Removing the front bezel

1. Follow the procedure in
2. Remove the cover.
3. To remove the front bezel:
a. Lift the retention tabs [1] to release the front bezel [2].
b. Lift the front bezel to remove it from the computer [3].

Installing the front bezel

1. Hold the bezel and ensure that the hooks on the bezel snap into the notches on the computer.
2. Rotate the front bezel toward the computer.
3. Press the front bezel until the tabs click into place.
4. Install the cover.
5. Follow the procedure in

Removing the hard drive assembly

1. Follow the procedure in
2. Remove the cover.
3. Disconnect the data cable and the power cable from the hard drive [1].
4. Press the blue securing bracket tabs [2] and lift the hard drive bracket out of the hard drive bay [3].
Before Working Inside Your
After Working Inside Your
Before Working Inside Your
Computer.
Computer.
Computer.
9
