Polar Air S725 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
With the following accessories you get the most out of your S725
Polar Cadence Sensor:
A wireless sensor that measures the speed at which
you turn the pedals of your bicycle.
IR Interface:
The Polar IR interface is designed for communication
between Polar heart rate monitors and Polar software
products. For infrared connection to your PC you need
a Polar IR interface if you do not have an IrDA port in
your PC.
Power Output Sensor:
The Polar Power Output system measures pedaling
power when cycling. It also measures left/right balance
(LRB describes the share of power output of left and
right as a percentage), pedaling Index (describes how
evenly power output was produced during a cycle
round), speed, cadence and distance. If you use the
Power Sensor, you do not need to mount any other
accessories on your bicycle.
Polar S725 offers you the possibility for
infrared communication with Polar training
analysis software. See the instructions from
the CD-ROM set.
S725
CYCLING HEART RATE MONITOR
E N G
S725
U S E R M A N U A L
CYCLING HEART RATE MONITOR
Display symbols
Indicates an ongoing heart rate measurement and flashes to the beat of your heart.
Indicates there has not been heart rate reception for at least 5 seconds.
- - Indicates there is no heart rate reception. Bring the wrist unit up to your chest
near the transmitter's Polar logo.
The wrist unit starts looking for the heart rate signal again.
Options mode: indicates that you are setting the bike functions.
Measuring/Recording mode: indicates that bike 1 or 2 is on.
File mode: indicates cycling information.
In the Time of day display the alarm is on.
Measuring mode: beeps if you are exercising outside your target heart rate zone.
Fitness Test mode: sounds an alarm at the end of the fitness test.
Indicates the Interval Trainer.
Indicates continuous interval (Cont).
Recording mode: indicates the heart rate above the target zone.
Recording mode: indicates the heart rate below the target zone.
The graphic bar consists of five blocks. A flashing block indicates in which level you are
in the Options settings or File recalling loops. Continuously running bars indicate that
the exercise is recorded.
Indicates low battery.
See the glossary for display text interpretation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S725 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Polar Air S725

  • Page 1 With the following accessories you get the most out of your S725 Display symbols Polar S725 offers you the possibility for Polar Cadence Sensor: infrared communication with Polar training A wireless sensor that measures the speed at which analysis software. See the instructions from you turn the pedals of your bicycle.
  • Page 2 Manufactured by: Dear Customer Road Map Quick Guide Polar Electro Oy Professorintie 5 FIN-90440 KEMPELE Signal/Light Time of • move onward File Options Fit. Test Connect • increase the Congratulations on purchasing a Polar Cycling Heart Rate Monitor! We are selected value Tel.
  • Page 3 The features of this cycling heart rate monitor provide you with the various ways to customize your exercise sessions so they meet your personal needs. For more information about the different functions, see the "All that you can do with your Heart Rate Monitor" section. Please read this manual carefully to familiarize yourself with the Polar cycling heart rate monitor.

  • Page 4: Table Of Contents

    CONTENTS A. Getting going ....... 5 Setting number of intervals and Starting the recovery calculation ..63 Swap time 1 or time 2 ....... 46 Heart rate monitor parts ......5 recoveries ........28 Stopping the exercise ......63 Shortcut to watch settings ....

  • Page 5: Getting Going

    A. GETTING GOING Heart rate monitor parts and their Power ..........69 E. Polar Fitness Test ....80 functions Pedaling index ........69 OwnIndex ..........80 Left right pedaling balance ....69 Predicted maximum heart rate ..... 82 Heart rate limits ......... 69 The elastic strap detects Fitness test settings ........

  • Page 6: Buttons And Their Functions

    Buttons and their functions Moves to the following mode. Increases the Signal/ Light Turns the beep on or off. SIGNAL selected value. LIGHT Turns the backlight on. Reset Resets the heart rate Stop Return - Stops measuring the heart rate. monitor.

  • Page 7: Easy Start

    If you are using Polar S725 with Polar Easy start Power Output Sensor, please see the bike mount and sensor installation instructions in the Power Output Sensor user manual. If you use the Power Sensor, you do not need How to prepare the wrist unit to mount any other sensors on your bicycle.

