Summary of Contents for SubGear XP-H

  • Page 1 XP-H English Deutsch Français Italiano Español Nederlands 日本語 简体中文...

  • Page 2: I Safety Considerations

    • If XP-H fails at any time during the dive, the dive must be terminated, and appropriate surfacing procedures (including a slow ascent and a 3 to 5 minute safety stop at 5m /15ft) should be initiated immediately.

  • Page 3: Safety Considerations

    After a reset of the remaining saturation do not dive for at least 48 hours. Altitude and diving • Do not dive at altitudes higher than 4000m (13000ft). • After a dive do not rise to altitudes that XP-H prohibits via the flashing altitude range number (see page 27). Flying after diving •...

  • Page 4: Introduction

    - equipped with SUBGEAR innovative technology - while diving. We thank you for choosing XP-H and we hope you will enjoy safe dives in the future! Further information on SUBGEAR and SUBGEAR products can be found on our web page at www.subgear.com.

  • Page 5: Quick Reference/Operating Scheme

    Quick reference Quick reference Time of day / Date Do not fly icon Decompression depth Setting icon Desaturation time (DESAT) No-dive warning Service icon Duration of no-dive warning Duration of surface interval Dive time / No-fly time / Current depth SOS duration Altitude sections Repetitive dive number Log Book Battery icon Decompression stop No-stop indicator obligation / Ignored Ascent time icon decompression stop No-stop time / Total ascent time Decompression stop indicator Partial pressure of oxygen ppO Decompression stop duration Alarm clock icon / Infrared icon MB level symbol Nitrogen loading bar (dive) mix icon (input) Residual Nitrogen bar (surface) Desaturation Too fast Battery condition Tank pressure ascent mix PDIS icon Max depth...
  • Page 6 Operating scheme Display switched off Logbook Diveplanner (PLn) Page 1 Dive time Surface Oxygen Max depth interval concentration Battery performance Date of No-stop dive the dive mix. No-stop time Dive max number (MOD) Page 2 Repetitive Confirmation divenumber Altitude range Depth (if >0) Starting time Minimum CNS O % at temperature Exit the end Page 3...

  • Page 7: Table Of Contents

    Dive.Log dedicated software application ................ 10 Configuring XP-H ........................10 Switching on the display ....................13 How to navigate XP-H at the surface ................13 Checking the desaturation time ..................14 Checking the surface interval ..................14 Displaying the date ......................14 Checking the battery condition ..................
  • Page 8 List of chapters Gauge Mode ..........................29 Diving with microbubble (MB) levels ................... 31 Comparison of dives with MB level L0 and MB level L5 ..........32 Terminology ........................32 Preparation for a dive with MB levels ................33 Functions during the dive with MB levels ................ 34 Complete a dive with MB levels ..................

  • Page 9: System And Operation

    System and operation 1 System description XP-H displays all important dive and decompression data and has a memory which stores the full dive data. The data can be transmitted with an infrared interface (IrDA) and Dive.Log software to a Windows ®...

  • Page 10: Water Contacts

    On submerging in water the water contacts switch on XP-H automatically. ! WARNING If you have chosen the option "Water contacts off" ("set 1", ->47), XP-H will turn on with a delay of up to 1 minute into the dive. This will affect functioning of the computer.
  • Page 11 Operation The following settings may be changed with Dive.Log or via "set 1" or "set 2" directly on XP-H: Setting Range Default Page • Depth alarm 5-100m / 15-330ft 40m/130ft • Dive time alarm 5-195 min 60min • Safety stop time...
  • Page 12 Operation Dive window Dive information panel Dive computer display Dive profile panel Tissue panel Physiology panel Alarm symbols Notes panel Dive table...

  • Page 13: Switching On The Display

    If there is a remaining saturation from the last dive or from a change of altitude, Time of day display XP-H also displays the "do not fly" time, the "do not fly" icon, the current altitude range and the prohibited altitude range (->27).

  • Page 14: Checking The Desaturation Time

    2x or 3 x (depending on whether there is desaturation time left). XP-H displays the estimated remaining battery performance for 5 seconds as a bar graph. If the bar graph shows 3 segments the battery warning appears ->15 and the battery Battery condition / has to be replaced ->52.

