5. PC Mode

Se ng up your PC so ware (based on Windows XP)
The Windows display-se ngs for a typical computer are shown below. But the actual screen on
your PC will probably be different, depending upon your par cular version of Windows and your
par cular video card. But even if your actual screen looks different, the same, basic set-up
informa on will apply in almost all cases.
1. First, click on "Control Panel" on the Windows start menu.
2. When the control panel window appears, click on "Appearance and Themes" and a display
dialog-box will appear.
3. When the control panel window appears, click on "Display" and a display dialog-box will
appear.
4. Navigate to the "Se ng" tab on the display dialog-box. The correct size se ng (res
Op 1360×768.
If a ver cal-frequency
Otherwise, just click "Enter" and exit the dialog box.
Res n
720x400
640x480
800x600
1024x768
1366x768
1920x1080
on exists on your display se ngs dialog box, the correct value is "60Hz".
Horizontal
Frequency (KHz)
31.47
37.9
37.9
48.4
64
64
Frequency (Hz)
70
60
60
60
60
60
Standard Mode
DOS
VGA
SVGA
XVGA
SXVGA
SXVGA