  • Page 8: How To Put The Transmitter On

    4. There are two spoke magnet options. How to put the transmitter on You only need to install one of them. Check which of the magnets fits the spoke 1. Moisten the electrode areas of the strap of your bike best. One (A) is installed by under running water and make sure that they rotating it around the spoke before putting are well moistened.

  • Page 9: How To Stop Measuring Your Heart Rate

    mobile phones may cause interference when starting All that you can do with your Heart Rate Monitor the heart rate measurement. Here is a short overview of the modes of the wrist unit and the different 4. Press the OK button to start measuring your heart rate. functions they offer you.
  • Page 10 A. BasicUse is the easiest way to start exercising because you do not 4. FILE (SEE SECTION D. HOW TO RECALL TRAINING INFORMATION) have to set different heart rate limits or timers. You just start in In this mode you can recall your training information. Your heart rate Measuring mode and choose BasicUse and you are ready to go.

  • Page 11: How To Enter Settings

    B. HOW TO ENTER SETTINGS 7. CONNECTION (SEE SEPARATE CD-ROM SET) In Connection mode you can download recorded training information from your wrist unit's memory to your PC for more elaborated analysis. You can also upload your wrist unit settings from your PC. To perform the above-mentioned operations, you need the Polar Precision Performance software.

  • Page 12: User Information Settings

    User information settings Weight (kg or lbs) 5. Scroll up or down to adjust your weight. Press OK. Options Height (cm or ft/ inch) 6. Scroll up or down to adjust your height. Press OK. User Set Date of birth (Birthday) kg/lbs Birthday Activity...

  • Page 13: Exercise Settings

    High You participate regularly, at least 3 times a week, in heavy physical Exercise settings for Recording mode exercise. E.g. you cycle 30-60 km per week or spend 2-3 hours per week in comparable physical activity. When you start setting your exercise preferences your first choice is to select whether you want to set your personal exercise set or to exercise with You participate regularly in heavy physical exercise at least 5 times a week.

  • Page 14: Setting Exercise Sets

    Setting exercise sets 1. In the Time of day display Options Preset exercise sets ready for five exercise sets; when you start exercising, scroll up or down until just select one of the sets. OPTIONS is displayed. Exercise Set 2. Press OK to enter the BasicSet Interval Training Set Options mode.

  • Page 15: Setting Timers

    Setting timers Heart rate If you start from the Time of day display, repeat steps 1-5. 6. Scroll up or down until desired timer is displayed. Press OK to start setting the timer. Summary 7. Scroll up or down to turn the timer on or off. Press OK. limits Timer OFF: skip steps 8-9.

  • Page 16: Setting Recovery Calculation

    Setting recovery calculation Setting interval type You can select 2 optional types of recoveries in a BasicSet: You can select four optional types of intervals: A. Time-based recovery Ends your recovery as you reach the preset time. A. Time-based interval Ends your interval when you have used B.

  • Page 17: Setting Number Of Intervals And Recoveries

    A. Time-based interval Setting interval recovery calculation 8. Scroll up or down to adjust minutes. Press OK. You can select 3 optional types of recoveries: 9. Scroll up or down to adjust seconds. Press OK. Interval TIMER appears. A. Time-based recovery Ends your recovery as you reach the preset time.

  • Page 18: Naming Exercise Sets

    C. Rec. Dist is displayed. Setting recording rate Units 2: Adjustable units 10. Scroll up or down to adjust kilometers. are miles and feet. 1. In the Time of day display scroll Press OK. Options up or down until OPTIONS 11.

  • Page 19: Turning Functions On/Off

    The following table shows the maximum exercise times for each Turning functions on/off recording rate. Options Altitude Speed Cadence Power Rec. Rate 5s Rec. Rate 15s Rec. Rate 60s Function Set 4 h 57 min 14 h 53 min 59 h 34 min 8 h 56 min 26 h 48 min 99 h 59 min...

