Sanyo SAP-CMRV1923GJH Technical & Service Manual

Hide thumbs

Advertisement

TECHNICAL & SERVICE MANUAL
OUTDOOR UNIT: SAP-CMRV1923GJH
DC INVERTER MULTI-SYSTEM AIR CONDITIONER
2-room multi Outdoor unit
SAP -CMRV1923GJH
3-room multi Outdoor unit
SAP – CMRV2433GJH
SAP-CMRV2433GJH
Capacity
Outdoor Model No.
5.6 kW
SAP -CMRV1923GJH-C
6.8 kW
SAP -CMRV2433GJH-C
Revised Edition
Destination: General area (50Hz)
Product Code No.
1 852 083 34
1 852 083 35
< Combined Indoor Units >
Concealed duct type
Wall mounted type
SAP-DMRV93GJH
SAP-KMRV93GJH
SAP-DMRV123GJH
SAP-KMRV123GJH
SAP-DMRV183GJH
SAP-KMRV183GJH
NOTE
1. How these units may be combined is given in
the Unit Combination Tables in the Appendix.
2. Be sure to operate the air conditioning
system only when 2 or more indoor units
have been installed. If operated with only a
single unit installed, the returning fluid to the
compressor may cause a malfunction.
IMPORTANT
These air conditioners employ
new refrigerant R410A.
Pay special attention when servicing
the unit.
REVISION NO.
NOV.2003
Europe (50Hz)
Australia (50Hz)
General area (60Hz)
SM
700539-02
