degrees. In this case, the output voltage (waveform) of L is based on N of the PCR-LA AC power supply OUTPUT terminal board. Positive zero Negative zero crossing crossing Fig.4-6 Zero Crossing 4-18 Operation Method RC04-PCR-LA...

  • Page 39: Sequence Operation

    In addition, the validity/invalidity of set values in sequence operation is determined by the output mode used to run a sequence. In Fig. 4-8, the relationship between the validity and the output modes is also shown. RC04-PCR-LA Operation Method 4-19...
  • Page 40 H O U R M I N S E C Setting range TIME HOUR 0 hr to 999 hrs 59 min 0 min to 999 min 59 sec 0.001 sec to 999.999 sec Fig.4-8 Sequence Setting Mode 4-20 Operation Method RC04-PCR-LA...
  • Page 41 AC+DC ✔ ✔ ✔ F1 (ADRS) Sequence address ✔ ✔ ✔ F3 (STAT) Status signal ON/OFF ✔ ✔ ✔ F4 (TRG) Trigger signal ON/OFF ✔ ✔ ✔ F5 (OUT) OUTPUT ON/OFF Fig.4-8 Sequence Setting Mode (Cont‘d) RC04-PCR-LA Operation Method 4-21...
  • Page 42 • Address 0 does not allow ramp specification. • Ramp specified at the start address is ignored during execution, and frequency or AC voltage changes by steps. • Ramp operation is not available in DC mode. 4-22 Operation Method RC04-PCR-LA...
  • Page 43 0 . 0 0 0 s 0h0m H O U R M I N S E C 0m0s 0.000s The time indication in the center of the display changes as shown in the table when the relevant function key is pressed. RC04-PCR-LA Operation Method 4-23...
  • Page 44 • Address 0 allows no ramp specification. Ramp specified for the start address is ignored, and frequency or AC voltage changes in step form. • Starting sequence operation in the DC mode causes frequency and AC voltage setting to be ignored. 4-24 Operation Method RC04-PCR-LA...
  • Page 45 Changes in the Output Voltage in Reading Data from Memory In the actual waveform, since the 30 μs shown in the above figure is very short in comparison with each ADRS time, out- put voltage changes like pulse. RC04-PCR-LA Operation Method 4-25...
  • Page 46 SEQ STAT OUT Terminal and Its Circuit NOTE • The status signal may output when any change occurred in the parameter setting under the Power Line Abnormality Sim- ulation or in the sequence setting under the Sequence Opera- tion. 4-26 Operation Method RC04-PCR-LA...
  • Page 47 OUT terminal TRIG SLOT 4 SLOT 3 SLOT 2 (GPIB) SLOT 1 Fig.4-12 SEQ TRIG OUT Terminal and Its Circuit NOTE • The trigger signal may output when any change occurred in the condition of sequence. RC04-PCR-LA Operation Method 4-27...
  • Page 48 R U N S T R T E N D L O O P (Example of setting the start address to “1”) 4-28 Operation Method RC04-PCR-LA...
  • Page 49 Setting OUTPUT key to OFF or pressing the ESC key in the pause status causes the sequence to stop. • During execution of the sequence, “1” in the S-MODE area on the PCR-LA power supply control panel lights up. RC04-PCR-LA Operation Method 4-29...
  • Page 50 OFF. Therefore, OUTPUT is not set to OFF until after the step being executed when the OUTPUT key was pressed has been output for several hundred ms. Output OFF Several hundred ms Fig.4-13 Lagged OUTPUT OFF 4-30 Operation Method RC04-PCR-LA...
  • Page 51 One point is sampled in one period of waveform. This sam- pling is repeated 256 times, and 256 points of data are obtained. Because 256 periods of waveform is required to obtain data for calculation, measurement window is 256 peri- ods. RC04-PCR-LA Operation Method 4-31...
  • Page 52 -48 VDC voltage and output for one second. The set values of these sequence operation examples are given in the setting sheet on the next page. The setting sheet is included in the “Appendix”. 4-32 Operation Method RC04-PCR-LA...
  • Page 53 (2) ADR 4 to 13 Automatic power line environment test (voltage variation, instantaneous voltage drop, voltage drop, and voltage rise) (3) ADR 14 to 15 AC + DC output (50 Vrms AC at 16 Hz, +48 V/-48 V DC) RC04-PCR-LA Operation Method 4-33...