  • Page 20: Fitness Test On/Off

    Fitness test on/off To use the thermometer the altitude must be turned on. If you start from the Time of day display, repeat steps 1-4. To continue setting your settings, press the stop button or to return to the 5. Scroll up or down until Fit. Test is displayed. Time of day display, press and hold the stop button.

  • Page 21: Bicycle Feature Settings

    Bicycle feature settings Adjusting the wheel size (Wheel) If you start from the Time of day display, repeat steps 1-5. 6. Start with the display showing Wheel. Options 7. Press OK to start setting the wheel size. 8. Scroll up or down to adjust the wheel size. Press OK. Bike Set You have the following alternatives to find out Bike 1/ Bike 2/ Bike OFF...

  • Page 22: Cadence On/Off

    METHOD 2. Power* on/off Mark the tread of the front tire with a line and roll the tire If you start from the Time of day display, repeat steps 1-5. perpendicular to the ground. You can also use the valve as Scroll up or down until Power is displayed.

  • Page 23: Monitor Settings

    Naming bike 1 and bike 2 Monitor settings You can name the bikes with four letters, numbers or marks. The number in the right corner indicates, which bike settings are in use. 1. In the Time of day display Options (b0=Bike OFF, b1=Bike 1, b2=Bike 2) scroll up or down until 1.

  • Page 24: Watch Settings

    The units settings affect the following features: Watch settings Units 1: Units 2: 1. In the Time of day User information kg, cm lbs, feet Options display scroll up or Date of birth day-month-year month-day-year down until OPTIONS Speed km/h Watch Set is displayed.

  • Page 25: Setting Time Of Day

    Setting time of day Turning reminders on/off If you start from the Time of day display, repeat steps 1-4. If you start from the Time of day display, repeat steps 1-4. 5. Scroll up or down until TIME1/ TIME2 is displayed. 5.

  • Page 26: Setting Tips

    Setting tips C. EXERCISE Swap time 1 or time 2 In the Time of day display press and hold the down button. Time 1 or Time 2 is displayed in the uppermost row for a couple of seconds. Displayed time will now be used in all watch and alarm functions. If you chose time 2, “2”...
  • Page 27 3. Start from the Time of day display by pressing the OK to start measuring The following displays start to alternate, if you have bike 1 or 2 and your heart rate. A heart symbol will start flashing and your heart rate in altitude settings on, as you enter the Measuring mode.

  • Page 28: Recording Mode

    Recording mode Turning the heart rate zone alarm on/off Note that you can not use the alarm when Bicycle functions are on. Before starting recording, check that you have enough memory left. This information is displayed in the upper row, in the Measuring mode. Note that trip distance is reset by pressing and holding signal/light button.

  • Page 29: Swapping The Heart Rate Limits

    Swapping the heart rate limits Storing lap and split time Press and hold the up button. Repeat until the desired limits are displayed. Press OK to store lap and split time. In the Interval Training mode the limits are automatically swapped when the phase changes to the preset limits.

  • Page 30: Swapping The Displayed Exercise Information

    Swapping the displayed exercise information When you have set your Interval Training Set on, you will have one You can swap the display information by pressing the down button in the Phase Name extra display. You can only change the Measuring or Recording mode.

  • Page 31: Resetting The Stopwatch To Zero

    3. Select the lower heart rate information row Exercising with Interval Training Set (Int On, E1-E5) Press and hold the down button to select from the following: Current heart rate, average heart rate (avg) or the reading in In this mode you can also use the functions described in “Recording mode” percentages of your maximum heart rate (% max) if you have set your section.

  • Page 32: Warm-Up Phase

    Warm-up phase Interval session 1. First 1. First Heart rate limits 1 (if set on). Preset heart rate limits 2 (if set on). 2. Then 2. Then One of the following is displayed depending on your settings: Countdown timer 1. A.

  • Page 33: Cool-Down Phase

    3. At the end of Interval At the end of recovery Interval duration. A. and B. Average heart rate of the interval. Recovery duration. Recovery distance. Drop in your heart rate. When your interval ends the wrist unit automatically continues with following preset function: recovery Cool-down phase calculation or cool-down phase.

