Electronic Washing Machine
Instruction Manual
MODEL: AWM500-AWM600
IMPORTANT SAFEGUARDS....................................................... 2
PARTS AND FEATURES..............................................................3
INSTALLATION INSTRUCTIONS.................................................4
USING YOUR WASHER..............................................................6
PROGRAM SELECTION..............................................................10
CARE OF YOUR WASHER.....................................................12
TROUBLE SHOOTING .................................................................14
BEFORE OPERATING THIS PRODUCT,
READ, UNDERSTAND, AND FOLLOW
THESE INSTRUCTIONS.
CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWM500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HELLER AWM500

Summary of Contents for HELLER AWM500

  • Page 1: Table Of Contents

    Electronic Washing Machine Instruction Manual MODEL: AWM500-AWM600 CONTENTS IMPORTANT SAFEGUARDS............2 PARTS AND FEATURES..............3 INSTALLATION INSTRUCTIONS..........4 USING YOUR WASHER……............6 PROGRAM SELECTION…............10 CARE OF YOUR WASHER………………………......12 TROUBLE SHOOTING ..............14 BEFORE OPERATING THIS PRODUCT, READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS Save these instructions Your safety is important to us. To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the following basic precautions. Read all instructions before using your washer • Flammable liquids such as dry cleaning solvents, kerosene , petrol, etc., should not be used or stored in or near the washer.

  • Page 3: Parts And Features

    • Digital display, with program indication. • Quiet operation, stable balance system. • Variable water level selection. • Heavy wash program. • Auto program senses wash load and programs wash parameters. • 6 kg dry weight wash capacity (5 kg dry weight Model: AWM500)

  • Page 4: Location Of Washer

    INSTALLATION Location of washer • The washer must be placed in a well ventilated area with the back of the washer not less than 10cm (4 inches) from the wall, 4.5cm (1¾ inches) from the left and 2cm (¾ inch) clear from the right side.

  • Page 5: Installation Of Drain Hose

    Important: • After installing the inlet hoses, do not immediately switch on the power. Open the tap, check both ends of the hose for water leakage. • If the inlet hose is difficult to install or screw to the tap etc., we recommend you can call experienced person to help.

  • Page 6: Using Your Washer

    or portable outlet device, is safe to use, capable of handling the electrical load of the washing machine (refer to the identification plate) and has been checked and tested by your electrical supplier or qualified technician. Always position the extension cord or portable outlet device so it is not subject to splashing or ingress of moisture.
  • Page 7 6. Add amount of detergent according to the wash load volume recommended by the manufacturer on the box of laundry powder detergent. Refer to the following charts as a guide for Model: AWM600.
  • Page 8 Notes: • For Model: AWM500; suggested use is approximately 10g of powder less at each level. • We recommend the use of low foam detergent. • Do not open the detergent draw while the washer is filling. • Use the guide in this book together with the manufacturers recommended amount of detergent for your wash type and load size.
  • Page 9 Operation 9. Switch on the power supply Press the Power button, the indicator will glow, it means that the machine is on auto- enter Normal program. The Normal program will auto-select the suitable water level and program itself according to the quantity and type of the clothes you put into the machine. To use the Normal program, Press the Start/Pause button, the machine will fill and run the Normal program;...

  • Page 10: Program Selection

    The dry weight of the blanket must be less than 4kg and suggest the use of a mesh bag for the bulky washing as follows: • Fold up the blanket as shown below and place into the washing machine. • Press the POWER and the PROGRAM buttons and select the "Heavy"...

  • Page 11: Control Panel

    ⇒ If the “Soak” function is selected, the washing machine will soak for 20 minutes before ⇒ commencing to wash. During this time, the washer will intermittently agitate to evenly mix the detergent with the wash load. ⇒ ⇒ The washer automatically detects the load and texture of the wash in the "Normal" program, and selects the wash, temperature of water and wash time.
  • Page 12 Press to turn the power on or off. After the program selection, press to start. The flashing light indicates the selected programs and the current state. If you want to change program operating; press the “Start/Pause” button → Select the program you want to change to →...

  • Page 13: Care Of Your Washer

    Note: End of wash time may be effected by water pressure variation. Confirmation of the delay time 1. Once the Start/Pause button has been pressed, the washer delay function starts, and the Delay indicator will flash; all other indicators will not be illuminated. 2.

  • Page 14: Cleaning The Water Inlet Filter

    Non-use or vacation If you are intending to go on vacation or don’t intend to use your washer for an extended period of time, you should: • Turn off the water taps, this helps avoid accidental flooding (due to a water pressure surge) while you are away.

  • Page 15: Troubleshooting

    TROUBLESHOOTING TROUBLE CHECK ⇒ ⇒ The LED indicator does not turn on Is the unit plugged in? ⇒ ⇒ Is the power switch on? ⇒ ⇒ Has the “Start/Pause” button been pressed? ⇒ ⇒ Check for power failure ⇒ ⇒ The unit is leaking water Check if the hoses are securely connected to the taps.
  • Page 16 ⇒ Intermittent spinning at the beginning of spin cycle is performed to achieve more efficient ⇒ spinning cycle. ⇒ During spinning, the washer may return to the wash cycle which is to rectify an unbalance ⇒ to redistribute the load. GAF Control (Sales) Pty.
