- Page 1 FHD 1080P Car DVR Dash Cam Instruction Manual AD 250...
-
Page 2: Table Of Contents
CONTENTS Introduction Package Contents Features Appearance Safety Precautions About the unit About the car charger About the mounting location About backing up data Mounting the Unit Inserting the Memory Card Connecting to Power LED/Charging LED Indicators Power the Unit On and Off Power Indication Video Recording Taking Photos... -
Page 3: Introduction
This manual will give you the instructions and information about the AD 250. Please read it carefully before using the AD 250, and keep it properly for future reference. Package Contents - AD250 Car DVR Recorder *1 - Car Charger *1 - Mounting Bracket *1 - Charging Cable *1... -
Page 4: Appearance
- Auto screen saver (wake up screen by any button on panel) - Select cycle recording time - Low power warning and auto power off to save videos. - Auto power on and record while auto engine started - Time-lapse power off after disconnecting with car power - Instant mute function - Video restore function if damaged - WDR conducting balancing light automatically in the shooting process... -
Page 5: Safety Precautions
Safety Precautions About the unit - Do not disassemble or modify the unit by yourself. Contact the dealer for help when the unit is failed to work. - Do not press hard on the LCD screen that will cause the unit malfunction. -
Page 6: Mounting The Unit
Mounting the Unit 1. Clean and dry thoroughly the windshield area where you want to mount the unit. (Refer to Picture 1) Windshield Mount Bracket Car DVR Recorder Picture 1 Picture 2 Note: Dirty and moist glass will cause the mounting bracket can not be firmly mounted on the windshield. -
Page 7: Inserting The Memory Card
Note: For the best field of view, it is better to mount the unit in the middle of the windshield near the rear-view mirror. Inserting the Memory Card 1. Before starting to record, you have to insert a Class 6 or above micro SD card with up to 32GB capacity into the slot located on the side of the unit. -
Page 8: Led/Charging Led Indicators
Charging Cable Car Charger Picture 7 Picture 8 Note: - The unit can be recharged and connected to the car’s lighter socket, PC or USB power supplier with the included cable. When the unit is connected to a PC, it can only be used for transferring files. You will not be able to use any of the unit’s features at this time. -
Page 9: Power Indication
Note: When the device crashes, you can press the Reset button located on the side of your unit to restore all settings to factory default settings and reboot. Power Indication The unit provides you a battery indication appeared on the bottom left of the screen clearly so that you can understand the current battery status. -
Page 10: Taking Photos
Note: - In the Recording Mode, you can press button to enable or disable the microphone function. - You can choose White Day Mode or Night Mode to improve the quality of photography by pressing power button once. The icon or will show on the upper middle of screen. - Page 11 White day Still mode Remaining numbers of photos Resolution Expose Quality White balance Memory card Battery indication Picture 13 Playback Mode 1. Press and hold 2 seconds to enter Playback Mode. 2. Press to select the photo or video clip you want to playback. 3.
-
Page 12: Video Menu Configurations
Picture 14 Video Menu Configurations In the Video Mode, press button once to enter Video setting Press button twice enter Setup setting Note: You can not configure the menu settings in the Recording Mode. When operating in the Recording Mode, press button to stop recoding and press button to enter menu configurations. - Page 13 Motion Detection When the Motion Detection is configured to on, any movement around the car’s surrounding will be recorded automatically. Recording will automatically power off if nothing happened and moved during the monitor mode. Once anything is movement, the unit will start recording immediately.
- Page 14 Date/Time Set the current date and time. Use buttons to switch Y/M/D/H/M and click button to confirm/save the settings. Auto Power Off Set the auto-off time without any operation and recording upon continuous power supply. Values: Off/1 minute/3 minutes Beep Sound Enable or disable the sound of the buttons located on the unit Values: On/Off Language...
-
Page 15: Still Menu Configurations
Note: Backup desired data before formatting. You can backup the data to the PC (Win XP2/Vista/Win 7/Win 8) via included USB cable. Default Setting Reset all settings to factory default values. Values: OK/Cancel Version Display the current firmware version. Still Menu Configurations In the Still Mode, press button once to enter Video setting Press... - Page 16 Sharpness Higher the sharpness is, clearer the picture. Values: Strong/Normal/Soft Off/On White Balance The White Balance feature can boil down to the concept of color temperature. Color temperature is a way of measuring the quality of a light source. Adjust the white balance to get the colors in your images as accurate as possible recorded the video.
-
Page 17: Specifications
Specifications Display Type 2.0” TFT LCD display Display Spec. LCD Resolution 480*240 Chipset NT96220+5B3 Color Black Sensor SAMSUNG 5B3 Storage Expansion Micro SD Card up to 32GB USB Interface USB 2.0 Hardware Spec. HD OUT Microphone Built in G-sensor System Win XP2/Vista/Win 7/Win 8 Decode Format 1080FHD 1920*1080/1080P 1440*1080/... - Page 18 For more information, please visit our official website www.ausdom.com Your valuable comments and suggestions on improving AUSDOM products are welcomed!