  • Page 34: Interrupting An Interval Training Exercise

    Interrupting an interval training exercise Starting the recovery calculation 1. Press the stop button to pause the exercise. To start the recovery calculation, press and hold the OK button. 2. Press and hold the stop button to return to the Time of day display. See “Exercising with Interval Trainer”/ “Recovery calculation”...

  • Page 35: Swapping The Bike Setting

    Swapping the bike setting (b0, b1 or b2) Tips during the exercise same calculation press the OK button or to reset the interval training Start from the Measuring mode. Press and hold the down button until Bike 1 exercise, see “Resetting stopwatch to zero” section. or 2 or Bike OFF is displayed.

  • Page 36: How To Recall Training Information

    File (F1-F99) D. HOW TO RECALL TRAINING Exe. Time If a function was not activated in the settings mode, that Recovery information will not be displayed in the recorded file. INFORMATION Distance Exercise file Speed 1. In the Time of day display scroll up or down until FILE is displayed. Cadence 2.

  • Page 37: Exercise Time

    Temperature (°C or °F Avg/ Max/ Min) Exercise time (Exe. Time) The exercise time is the amount of time that you have exercised Average, maximum and minimum temperature of the exercise alternate. with the stopwatch running. Average and maximum heart rates of your exercise alternate on the display.

  • Page 38: Exercise Time Within, Above And Below The Heart Rate Zones

    Exercise time within, above and below the heart rate zones Odometer Indicates the exercise time, which you have spent within (InZone), above and Measures cumulative total distance of several exercise sessions starting below each heart rate limits. Time within, above and below limits 1,2 and 3 from the previous resetting of the value in records file.

  • Page 39: Lap Information

    Cool-down phase Recovery information Duration of the cool-down. Time-based recovery. The heart rate at the end of the cool-down, Recovery duration. average and Drop in your heart rate. maximum heart rates of the cool-down phase. Heart-rate-based recovery. Time it took reach the preset heart rate reading. 3.

  • Page 40: Recorded Samples

    Best Lap • left right pedaling balance at the end of the lap* (LRB), Shortest lap time. • pedaling index* (PI %), The number of the best lap. • ridden distance at the end of the lap (Distance), • temperature at the end of the lap (°C/ °F). The best lap information is displayed if you have stored at least 3 laps.

  • Page 41: Deleting A File

    Deleting a file Records file 1. In the Time of day display scroll up or down until FILE is displayed. 2. Press OK to enter the File mode. This file is updated each time your exercise is recorded to file. 3.

  • Page 42: Resetting Cumulative Counts To Zero

    Resetting your cumulative counts to zero Returning to your previous maximum value Once your have reset the cumulative count you cannot retrieve it. Start with the display showing Max Spd, Max Cad*, Max Alt or Max Pwr* in Start with the display showing Tot. KCal, Tot. Time, Rid. Time or Odometer the records file.

  • Page 43: Polar Fitness Test

    E. POLAR FITNESS TEST If you want to improve your cardiovascular fitness, it takes a minimum of 6 weeks on an average to see a noticeable change in OwnIndex. Less fit individuals see progress even more rapidly and for more fit individuals more time is needed.

  • Page 44: Predicted Maximum Heart Rate

    Predicted maximum heart rate (HR Fitness test settings The HR -p definition is carried out simultaneously with the Polar Fitness To be able to carry out the Polar Fitness Test you need to do the following settings in the Options mode: Test.

  • Page 45: Update Ownindex And Hr

    Interrupt the test Time of Day File Options Fit. Test Connect • You can stop the test any time during the test by pressing the stop button. Failed TEST is displayed for a few seconds. Fitness Test The latest OwnIndex and HR -p are not replaced.

  • Page 46: Fitness Classes

    Fitness classes For various fitness classes we recommend the following: The Polar Fitness Test result, your OwnIndex, is most meaningful when comparing your individual values and changes in them. OwnIndex can also 5-7 Maintain current be interpreted according to your gender and age. Locate your OwnIndex on exercise habits To ensure good health, for good health...

