HCD-GRX70/GRX70J/RXD80
SERVICE MANUAL
HCD-GRX70/GRX70J/RXD80 are the Am-
plifier, CD player, Tape Deck and Tuner
section in HMC-GRX70/GRX70J/RXD80.
Dolby noise reduction manufactured under license
from Dolby Laboratories Licensing Corporation.
"DOLBY" and the double-D symbol a are trade-
marks of Dolby Laboratories Licensing Corporation.
Amplifier section
Canadian model:
Continuous RMS power output (reference)
Total harmonic distortion less than 0.07%
Other models:
The following measured at AC 120, 220, 240 V 50/60 Hz
DIN power output (rated)
Continuous RMS power output (reference)
MICROFILM
Photo: HCD-GRX70 (GRAY)
CD
Section
Tape deck
Section
SPECIFICATIONS
100 + 100 watts
(8 ohms at 1 kHz, 10% THD)
(8 ohms at 1 kHz, 55 W)
130 + 130 watts
(6 ohms at 1 kHz, DIN)
170 + 170 watts
(6 ohms at 1 kHz, 10% THD)
Model Name Using Similar Mechanism
CD Mechanism Type
Base Unit Name
Optical Pick-up Name
Model Name Using Similar Mechanism
Tape Transport Mechanism Type
Inputs
MD/VIDEO (AUDIO) IN:
voltage 450 mV/250 mV,
(phono jacks)
impedance 47 kilohms
MIX MIC: (phone jack)
sensitivity 1 mV, impedance 10
kilohms
Outputs
MD OUT:
voltage 250 mV,
(phono jacks)
impedance 1 kilohms
PHONES:
accepts headphones of 8 ohms
(stereo mini jack)
or more
SPEAKER:
Canadian model:
accepts impedance of 8 to 16 ohms
SURROUND SPEAKER (GRX70/GRX70J):
accepts impedance of 16 ohms
SUPER WOOFER:
Voltage 1 V, impedance 1 kilohm
MINI Hi-Fi COMPONENT SYSTEM
Canadian Model
HCD-RXD80
E Model
HCD-GRX70/GRX70J
Australian Model
HCD-GRX70
HCD-GRX50/RXD7
CDM38LH-5BD32L
BU-5BD32L
KSS-213D/Q-NP
HCD-GRX50/RXD7
TCM-230AWR2
– Continued on next page –
Advertisement
Table of Contents
Related Manuals for Sony HCD-GRX70
Summary of Contents for Sony HCD-GRX70
- Page 1 SERVICE MANUAL Canadian Model HCD-RXD80 E Model HCD-GRX70/GRX70J Australian Model HCD-GRX70 HCD-GRX70/GRX70J/RXD80 are the Am- plifier, CD player, Tape Deck and Tuner Photo: HCD-GRX70 (GRAY) section in HMC-GRX70/GRX70J/RXD80. Dolby noise reduction manufactured under license Model Name Using Similar Mechanism HCD-GRX50/RXD7 from Dolby Laboratories Licensing Corporation.
