Blue Angel CSE40M Operating Instructions And Parts Manual

Description
A sewage pump is intended for use in
domestic sewage lift stations. It is suitable
for pumping sewage, effluent, wastewater,
groundwater, and other nonexplosive,
noncorrosive liquids with up to 2 inch solids.
The pump is controlled by a switch with a
piggyback style plug which accepts the pump
plug and, in turn, plugs into a 120-volt outlet.
The float switch is a wide angle differential
switch that rises with the liquid level and turns
the pump on. As the liquid level decreases,
the float lowers and turns the pump off.
The BCAPSE40 is provided with a solid-
state electronic water level control. When
water is detected, the pump will start
automatically. This pump is intended for
use in domestic sewage lift stations.
Unpacking
Inspect this unit before it is used.
Occasionally, products are damaged
during shipment. If the pump or
components are damaged, return
the unit to the place of purchase for
replacement. Failure to do so could
result in serious injury or death.
Specifications
Power supply requirements
Circuit requirements
Motor duty
Motor
Horsepower
Motor full load
Liquid temperature range
Max. operating position
Dimensions
Intake
Discharge
Cut-in level (factory set)
Cut-out level (factory set)
Differential
Switch
Power cord
REMINDER: Keep your dated proof of purchase for warranty purposes!
© 2009 Blue Angel™ Pumps
Operating Instructions and Parts Manual
Please read and save these instructions. Read carefully before
attempting to assemble, install, operate or maintain the product
described. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in
personal injury and/or property damage! Retain instructions for
future reference.
Sewage Pump
Safety Guidelines
This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
hazardous situation which, if not avoided,
WILL result in death or serious injury.
hazardous situation which, if not avoided,
COULD result in death or serious injury.
hazardous situation which, if not avoided,
MAY result in minor or moderate injury.
information, that if not followed, may
cause damage to equipment.
BCSE50M & BCSE50T
120V, 60 hz
15 amps (min)
Intermittent
120V, 1 Phase
4/10
12.0 amps
40°F to 120°F
45o from vertical
14 inch x 12 inch
2 inch
2 inch NPT female
19 inch
9 inch
10 inch
90° wide angle
mechanical tether switch
16 gauge 3 conductor
with plug
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.blueangelpumps.com

General Safety

Information
CAlIfORNIA PROPOSITION 65
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
Danger indicates
an imminently
GENERAl SAfETy
1.
Warning indicates
a potentially
pump flammable or
explosive fluids such as
Caution indicates
gasoline, fuel oil, kerosene,
a potentially
etc. Do not use in a
flammable and/or explosive atmosphere.
Use pump only with liquids compatible
with pump component materials. Failure
Notice indicates
to follow this warning can result in
important
personal injury and/or property damage.
2.
Disconnect power before
BCAPSE50 &
servicing. If the power
BCAPSE50-2
dis con nect is out of sight,
120V, 60hz
lock in the open po si tion and tag it
to prevent unexpected application of
15 amps (min)
power. Failure to do so could result in
Intermittent
fatal electrical shock!
120V, 1 Phase
4/10
8.7 amps
40°F to 120°F
45o from vertical
14 inch x 12 inch
2 inch
2 inch NPT female
11 inch
3 inch
7 inch
Capacitive water sensor
16 gauge 3 conductor
with plug
CSE40M, CSE40T
CSE40T-2 and BCAPSE40
This product or its
power cord contains
Know the pump application,
limitations, and po ten tial hazards.
Do not
use to
Make certain that the power source
(electric motor) conforms to the
requirements of the equipment.
Construction
Motor
body material .......... Cold rolled steel
Motor housing ...................... Cast iron
Volute .................................... Cast iron
Impeller .............. Glass reinforced PBT
Seal plate .............................. Cast Iron
Shaft seal ........................... Mechanical
Performance
GAllONS PER MINUTE AT TOTAl
hEAD IN fEET
5 10
90 62
330804-002 12/09
15
23