  • Page 47: Care And Maintenance

    F. CARE AND • Never put the connector in a washing machine or a drier! • You can wash the strap in a washing machine at +40° C / 104° F. We MAINTENANCE recommend that you use a washing pouch. •...
  • Page 48 2. Remove the battery cover from the connector, lift the battery from the Wrist unit niche and replace it with a new battery. The estimated average battery life of the wrist unit is 2 years in normal 3. Remove the sealing ring of the battery cover and replace it with a new use (2h/ day, 7 days a week).

  • Page 49: Precautions

    G. PRECAUTIONS 6. Put the PCBA back into place. 7. Check that the sealing ring stays in its groove. Replace the cover back. 8. Insert the two screws in their holes and tighten them gradually in turn. 9. Test the sensor by checking that it gives out an orange flash when the spoke magnet passes the speed sensor.
  • Page 50 Polar heart rate monitor and interference Minimising possible risks in exercising with a heart rate monitor Exercise may include some risk, especially for those who have been sedentary. Electromagnetic interference Disturbances may occur near high voltage power lines, traffic lights, overhead lines of electric railways, electric bus lines or trams, televisions, Before starting a regular exercise program you are recommended to car motors, bike computers, some motor driven exercise equipment, mobile...

  • Page 51: Frequently Asked

    H. FREQUENTLY ASKED Notice to persons with pacemakers, defibrillator or other implanted electronic device. Persons who have a pacemaker use the QUESTIONS Polar heart rate monitor at their own risk. Before starting use, we always recommend an exercise test under doctor’s supervision. The test is to ensure the safety and reliability of the simultaneous use of the pacemaker and the heart rate monitor.
  • Page 52 3. Check that you are not near other people that have heart rate monitors, cause erratic readings. Check your surroundings and move further away high voltage power lines, televisions, mobile phones or other sources of from the source of disturbance. electromagnetic disturbance.

  • Page 53: Technical Specifications

    3. If the 00 reading appears irregularly, this may be due to temporary electromagnetic interference in your current surroundings. Polar S725 is designed to indicate the level of physiological strain and 4. If the 00 reading is constant, you may have exceeded 2500 riding hours intensity in sports and exercise.
  • Page 54 2100 Recovery time 99 min 59 s Cadence Calories 99999 kcal Altitude and temperature measurement: The Polar S725 calculates altitude Power Cumulative calories 999999 kcal by using the standard average altitude in certain air pressures according to Activity sound Cumulative the ISO 2533.

  • Page 55: Limited Polar International Guarantee

    J. LIMITED POLAR INTERNATIONAL K. POLAR DISCLAIMER GUARANTEE • This limited Polar international guarantee is issued by Polar Electro Inc. for the consumers who have purchased this product in the USA or Canada. This • The material in this manual is for informational purposes only. The limited Polar international guarantee is issued by Polar Electro Oy for the products it describes are subject to change without prior notice, due to consumers who have purchased this product in other countries.

  • Page 56: Polar Glossary

    L. POLAR GLOSSARY Display texts ALARM: Indicates the alarm in CONNECT: Infrared Activity level: Your long-term Coded heart rate transmission: watch settings. communication mode. physical activity level you need to Polar coded transmitter automatically Alt.: Indicates altitude. Cont: Up to 30 intervals succeed assess in order to do the Polar Fitness locks in a code to transmit your AM or PM: Are used in 12h Time...
  • Page 57 -p: Predicted maximum heart MAX: Together with a heart rate week or even a year. The OwnCal can PI %, Pedaling index*: Helps you rate value. reading indicates the highest heart be used as a dose measure of exercise to analyze how evenly the power is Interval, Int: Options mode: rate.

  • Page 58: Index

    will see the drop in your heart rate Index and the recovery duration. Spd: Indicates velocity. 12h/ 24h time mode ....... 44 How to enter settings ......17 Split Time: The elapsed time from Activity/ button sound on/off ....41 -p on/off .........
  • Page 59 Reset the stopwatch ......56 Reset the trip distance ......64 Return to the Time of day display ..7 Selecting exercise type ......21 Setting tips ..........46 Start an exercise set ....... 56 Start cycling measurement ....49 Start measuring your heart rate ..