  • Page 54: Harmonic Current Analysis Function

    When the F3 (%) key is pressed, the harmonic current value is dis- played as a percentage, with a current value not containing har- monic current regarded as 100%. (First display for ALL) (First display for ODD) (First display for EVEN) 4-34 Operation Method RC04-PCR-LA...
  • Page 55 • Harmonic analysis can be performed using the PCR-LA Series only. However, harmonic analysis generally requires that line impedance is adjusted to the standard value. There- fore, the Line Impedance Network (LIN Series) is also neces- sary. RC04-PCR-LA Operation Method 4-35...

  • Page 56: Special Waveform Output

    Waveform bank display SIN: Sine waveform P.C: Peak-clipped waveform USR: User defined waveform (see the PCR-LA AC Power Supply Operation Manual.) • Crest Factor Crest factor is the ratio between AC waveform rms and peak values. 4-36 Operation Method RC04-PCR-LA...
  • Page 57 W00 through W04.) 3. Press the MENU key to select the display to change the waveform banks to be displayed. Three displays are provided. These are selected in turn whenever the MENU key is pressed. RC04-PCR-LA Operation Method 4-37...
  • Page 58 Home Position. Special Waveform Output Mode Operating Procedure • Special waveform output is available only in the AC or AC + DC mode. 1. Press the ESC key to call the Home Position. 4-38 Operation Method RC04-PCR-LA...
  • Page 59 NOTE • The waveform always switches to the selected one after com- pleting a single cycle. Even if a waveform bank is selected here, the waveform actually changes at this point. Fig.4-18 Waveform Switching RC04-PCR-LA Operation Method 4-39...

  • Page 60: Output Impedance Setting

    Setting 0 ohm cancels output impedance setting. Switching the PCR-LA AC power supply output range always sets output impedance to 0 ohm. When the output impedance setting function is operating, “2” lights up in the PCR-LA AC power supply S-MODE area. 4-40 Operation Method RC04-PCR-LA...
  • Page 61 Therefore, data obtained by output impedance setting can be used only as a approximation of harmonic current analysis. Accurate data acquisition requires that the Line Impedance Network (LIN Series) should be used. RC04-PCR-LA Operation Method 4-41...

  • Page 62: Output On/Off Phase Setting

    O U T – O N O U T – O F F 4. Press the F3 (OUT_ON) or F5 (OUT_OFF) key to select ON or OFF phase. If the F3 (OUT_ON) key is pressed, the following display appears. 4-42 Operation Method RC04-PCR-LA...
  • Page 63 The set content is backed up inside the PCR-LA AC power supply. Therefore, once a setting is made using the Remote Controller, the power supply can operate in the same condition continuously even if the device is disconnected, as long as the setting conditions remain the same. RC04-PCR-LA Operation Method 4-43...

  • Page 64: Regulation Adjustment

    +10% of the PCR-LA power supply output volt- age. 1. Press the ESC key to call the Home Position. 2. Press the MODE key. The PCR-LA power supply will enter the key-lock mode automat- ically. 4-44 Operation Method RC04-PCR-LA...
  • Page 65 5. Press the ESC key to return to the Home Position. This will cancel the key-lock mode in the PCR-LA power supply. Pressing the ESC key on the PCR-LA power supply also returns the status to the Home Position. RC04-PCR-LA Operation Method 4-45...

  • Page 66: Zero Calibration Function For Measured Current Values -4-46

    4. Press the ESC key to exit the zero calibration mode. The calibrated value will be stored in the PCR-LA power supply. However, re-calibration must be performed, depending on changes in ambient temperature and the like. 4-46 Operation Method RC04-PCR-LA...