  • Page 15: Active Backlight

    Diving not possible, dive planner and settings are disabled XP-H marks dives started with 3 or less segments in the logbook with the battery symbol. Logbook information is not lost even when the battery is removed for a long time.

  • Page 16: Switching Off The Display

    Operation / SOS 2.11 Switching off the display From the time of day display you can switch off XP-H by pushing On the surface XP-H switches off automatically after 3 minutes without operation. 2.12 Alarm clock The alarm clock goes off only at the surface.

  • Page 17: Diving With Xp-H

    III Diving with XP-H Diving with XP-H 1 Terminology / Symbols The information on the display of XP-H varies depending on the kind of dive and the dive phase. 1.1 General terminology / Display during no-stop phase Decompression phase No-stop phase...

  • Page 18: Nitrox Information (O Information)

    The depth at which ppO max is reached is called Maximum Operating Depth (MOD). When you enter the settings for the gas mixture, XP-H will display the ppO max limit setting and the corresponding MOD. XP-H warns you audibly and visually once the depth is reached at which the ppO reaches the maximum allowed value ->23.

  • Page 19: Attention Messages And Alarms

    Attention messages and alarms 2 Attention messages and alarms XP-H draws the diver’s attention to certain situations and warns the diver of unsafe diving practices. Attention messages and alarms are visual and / or audible. • The audible attention messages can be switched off in "set 1" ->47 or Dive.Log. With Dive.Log they can be switched off selectively.

  • Page 20: Preparation For The Dive

    Preparation for the dive 3 Preparation for the dive You have to check the settings of XP-H especially before the first dive. All settings can be checked and changed directly at XP-H or via Dive.Log. 3.1 Setting the gas mixture and ppO...

  • Page 21: Functions During The Dive

    ! WARNING If you have chosen the option "Water contacts off" ("set 1" or Dive.Log), XP-H will turn on with a delay of up to 1 minute into the dive. This will affect functioning of the computer. Make sure that the computer is on before starting the dive.

  • Page 22: Ascent Rate

    • In case of an improper ascent XP-H may require a decompression stop even within the no-stop phase because of the danger of microbubble formation. •...

  • Page 23: Partial Pressure Of Oxygen (Ppo 2 4.7 Oxygen Toxicity (Cns O 2 %)

    The MOD is a function of ppO max and the mixture used. If during the dive the MOD is reached or exceeded XP-H sends an audible attention message and the MOD is displayed (flashing) in the lower left corner. Ascend to a depth shallower than the displayed MOD in order to diminish the danger of oxygen poisoning.

  • Page 24: Nitrogen Loading Bar Graph

    Functions during the dive 4.8 Nitrogen loading bar graph The nitrogen loading bar gives a graphical representation of how close to decompression you are. As you absorb nitrogen during the dive, more and more segments of the bar will light up. Depending on your depth, the segments can light up more or less rapidly.

  • Page 25: Safety Stop Timer

    Ascent time greater than 99 minutes is displayed as " – – ". ! WARNING Total ascent time On all dives with XP-H, make a safety stop for at least three minutes at a depth of 5m (15ft). 4.10 Safety stop timer The safety stop timer displays the time span a diver should spend at the safety stop depth at the end of the dive.

  • Page 26: Functions At The Surface

    5.2 Residual nitrogen bar graph The segments in the residual nitrogen bar graph will gradually turn off as XP-H follows the offgassing of your tissues during your surface interval. There is a 1:1 equivalence in the meaning of the segments between diving and surface.

  • Page 27: Diving In Mountain Lakes

    Surface interval If XP-H detects a situation of increased risk (due to the potential of microbubble accumulation from previous dives or a CNS O level above 40%), the no-dive symbol No-dive will appear on the display. The duration of the no-dive warning is visible in the dive warning planner menu.

  • Page 28: Prohibited Altitude

    2000m 815mbar 6560ft 11.82psi 1000m 905mbar Altitude ranges 3280ft 13.12psi 6.2 Prohibited altitude ! WARNING Flying while XP-H displays "do not fly" may lead to serious injury or Ascent to altitude range death from decompression sickness. 3 and 4 prohibited. Max allowed altitude: 2650 m (8694ft). Max altitude: 850m 1650m 2650m 4000m...

