Balsa Wood Airplane--Space Walker Installation Instructions
Space Walker
Balsa Wood Airplane
Specification:
Wingspan : 1230mm
Length: 1140mm
Flying Weight:EP 900-1000g
GP 1200-1300g
Motor: 2216/1400KV
Engine:25-32 Methanol Engine
ESC: 40A
Prop: 10*6-11*4
Servo: 17g*4 ( standard )
Battery: 3S 2200-2600
Receiver: ≥4CH
Tool needed：
Advertisement
Table of Contents
Related Manuals for Balsa Space Walker
Summary of Contents for Balsa Space Walker
- Page 1 Balsa Wood Airplane--Space Walker Installation Instructions Space Walker Balsa Wood Airplane Specification: Tool needed： Wingspan : 1230mm Length: 1140mm Flying Weight:EP 900-1000g GP 1200-1300g Motor: 2216/1400KV Engine:25-32 Methanol Engine ESC: 40A Prop: 10*6-11*4 Servo: 17g*4 ( standard ) Battery: 3S 2200-2600...
- Page 2 Balsa Wood Airplane--Space Walker Installation Instructions Installation of Fuselage Notice: With two version: -Electric Power Mounting Board for GP Version -Gas Power Please assemble it as what show in the picture. Mounting Board for EP Version...
- Page 3 Balsa Wood Airplane--Space Walker Installation Instructions Mounting Board for EP Version Mounting Board for GP Version For electric version, you can open this top cover, which is easy to install battery. Don’t stick it with the fuselage during the installation.
- Page 4 Balsa Wood Airplane--Space Walker Installation Instructions This part is same as electric version’s structure, below we will take the gas version for example to install. Paulownia Wood Stick3×3mm...
- Page 5 Balsa Wood Airplane--Space Walker Installation Instructions Installation of Tail Wing Change this part to homologous radian with sanding.
- Page 6 Balsa Wood Airplane--Space Walker Installation Instructions Installation of Wing E3*2 E8(A3)*2 Change this part to homologous radian with sanding. B3+*2 Change this part to homologous radian K3(L7) with sanding. Change this part to homologous radian with sanding.
- Page 7 Balsa Wood Airplane--Space Walker Installation Instructions Change this part to homologous radian with sanding. Even distribution N6 Fill the void,enhance the strength of the aileron Assemble the left and right in the same way, then stick in as the pictures show.
- Page 8 Balsa Wood Airplane--Space Walker Installation Instructions Assemble the Wing and Fuselage Together 70mm...
