- Page 1 Recommendations Instructions for use and maintenance Installation instructions PHENIX 1000 PHENIX 850 PHENIX 650 07DHPH2A 06.04 ® PHENIX II - Bodart & Gonay...
- Page 2 NOTE (to be completed by the installer) * DISTRIBUTOR: * PHENIX II appliance Name ............... * REFERENCES: 47B10BOV PHENIX 1000 No / Street ............47B85BOV PHENIX 850 47B65BOV PHENIX 650 Town ............* PURCHASE DATE: ../ ../ ..
-
Page 3: Table Of Contents
CONTENTS RECOMMENDATIONS 1. Transport 2. Installation 3. Fue 4. First fi re 5. Options INSTRUCTIONS FOR USE AND MAINTENANCE 5 1.Use: 1.1. Description of parts 1.2. Operation of the automatic key 1.3. Opening and closing the hearth 1.4.Fire fl ue 1.4.1 Air regulator 1.4.2. -
Page 4: Transport
RECOMMENDATIONS 1. Transport: OPTION 2. Installation: 1. The hearth must be absolutely level (references: from side and front edge of the fi re box). 2. Unscrew the two screws on the front and remove. 3. Cut the Colson collar around the counterweight and the support. CHECK 4. -
Page 5: Instructions For Use And Maintenance
INSTRUCTIONS FOR USE AND MAINTENANCE 1.Use: 1.1. Description of parts 1. Door 2. Counterweight and support. 3. Cover façade 4. Cover 5. Automatic key transmission 6. Automatic key valve 7. Side plates 8. Lateral base plates 9. Base bricks 10. Maintenance of vermiculite plaque 11. -
Page 6: Opening And Closing The Hearth
1.3. Opening and closing the hearth 1.4. Fire fl ue The quality of the wood is of vital importance to the opti- mum operation of the hearth (heat output and power, cleanli- ness of the glass). High quality wood is: - dry, having been dried for at least two years under ventilated shelter. -
Page 7: Lighting
The maximum load permissible at maximum rate (with the air regulator open) is 5 kg/hour for the PHENIX 1000, 4 kg/hour for the PHENIX 850 and 3 kg/hour for the PHENIX 650. Ensure that the door is properly lowered so that it closes completely and thus engages the automatic key. -
Page 8: Warning
CAUTION When the hearth is in operation, some accessible parts of the appliance reach very high temperatures, even if no fl ames are visible. Do not leave children near the fi re without supervision. 1.5. Option: Fan and speed variator MAX. -
Page 9: Maintenance
2. Maintenance: 2.1. Regular maintenance -- Remove excess cinders, and if possible vacuum the ashes from the air distributor and air regulator. - To clean the glass, open the door laterally and proceed as follows: OPENING PUSH CLOSING WARNING ! - Do not clean the glass while hot - Spray the product* in the centre of the glass and spread with a cloth or absorbent paper. -
Page 10: Annual Maintenance
2.2. Annual maintenance VERMICULITE PLATES Vermiculite is a natural mineral substance (without asbestos) which has been processed and which is completely recyclable. These insulating plates are resistant to very high temperatures. The vermiculite plates must not be exposed to water hence the importance of having a cover on the chimney. -
Page 11: Operating Faults
3. Operating faults FAULTS CAUSES / REMEDIES GLASS BECOMES DIRTY TOO QUICKLY - Door not suffi ciently airtight (check the adjustment of the door). - Wood too damp- Rate of consumption too low - Inappropriate draught (too much or too little) ‘LAZY’... -
Page 12: Guarantee
4. Guarantee LENGTH AND RESTRICTIONS - 6 years’ guarantee on: the general structure - 2 years’ guarantee on: non-moving parts - 1 year’s guarantee on: fan and speed variator - no guarantee on: glass, vermiculite plates RESERVED RIGHTS Bodart & Gonay reserve the right to alter or amend their appliances, catalogues, and instructions for use, independently, at any time and without prior notice. -
Page 13: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Characteristics PHENIX 1000 ® PHENIX II - Bodart & Gonay... - Page 14 PHENIX 850 ® PHENIX II - Bodart & Gonay...