  • Page 67: Chapter 5 Parts Names And Functions

    Chapter 5 Parts Names and Functions Denotes the names of the switches, indications, and other parts of the RC04-PCR-LA, and describes their functions. Fig.5-1 RC04-PCR-LA (front view) [1] OUTPUT key Selects output ON/OFF. (Whenever this switch is pressed, output ON/OFF is switched alternately.) When output is ON, the LED at the right of the key lights up.
  • Page 68 Selects the limit value display mode for voltage, frequency, and current. PHASE (SHIFT, 2) key Available when the device is connected to a three-phase system PCR-LA power supply. SELFTEST (SHIFT, 3) key Selects the self-test mode in the event of an alarm or overload. 5-2 Parts Names and Functions RC04-PCR-LA...
  • Page 69 In the digit mode, the cursor (under bar) blinks below the digit to change in the LCD’s voltage or frequency display area, thereby allowing the relevant digit and higher digits (left of the relevant digit) to be changed. RC04-PCR-LA Parts Names and Functions 5-3...
  • Page 70 F1 to F5 key for data setting. CUR HMNC (SHIFT, SEQ) key Selects the harmonic current analysis mode. In the harmonic current analysis mode, press the F1 (ALL/ODD/ 5-4 Parts Names and Functions RC04-PCR-LA...
  • Page 71 “AC” and “DC” in the AC + DC mode. [19]POL indication Displays the voltage change start polarity. For positive polarity, “+” lights up; for negative polarity, “-” lights up. [20]RUN indication Lights up while a sequence or simulation is in operation. RC04-PCR-LA Parts Names and Functions 5-5...
  • Page 72 PCR-LA AC power supply or other vertical steel surface. Fig.5-2 RC04-PCR-LA [28]Quick reference card (side view) Briefly describes keys and simula- tion waveforms. Pull it out and use as necessary.

  • Page 73: Chapter 6 Maintenance

    Chapter 6 Maintenance Describes the maintenance procedures for the RC04-PCR-LA. Cleaning If the panel surface becomes soiled, wet a piece of soft cloth with a water-diluted neutral detergent, and wipe the panel gently. • Be sure to turn the POWER switch of the PCR-LA CAUTION power supply OFF before performing maintenance.

  • Page 74: Before Requesting A Repair

    Before Requesting a Repair If a problem occurs in the RC04-PCR-LA, check that problem in accordance with the following Table 6-1. Also, disconnect the Remote Controller from the PCR-LA AC power supply and check if the power supply alone operates normally. If it is not possible to recover a normal status, contact Kikusui distributor/agent to request repairs.

  • Page 75: Chapter 7 Specifications

    1 cycle 0 cycle to 99 990 cycles 10 cycles x100 0 cycle to 999 900 cycles 100 cycles V (T3) Same as output voltage setting 0.1 V range 0 to 9998 times or ∞ Once Once RC04-PCR-LA Specifications 7-1...
  • Page 76 100 V range 0 Ω to 0.333 Ω 3.33 mΩ ± (20 % +6.67 mΩ) 6000LA 200 V range 0 Ω to 1.333 Ω 13.33 mΩ ± (20 % +26.67 mΩ) Output ON/OFF phase 0 deg to 360 deg 1 deg 1 deg setting 7-2 Specifications RC04-PCR-LA...
  • Page 77 Peak holding current Same as that of Within ± (2 % of rdg measurement peak ammeter + 16 digits) (from 5 % of maxi- mum rated current to maximum rated peak current at normal temperature) RC04-PCR-LA Specifications 7-3...

  • Page 78: Dimensions

    Dimensions MAX 55 Unit: mm Fig.7-1 Dimension of RC04-PCR-LA 7-4 Specifications RC04-PCR-LA...

