  • Page 1 MA823T OPERATION MANUAL...
  • Page 2: Fcc Certification

    FCC Certification THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : ( 1) THIS DEVICES MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE, RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
  • Page 3: Table Of Contents

    Table of Contents 1. Function summary 2. Announcement 3. Getting to know the player Appearance and keystroke Display screen 4. Basic functions Start up/shutdown Enter a menu Browse Tracks Use different function modes Adjust volume Key lock function Press PLAY 5.
  • Page 4 7. Voice recorder Record mode Choose record type 8. Play recorded files 9. Transfer recorded file of ACT into WAV on your PC 10. How to use FM 11. System Setup How to enter Brief introduction to every options Detailed operating instructions 12.
  • Page 5: Function Summary

    MP1, MP2, MP3, WMA, WMV, ASF, WAV (Easy to work with Windows Media Player). Firmware upgrades (Check periodically) www.macvision.com will provide the latest software upgrades and functions. Function of free-drive U disk Manipulate files via the "mobile disk" in "My PC" without any additional programs on your PC(drive program needs to be installed for operating systems prior to WIN2000).
  • Page 6: Announcement

    USB connection Quick connection to USB port. Built-in FM radio You may easily listen to FM stations and set your favourite stations by using Auto Preset or Manual Preset. The player can save 40(20 for each Band) local stations at different frequency. 2.
  • Page 7: Display Screen

    Display screen Sound effect mode/Replay mode/Follow and contrast Play time Cycle mode Play state Song number Display electric quantity Work mode Aqua Barbie girl.mp3 Singer/Name of song 4. Basic functions Start up/shutdown Start up or shutdown player by press and hold "PLAY". Enter a menu Menus: Main menu (entered by momentarily holding Mode key when not playing), Play submenu (entered by pressing Mode key while playing), and Stop submenu...
  • Page 8: Use Different Function Modes

    Use different function modes Go into different modes from main menu by sliding Mode key clockwise or anti-clockwise then pressing Mode key: Main menu: Select Music mode, display shows something like this: Select Record mode, display Aqua Barbie girl.mp3 shows something like this: Select Play mode, display shows something like this: Select System setup, display...
  • Page 9: Adjust Volume

    Adjust volume Decrease volume by pressing VOL-; increase volume by pressing VOL+. Key lock function Dial HOLD switch to the position of lock. When Hold is ON, any operations on buttons will be displayed as: When Hold is ON, USB mode will be displayed as: Press PLAY Play or stop (or pause while recording);...
  • Page 10: Operation

    5. Operation Music mode , Play mode Stop state Play state Play submenu Stop submenu Action Play Stop Press Exit from menu Exit menu Play Hold Shutdown Shutdown Shutdown Shutdown Long press Enter main menu Enter main menu Enter main menu Enter main menu Mode Enter/stop Enter/play...
  • Page 11: Record Mode

    Record mode Stop state Action Record state Press Start to record Pause record Play Stop record Hold Shutdown Press Enter record submenu Mode Hold Enter main menu FM mode FM status Action FM submenu Hold Shutdown Shutdown Play Channels have been saved: Next channel Press Exit menu Channels have not been saved: X...
  • Page 12: Play Music

    6. Play music Add and Delete files To add and delete music file on your PC or Notebookcomputer to your MP3 player, simply connect the unit to the USB port of your PC or Notebook computer, click open the "RemovableDisk" drive then you can add or delete files. Before you disconnect the player, please follow these steps or it may result in lost of files: 1).
  • Page 13: Simple Operation

    Attention: you must eject player from USB if you delete files on PC, or it will tell you "the files are not deleted". Simple operation 1). Connect earphone plugging the pin of 2). Please make sure keyboard is unlocked. earphone into earphone jack. 3).
  • Page 14: Display Synchronized Lyrics (Karaoke Function)

    Display synchronized lyrics (Karaoke function) This player supports "LRC" files. (Search online for "LRC lyrics", play song and lyrics simultaneously.) How to use lyric files: Keep the names of lyric file and song the same. Such as: Name of song: Jay-Sky.mp3 Name of lyric file: Jay-Sky.lrc How to know whether a song has lyrics: If there is a lyric file matching the song, the icon...
  • Page 15: Record Mode

    Record mode 2). Dial Next to choose 1). Enter main menu. record mode. 3). Press Mode to enter 4). Press Play to start recording. record mode. 5). Other operations use steps 1 through 3. 6). Voice recordings are saved in the current directory;...
  • Page 16: Play Recorded Files

    8. Play recorded files 1). Enter main menu. 2). Dial Next to choose "Voice mode". 3). Press Mode to 4). Press Play to start playing. enter Voice mode. 5). Choose record file: 6). Control volume: Last: choose last record file VOL+: increase volume Next: choose next record file VOL-: decrease volume...
  • Page 17: How To Use Fm