- Page 15 PHENIX 650 ® PHENIX II - Bodart & Gonay...
-
Page 16: Overall Dimensions
PHENIX 850 to dismantle the min 460mm mechanisms. PHENIX 1000 min 510mm 2.2. Hearth with 6 mm inner/30 mm outer surround PHENIX 650 min 538+4 = 542 mm E = 80mm E = 40 mm... -
Page 17: Smoke Fl Ue
3. Smoke fl ue Recommendations The chimney fl ue must be built in compliance with building regu- lations of which the following features are the most important: 5m ideal - Minimum height (distance between connection and top of stack) will be 5 m for a hearth which can operate with Moderator the door open. -
Page 18: External Air Supply
- If there is a double fl ue: - Sealed con- nector - choose the better, - close off the unused vent. - «Breech» to avoid 45° soot retention - In the case of a lateral connection on an existing Soot fl... -
Page 19: Convection Air Circuit
- If the hot air is carried into another room, a return duct to the hearth of identical cross-section must be fi tted in order to avoid a pressure imbalance between the rooms of the house. - Do not forget that smells will be carried into other rooms via the hot air vents. - It is highly inadvisable to take all the convection air from the outside (too much cold air results in lower performance). -
Page 20: Natural Convection
5.2. Natural convection It is vital to open four hot air vents for the Phénix 1000 and at least two for the Phénix 850 and 650. These vents must be connected to a conduit at least 50 cm high. The top of the hearth must not be insulated. If the hearth is positioned at least 4 cm from the ground, air intake is ensured by the ventilation hole under- neath the hearth. -
Page 21: Positioning The Hearth
6.1. Positioning the hearth 1. The hearth must be absolutely level. 2. Unscrew the two screws on the front and remove. 3. Cut the cable tie around the counterweight and the support. CHECK 4. Ensure that the door is operating correctly (lateral opening, lifting/ lowering) 5. -
Page 22: Frame (Option)
- Avoid installing the variator near audio and video equi- pment. 230 V MAX. AC 50Hz T.V. OFF= O MINI. 1. Setting the speed. 2. Setting screw for minimum speed under the button (calibration required). 3. 1.25A fuse (remove the button, unscrew the panel, pull out and replace). -
Page 23: Replacement Parts
25 5 5 5 5 5 5 25 5 5 5 5 25 2 2 30 0 0 29 2 2 2 29 2 2 30 0 30 0 0 PHENIX 650 PHENIX 650 PHENIX 850 PHENIX 850 PHENIX 1000 PHENIX 1000... - Page 24 OPCIONES Y RECAMBIOS PHENIX 1000 OPTIONS AND SPARE PARTS PHENIX 1000 RECAMBIOS / SPARE PARTS Concepto Description Code TRAMPILLA VENTILACION PHENIX 650 VENTILATION HATCH PHENIX 650/850/1000 37B10030 REPARTIDOR DE AIRE PHENIX 1000 AIR DISTRIBUTOR PHENIX 1000 37B10031 DOSIFICADOR DE AIRE PHENIX 850/1000...
- Page 25 LADRILLO 165X115X30 REFRACTORY BRICK 165X115X30 07CB316 VERMICULITA 340 x 114 35 DERECHA VERMICULITE 340 x 114 35 RIGHT 07CV850B VERMICULITA 330 X 320 25 VERMICULITE 330 X 320 25 07CV850A SUJETA PLACA PH 850/1000 PLATE HOLDER PHENIX 850/1000 37B10009 COMPENSACION VERMICULITA PHENIX 8 VERMICULITE PACKING PHENIX 850/1000 37B10035 COMPENSACION VERMICULITA PHENIX 8 COMPENSATION VERMICULITE PHENIX 850 37B85035...
-
Page 26: Checklist
8. Checklist: Check the various minimum installation space dimensions (including room for options!) See p.17. If these dimensions are not respected, it will be impossible to strip down the various component assemblies! Levelling the hearth, 2 reference points. See pp. 4 & 21. Mount the chimney duct and the hot air outlet duct.