  • Page 29: Gauge Mode

    Supervision of ppO 2 max and CNS O 2 % will also be switched off. XP-H will display no information about microbubble development. The settings for the gas mixture, MOD and microbubble level cannot be set and the dive planner cannot be selected.
  • Page 30 Minutes Seconds After diving in gauge mode XP-H shows the remaining time span during which it cannot be used in computer mode. Once the waiting period is over, the gauge mode can be switched off manually. The no-fly time after diving in gauge mode is 48 hours.

  • Page 31: Diving With Microbubble (Mb) Levels

    (level stop) sooner than a diver using level L0. If a diver ignores a required level stop, XP-H will cascade to a lower MB level and the dive can not be completed with the initially chosen MB level. E.g. if a diver sets level L4 on XP-H prior to the dive and during the dive ignores the recommended stops XP-H will automatically adjust the setting to level L3 or lower.

  • Page 32: Comparison Of Dives With Mb Level L0 And Mb Level L5

    8.1 Comparison of dives with MB level L0 and MB level L5 When two XP-H are used simultaneously, one unit is set for example to MB level L5, the other to L0, the no-stop time will be shortened and level stops will be required before the diver has the obligation of a decompression stop.

  • Page 33: Preparation For A Dive With Mb Levels

    > (Tank pressure)… 8.3 Preparation for a dive with MB levels 8.3.1 Setting the MB level To change the MB level XP-H must be in user mode (time of day display). 1. Push until the symbol for MB levels until appears.

  • Page 34: Functions During The Dive With Mb Levels

    DEPTH DIVE TIME MB no-stop time While diving with MB levels L1 to L5 XP-H will display the MB no- NO STOP stop time instead of the ordinary no-stop time. Within the MB no- stop time no level stops are required.
  • Page 35 The warning “MB level reduced” is activated if the diver ascends more than 1.5m (5ft) above the required level stop. XP-H reduces the MB level, an attention beep* goes off and the new MB level is shown in the lower left corner.
  • Page 36 Diving with microbubble (MB) levels 8.4.3 Decompression obligation XP-H calculates and displays level stops to reduce microbubble formation, but it also calculates the diver’s decompression data. ! WARNING Avoid decompression dives when diving with MB levels. How to avoid decompression stops:...

  • Page 37: Complete A Dive With Mb Levels

    Repetitive dives and MB levels: If during a dive a level stop is being ignored and the diver starts another descent shortly afterwards, XP-H might immediately request level stops. To complete the dive with the initially set MB level all level stops must be observed.

  • Page 38: Pdis (Profile Dependent Intermediate Stop)

    Spending 2 or 15 minutes at 30m/100ft would result in the same deep stop of 15m/50ft. With PDIS, as the name suggests, XP-H interprets your dive profile and suggests an intermediate stop that is a function of your nitrogen uptake so far. The PDI stop will therefore change through the course of the dive to reflect the continuosly changing situation in your body.

  • Page 39: How Does Pdis Work

    PDIS (Profile DependENT Intermediate Stop) 9.2 How does PDIS work? The mathematical decompression model in XP-H, called ZH-L8 ADT MB, tracks your decompression status by dividing your body into 8 so-called compartments and mathematically following the uptake and release of nitrogen in each with the appropriate laws of physics. The various compartments simulate parts of your body such as central nervous system, muscles, bones, skin and so on.

  • Page 40: Diving With Pdis

    NO to indicate the fact that you have not performed the PDI stop. If XP-H is displaying a decompression obligation when you reach the PDIS depth during an ascent, all rules apply the same way, but the 2-minute countdown runs in the background and is not displayed...
  • Page 41 PDIS (Profile DependENT Intermediate Stop) NOTE: XP-H issues no warnings relating to a missed PDI stop. When diving with MB levels, PDIS follows the same rules as described above. MB levels, however, introduce stops earlier and deeper than the L0 base algorithm. As such, the PDIS display may be delayed and for certain dives it may not be displayed at all.

