Washer-dryer installation and operation manual

Built-in Washing Machine

WD1200LUXNMWH

WD1200LUXNMSL

Table of Contents

Need help?

Do you have a question about the WD1200LUXNMWH and is the answer not in the manual?

Questions and answers

Summary of Contents for Nordmende WD1200LUXNMWH

Page 1 Washer-dryer installation and operation manual Built-in Washing Machine WD1200LUXNMWH WD1200LUXNMSL...
Page 3: Table Of Contents
washing machine contents WARNINGS SPECIFICATIONS INSTALLATION AND ASSEMBLY USING THE APPLIANCE. PRACTICAL TIPS MAINTENANCE AND CLEANING SAFETY AND TROUBLESHOOTING ENVIRONMENTAL WARNINGS...
Page 4: Warnings
warnings To avoid the risk of fire, electric shocks, injury or damage when using your washing machine, please take the following precautions: This washing machine comes with a Do not climb onto the machine or stand manual that includes operating, maintenance on the open hatch door.
Page 5: Specifications
washing machine specifications Power cord Work top Detergent dispenser Control panel Stainless Drain hose steel drum Hatch Accesible filter (behind kickplate) Kickplate Adjustable feet ACCESSORIES Water inlet hose.
Page 6: Installation And Assembly
washing machine installation and assembly UNPACKING AND UNBLOCKING THE WASHING MACHINE UNPACKING a Remove the base, corner protectors and top cover. UNBLOCKING a Remove the screws holding the plastic covers to the back of the washing machine. b Loosen and remove the 3 blocking screws.
Page 7 CONNECTION TO THE MAINS WATER SUPPLY AND DRAINAGE installation and assembly CONNECTION TO THE MAINS WATER SUPPLY The water supply hose is inside the drum: a Connect the bent end of the hose to the threaded inlet of the electrovalve located at the rear of the washing machine.
Page 8 LEVELLING THE WASHING MACHINE AND CONNECTING IT TO THE MAINS ELECTRICITY SUPPLY installation and assembly LEVELLING Use the adjustable feet to level the washing machine. This will reduce the noise level and prevent it from moving during use. Do not bring the feet too far out, you will achieve better stability.
Page 9 INSTALLING THE WASHING MACHINE UNDER A KITCHEN WORKTOP AND PRE-CLEANING INSTALLATION UNDER A WORKTOP Your washing machine may be fitted underneath a kitchen worktop. If you need to remove the washing machine’s worktop, for safety reasons you need to fit a protection plate which you can obtain from your Dealer or Technical Assistance Service.
Page 10: Using The Appliance
washing machine using the appliance and practical tips PREPARING GARMENTS FOR WASHING PREPARATION Before placing the clothes in the drum, make sure all the pockets are empty. Any small objects may block the drain pump. Important SORTING THE CLOTHES Make sure beforehand a Sort the clothes according to fabric that your...
Page 11 USING DETERGENT AND ADDITIVES using the appliance and practical tips DETERGENT AND ADDITIVES a Your washing machine’s detergent dispenser has three compartments. PREWASH WASH FABRIC SOFTENER b Put the detergent or additive into the detergent dispenser before starting the wash programme. c Liquid detergents may also be used in this washing machine.
Page 12 SELECTION OF WASHING AND DRYING PROGRAMME using the appliance and practical tips drying start/ time stop programme centrifuge intensive easy extra detergent dispenser selector selector wash ironing rinsing command command additional function To select a wash programme, proceed as Celeris 30 Celeris 30 follows: a Starting from the off “0”...
Page 13 using the appliance and practical tips The procedure for selecting the drying time is as follows: a Select drying time in minutes using the drying time button. The time will appear on the display, increasing each time the drying time button is pressed.
Page 14 Possible option buttons Recommended Programme Fabric type temperature Cotton/Linen Quick 30ºC whites/colours very light soil Cotton/Linen Normal cold Cold delicate colours very light soil Cotton/Linen Normal 30ºC delicate colours light soil Cotton/Linen Normal 40ºC fast colours light soil Cotton/Linen 5 (*) Normal 60ºC fast colours medium soil...
Page 15 Approx. Max load Wash Programme Total consumption duration of clothes product description kWh/litres (minutes) (Kg) compartment SHORT wash, rinses, automatic additive absorption if 0,20/30 desired and long final spin Normal wash, rinses, automatic additive absorption if 0,15/49 desired and long final spin 0,40/49 0,65/49 Normal wash, rinses,...
Page 16 SELECTING THE ADDITIONAL FUNCTIONS using the appliance and practical tips SPIN-DRYING The selected programme is associated with centrifuge revolutions. a It can be changed by turning the centrifuge selector command. b Elimination of centrifuge By turning the centrifuge selector command we come to the centrifuge elimination command.
Page 17 using the appliance and practical tips EASY IRONING This option avoids the formation of creases in the garments by the operation of a special programme with special turns to soften the clothes after the centrifuge so as to make ironing easier. EXTRA RINSE Increases the level of the final rinse obtained in the clothes;...
Page 18 WASH/DRY PROGRAM STATUS AND POWER CUTS using the appliance and practical tips PROGRAMME PHASES Once started, current programme status and time remaining till completion can be ascertained from the screen. The active phases will appear successively at the top of the display as the programme progresses.
Page 19: Maintenance And Cleaning
washing machine maintenance and cleaning MAINTENANCE After each wash, leave the door open for a while to allow the air to circulate freely inside the machine. From time to time, depending on the hardness of your water, it is recommendable to run a full wash cycle using a decalcifying product.
Page 20 CLEANING THE ACCESISBLE FILTER AND THE OUTSIDE maintenance and cleaning CLEANING THE FILTER Clean the accessible filter if the drain pump is blocked by any foreign objects. a Remove the kickplate by pulling gently on its edges and turning it downwards, to release the clips.
Page 21: Safety And Troubleshooting
washing machine safety and troubleshooting If you detect any problems with your washing machine, you will Indicator Problems probably be able to rectify them yourself by consulting the following No water coming in instructions. Does not drain or spin-dry If this is not the case, unplug the appliance and contact the Does not spin-dry TECHNICAL ASSISTANCE...
Page 22 safety and troubleshooting Why doesn’t the washing Indicator F01, no water coming in, this may be due to machine take in water? a cut in the water supply, a tap turned off or a blocked water inlet filter. The possible solutions are as follows: wait for the water supply to be reconnected, turn on the tap, or remove the water inlet hose and clean the filter.
Page 23 safety and troubleshooting Why is there still some water This may be because the dispenser needs cleaning. This in the dispenser? simple operation is described in Maintaining and cleaning the appliance. 1- Cleaning the detergent dispenser. Why can’t I open the hatch Washing machines today are provided with safety systems immediately after the wash for users.
Page 24: Environmental Warnings
environmental warnings eco-note INFORMATION FOR THE CORRECT DISPOSAL OF WASTE ELECTRICAL AND ELECTRONIC APPLIANCES When your appliance is of no further use, it should To highlight the obligation of collaborating with not be disposed of together with general domestic selective waste collection, the product is marked waste.
Page 28 05-09 LJ6A033Z5 / B0J6A1100...