  • Page 79: Appendix

    [Valid only in AC and AC + DC modes.] F1 (FRQ) [Frequency setting mode] Numeric keys or JOG/SHUTTLE [Frequency setting] DIGIT (SHIFT, .) [Digit function] Vrms/Vpk/Vset/Vavc (SHIFT, F5) [Voltage display mode selection] [Valid only for Iph.] [Peak holding current value clear] F4 (clr) RC04-PCR-LA Appendix A-1...
  • Page 80 Vrms/Vpk/Vset/Vave (SHIFT, F5) [Current display mode selection] Irms/Ip/Iph/WATT/Iave (SHIFT, F3) MENU [Power, VA, and power-factor display mode OUTPUT [Output ON/OFF] [Exits the power, VA, and power-factor display mode.] MENU [Exits the power, VA, and power-factor display mode.] A-2 Appendix RC04-PCR-LA...
  • Page 81 [AC voltage setting mode] Numeric keys or JOG/SHUTTLE [AC voltage setting] [Address setting mode] F1 (ADRS) [Frequency setting mode] F3 (FREQ) [Memory content display method selection] MENU (Second display) [Output ON/OFF] OUTPUT [Exits the memory store mode] RC04-PCR-LA Appendix A-3...
  • Page 82 [Memory content display method selection (First display) OUTPUT [Output ON/OFF] [Exits the memory store mode.] MENU [Memory display method selection] (First display) OUTPUT [Output ON/OFF] [Exits the memory store mode.] OUTPUT [Output ON/OFF] [Exits the memory store mode.] A-4 Appendix RC04-PCR-LA...
  • Page 83 [T2 setting mode] F3 (T2) F5 (T3) [T3 setting mode] [T1 mS/deg. selection] T1 (SHIFT, F1) [POL selection] +/- (SHIFT, 0) MENU [Display selection] (second display) (SHIFT, MENU) [Display selection] (execution display) [Exits the T1 setting mode.] RC04-PCR-LA Appendix A-5...
  • Page 84 [T5/N setting mode] F5 (V (T3)) [V (T3) setting mode] [T4 mS/S selection] T4 (SHIFT, F1) [POL selection] +/- (SHIFT, 0) MENU [Display selection] (third display) [Display selection] (second display) (SHIFT, MENU) [Exits the T4 setting mode.] A-6 Appendix RC04-PCR-LA...
  • Page 85 Valid only for [OUTPUT ON] [Simulation start] F1 (RUN) [Simulation cancel] OUTPUT [OUT OFF] F3 (STOP) [Simulation cancel] [Simulation cancel] +/- (SHIFT, 0) [POL selection] OUTPUT [Output ON/OFF] [Display selection] (third display) (SHIFT, MENU) [Display selection] (first display) MENU RC04-PCR-LA Appendix A-7...
  • Page 86 [Address setting mode] [Numeric keys or JOG/SHUTTLE] [Address setting] [Valid for addresses other than 0.] [Frequency ramp specification ON/OFF] F2 (R) [AC voltage ramp specification ON/OFF] F4 (R) F3 (FRQ) [Frequency setting mode] [AC voltage setting mode] F5 (Vac) A-8 Appendix RC04-PCR-LA...
  • Page 87 [Numeric keys or JOG/SHUTTLE] [Address setting] F3 (TIME) [Time setting mode] F5 (WAVE) [Waveform bank setting mode] [Display selection] (first display) (SHIFT, MENU) [Display selection] (third display) MENU OUTPUT [Output ON/OFF] [Exits the AC voltage setting mode.] RC04-PCR-LA Appendix A-9...
  • Page 88 [Display selection] (fourth display) OUTPUT [Output ON/OFF) [Exits the output impedance setting mode. F5 (Vdc) [DC voltage setting mode] Numeric keys or JOG/SHUTTLE [DC voltage setting] [Address setting mode.] F1 (ADRS) F3 (IMP) [Output impedance setting mode] A-10 Appendix RC04-PCR-LA...
  • Page 89 [Exits the address setting mode.] [Status signal setting] F3 (STAT) [Trigger signal setting] F4 (TRG) F5 (OUT) [OUTPUT status setting] [Output ON/OFF] OUTPUT [Exits the sequence setting mode.] [Display selection] (third display) (SHIFT, MENU) MENU [Display selection] (first display) RC04-PCR-LA Appendix A-11...