    10. How to use FM 1). Enter main menu. 2). Push Next to select FM Mode. 3). Press Mode button to enter FM Mode. 4). Search automatically Push on Last/Next for 2 seconds, the player search forward or backward with 100Khz and stop the searched channel.
  • Page 18: System Setup

    11. System Setup How to enter Set system parameters here; every option should change with firmware upgrade. 1). Enter main menu. 2). Dial Next to choose "System setup". 3). Press Mode to enter "System setup". R e c o r d Ti m e Brief introduction to every option Record time Set save time and date for record files...
  • Page 19: Detailed Operating Instructions

    Detailed operating instruction Set "Record time" 1). Interface for system setup. 2). Press Mode to enter the record time interface. R e c o r d Ti m e 3). Press VOL+/- to select number to 4). Dial Next/Last to increase/decrease number: change: 5).
  • Page 20 Set Language 1). Interface for setting system. 2). Dial Next to select "Language". R e c o r d Ti m e L a n g u a g e 3). Press Mode to enter interface. 4). Dial Next/Last to select language. E n g l i s h F r e n c h 5).
  • Page 21 Adjust Contrast See "Backlight time", operations are the same. Online Mode Operating systems earlier than Windows 2000 Service Pack 4 cannot support two partitions. To display chosen disk after connected to PC, You need to choose which disk you want to use between "single normal disk" and "single cryptographic disk" after use the function of "dream space".
  • Page 22: Use Usb Disk

    12. Use USB disk This player has a standard USB function, supports Windows98 (a driver needs to be installed), Windows 2000 and newer (drivers need not to be installed), MacOS X 10.3 or Linux Red Hat 8.0 or newer. This player can be supplied power via USB, and can be played without batteries. From the main menu, choose the work mode you want and enter it.
  • Page 23: Upgrade Player

    13. Upgrade player Upgrade this player or service the system firmware with the utility installed on the PC. 1). Enter main menu. 2). Dial Next to choose "system setup". 3). Press Mode to enter "system 4). Dial Next to choose "firmware setup".
  • Page 24: Miscellaneous Settings

    Upgrades for firmware are for improvement and optimization of the performance of the player. It could impact normal operation if you fail to upgrade firmware. Upgrading the firmware could cause the player to function incorrectly if not done properly. Please read the instructions before you begin. This operation is meant for people who have some computer experience.
  • Page 25: Play Mode (Play Submenu)

    Play mode (play submenu) You can choose different play modes while playing music or record files. Play all the music in normal mode Normal Repeat One Repeat to play one single music file Repeat All Repeat to play all music in current folder Play Directory Play all the music in current folder Repeat Folder...
  • Page 26: Replay Mode (Play Submenu)

    Attention: The speed setting will apply to all songs until changed. Replay mode (Play submenu) Enter by pressing "REC/A-B" directly or from submenu. A-B replay 1). Play music or record. 2). Press Mode to enter play submenu. Aqua Barbie girl.mp3 Repeat 3).
  • Page 27: Replay Times (Play Submenu)

    3). It begins to record the voice of user when 4). Play original voice if the time ends and the Replay icon changes to follow-read icon icon changes to , dial next to enter this length is the same as the time of the A-B replay. function at this time.
  • Page 28: Important Recommendation

    15. Important recommendation Function of "Dream space" In the past, MP3 users who wanted others to see his individual data could only delete their privacy settings while friends borrowed his MP3. Now, the function of "dream space" solves that problem. Using the included utilities, users can separate the disk into two partitions with optional proportions.
  • Page 29: Definition

    Attention: Data in disk will be erased if you separate the disk into two sections, please back up the data on the disk beforehand. Uniting two disks into one disk will also clean out the data. Warning: Do not lose your username and password. You can only erase the encrypted disk by uniting partitions, which will erase the files.
  • Page 30: Troubleshooting

    17. Troubleshooting Check if the batteries are installed correctly; No power Check if the USB connection is solid; Check if the player has been started. Check if the volume is turned down; Check for a problem with the connection of earphones; No sound in earphones Ensure the cleanliness of the earphones;...
  • Page 31: Technical Specifications

    Note: "DRM" Stands for "Digital Rights Management". DRM refers to a collection of systems used to protect the copyrights of electronic media. These include digital music and movies, as well as other data that is stored and transferred digitally. For example, the Apple iTunes Music Store uses a DRM system to limit the number of computers that songs can be played on.
  • Page 32 Highest output of earphones (L) 10mW+ (R) 10mW (32Ohm) 8K bps - 320K bps MP3 bit rate MP3, WMA, WMV, 5K bps - 384K bps WMA, WMV, ASF bit rate Frequency response 20Hz to 20KHz 85dB Range of received frequency 76MHz-96MHz/87MHz-108MHz FM wireless Number of channels saved...
  • Page 33 Customer Service Number: 1.800.938.9886 Website: www.macvision.com...