  • Page 42: Dive Planner

    • assuming a normal workload of the diver and observance of the prescribed ascent rates 1 Planning a no-stop dive To select the dive planner XP-H must be in user mode (time of day display). Push until the symbol for the dive planner PLn appears.

  • Page 43: Logbook

    1 Survey A dive is entered in the logbook if the dive time is longer than 2 minutes. XP-H records the profiles of about 15 hours of diving. This information can be transferred to a PC with the standard infrared interface (IrDA) and the Windows ®...
  • Page 44 Operation Page 2 Altitude range (if >0) Repetitive dive number Starting time CNS value at the end of the dive Minimum temperature Push to get more information about the dive. Page 3 Gas used gives the consumed gas amount on that dive. Page 4 SOS if applicable If a dive is started within adaptation time (after a change of altitude), the adaptation time is displayed instead of the surface interval.

  • Page 45: Settings

    VI Settings Statistic information From the time of day display you can get the following statistic information over all dives. Push Deepest dive DEPTH DIVE TIME Longest dive Cumulative bottom time Leaving the logbook By pushing once or twice you can exit the Number of dives logbook.
  • Page 46 Settings Setting the dive time alarm 1. Confirm that you wish to change the dive time alarm by pushing 2. Change the value in increments of 5 minutes by pushing 3. Switch between 'on' or 'off' by pressing 4. Confirm the setting with Setting the safety stop counter time 1.
  • Page 47 On submerging in water the water contacts switch on XP-H automatically. ! WARNING If you chose the option "Water contacts off", XP-H will turn on with a delay of up to 1 minute into the dive. This will affect functioning of the computer.

  • Page 48: Menu "Set 2

    / high • Sound on / off • Show XP-H electronic ID Starting from the time of day display push until "set 2" appears. Confirm that you wish to enter into the menu of "set 2" by pushing Once entered into the menu you can scroll with through the menu.
  • Page 49 Settings 3. Confirm the setting with . The minutes start to flash. 4. Set the minutes by pushing 5. Confirm the setting with . "On" or "off" starts to flash. 6. "On" indicates "activated" (time of day display shows ), "off" indicates "deactivated".
  • Page 50 Code: 313 Setting the "sound" to "off" applies also to surface functions (mountain alarm, wake-up alarm, change of altitude range). Showing the hardware electronic ID of XP-H This number is needed when reporting problems or for other maintenance related issues.

  • Page 51: Appendix

    Check XP-H high pressure connection and hose condition periodically and service them at least every 2 years. Rinse XP-H carefully with fresh water after each use and to have the batteries changed when needed ->52. To avoid possible problems with your XP-H, the following recommendations will help...

  • Page 52: Connecting The High Pressure Hose

    When quick release system is assembled, bayonet the O-ring between XP-H and the replaces the swivel. Quick release system attached to the XP-H is shown at the picture. Be sure that high pressure is not applied when connecting or disconnecting the XP-H from the quick release.
  • Page 53 To replace the battery you need a coin or a universal tool and a clean cloth. ! WARNING • A leaking battery cap may lead to the destruction of XP-H by water seeping in or cause XP-H to switch off without prior notice. •...

  • Page 54: Warranty

    Insert the new battery, with "+" pointing outwards, into the battery compartment. After battery replacement XP-H will perform an automatic test (8s) and gives a short beep when the test is done. ! WARNING 10. The battery cap can be installed with a ±120° offset. The alignment circles are there to ensure proper positioning of the cap.

  • Page 55: Index

    _________________ 18, 19, 23 partial pressure, ppO max ___ 18, 20, 23, 46 toxicity ________________________ 18, 19, 23 Operating XP-H ______________________ 4, 5, 9 PC, transfer to PC (logbook) ____________ 9, 11 PDIS ___________________________________38 , see O partial pressure...
  • Page 56 El Cajon, CA 92020 Unit 21 380 Eastern Valley Way Chatswood NSW 2067 Australia 1208 Black A, MP Industrial Center 18 Ka Yip St. Chai Wan-Hong Kong Mitsubishi Juko Yokohama Bldg. 22F 3-3-1 Minatomirai, Nishi Ku Yokohama 220-0012 Japan www.SUBGEAR.com...
