Technics BL-PD349 Service Manual

ORDER NO. AD98O1OO5SO
ceManL
Servl
Compact Disc Changer
Compact Disc Changer
SL-PD887
Golour (K) ... BlackType
Areas
P . . . . . . . . . . . . . . . . . U . S . A .
PP .............. U.S.A. and Canada.
E . . . . . . . . . . . . . . . . . E u r o p e .
EB .............. Great Britain.
EG .............. Germany and ltaly.
GC .............. Asia, Latin America,
Middle Near East
and Africa.
GN ..............
Oceania.
\'-'
I Applicable Serial Number Suffix
I How to distinguish in GD unit
I Interchangeability
SL-PD349
I This document is supplementary to the
SL.PD687
following Service Manuals:
Model No. Area Code
Order No.
sL-PD349 ( P ) AD9404110A1
SL-PD665
( P P ) 4D9401023A1
SL-PD687
(E) (EB) (EG) (GC) (GN) 4D9502043C8
SL-PD887
( E ) ( E B ) ( E G )
4D950206642
(GC) (GN) 4D950206743
The "NEW" Traverse Deck (Ass'y) (RAEO152Z)
and the "FORMER" Traverse Deck (Ass'y) are interchangeable.
Even if the CD unit has the former servo P.C.B., only the traverse deck is changeable to the new one.
A WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general public. lt
does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this service information by anyone else could result in serious f njury or death.
1998 Matsushita Electric Industrial Co.. Ltd.
All rights reserved. Unauthorized copying and
distribution is a violation of law.
SL-PD665
CD servo P.C.B.
I Purpose
Please be informed of that the "Traverse Deck (Ass'y)" and "CD Servo
P.C.B." of the CD unit have been changed on production.
Model No.
SL-PD349
sL-PD665
SL-PD687
SL-PD887
SerialNo. Suffix l r o m " K " o n w a r d f r o m " l " o n w a r d f r o m " F " o n w a r d f r o m " F " o n w a r d
CD unit
" is shown in this olace
of CD servo P.C.B.
Technics'