  • Page 90 (ALL:17.18.19.20 ODD:33.35.37.39 EVEN:32.34.36.38) MENU [ALL:Display 6 (separately noted), Others:Display1] (SHIFT, MENU) [Arms display 4] OUTPUT [Output ON/OFF] [Returns to the display mode selecting] (SHIFT, MENU) [Arms display 3] [Output ON/OFF] OUTPUT [Returns to the display mode selecting] A-12 Appendix RC04-PCR-LA...
  • Page 91 [Output ON/OFF] OUTPUT [Returns to the display mode selecting] (SHIFT, MENU) [% display 6] OUTPUT [Output ON/OFF] [Returns to the display mode selecting] (SHIFT, MENU) [% display 5] OUTPUT [Output ON/OFF] [Returns to the display mode selecting] RC04-PCR-LA Appendix A-13...
  • Page 92 [Output ON/OFF] OUTPUT [Returns to the display mode selecting] [Arms display 6] (SHIFT, MENU) OUTPUT [Output ON/OFF] [Returns to the display mode selecting] (SHIFT, MENU) [Arms display 5] OUTPUT [Output ON/OFF] [Returns to the display mode selecting] A-14 Appendix RC04-PCR-LA...
  • Page 93 ESC [Exits waveform 04 setting.] MENU [Special waveform setting mode] (second display) ESC [Exits the special waveform setting mode.] (SHIFT, MENU) [Special waveform setting mode] (first display) [Sets waveform 05.] F1 (W05) [Valid only for SIN.] F2 (PC) [Note 1] RC04-PCR-LA Appendix A-15...
  • Page 94 ESC [Exits the special waveform setting mode.] [Special waveform setting mode] (second display) (SHIFT, MENU) [Sets waveform 10.] F1 (W10) [Valid only for SIN.] F2 (PC) [Note 1] [Valid only for PC.] [Note 1] [Note 2] F3 (SIN) A-16 Appendix RC04-PCR-LA...
  • Page 95 [Peak clipped voltage waveform setting] ESC [Exits the peak clipped voltage waveform setting mode.] F2 (YES) [Waveform clear (change to sine wave)] [Note 2] ENTER [Waveform clear (change to sine wave)] [Waveform clear/cancel] F4 (NO) ESC [Waveform clear/cancel] RC04-PCR-LA Appendix A-17...
  • Page 96 [Set waveform to 11.] [Cancel] [Enter] F3 (W12) ENTER [Set waveform to 12.] [Cancel] [Enter] F4 (W13) ENTER [Set waveform to 13.] [Cancel] [Enter] F5 (W14) ENTER [Set waveform to 14.] [Cancel] [Special waveform output mode] (first display) MENU A-18 Appendix RC04-PCR-LA...
  • Page 97 [Exits the output impedance setting mode.] F5 (REG) [Regulation adjustment ON/OFF] [Valid only for REG ON, OUT, ON and when current value is 10% or more.] [Sets regulation adjustment rate.] OUTPUT [Output ON/OFF] [Exits the special function mode.] RC04-PCR-LA Appendix A-19...

  • Page 98: Power Line Abnormality Simulation

    Power Line Abnormality Simulation Operation Setting Sheet PCR-LA Series TITLE DATE T5/N V(T3) MEMO MEMO A-20 Appendix RC04-PCR-LA...

  • Page 99: Sequence Operation Setting Sheet

    Sequence Operation Setting Sheet PCR-LA Series TITLE DATE START LOOP Ts WAVE IMP Vdc STRT TRG OUT MEMO RC04-PCR-LA Appendix A-21...
  • Page 100 A-22 Appendix RC04-PCR-LA...

  • Page 101: Index

    Special waveform output operating A- Limit value setting function - - - 4-4 Special waveform setting - - - - A-15 Status signal - - - - - - - - - - - - - 4-26 RC04-PCR-LA Index I-1...
  • Page 102 Voltage display mode change - - - 4-4 Voltage setting function - - - - - - 4-3 Voltage, current, frequency, and other factor setting and display operating Waveform bank - - - - - - - - - - - 4-36 I-2 Index RC04-PCR-LA...
